Page 2
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
Notices Federal.Communications.Commission.Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation.
Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury.
Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord.
These documents are not part of the standard package. Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for our customers to be able to responsibly recycle our products, batteries and other components as well as the packaging materials.
Thank you for purchasing the ASUS LCD monitor! The latest widescreen LCD monitor from ASUS provides a broader, brighter and crystal-clear display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual...
Monitor introduction 1.3.1. Front.view Standard Mode VGA 1920 x 1080 @ 60Hz Menu Close Input Select Quick Fit Brighness Blue Light Filter Menu (5-way) button: • Press this button to enter the OSD menu. • Enacts the selected OSD menu items. •...
DVI.port. This 24-pin port is for PC (Personal Computer) DVI-D digital signal connection. DisplayPort.in. This port is for connection with a DisplayPort compatible device. HDMI.port. This port is for connection with an HDMI compatible device. VGA.port. This 15-pin port is for PC VGA connection. ASUS PB328 Series LCD Monitor...
Earphone.jack. This port is only available when an HDMI/DisplayPort cable is connected. Audio-in.port. This port connects PC audio source by the bundled audio cable. 10.. USB.3.0.upstream.port. This port is for connection with a USB upstream cable. The connection enables the USB ports on the monitor. 11..
Page 13
The various real photo sizes displayed in the QuickFit function provides photographers and other users to accurately view and edit their photos in real size on the screen. Photo 4x6, 3x5, 2x2 Photo 8x10, 5x7 8x10 ASUS PB328 Series LCD Monitor...
• The VESA wall mount kit (100 x 100 mm) is purchased separately. • Use only the UL Listed Wall Mount Bracket with minimum weight/load 22.7kg (Screw size: M4 x 10 mm) ASUS PB328 Series LCD Monitor...
Adjusting the monitor • For optimal viewing, we recommend that you look at the full face of the monitor, then adjust the monitor to the angle that is most comfortable for you. • Hold the stand to prevent the monitor from falling when you change its angle. •...
Make sure your computer is installed with the lastest Windows 7/Windows 8 operating system. That will enable the USB ports on the monitor to work. When these cables are connected, you can choose the desired signal from the Input Select item in the OSD menu. ASUS PB328 Series LCD Monitor...
Turning on the monitor Press the power button . See page 1-2 for the location of the power button. The power indicator lights up in white to show that the monitor is ON. Chapter 2: Setup...
Standard Mode DisplayPort 2560 x 1440 @ 60Hz Splendid Standard Mode Blue Light Filter sRGB Mode Color Scenery Mode Image Reading Mode Sound Darkroom Mode PIP/PBP Setting User Mode 1 Input Select User Mode 2 More ASUS PB328 Series LCD Monitor...
Page 20
•. Standard.Mode: Best choice for document editing with SplendidPlus Video Enhancement. •. sRGB.Mode: Compatible with sRGB color space, sRGB mode is the best choice for document editing. Color White Point Primaries Space sRGB 0.3127 0.329 0.64 0.33 0.15 0.06 •. Scenery.Mode:.Best choice for scenery photo display with SplendidPlus Video Enhancement.
Hue: Shifts the image color between green and purple. •. Color.Temp.: Contains 4 modes including 9300K, 6500K, 5500K and 5000K. •. Gamma: Allows you to set the color mode to 2.4, 2.2, 2.0 or 1.8. •. Advanced.Setting: ASUS PB328 Series LCD Monitor...
Page 22
VividPixel: Enhances the outline of the displayed picture and generates high-quality images on screen. •. ASCR: Turns on/off the ASCR (ASUS Smart Contrast Ratio) function. •. Position.(Only.available.for.VGA.input): adjusts the horizontal position (H-Position) and the vertical position (V-Position) of the image. The adjusting range is from 0 to 100.
Page 23
PB328 Standard Mode DisplayPort 2560 x 1440 @ 60Hz Splendid PIP/PBP Mode Blue Light Filter PIP/PBP Source Color PIP Size Image PIP Position Sound Swap PIP/PBP Setting Input Select More ASUS PB328 Series LCD Monitor...
Page 24
•. PIP/PBP.Mode: Turns the PIP or PBP function on or off. •. PIP/PBP.Source: Selects the video input source from among VGA, DVI, HDMI and DisplayPort. •. PIP.Size: Adjusts the PIP size to Small, Middle, or Large. (Only available for the PIP mode) •.
Page 25
Shortcut.1/Shortcut.2: selects a function for Shortcut 1 and 2 buttons. When a certain function is selected or activated, your shortcut key may not support. Available function choices for shortcut: Brightness, Auto Adjust, Contrast, PIP/PBP Setting, Color Temp., Volume, User Mode 1, User Mode ASUS PB328 Series LCD Monitor...
• Ensure that the HDMI/DisplayPort cable is properly connected to the monitor and the computer. • Adjust the volume settings of both your monitor and HDMI/DisplayPort device. • Ensure that the computer sound card driver is properly installed and activated. ASUS PB328 Series LCD Monitor...
