Sony CFD-S36 Service Manual

Cd radio cassette-corder
Hide thumbs Also See for CFD-S36:

Advertisement

SERVICE MANUAL
Ver 1.0 2001.02
CD player section
System
Compact disc digital audio system
Laser diode properties
Material: GaAlAs
Wave length: 780 nm
Emission duration: Continuous
Laser output: Less than 44.6 µW
(This output is the value measured at a distance of
about 200 mm from the objective lens surface on
the optical pick-up block with 7 mm aperture.)
Spindle speed
200 r/min (rpm) to 500 r/min (rpm) (CLV)
Number of channels
2
Frequency response
20 - 20,000 Hz +1/–2 dB
Wow and flutter
Below measurable limit
Radio section
Frequency range
FM: 87.6 - 108 MHz
AM: 530 - 1,710 kHz
Antennas
FM: Telescopic antenna
AM: Built-in ferrite bar antenna
Sony Corporation
9-873-061-31
2001B0400-1
Audio Entertainment Group
© 2001.2
General Engineering Dept.
CFD-S36
Photo: SILVER
Model Name Using Similar Mechanism CFD-S22/S32
CD
CD Mechanism Type
Section
Optical Pick-up Name
Model Name Using Similar Mechanism CFD-V5
TC
Section Tape Transport Mechanism Type
SPECIFICATIONS
Cassette-corder section
Recording system
4-track 2 channel stereo
Fast winding time
Approx. 120 sec. with Sony cassette C-60
Frequency response
TYPE I (normal): 80 - 10,000 Hz
General
Speaker
Full range: 10 cm dia.,
3.2 ohms, cone type (2)
Outputs
Headphones jack (stereo minijack)
For 16 - 68 ohms impedance headphones
Power output
2.3 W + 2.3 W (at 3.2 ohms, 10 %
harmonic distortion in AC operation)
Power requirements
For CD radio cassette-corder:
120 V AC, 60 Hz
9 V DC, 6 size D (R20) batteries
For remote control
3 V DC, 2 size AA (R6) batteries
Power consumption
AC 20 W
CD RADIO CASSETTE-CORDER
Canadian Model
KSM-213CDP
KSS-213C
MF-V5-117
– Continued on next page –
1
