Sharp FO-6600 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CAUTION
This laser printer is a class 1 laser product that complies with 21CFR 1040.10 and 1040.11 of the CDRH standard. This means that
this machine does not produce a hazardous laser radiation. The use of controls, adjustments or performance of procedures other
than those specified herein may result in hazardous radiation exposure.
This laser radiation is not a danger to the skin, but when an exact focusing of the laser beam is achieved on the eyes retina, there is
danger of spot damage to the retina.
The following cautions must be observed to avoid exposure of the laser beam to your eyes at the time of servicing.
1) When a problem in the laser optical unit has occurred, the whole optical unit must be exchanged as a unit, not an individual part.
2) Do not look into the machine with the main switch turned on after removing the toner/developer unit and drum cartridge.
3) Do not look into the laser beam exposure slit of the laser optical unit with the connector connected when removing and installing
the optical system.
4) The cover of Laser Printer Unit contains the safety interlock switch.
Do not defeat the safety interlock by inserting wedges or other items into the switch slot.
Laser Wave Length : 770-810 mm
Laser Pulse Times : 49.2 µs
Laser Output Power : 0.5 mW
Parts marked with " " is important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintain-
ing the safety and performance of the set.
SERVICE MANUAL
SHARP CORPORATION
1 - 1
No. 00ZFO6600USME
FACSIMILE
FO-6600
MODEL
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
FO-6600U

Advertisement

Table of Contents
loading

Related Manuals for Sharp FO-6600

Summary of Contents for Sharp FO-6600

  • Page 1 FO-6600U SERVICE MANUAL No. 00ZFO6600USME FACSIMILE FO-6600 MODEL CAUTION This laser printer is a class 1 laser product that complies with 21CFR 1040.10 and 1040.11 of the CDRH standard. This means that this machine does not produce a hazardous laser radiation. The use of controls, adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
  • Page 2 FO-6600U CONTENTS CHAPTER 1. GENERAL DESCRIPTION [1] Specifications ..............1-1 [2] Operation panel .

  • Page 3: Specifications

    Length  5.0 to 17.0" (128 to 432 mm) Width  8.5" (216 mm) Paper size: * Based on ITU-T (CCITT) Test Chart #1 at standard resolution in Sharp special mode, excluding time for protocol signals (i.e., ITU-T phase C Length  11-14" (280-356 mm) time only).

  • Page 4: Operation Panel

    FO-6600U [2] Operation panel (1) LINE STATUS lights This LINE-1 lights illuminates when Line 1 is being used, and LINE key the LINE-2 lights illuminates Press this key before when Line 2 is being used. dialing to select the line. Display This displays messages and prompts during...
  • Page 5 FO-6600U Operation panel (2) RELAY key Press this key to send a document to another fax machine and have that machine in turn send the document to a number of end receiving machines. PAGE COUNTER key TIMER key LIFE key Press this key to have a slash and Press this key to set an Press this key, followed...

  • Page 6: Transmittable Documents

    FO-6600U [3] Transmittable documents 4. Cautions on Transmitting Documents 1. Document Sizes • Documents written in yellow, greenish yellow, or light blue ink cannot be transmitted. width 5.83"–8.5"(148 – 216 mm) Normal size • Ink, glue, and correcting fluid on documents must be dry before the length 5.04"...

  • Page 7: Installation

    FO-6600U 7. Use of Document Carrier Sheet TELEPHONE JACK A document carrier sheet must be used for the following documents. A standard RJ11C telephone jack must be located near the machine. • Those with tears. This is the telephone jack commonly used in most homes and offices. Those smaller than size 5.83"...
  • Page 8 FO-6600U Remove the new drum cartridge from its packaging. If you replace the toner cartridge, reset the toner counter by pressing the LIFE key (flip up the Rapid Key overlay if necessary), the "2" key, and the START key. LIFE START If you replace the drum cartridge, reset the drum counter by pressing Align the arrowhead on the right side of the drum cartridge (the right...
  • Page 9 4. Loading printing paper The paper cassettes and the paper tray hold the paper on which re- ceived documents are printed. The FO-6600 comes with two paper cas- settes. Each paper cassette can hold 500 sheets of either legal or letter size paper.
  • Page 10 FO-6600U Rotate the received document tray back. Grasp the hand hold on the Pinch the ends of the paper guide together, and move the guide to original document IN tray as shown, and open it. the appropriate position depending on whether you are loading letter or legal size paper.
  • Page 11 FO-6600U 5. Clearing paper jams Replace the drum cartridge, and then the toner cartridge. If a document doesn’t feed through the scanner properly during trans- mission or copying, or DOCUMENT JAM appears in the display, first try pressing the START key. If the document doesn’t come out of the feeder, open the operation panel by squeezing the operation panel release on the right side of the operation panel (marked "PULL OPEN"), and gently Left...

  • Page 12: Quick Reference Guide

    FO-6600U [5] Quick reference guide FUNCTION key menu The following chart shows the layout of the functions and settings accessed by pressing the FUNCTION key. First press the FUNCTION key, the appropriate numeric key as shown, and then "#" or " " until the desired item appears. Instructions for making each setting appear in the display. Refer to the detailed instructions on the page shown below the setting.
