Panasonic WV-NP240 Manual

http://www.gepanet.com
High quality MPEG-4 and JPEG dual streaming network camera
Key Features
• MPEG-4/JPEG digital signal output at VGA image size with up to 30 ips.
• MPEG-4 and JPEG dual stream output for simultaneous live
monitoring and high resolution recording.
• Progressive output provides clear images, even when the subject is
moving.
• High sensitivity: 1.1 lux at F1.2, 1.5 lux at F1.4.
• Up to 16x automatic electronic sensitivity enhancement.
• Electronic shutter for anti flicker.
• Video Motion Detector with 4 programmable detection areas and 3
sensitivity levels.
• Monitor output for easier installation.
• Up to 3x digital zoom with controlled by browser.
• Camera title display: Up to 20 alphanumeric characters on browser.
• SD Memory card slot for alarm recording and backup upon network
failure. Recorded dada can be downloaded by using FTP command.
• Alarm sources including Terminal input, VMD and Panasonic alarm
command can trigger actions including SD memory recording/FTP
image transfer, E-mail notification, Alarm indication, Terminal output
and Panasonic protocol output.
• Built-in microphone for audio (one-way).
• Built-in network interface (10Base-T / 100Base-TX).
• Power over Ethernet (PoE) IEEE 802.3af.
• Multiscreen: Images from 8 cameras can be displayed in two
separate Quad screens (JPEG only). 20 characters camera title is
available for each camera.
• FTP client function enables periodic image data transfer or transfer
upon alarm.
• Alarm e-mail notification
Color Network Camera
WV-NP240
WV-NP244
(24V AC, 12V DC or PoE)
Lens: optional
• Max bit rate/client for MPEG-4 (64 / 128 / 256 / 512 / 1,024 / 1,536 /
2,048 / 3,072 / 2,048 / 4,096 kbps) combined with Total bit rate
control (64 / 128 / 256 / 512 / 1,024 / 2,048 / 4,096 kbps / Unlimited)
allowing flexible network management.
• Supported Protocol: TCP/IP, UDP/IP, HTTP, FTP, SMTP, DHCP,
DNS, DDNS, NTP, RTP and SNMP.
• Multi-language GUI and setup menu: English, French, Italian,
Spanish, German, Russian (PAL), English, French (NTSC),
(Installation required except for English).
Standard Accessories
• CD-ROM* .......................................1 pc.
• Operating Instructions
(English version) ........................... 1 pc.
• Code Label ................................... 1 pc.
• Power cord
(only for the WV-NP240) .............. 1 pc.
Optional Accessories
1/3-type 2x Varifocal Lens
WV-LZA61/2S
(3.8 ~ 8 mm)
Series
WV-NP240
(220V ~ 240V AC or PoE)
WV-NP244
(24V AC, 12V DC or PoE)
The following parts are used during
installation procedures.
• Safety wire lug (for wall)................ 1 pc.
• Safety wire plate (for ceiling) ........ 1 pc.
• Screw (M2.5) ................................ 1 pc.
* Panasonic IP setting software, the viewer
software and the operating instructions (PDF)
are included on the CD-ROM.
1/3-type 8x Varifocal Lens
WV-LZ62/8S
(5 ~ 40 mm)
