Sony SAT-A55P Service Manual page 25

REF.NO. PART NO. DESCRIPTION
COIL
L110 1-408-608-31 INDUCTOR
L111 1-408-608-31 INDUCTOR
L112 1-408-608-31 INDUCTOR
L210 1-406-669-11 INDUCTOR
L290 1-406-669-11 INDUCTOR
L300 1-408-605-31 INDUCTOR
L301 1-408-605-31 INDUCTOR
L302 1-408-613-31 INDUCTOR
L303 1-408-608-31 INDUCTOR
L304 1-410-471-11 INDUCTOR
L625 1-406-659-11 INDUCTOR
L800 1-408-608-31 INDUCTOR
L805 1-408-608-31 INDUCTOR
L850 1-414-108-11 INDUCTOR
IC LINK
PS260 1-532-605-00 LINK, IC 0.4A/150V
TRANSISTOR
Q101 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q160 8-729-027-23 TRANSISTOR DTA114EKA-T146
(SAT-A55P ONLY)
Q190 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q199 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q201 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q202 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q203 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q204 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q240 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q241 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q290 8-729-019-01 TRANSISTOR 2SD2394-EF
Q301 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q302 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q303 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q304 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q520 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q521 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q522 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q550 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q551 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q630 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q631 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q632 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q650 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q651 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q652 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q653 8-729-019-01 TRANSISTOR 2SD2394-EF
VALUES
27µH
27µH
27µH
470µH
470µH
15µH
15µH
68µH
27µH
12µH
10µH
27µH
27µH
0.68µH
— 25 —
REF.NO. PART NO. DESCRIPTION
Q654 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q655 8-729-140-96 TRANSISTOR 2SD774-T-4
Q690 8-729-019-01 TRANSISTOR 2SD2394-EF
Q691 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q692 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q693 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q800 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q801 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
(SAT-A55P ONLY)
Q802 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
(SAT-A55P ONLY)
RESISTOR
R010 1-216-813-11 RES-CHIP
R011 1-216-813-11 RES-CHIP
R012 1-216-813-11 RES-CHIP
R013 1-216-817-11 RES-CHIP
R100 1-216-833-11 RES-CHIP
R101 1-216-821-11 RES-CHIP
R102 1-216-817-11 RES-CHIP
R103 1-216-817-11 RES-CHIP
R104 1-216-817-11 RES-CHIP
R105 1-216-818-11 RES-CHIP
R106 1-216-818-11 RES-CHIP
R107 1-216-818-11 RES-CHIP
R108 1-208-817-11 METAL CHIP
R109 1-216-833-11 RES-CHIP
R110 1-216-833-11 RES-CHIP
R111 1-216-833-11 RES-CHIP
R112 1-216-833-11 RES-CHIP
R115 1-216-833-11 RES-CHIP
R119 1-216-864-11 SHORT
R123 1-216-864-11 SHORT
R137 1-216-833-11 RES-CHIP
R138 1-216-833-11 RES-CHIP
R139 1-216-801-11 RES-CHIP
R150 1-216-833-11 RES-CHIP
R152 1-216-833-11 RES-CHIP
R154 1-216-829-11 RES-CHIP
R160 1-216-829-11 RES-CHIP
R161 1-216-864-11 SHORT
R162 1-216-864-11 SHORT
R164 1-216-825-11 RES-CHIP
R165 1-216-825-11 RES-CHIP
R170 1-216-829-11 RES-CHIP
R172 1-216-833-11 RES-CHIP
R188 1-216-833-11 RES-CHIP
R190 1-216-825-11 RES-CHIP
R191 1-216-845-11 RES-CHIP
SAT-A55P/B55P
A
VALUES
220 5% 1/16W
220 5% 1/16W
220 5% 1/16W
470 5% 1/16W
10K 5% 1/16W
1K 5% 1/16W
470 5% 1/16W
470 5% 1/16W
470 5% 1/16W
560 5% 1/16W
560 5% 1/16W
560 5% 1/16W
30K 0.50% 1/10W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
22 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
4.7K 5% 1/16W
4.7K 5% 1/16W
2.2K 5% 1/16W
2.2K 5% 1/16W
4.7K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
2.2K 5% 1/16W
100K 5% 1/16W
