Customer Support and Service Unpacking Parts List Exploded View Description Features Power Installing the UML-190-90 Mounting the UML-190-90 5.1.1 Desktop Installation 5.1.2 Wall Mount Installation Connecting the Composite Video Signal to the Monitor Connecting the Y/C (S-Video) Signal to the Monitor...
– For 24 VAC units, voltage applied to the unit's power input should not exceed ±10%, or 28 VAC. User-supplied wiring must comply with local electrical codes (Class 2 Bosch Security Systems, Inc. Installation Manual F01U075712 | 1.0 | 2007.09...
16. Attachments, changes or modifications - Only use attachments/accessories specified by the manufacturer. Any change or modification of the equipment, not expressly approved by Bosch, could void the warranty or, in the case of an authorization agreement, authority to operate the equipment.
Disposal - Your Bosch product was developed and manufactured with high-quality material and components that can be recycled and reused. This symbol means that electronic and elec- trical appliances, which have reached the end of their working life, must be collected and dis- posed of separately from household waste material.
Page 8
Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his expense. F01U075712 | 1.0 | 2007.09 Installation Manual Bosch Security Systems, Inc.
Page 9
UL MAKES NO REPRESENTATIONS, WARRANTIES, OR CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING-RELATED FUNCTIONS OF THIS PRODUCT. Copyright This user guide is the intellectual property of Bosch Security Systems and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly.
| Safety UML -190-90 Customer Support and Service If this unit needs service, contact the nearest Bosch Security Systems Service Center for authorization to return and shipping instructions. Service Centers Telephone: 800-366-2283 or 585-340-4162 Fax: 800-366-1329 Email: cctv.repair@us.bosch.com Customer Service...
Verify that all the parts listed in the Parts List below are included. If any items are missing, notify your Bosch Security Systems Sales or Customer Service Representative. The original packing carton is the safest container in which to transport the unit and must be used if returning the unit for service.
Scrolls right in the OSD the OSD Not Used. Power Button / LED Display power (On/Off) Indicator Power On (green) Standby, suspend, active Off (amber) Unsupported mode (green) Power Off (red) Bosch Security Systems, Inc. Installation Manual F01U075712 | 1.0 | 2007.09...
Page 13
Composite signal Input for AV2 VIDEO 2 (AV2) OUT Video looping output for AV2 S-VIDEO (Y/C) IN Y/C separated signal input S-VIDEO (Y/C) OUT Y/C separated signal looping output F01U075712 | 1.0 | 2007.09 Installation Manual Bosch Security Systems, Inc.
Description | en Description The UML-190-90 19-inch (48-cm) Color Panel Display Monitor displays PAL or NTSC standard color pictures in CCTV systems. The UML-190-90 monitor includes two (2) looping Composite Video BNC connector inputs, and one (1) looping Y/C (S-Video) input using a 4-pin mini-DIN.
This chapter outlines the procedures needed to install the UML-190-90 Series. A qualified ser- vice person should install the monitor and adhere to all local codes. Mounting the UML -190-90 The UML-190-90 is designed to be used on a desktop or mounted to a wall or rack. 5.1.1 Desktop Installation The UML-190-90 monitor is delivered with a 3-pole US-style power cord and a 3-pole Euro- style power cord.
Page 16
UML -190-90 Installing the UML -190-90 | en Fig. 5.2 Mounting the Device Bosch Security Systems, Inc. Installation Manual F01U075712 | 1.0 | 2007.09...
Connecting the PC Signal to the Monitor The monitor can be connected to the analog VGA signal by using the provided VGA cable (D- SUB to D-SUB). Fig. 5.4 VGA Input F01U075712 | 1.0 | 2007.09 Installation Manual Bosch Security Systems, Inc.
Description Video Camera VIDEO 1 (AV1) IN VIDEO 1 (AV1) OUT Fig. 5.6 Multiple Monitor Configuration Reference # Description Video Camera VIDEO 1 (AV1) IN VIDEO 1 (AV1) OUT Bosch Security Systems, Inc. Installation Manual F01U075712 | 1.0 | 2007.09...
UML -190-90 Navigating the Monitor Navigating the Front Panel Use the front panel to make any necessary OSD adjustments to the UML-190-90. See the fig- ure below for an explanation of the front panel. Fig. 6.1 Front Panel Buttons Reference...
To access the OSD menus, press the Menu button. Use the front panel of the UML-190-90 to make any necessary adjustments to the OSD. To navigate the set up menus, follow the steps below: Connect the CVBS or VGA cable.
Exit Enables the user to turn on and off the OSD menu, and displays the following information: horizontal frequency, vertical frequency, and the firmware version number. F01U075712 | 1.0 | 2007.09 Installation Manual Bosch Security Systems, Inc.
Saturation Sharpness Move: EXIT: MENU Fig. 6.3 Screen Menu (Video Mode) Screen Brightness Contrast H. Position V. Position Clock Phase Move: EXIT: MENU Fig. 6.4 Screen Menu (PC Mode) Bosch Security Systems, Inc. Installation Manual F01U075712 | 1.0 | 2007.09...
Adjusts the transparency level for video performance (0, 25, 50, and 100% increments). OSD Timer Adjusts the on-screen display time (range 5s-20s). Language Adjusts the language of the OSD. Choices are: English, French, Ger- man, Italian, Dutch, and Spanish. F01U075712 | 1.0 | 2007.09 Installation Manual Bosch Security Systems, Inc.
Utility submenu. Utility Recall Lock Move: EXIT: MENU Fig. 6.7 Utility Menu (Video Mode) Utility Recall AUTO Full Auto Lock Move: EXIT: MENU Fig. 6.8 Utility Menu (PC Mode) Bosch Security Systems, Inc. Installation Manual F01U075712 | 1.0 | 2007.09...
Exit icon, then press the menu buttons to exit the OSD. Exit H: 63.1KHz PC V: 70.0Hz VER. 1.0 Move: EXIT: MENU Fig. 6.9 Exit Menu F01U075712 | 1.0 | 2007.09 Installation Manual Bosch Security Systems, Inc.
Screen blanks after idle time and some electronic cir- cuits or all circuitry in the monitor shut down. SUSPEND ACTIVE OFF UNSUPPORTED MODE Green Normal operation but the screen displays error mes- sage. POWER OFF Not operational. Bosch Security Systems, Inc. Installation Manual F01U075712 | 1.0 | 2007.09...
The error message PC is operating with either a resolution or timing mode that is not “Unsupport Mode” is dis- supported by the UML-190-90. Change the PC timing mode to one played of the valid combinations below: 640 x 480; 60/72/75 Hz 800 x 600;...
Ketone type materials – Ethyl alcohol – Ethyl acid – Tolulene – Methyl chloride – Ammonia Use of these materials may permanently damage the polarizer due to a chemical reaction. Bosch Security Systems, Inc. Installation Manual F01U075712 | 1.0 | 2007.09...
