Panasonic SA-AK340P Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Stereo System
  5. SA-AK340P
  6. Service manual

Panasonic SA-AK340P Service Manual

Cd stereo system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Notes: This model's CD mechanism changer unit is CRS1. Please refer to the original Service Manual
(Order No. MD0509368C0) for this mechanism.

Specifications

n AMPLIFIER SECTION
FTC output power
THD 10%, both channels driven
50 Hz to 3 kHz
(Low channel)
3 kHz to 12 kHz
(High channel)
Total FTC Bi-Amp power
RMS output power
THD 10%, both channels driven
1 kHz
(Low channel)
10 kHz
(High channel)
Total Bi-Amp power
n FM/AM TUNER, TERMINALS SECTION
Preset station
Frequency Modulation (FM)
Frequency range
Sensitivity
81 W per channel (3 Ω)
81 W per channel (3 Ω)
324 W
105 W per channel (3 Ω)
105 W per channel (3 Ω)
420 W
FM 15 stations
AM 15 stations
87.9 to 107.9 MHz (200 kHz
steps)
87.5 to 108.0 MHz (100 kHz
steps)
4.0 µV (IHF)
SA-AK340P
SA-AK340PC
Colour
(S)... Silver Type
S/N 26dB
Antenna terminal(s)
Amplitude Modulation (AM)
Frequency range
Sensitivity
S/N 20dB (at 1000 kHz)
Music Port input jack
Terminal
Sensitivity
Phone jack
Terminal
n CASSETTE DECK SECTION
Track system
Heads
Record/playback
Erasure
Motor
Recording system
Erasing system
Tape speed
Overall frequency response (+3, -6 dB) at DECK OUT
NORMAL
S/N ratio
© 2005 Matsushita Electric Industrial Co. Ltd.. All
rights
reserved.
distribution is a violation of law.
ORDER NO. MD0510381C1
CD Stereo System
75 Ω (unbalanced)
520 to 1710 kHz (10 kHz step)
560 µV/m
Stereo, 3.5 mm (1/8") jack
100 mV, 4.7 kΩ
Stereo, 3.5 mm (1/8") jack
4 track, 2 channel
Solid permalloy head
Double gap ferrite head
DC servo motor
AC bias 100 kHz
AC erase 100 kHz
4.8 cm/s (1-7/8 ips)
35 Hz to 14 kHz
50 dB (A weighted)
Unauthorized
copying
A6
2.2 µV
and
