SERVICE MANUAL

MODEL
KLV-S40A10E
KDL-S40A11E
RM-EA002
COMMANDER
DEST
RM-EA002
AEP
RM-ED002
AEP
KLV-S40A10E / KDL-S40A11E / KDL-S40A12U
- 1 -
WAX
MODEL
KDL-S40A12U
FLAT PANEL COLOR TV
WAX
RM-EA002 / RM-ED002
CHASSIS
COMMANDER
DEST
RM-ED002
UK
RM-ED002

Advertisement

Table of Contents
loading

Related Manuals for Sony KLV-S40A10E

Summary of Contents for Sony KLV-S40A10E

  • Page 1: Service Manual

    RM-EA002 / RM-ED002 SERVICE MANUAL CHASSIS MODEL MODEL COMMANDER DEST COMMANDER DEST KLV-S40A10E KDL-S40A12U RM-EA002 RM-ED002 KDL-S40A11E RM-ED002 RM-EA002 KLV-S40A10E / KDL-S40A11E / KDL-S40A12U RM-ED002 FLAT PANEL COLOR TV - 1 -...

  • Page 2: Table Of Contents

    DIRECTLY CONNECTED TO THE POWER LINE. THE SCHEMATIC DIAGRAMS, EXPLODED VIEWS AND IN THE PARTS LIST ARE CRITICAL FOR SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.

  • Page 3: Caution

    Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade. This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics. For more information on the use of Lead Free Solder, please refer to http://www.sony-training.com - 3 -...
  • Page 4 RM-EA002 / RM-ED002 . s l . s l . s l e i l . s l i g i i n i i n i - 4 -...
  • Page 5 RM-EA002 / RM-ED002 y t i WARNING (UK Models only) The flexible mains lead is supplied connected to a B.S. 1363 fused plug having a fuse of 13 AMP rating. Should the fuse need to be replaced, use a 13AMP FUSE approved by ASTA to BS 1362, ie one that carries the mark.
  • Page 6 RM-EA002 / RM-ED002 21 pin connector Pin No Signal Signal level Audio output B Standard level : 0.5V rms (right) Output impedence : Less than 1kohm* Audio input B Standard level : 0.5V rms (right) Output impedence : More than 10kohm* Audio output A Standard level : 0.5V rms (left)

  • Page 7: Self Diagnosis

    RM-EA002 / RM-ED002 WAX SELF DIAGNOSTIC SOFTWARE The identification of errors within the WAX chassis is triggered in one of two ways :- 1: Busy or 2: Device failure to respond to IIC. In the event of one of these situations arising the software will first try to release the bus if busy (Failure to do so will report with a continuous flashing LED) and then communicate with each device in turn to establish if a device is faulty.

  • Page 8: General

    The operating instructions mentioned here are partial abstracts from the Operating Instruction Manual. The page numbers of the Operating Instruction Manual remain as in the manual. 3: Connecting an aerial/VCR 4: Preventing the TV 6: Selecting the language and country/region from toppling over When you switch on the TV for the first time, the Language menu appears on the screen.
  • Page 9 Press OK to select “Yes”. Watching TV 7: Auto-tuning the TV Do you want to start Watching TV After selecting the language and country/region, a automatic tuning ? Press DIGITAL to switch to digital mode or message confirming the TV start auto-tuning appears ANALOG to switch to analogue mode.
  • Page 10 Using the Menu Checking the Digital Electronic Programme Guide Viewing pictures from connected equipment (EPG) Navigating through Switch on the connected equipment, then menus perform one of the following operation. All Categories Thu 27 May 10:31 In digital mode, press to display the Thu 27 May 10:30...

  • Page 11: Picture Adjustment Menu

    Picture Adjustment menu Sound Adjustment menu You can select the options listed below on the Picture You can select the options listed below on the Sound Picture Adjustment Sound Adjustment Adjustment menu. To select options, see “Navigating Adjustment menu. To select options, see “Navigating Picture Mode: Custom Sound Effect:...

  • Page 12: Screen Menu

    Screen menu Features menu You can select the options listed below on the Screen You can select the options listed below on the Screen Features Control menu. To select options, see “Navigating Features menu. To select options, see “Navigating Auto Format: Power Saving Standard Screen Format:...

  • Page 13: Timer Menu

    Timer menu Set Up menu You can select the options listed below on the Timer You can select the options listed below on the Set Up Timer Set Up menu. To select options, see “Navigating through menu. To select options, see “Navigating through Sleep Timer Auto Start Up Clock Set...

  • Page 14: Connecting Optional Equipment

    Connecting to the rear of the TV Using Optional Equipment Connecting optional equipment You can connect a wide range of optional equipment to your TV. Connecting cables are not supplied. Connecting to the side of the TV (KDL-S32A11E, To connect Do this KDL-S26A11E only) Connect to the i socket to listen to...

  • Page 15: Specifications

    Optional Accessories Additional Information • Wall-Mount Bracket SU-PW2 (KDL-S40A11E) • Wall-Mount Bracket SU-WL31 (KDL-S32A11E, KDL-S26A11E, KDL-S23A11E) Specifications Aerial • TV Stand SU-FF51 (KDL-S40A11E) 75 ohm external terminal for VHF/UHF Design and specifications are subject to change Channel Coverage Display Unit without notice.

  • Page 16: Connectors

    For example, the indicator flashes for two seconds, stops flashing for one second, and flashes for two seconds. Sound Press 1 on the TV (Top side) to switch it off, disconnect the mains lead, and inform your dealer or Sony service centre of how the indicator flashes (duration and interval). Problem Cause/Remedy When it is not flashing •...

  • Page 17: Disassembly

    RM-EA002/RM-ED002 SECTION 2 DISASSEMBLY 2-1. REAR COVER REMOVAL 2-2. STAND REMOVAL – 17 –...

  • Page 18: Shield Cover Removal

    RM-EA002/RM-ED002 2-3. SHIELD COVER REMOVAL 2-4. SPEAKER REMOVAL – 18 –...

  • Page 19: A2E4 Removal

    RM-EA002/RM-ED002 2-5. A2E4 BOARD REMOVAL 2-6. BE BOARD REMOVAL – 19 –...

  • Page 20: G3 Board Removal

    RM-EA002/RM-ED002 2-7. G3 BOARD REMOVAL 2-8. GE2 BOARD REMOVAL – 20 –...

  • Page 21: H1E Board Removal

    RM-EA002/RM-ED002 2-9. H1E BOARD REMOVAL 2-10. H2 BOARD REMOVAL – 21 –...

  • Page 22: H3 Board Removal

    RM-EA002/RM-ED002 2-11. H3 BOARD REMOVAL 2-12. N BOARD REMOVAL – 22 –...

  • Page 23: N1 Board Removal (Digital Models Only)

    RM-EA002/RM-ED002 2-13. N1 BOARD REMOVAL – 23 –...

  • Page 24: Set-Up Adjustments

    RM-EA002/RM-ED002 SECTION 3 SET-UP ADJUSTMENTS 3-1. Signal Adjustment 3-2. White Balance Adjustment Service adjustments to this model can be performed using the 3-2-1. White Balance adjustment (H/L) supplied remote Commander RM-EA002 or RM-ED002. 1. Select AV1. How to enter into the Service Mode 2.

  • Page 25: White Balance Adjustment (C/O)

    RM-EA002/RM-ED002 3-2-2. White Balance adjustment (C/O) 3-2-3. SECAM White Balance adjustment (H/L) 1. Select AV1. 1. Select AV1. 2. Change the TV to Custom Mode and set the following registers by 2. Change the TV to Custom Mode and set the following registers by sending “TT54”.

  • Page 26: Secam White Balance Adjustment (C/O)

    RM-EA002/RM-ED002 3-2-4. SECAM White Balance adjustment (C/O) 3-3. TEST TEST MODE 1. Select AV1. Test Test Mode is available in Service Mode, OSD ‘TT’ appears. The 2. Change the TV to Custom Mode and set the following registers by functions described below are available by selecting the two numbers. sending “TT54”.

  • Page 27: Block Diagrams(1)

    4-1. BLOCK DIAGRAMS (1) A3.3V Q6008 DC ALERT1 Q6010 AU-15V DC ALERT AU-9V HDMI 9V CN8550 IC8500 CVBS 12SWS3/ALRCK CN8605 PORT EXPANDER CVBS MAIN TRIDENT Q2501 FL2500 Q2503 BUFFER FILTER BUFFER TO NP1 BOARD BYPASS 12SCL3/ABCK TO N BOARD Q8507 FB DET IC2507 CN0005...

  • Page 28: Block Diagrams(2)

    4-1. BLOCK DIAGRAMS (2) CN5402 IC7403 SRAM TELETEXT IC1002 DATA STORAGE IC5000 IC5500 RST-0 VIDEO PROCESSOR SDRAM OPEN MD[13] MD[12] RST-1 MD[15] MD[14] MD[14] MD[11] ALE-M DQM[2] MD[13] MD[15] MD[10] DQM[0] MD[12] IC1006 MD[9] MD[16] RESET IC DQM[3] MD[11] MD[17] MD[8] RST-0 DQM[1]...

  • Page 29: Block Diagrams(3)

    4-1. BLOCK DIAGRAMS (3) RY6004 IC6500 UNREG 10.5V SWITCHING CONTROL L6102 L6104 T6100 CN6204 PFC OUT 17.5V D6602 F6001 DIODE CN6001 L6002 L6003 Q6500 FUSE SWITCH AC(L) R6839 TO PANEL 6.3 AMP AC(N) D6104 Q6501 SWITCH BRIDGE D6601 RECTIFIER DIODE CN6202 17.5V T6101...

  • Page 30: Block Diagrams(4)

    4-1. BLOCK DIAGRAMS (4) SWITCH DTE_RXD Q3504 IC3504 IC3309 IC3306 nPC-EN nPC-EN IN_TS_BCLK SMC_RXD nFE_RST DTE_TXD MDI(7) RADD(25) IN_TS_PSYNC SMC_TXD DTE_RTS MDI(6) RADD(24) MDO(7) IN_TS_PVAL DTE_CTS CN3500 IC3502 SMART MDI(5) RADD(23) MDO(6) +5VD-CI nSCM_RST nSMC_INT OCTAL TRANCEIVER CARD AND MODEM-EN IN_TSD(0) IC3303 MODEM...

  • Page 31: Block Diagrams(5)

    4-1. BLOCK DIAGRAMS (5) 4-2. CIRCUIT BOARD LOCATION 5-2. CIRCUIT BOARD LOCATION Reference Information RESISTOR : METAL FILM : SOLID FPRD : NON FLAMMABLE CARBON N 2/2 ( MPEG2 IC3801 FUSE : NON FLAMMABLE FUSIBLE IC3805 DECODER OCTAL D-TYPE QUAD AND GATE FLIP/FLOP : NON FLAMMABLE METAL OXIDE nMASTER RESET...

  • Page 32: A2E4 Board Schematic Diagram

    A2E4.-S40-WAX AU_9V A2E4 R7980 D7820 REG17.5V 1/5 ANALOGUE TUNER, AUDIO AMP, CHOMA DECODER AV SWITCH, SCARTS, YUV INPUT R7978 R7976 R7977 CHIP C9635 R7851 1/10W AU_9V Q7809 R7853 Q7808 MUN5213T1 2SC4081T106R R7979 1/10W RN-CP CHIP LINE_MUTE R7852 C7862 AC_OFF_DET_AU R7810 C7863 1/10W C7867...
  • Page 33 A2E4.-S40-WAX A3.3V C7882 C7881 0.22 0.22 I2S_DATA_OUT_3.3 I2S_DATA_OUT_5V R7930 R7931 R7894 L7804 4.7k 4.7k 1/10W TO DETECT 1/10W R7831 L7810 C7848 C7886 C7887 C7831 33uH L7812 47uH R7956 C7913 100k C7915 I2S_DATA_OUT_3.3 1/10W FB7810 FB7811 AU_9V R7951 100k I2S_WS_3.3 IC7805 I2S_DATA_IN_3.3 D7812 D7816...
  • Page 34 A2E4.-S40-WAX A5V_1 A5V_1 R2511 1/10W L2500 B_SCART2 100uH R2513 C2550 0.47 R2512 1/10W C2500 C2501 1/10W B_SCART1 L2511 10uH R9905 C2551 R2565 A5V_1 0.47 C2540 R2558 C2609 R2518 R_IN C2608 1/10W CHIP A5V_1 R2559 CHIP R2575 CHIP G_IN L2509 R_IN 10uH R2560 A5V_1...
  • Page 35 A2E4.-S40-WAX A2E4 D9605 MMDL914T1 R9592 C9548 D9606 MMDL914T1 TU9500 D9604 Q9502 R_OUT1 MMDL914T1 R9584 R9694 CHIP J9153 Y_HD R9717 VDR001 C9512 R9507 D9603 R9693 R9707 C9500 R9503 R9505 C9539 CHIP 0.022 470k MM3Z6V8T1 470p 1/10W 1/10W 1/10W D9522 R9591 R9593 1/10W 1/10W R9695...
  • Page 36 TO BE BOARD TO BE BOARD CN1001 CN1003 CN8530 CN9405 A2E4.-S40-WAX STBY5V R8001 R8000 CHIP C8500 FB_DET PANEL5V_GND JL8536 R9401 R9409 COINCIDENCE C9409 R8569 R8572 R8574 R8575 R8707 R8532 R8531 R8538 C8530 C8531 C8532 C8533 C8534 C8535 CHIP CHIP CHIP CHIP R8576 CHIP...

  • Page 37: A2E4 Printed Wiring Board

    ~ A2E4 Board Semiconductor Location Table Side A ~ ~ A2E4 Printed Wiring Board Conductor Side A ~ ~ A2E4 Board IC Voltage Table Side A ~ ~ A2E4 Board Semiconductor Voltage Table Side A ~ - 37 -...
  • Page 38 ~ A2E4 Printed Wiring Board Conductor Side B ~ ~ A2E4 Board Semiconductor Location Table Side B ~ ~ A2E4 Board Difference Table ~ & - 38 -...

  • Page 39: Be Board Schematic Diagram

    BE.-S40-WAX VD3_3 R7549 4.7k R7535 1/16W CHIP ALE_M R7548 C1012 C1009 RESET_AUDIO N_RESET SIRCS R1066 C1017 C1019 C1021 PB_FAIL STBY3.3V C1006 Q1001 R7547 R1062 R1000 R1073 R1076 R1002 MSB709-RT1 1/16W STBY3.3V RB1007 R1014 1/16W 1/16W X1000 CHIP L1000 6MHz VD3_3 C1007 10uH CHIP...
  • Page 40 BE.-S40-WAX CN1001 COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL PC_IN_L A.GND PC_IN_R CVBS_1 C1061 R7568 A.GND CHIP CVBS YC_Y C1052 R1102 YC_Y CHIP IC1000 YC_C S-1111B33MC-NYSTFG C1053 R1103 YC-C CHIP STBY5V VOUT Y_IN IC7404 C8541 R1104 ON/OFF DIMMER2 NJM2904M(TE2) CB_IN...
  • Page 41 BE.-S40-WAX MD[0-31] DQS[0-3] DQM[0-3] MA[0-11] VD3_3 R5010 1/10W R5011 VDDMQ C5049 C5058 C5093 C5092 C5060 C5089 C5094 C5112 C5096 1000p R5033 R5032 C5061 C5091 C5090 C5114 C5097 C5113 C5095 1000p 1000p 1/16W 1/16W VD1_8 FL5005 MPUGPIO0 VDDL L5015 A_D0 VSSL C5115 MA[0] A_D1...
  • Page 42 BE.-S40-WAX R5519 R5521 C5516 C5503 VDDQSNS VCC5V VDDMQ R5522 VDDMQ VLDOIN C5523 RB5507 R5501 R5500 VDDMQ PGND POWER2 MD[16] 1/10W 1/10W R5517 MD[18] VTTSNS C5522 C5519 C5520 C5521 C5518 VTTREF MD[17] R5518 C5517 IC5501 MD[19] RB5506 VDDM MD[20] MD[21] MD[22] MD[23] RB5505 MD[0]...
  • Page 43 BE.-S40-WAX STBY5V CN1004 L1001 2.2UH C1036 100 6.3V C1038 100PF FROM S1 PWB (DIGITAL) R1004 C1047 CHIP INPUT TO Trident MAIN_DIN R1005 C1048 RB4704 CHIP DT_C_DC0 NC(P-TXD) SERVICE CONNECTOR C1049 DT_C_DC1 NC(P-RXD) DT_C_DC2 DT_C_DC3 NC(P-RES) DTTLOG B INT RB4705 DT_C_DC4 DT_C_DC5 DT_C_DC6 STBY3.3V...
  • Page 44 BE.-S40-WAX D5700 IC5740 L88M05T-FA-TL +5V REGULATOR IC5700 VCC5V PQ1CZ41H2ZPH C5740 R5740 R5742 DC/DC CONVERTER CHIP C5742 C5743 CHIP C5741 R5710 F5700 L5700 L5701 2.2k 10uH 47uH VD3_3 1/10W REG17.5V R5717 C5711 POWER2 IC5722 C5707 C5708 R5713 C5705 CHIP C5702 R5701 BA25BC0FP-E2 0.01 DC/DC REGULATOR...

  • Page 45: Be Printed Wiring Board

    ~ BE Printed Wiring Board Conductor Side A ~ ~ BE Board Semiconductor Location Table Side A ~ ~ BE Printed Wiring Board Conductor Side B ~ ~ BE Board Semiconductor Location Table Side B ~ - 45 -...

  • Page 46: G3 Board Schematic Diagram

    G3.-S40-WAX COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL R6057 R6051 F6001 R6058 CN6001 6.3A R6007 C6002 R6052 250V 1/2W 275V FH6002 R6059 AC(L) R6053 FH6001 AC(N) R6002 C6013 VD6002 1/2W C6004 0.22 L6003 250V VD6001 1/2 POWER SUPPLY R6001 8.2M L6002...
  • Page 47 G3.-S40-WAX CN6204 +17.5V +17.5V +17.5V +17.5V TO PANEL C6609 1000p D6602 FCQ10A06 CN6202 L6601 10uH +17.5V L6602 10uH +17.5V L6603 C6607 10uH 1000p +17.5V PFC_OUT D6601 C6606 L6500 R6501 R6504 FCQ10A06 +17.5V 100uH 220k TO PANEL 1/10W FB6500 FB6501 1/2W +17.5V RN-CP 1.1uH...

  • Page 48: G3 Printed Wiring Board

    ~ G3 Printed Wiring Board Conductor Side A ~ ~ G3 Board Semiconductor Location Table Side A ~ - 48 -...
  • Page 49 ~ G3 Printed Wiring Board Conductor Side B ~ ~ G3 Board Semiconductor Location Table Side B ~ - 49 -...

  • Page 50: Ge2 Board Schematic Diagram

    GE2.-S40-WAX D8800 D8811 MMDL914T1 IC8800 IC8805 PQ1CY1032ZP PQ1CY1032ZP +5V REGULATOR +5V REGULATOR L8809 R8822 47uH C8853 C8852 L8808 PANEL5V R8827 FB8823 47uH C8842 C8801 C8850 L8800 PANEL5V PS8801 L8802 C8808 47uH C8841 1000 C8864 47uH 1000 6.3V R8836 Q8806 6.3V UNREG10.5V 2SD601A-Q-TX R8840...

  • Page 51: Ge2 Printed Wiring Board

    ~ GE2 Board Semiconductor Location Table Side A ~ ~ GE2 Printed Wiring Board Conductor Side A ~ ~ GE2 Board IC Voltage Table ~ ~ GE2 Printed Wiring Board Conductor Side B ~ ~ GE2 Board Semiconductor Location Table Side B ~ - 51 -...

  • Page 52: H1E Board Schematic Diagram

    ~ H2 Board Schematic Diagram [ Y/C, AV, Headphones ] ~ H2.-S40-WAX CN9855 COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL S2SW R9112 R9103 R9108 C9048 ~ H1E Board Schematic Diagram [ Switches ] ~ 1/10W 1/10W D9035 1/10W RN-CP RN-CP...

  • Page 53: H1E Printed Wiring Board

    ~ H1E Printed Wiring Board Conductor Side A ~ ~ H1E Printed Wiring Board Conductor Side B ~ ~ H2 Printed Wiring Board Conductor Side A ~ ~ H2 Printed Wiring Board Conductor Side B ~ ~ H3 Printed Wiring Board Conductor Side A ~ ~ H3 Printed Wiring Board Conductor Side B ~ - 53 -...

  • Page 54: N Board Schematic Diagram (Digital Models Only)

    N.-S40-WAX NAND_ALE,NAND_CLE,NAND_RBB +3V3D_STRAPS +3V3D FB3100 THESE CAPACITORS TO BE PLACED UNDERNEATH BGA C3100 C3106 C3109 C3112 C3115 C3119 C3103 +2V5D_DDR +2V5D FB3101 THESE CAPACITORS TO BE PLACED UNDERNEATH BGA C3116 C3120 C3107 C3110 C3113 C3104 151 150 142 141 139 138 +1V5D FB3102 THESE CAPACITORS TO BE PLACED UNDERNEATH BGA...
  • Page 55 N.-S40-WAX COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL +3V3D FB3201 C3205 C3208 C3206 NAND FLASH C3209 +3V3D R3251 R3238 RDATA[7] IO/8 RDATA[6] IO/7 NAND_RBB RDATA[5] IO/6 RDATA[4] C3230 1000p FOEB IO/5 +2V5D_DDR PLACE THESE CAPACITORS CLOSE TO IC PINS. FCSB1 C3220 C3203...
  • Page 56 EXTERNAL CONNECTOR CN3300 N.-S40-WAX +3V3D_31 COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL Mount Mecha A3300 181564021 IC3311 74LVT245PW C3315 OCTAL TRANSCEIVER +3V3D_31 +3V3D FB3300 C3324 C3300 C3320 C3301 R3308 CHIP +5VD_CI D[15:8] R3303 FB3301 1/16W nCI_WAIT TS_BCLK, VS1B TP_SYNC, C3326...
  • Page 57 N.-S40-WAX +5VA FB3402 +3V3D D3400 +3V3D RB706F-40 R3442 C3404 C3403 Q3412 0.01 GAIN = R3482 + (R3470 + R3471) 2SC5658T2LQ/R ----------------------- (R3470 + R3471) CN3401 R3493 VIDEO CIRCUIT C3402 R3438 R3469 R3492 SPDIF Q3405 D3401 2SA2029T2LQ/R RB706F-40 Q3401 R3439 2SC5658T2LQ/R SCL_TV SCL_TV R3440...
  • Page 58 N.-S40-WAX +3V3D +3V3D_MODEM +3V3D R3537 FB3557 2.2k CHIP SMC/MODEM Connector nMODEM_EN CN3500 PIN 1 : GND MODEM C3570 C3504 MODEM_EN PIN 2 : nSMC_INT PIN 3 : DTE-CTS Q3504 PIN 4 : DTE-RTS DTC114EKA-T146 PIN 5 : nSMC_RST PIN 6 : SMC_RXD FB3555 PIN 7 : SMC_TXD PIN 8 : DTE-TXD...
  • Page 59 N.-S40-WAX +3V3D_STRAPS +3V3D_STRAPS +5VD +3V3D R3630 FIT FOR JTAG FIT FOR FWEB EJTAG R3632 R3634 R3636 FWEB TESTPIN FOEB FOEB CN3603 TMODE2 TMODE0 GCSB1 GCSB TMODE1 JTCK JTCK R3631 R3633 R3635 R3645 JTDO JTDO FIT FOR FCSB0 FCSB JTAG JTMS JTMS nRDY_DAMON JTRST...
  • Page 60 N.-S40-WAX +3V3D RESET SIGNAL GENERATION FB3801 +3V3D IC3805 74LVC08APW QUAD AND GATE C3810 R3839 R3827 C3809 R3800 nDAMON_RST 1/16W D3800 1PS184-115 1/16W R3832 nMASTER_RESET nCI_EN C3801 nPC_EN R3801 nCIPC_EN 1/16W C3802 nSW_FE_RESET nCI_WAIT nRDY_DAMON GRDYB R3803 IC3803 IC3800 C3800 TC7SH08FU(T5RSOYJF) +3V3D PST3629UL nMASTER_RESET...

  • Page 61: N Printed Wiring Board (Digital Models Only)

    ~ N Printed Wiring Board Conductor Side A ~ ~ N Board Semiconductor Location Table Side A ~ ~ N Board Difference Table ~ ~ N Printed Wiring Board Conductor Side B ~ ~ N Board Semiconductor Location Table Side B ~ - 61 -...

  • Page 62: N1 Schematic Diagram (Digital Models Only)

    TO N BOARD TO N BOARD TO N BOARD TO AE24 BOARD CN3403 CN3404 CN3503 TAB (CONTACT) CN8605 CN0005 CN0001 CN0003 CN0004 CN0002 N1.-S40-WAX COMPONENTS MARKED AS XX ARE NOT FITTED ON THIS MODEL R0021 TUNER_SCL CHIP TUNER_SDA 5VAEMI IF_AGC CHIP R0022 D0007...

  • Page 63: N1 Printed Wiring Board (Digital Models Only)

    ~ N1 Printed Wiring Board Conductor Side A ~ ~ N1 Board Semiconductor Location Table Side A ~ ~ N1 Printed Wiring Board Conductor Side B ~ ~ N1 Board Semiconductor Location Table Side B ~ - 63 -...

  • Page 64: Semiconductors

    4-4. SEMICONDUCTORS 74LVC00-PW CXD9841M MC74LVX8053DTR2 74LVC08APW 74LVC14APW 74LVC273PW 74LVC32A-PW 74LVC541APW 74LVT245PW K6F2008V2E-LF70000 MM1431ATT BA09CC0WFP-E2 BA09FP-E2 BA18BC0FP-E2 MSP4411K-QA-D5-001 BA25BC0FP-E2 BA33BC0FP-E2 KA5SDKASO1TSL LM3526MX-H/J5000396 LM75CIMX-3 BA7046F M24C02-WMN6T(B) M24C32-WMN6T(B) L88M05T-FA-TL NJM2904M CXA1875AM-T4 NJM3404AM-T1 NJM3414AV(TE2) LM393DT (A) CXA2069Q PQ070XZ01ZPH PQ070XZ1HZPH PQ1CY1032ZP M24128-BWMN6T(A) PQ1CZ41H2ZPH PQ12DZ5UJ00H CXA2163AQ-T6 M52347FP-TE - 64 -...
  • Page 65 PST3629UL SN74LVC14APWR TC7SET02FU(T5RSOJF) TC7SH08FU(T5RSOYJF) PST600IMT TC7WT241FU(TE12R) SOCKET, IC RC4558PWR TK11819MTL RPM7140-H8 STR-A6169 TPA3004D2PHPR SVPEX-SREVB UC3854BN RV5C387A-E2-FB S-1111B33MC-NYSTFG UPD61120AF1-100-JN1-A SDA5550M-QB-T TC58DVM72A1TG00 - 65 -...

  • Page 66: Exploded Views

    5-1. CHASSIS REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK X-2067-506-2 BEZEL(40)(KDL-S40A12U/KLV-S40A10E) 2 *2-589-406-03 S1 SHIELD MAIN(A) X-2102-765-1 BEZEL ASSY(40Z)(KDL-S40A11E) *2-515-692-12 HOLDER SIDE JACK 2-639-176-11 WINDOW(40),FRONT(KDL-S40A12U/KLV-S40A10E) *A-1147-502-A H2 BOARD, COMPLETE 2-639-176-41 WINDOW(40),FRONT(KDL-S40A11E) £ 1-819-763-11 INLET, AC (WITH NOISE FILTER) 1-826-231-11 SPEAKER...
  • Page 67 *A-1148-761-E G3 BOARD, COMPLETE *A-1149-548-E BE BOARD, COMPLETE *X-2055-717-1 BRACKET SIDE ASSY (A D)(KDL-S40A12U/A11E) *A-1147-503-A H3 BOARD, COMPLETE *X-2055-718-1 BRACKET SIDE ASSY (A A)(KLV-S40A10E) *A-1128-518-B H1E BOARD, COMPLETE *A-1128-516-A GE2 BOARD, COMPLETE X-2059-424-1 BUTTON, MULTI ASSY (32A) 8-597-993-00 TUNER, FSS BTF-EF412Z...

  • Page 68: Rear Cover And Stand

    5-2. REAR COVER AND STAND REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK - 68 -...

  • Page 69: Electrical Parts List

    Parts common to all models listed in this manual ...... 78 Model Parts that belong only to the model specified KDL-S40A11E/KDL-S40A12U ....................89 KLV-S40A10E ....................89 N1 BOARD COMPLETE Parts List : ....................90 N BOARD COMMON Parts List : Parts common to all models listed in this manual ......
  • Page 70 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK *A-1128-518-B H1E Board, Complete *A-1128-516-A GE2 Board, Complete 2-515-720-21 COVER, BUTTON(32) *2-637-727-01 SPACER 4-908-792-41 SCREW (B2) < CAPACITOR > < CAPACITOR > C8801 1-137-894-21 ELECT CHIP 470UF C9801 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C8803 1-137-894-21...
  • Page 71 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK D8812 8-719-073-34 DIODE EC21QS03L-TE12L L8813 1-412-058-11 INDUCTOR 10UH D8813 8-719-073-34 DIODE EC21QS03L-TE12L L8814 1-412-058-11 INDUCTOR 10UH D8814 8-719-069-55 DIODE UDZSTE-175.6B D8815 8-719-069-55 DIODE UDZSTE-175.6B < TRANSISTOR > D8816 8-719-073-34 DIODE EC21QS03L-TE12L Q8803 6-550-549-01 TRANSISTOR DTC114EUAFT106 <...
  • Page 72 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C6103 £ 1-115-350-51 CERAMIC 0.0047UF C6321 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V C6104 £ 1-115-350-51 CERAMIC 0.0047UF C6400 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C6106 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V C6401 1-104-653-11 ELECT 220UF...
  • Page 73 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C6705 1-100-831-91 CERAMIC CHIP 0.001UF D6301 8-719-948-45 DIODE ERA22-08 C6706 1-107-906-11 ELECT 10UF D6302 8-719-069-55 DIODE UDZSTE-175.6B C6707 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V D6401 8-719-081-97 DIODE MMDL914T1 C6708 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V D6420 8-719-081-97...
  • Page 74 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK < FUSE > Q6102 8-729-820-86 TRANSISTOR 2SB1121-ST Q6103 8-729-905-35 TRANSISTOR 2SC4081-R F6001 £ 1-576-233-51 FUSE 6.3A 250V Q6104 8-729-807-17 TRANSISTOR 2SD1621-S FH6001 £ 1-533-223-11 FUSE HOLDER Q6105 6-550-372-01 TRANSISTOR SPA20N60C3E8152 FH6002 £ 1-533-223-11 FUSE HOLDER Q6106...
  • Page 75 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R6118 1-216-830-11 METAL CHIP 5.6K 5% 1/10W R6302 1-260-129-11 CARBON 330K 5% 1/2W R6119 1-216-857-11 METAL CHIP 1/10W R6303 1-216-864-11 SHORT CHIP R6120 1-216-837-11 METAL CHIP 1/10W R6304 1-249-393-11 CARBON 1/4W R6122 1-243-665-11 METAL 0.05 5%...
  • Page 76 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R6454 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R6604 1-216-813-11 METAL CHIP 1/10W R6455 1-216-833-11 METAL CHIP 1/10W R6605 1-218-865-11 METAL CHIP 5.6K 0.5% 1/10W R6456 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W R6607 1-218-847-11 METAL CHIP 0.5% 1/10W...
  • Page 77 G3 H2 H3 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK < RESISTOR VARIABLE > < SOCKET > RV6100 1-227-703-91 RES, CERMET VAR 1K J9006 1-780-244-11 TERMINAL BLOCK, S(RIGHT ANGLE) J9852 1-568-267-11 JACK < RELAY > < RESISTOR > RY6002 £ 1-755-418-12 RELAY (AC POWER) RY6004 £...
  • Page 78 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V IC9901 6-600-271-01 IC RPM7140-H8 C2522 1-126-396-11 ELECT CHIP 47UF 20.00% 16V IC9902 6-600-418-01 IC TPS851(A.SONY) C2523 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C2524 1-126-396-11 ELECT CHIP 47UF 20.00% 16V < TRANSISTOR > C2526 1-107-826-11 CERAMIC CHIP 0.1UF...
  • Page 79 A2E4 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C7823 1-124-779-00 ELECT CHIP 10UF 20.00% 16V C7883 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C7825 1-162-906-11 CERAMIC CHIP 1.5PF 0.25PF 50V C7884 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C7826 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V C7885 1-128-536-11...
  • Page 80 A2E4 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C8427 1-107-905-11 ELECT 4.7UF C9576 1-126-964-11 ELECT 10UF 20.00% 50V C8429 1-126-396-11 ELECT CHIP 47UF 20.00% 16V C9578 1-162-925-11 CERAMIC CHIP 68PF 5.00% 50V C8430 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V C9579 1-162-925-11 CERAMIC CHIP 68PF...
  • Page 81 A2E4 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK CN9500 1-695-549-11 SOCKET, PIN 21P D9509 8-719-069-55 DIODE UDZSTE-175.6B CN9501 1-695-549-11 SOCKET, PIN 21P D9510 8-719-069-55 DIODE UDZSTE-175.6B CN9505 1-819-443-11 HEADER ASEEMBLY FOR PWB 15P D9511 8-719-069-60 DIODE UDZSTE-179.1B D9512 8-719-069-55 DIODE UDZSTE-175.6B <...
  • Page 82 A2E4 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK FB8710 1-469-775-21 FERRITE L7806 1-412-058-11 INDUCTOR 10UH FB8711 1-469-775-21 FERRITE L7807 1-412-058-11 INDUCTOR 10UH FB8712 1-469-775-21 FERRITE L7809 1-406-663-21 INDUCTOR 47UH FB8713 1-469-775-21 FERRITE L7810 1-456-515-11 INDUCTOR 33UH FB8714 1-469-775-21 FERRITE L7811 1-456-515-11 INDUCTOR...
  • Page 83 A2E4 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK Q6006 6-550-363-01 TRANSISTOR 2SB1690KT146 Q8616 6-550-549-01 TRANSISTOR DTC114EUAFT106 Q6007 8-729-045-62 TRANSISTOR 2SK2158-T2B Q9500 8-729-010-29 TRANSISTOR MSD601-RST1 Q6008 6-550-549-01 TRANSISTOR DTC114EUAFT106 Q9508 8-729-010-29 TRANSISTOR MSD601-RST1 Q6010 6-550-549-01 TRANSISTOR DTC114EUAFT106 Q9509 8-729-010-29 TRANSISTOR MSD601-RST1 Q7801 8-729-010-29 TRANSISTOR MSD601-RST1...
  • Page 84 A2E4 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R2549 1-211-985-11 METAL CHIP 0.5% 1/10W R2614 1-216-864-11 SHORT CHIP R2556 1-216-833-11 METAL CHIP 1/10W R2615 1-216-864-11 SHORT CHIP R2558 1-216-864-11 SHORT CHIP R2616 1-216-864-11 SHORT CHIP R2559 1-216-864-11 SHORT CHIP R2618 1-216-864-11 SHORT CHIP...
  • Page 85 A2E4 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R6056 1-216-864-11 SHORT CHIP R7876 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R7800 1-216-833-11 METAL CHIP 1/10W R7877 1-216-837-11 METAL CHIP 1/10W R7801 1-216-841-11 METAL CHIP 1/10W R7878 1-218-869-11 METAL CHIP 8.2K 0.5% 1/10W R7802 1-216-841-11 METAL CHIP...
  • Page 86 A2E4 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R7934 1-216-864-11 SHORT CHIP R8003 1-216-833-11 METAL CHIP 1/10W R7935 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R8004 1-216-833-11 METAL CHIP 1/10W R7936 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R8010 1-216-837-11 METAL CHIP 1/10W R7937 1-216-813-11...
  • Page 87 A2E4 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R8539 1-216-864-11 SHORT CHIP R8618 1-216-864-11 SHORT CHIP R8540 1-216-864-11 SHORT CHIP R8619 1-216-843-11 METAL CHIP 1/10W R8541 1-216-864-11 SHORT CHIP R8620 1-216-851-11 METAL CHIP 330K 5% 1/10W R8542 1-216-864-11 SHORT CHIP R8622 1-216-833-11 METAL CHIP...
  • Page 88 A2E4 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R9535 1-216-813-11 METAL CHIP 1/10W R9617 1-216-809-11 METAL CHIP 1/10W R9536 1-216-864-11 SHORT CHIP R9618 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R9537 1-216-813-11 METAL CHIP 1/10W R9619 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R9538 1-216-853-11...
  • Page 89 SHORT CHIP R9727 1-216-864-11 SHORT CHIP R9899 1-216-864-11 SHORT CHIP R8563 1-216-864-11 SHORT CHIP < TUNER > A2E4 Variant Parts KLV-S40A10E TU9500 8-597-993-00 TUNER, FSS BTF-EF412Z < CONNECTOR > < VARISTOR > CN8550 NOT FITTED CN8551 NOT FITTED VD7800 1-803-974-21...
  • Page 90 A2E4 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK < RESISTOR > D0008 8-719-083-58 DIODE UDZSTE-173.9B R6045 NOT FITTED < FUSE > R8002 1-216-845-11 METAL CHIP 100K 5% 1/10W R8560 NOT FITTED F0001 £ 1-576-415-21 FUSE R8561 NOT FITTED R8562 NOT FITTED <...
  • Page 91 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK *A-1142-596-B N Board, Complete KDL-S40A11E only C3201 1-117-720-11 CERAMIC CHIP 4.7UF *A-1122-473-D N Board, Complete KDL-S40A12U only C3202 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3203 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V N Board Common Parts C3204 1-164-846-11 CERAMIC CHIP 6PF...
  • Page 92 J3 N REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C3407 1-124-779-00 ELECT CHIP 10UF 20.00% 16V C3520 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3408 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3521 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V C3409 1-124-779-00 ELECT CHIP 10UF 20.00% 16V...
  • Page 93 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C3816 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V FB3408 1-400-461-21 FERRITE C3817 1-125-777-11 CERAMIC CHIP 0.1UF 10.00% 10V FB3409 1-400-461-21 FERRITE FB3410 1-400-461-21 FERRITE < CONNECTOR > FB3411 1-400-461-21 FERRITE FB3412 1-400-834-11 FERRITE CN3300 *1-815-641-11 CONNECTOR, CARD (PCMCIA CARD)
  • Page 94 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK IC3303 8-759-564-22 IC 74LVC00-PW Q3410 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R IC3304 8-759-644-48 IC 74LVC541APW Q3411 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R IC3305 8-759-644-48 IC 74LVC541APW Q3412 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R IC3306 8-759-644-48 IC 74LVC541APW Q3504 8-729-027-43 TRANSISTOR DTC114EKA-T146 IC3307 8-759-298-90 IC 74LVT245PW...
  • Page 95 B1 N REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R3147 1-218-937-11 RES-CHIP 1/16W R3407 1-208-675-11 METAL CHIP 0.5% 1/16W R3148 1-218-937-11 RES-CHIP 1/16W R3408 1-208-885-11 METAL CHIP 0.5% 1/16W R3149 1-218-937-11 RES-CHIP 1/16W R3415 1-208-675-11 METAL CHIP 0.5% 1/16W R3156 1-218-937-11 RES-CHIP...
  • Page 96 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R3474 1-208-885-11 METAL CHIP 0.5% 1/16W R3566 1-218-989-11 RES-CHIP 1/16W R3475 1-218-949-11 RES-CHIP 1/16W R3567 1-218-941-81 RES-CHIP 1/16W R3478 1-208-675-11 METAL CHIP 0.5% 1/16W R3601 1-218-953-11 RES-CHIP 1/16W R3479 1-208-885-11 METAL CHIP 0.5% 1/16W R3602 1-218-941-81...
  • Page 97 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R3830 1-218-941-81 RES-CHIP 1/16W RB3206 1-234-372-21 RES, NETWORK 100 (1005X4) RB3207 1-234-372-21 RES, NETWORK 100 (1005X4) R3831 1-218-941-81 RES-CHIP 1/16W RB3208 1-234-702-11 RES, NETWORK 68 (1005X4) R3832 1-218-990-81 SHORT CHIP RB3209 1-234-702-11 RES, NETWORK 68 (1005X4) R3835...
  • Page 98 B1 BE REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C1027 1-164-156-11 CERAMIC CHIP 0.1UF C5037 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V C1028 1-126-396-11 ELECT CHIP 47UF 20.00% 16V C5038 1-162-916-11 CERAMIC CHIP 12PF 5.00% 50V C1029 1-126-396-11 ELECT CHIP 47UF 20.00% 16V C5039...
  • Page 99 B1 BE REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C5087 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V C5703 1-100-911-11 CERAMIC CHIP 4.7UF C5088 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V C5704 1-100-911-11 CERAMIC CHIP 4.7UF C5089 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V C5705 1-162-970-11 CERAMIC CHIP 0.01UF...
  • Page 100 B1 BE REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C9001 1-127-715-91 CERAMIC CHIP 0.22UF < FILTER > C9002 1-127-573-11 CERAMIC CHIP 1UF C9003 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V FL5000 1-234-177-21 FERRITE C9004 1-127-715-91 CERAMIC CHIP 0.22UF FL5001 1-234-177-21 FERRITE FL5002 1-234-177-21...
  • Page 101 B1 BE REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK L5010 1-400-179-21 INDUCTOR R1021 1-218-973-11 RES-CHIP 1/16W L5011 1-400-180-21 INDUCTOR R1027 1-218-990-81 SHORT CHIP L5012 1-456-984-11 INDUCTOR R1028 1-216-809-11 METAL CHIP 1/10W L5013 1-456-984-11 INDUCTOR R1030 1-216-809-11 METAL CHIP 1/10W L5014 1-456-984-11 INDUCTOR...
  • Page 102 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R1126 1-218-941-81 RES-CHIP 1/16W R5410 1-216-833-11 METAL CHIP 1/10W R1200 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R5411 1-216-805-11 METAL CHIP 1/10W R1201 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R5412 1-216-805-11 METAL CHIP 1/10W R1202 1-218-990-81...
  • Page 103 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R5720 1-216-295-91 SHORT CHIP R7475 1-216-864-11 SHORT CHIP R5721 1-216-295-91 SHORT CHIP R7476 1-216-864-11 SHORT CHIP R5722 1-216-295-91 SHORT CHIP R7482 1-218-990-81 SHORT CHIP R5723 1-216-295-91 SHORT CHIP R7484 1-218-990-81 SHORT CHIP R5724 1-216-295-91 SHORT CHIP...
  • Page 104 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R7542 1-218-990-81 SHORT CHIP RB1010 1-234-372-21 RES, NETWORK 100 (1005X4) R7549 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W RB1011 1-234-372-21 RES, NETWORK 100 (1005X4) R7550 1-218-990-81 SHORT CHIP RB1012 1-234-371-21 RES, NETWORK 47 (1005X4) R7552 1-216-841-11...
  • Page 105 *1-910-020-06 CONNECTOR ASSY 15P *1-910-020-07 HARNESS ASSY 15P *1-910-020-08 HARNESS ASSY 11P *1-910-021-59 FFC CABLE 49 PINS *1-910-023-30 CONNECTOR ASSY 10P *1-910-023-31 HARNESS ASSY H2 REMOTE COMMANDER 1-479-392-12 REMOTE COMMANDER (RM-ED002) (KDL-S40A12U/A11E) 1-479-393-11 REMOTE COMMANDER (RM-EA002) (KLV-S40A10E) - 105 -...
  • Page 106 English Sony Corporation 05JP7100-1 Sony UK Printed in U.K. Service Promotions Dept. © 2005.10 9-927-523-01...
