SERVICE MANUAL Colour Television
Specifications
Power Source . . . . . . . . . AC220-240V, 50Hz/60Hz.
Colour System . . . . . . . . PAL (AV input: PAL/NTSC4.43/NTSC/PAL-60Hz)
Television System . . . . . . B/G
Channel Coverage . . . . .Australia
New Zealand
Video IF . . . . . . . . . . . . . . 38.0MHz
Aerial Input Impedance . . 75Ω
Ext. Terminals
Video inputs: Phono jack
Audio inputs: Phono jack
Video monitor outputs: Phono jack
Audio monitor outputs: Phono jack
Sound Output (RMS) . . . . 2 W
Speaker . . . . . . . . . . . . . . ø8 cm
Dimensions . . . . . . . . . . . . 501 (W)
Weight . . . . . . . . . . . . . . . approx. 20.5 Kg
Specifications subject to change without notice.
C5TWG/C5TVG
TV/AV
MENU
-
+
CH
VHF: 0-11, 5A
UHF: 28-69
CATV: S1-S41, X, Y, Z, Z+1, Z+2
VHF: 1-11
UHF: 21-69
CATV: S1-S41, X, Y, Z, Z+1, Z+2
2 (1Vp - p, 75Ω)
2 (436mVrms, more than 40KΩ)
1(1Vp - p, 75Ω)
1(436mVrms, less than 600Ω)
1 pc.
476 (H)
492 (D)mm
FILE NO.
Model No. CP21SA1
(Australia/New Zealand)
Service Ref. No. CP21SA1-55
TV/AV
TIMER
1
2
3
4
5
6
7
8
9
0
-/--
BASS
A B
SURROUND
P
P
P
CH SCAN
P
SWAP
MENU
PIC MODE
JXMYA
Product Code: 111362037
Original Version
Chassis Series: AC5-G
(Software: AC5-G2)
- NOTE -
Service Ref. No. CP21SA1-65 is electrically the
same as Service Ref. No. CP21SA1-55.
The difference between Service Ref. No.
CP21SA1-55 and CP21SA1-65 are as follows:
1) Destination CP21SA1-55...Australia
CP21SA1-65...New Zealand
Give complete "SERVICE REF. NO." for
parts order or servicing. It is shown on the
rating plate at the cabinet back of the unit.
This T.V. receiver will not work properly in
foreign countries where the television
transmission system and power source dif-
fer from the design specifications. Refer to
the specification table.
REFERENCE NO.
(A)
(Australia)
CP21SA1-65
(New Zealand)
SM
5110599
