Building Air-Conditioners Control System
AIR CONDITIONER INTERFACE
Model : LMAP02-E
Before using the unit, please read this Installation
Manual carefully to ensure correct operation. Store this
Installation Manual in a location that is easy to find.
Echelon
®
,LON
®
,L
W
ON
Echelon logo are trademarks of Echelon Corporation
registered in the United States and other countries.
LonMaker™ and the Lon Users logo are trademarks of
Echelon Corporation.
®
,Neuron
®
,3150
®
ORKS
Contents
Safety precautions ..........................................1,2
1 .Parts Inclue ...................................................3
2 .Specifications ................................................3
2 -1 External View ..........................................3
2 -2 Enviroment Specifications ........................3
2 -5 Variables of LM-AP network .....................5
3.Installation ...................................................6
3 -1 Locally Procured Parts ..............................6
3 -2 Securing the Unit ....................................7
3 -3 Connection Methods .................................8
3 -4 Electrical Wiring .......................................9
4 .Sysyem Settings ..........................................10
4 -1 If not used together with MELANS ............10
4 -2 If used together with MELANS ..................11
4 -3 Initialization Settings of L
5 .Confirming Operation ....................................13
5 -1 Pre-operation preparations and settings ......13
5 -2 Test-operation procedure ........................13
6 .Troubleshooting ..........................................14
6 -1 Abstract ................................................14
6 -2 Troubleshooting ....................................15
6 -3 Error Code list .......................................15
and the
Installation Manual
Network Specifications ............4
®
......4
®
Network ...12
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Mitsubishi Electric LMAP02-E
Summary of Contents for Mitsubishi Electric LMAP02-E
-
Page 1: Table Of Contents
Building Air-Conditioners Control System AIR CONDITIONER INTERFACE Model : LMAP02-E Installation Manual Contents Safety precautions ……………………………………1,2 1 .Parts Inclue ……………………………………………3 2 .Specifications …………………………………………3 2 -1 External View ……………………………………3 2 -2 Enviroment Specifications ……………………3 2 -3 Connected Air Conditioning Equipment ……4 2 -4 L Network Specifications …………4... -
