3.CAUTION: Do not open the top cover. There are no user-serviceable parts inside. Leave all servicing to qualified service personnel. 4.CAUTION: This CD player uses invisible laser radiation and is equipped with safety switches to prevent radiation emission when unloading CDs. It is dangerous to defeat the safety switches.
Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. CONTENTS How to reset your unit ... LOCATION OF THE BUTTONS ...
MO (monaural), ST (stereo) indicator h RND (random) indicator j RPT (repeat) indicator k SCM (sound control memory) indicator l LOUD (loudness) indicator / AM indicator z Main display x CD–in indicator c Sound mode indicators BEAT, SOFT, POP KD-S785 TUNER SCAN...
Remote controller RM-RK50 SOUND SOURCE 1 • Turns on the unit if pressed when the unit is turned off. • Turns off the unit if pressed and held until “SEE YOU” appears on the display. • Drops the volume level in a moment if pressed briefly.
Preparing the remote controller Before using the remote controller: • Aim the remote controller directly at the remote sensor on the main unit. Make sure there is no obstacle in between. 45Wx4 LOUD DISP Remote sensor • Do not expose the remote sensor to strong light (direct sunlight or artificial lighting).
To increase the volume. To decrease the volume. Volume or audio level indicator (See page 25.) Volume level appears. BASIC OPERATIONS 45Wx4 KD-S785 LOUD DISP SCAN Adjust the sound as you want. (See pages 21 – 23.) To drop the volume in a moment Press source.
Select the band (FM1 – 3, AM) if neccessary. Note: This receiver has three FM bands (FM1, FM2, FM3). You can use any one of them to listen to an FM broadcast. KD-S785 45Wx4 LOUD DISP SCAN Start searching a station.
Searching a station manually: Manual search Select the tuner as the source. Tuner TUNER (FM1 – 3, AM) • The last selected station is tuned in. Select the band (FM1 – 3, AM) if neccessary. Note: This receiver has three FM bands (FM1, FM2, FM3).
Storing stations in memory You can use one of the following two methods to store broadcasting stations in memory. • Automatic preset of FM stations: SSM (Strong- station Sequential Memory) • Manual preset of both FM and AM stations FM station automatic preset: SSM You can preset 6 local FM stations in each FM band (FM1, FM2 and FM3).
Press and hold the number button (in this example, 1) for more than 2 seconds. “P1” flashes for a few seconds. Repeat the above procedure to store other stations into other preset numbers. Notes: • A previously preset station is erased when a new station is stored in the same preset number.
(CD play will not start this time.) • You can eject the CD even when the unit is turned off. KD-S785 TUNER SCAN Total playing time of Total track number...
Locating a track or a particular portion on a CD To fast-forward or reverse the track Press and hold ¢ playing a CD, to fast-forward the track. Press and hold 4 playing a CD, to reverse the track. To go to the next tracks or the previous tracks Press ¢...
Playing a CD Text In a CD Text, some information about the disc (its disc title, performer and track title) is recorded. You can show these disc information on the display. Select text display mode while playing a CD Text. DISP Each time you press the button, the display changes as follows:...
What is MP3? MP3 is an abbreviation of Motion Picture Experts Group (or MPEG) Audio Layer 3*. MP3 is simply a file format with a data compression ratio of 1:10 (128 Kbps**). That means, by using MP3 format, one CD-R or CD-RW can contain 10 times as much data volume as a regular CD can.
Page 16
MP3 directory/file configuration : Root ROOT : Directories : MP3 files MP3 playback/search order (page 18) • The numbers in circles below the MP3 files ( MP3 files. Normally this unit plays back MP3 files in the recorded order. • The numbers inside the directories indicate the playback order and search order of the directories on an MP3 disc.
SCM indicator flashes. The CD–in indicator lights up. The CD–in indicator lights up. Ex.: When the disc contains 10 directories and 127 MP3 files. MP3 OPERATIONS KD-S785 45Wx4 LOUD DISP SCAN Playback starts automatically from the first file of the first directory once disc check is completed.
To stop play and eject the disc Press 0. Playback stops and the disc automatically ejects from the loading slot. If you change the source to FM or AM, the playback also stops (without ejecting the disc this time). Locating a file or particular portion on an MP3 disc To fast-forward or reverse the file Press and hold ¢...
To skip to the next directory Press 5 (up) briefly while playing an MP3 disc. Each time you press the button consecutively, the next directory is located (and the first file in the directory starts playing, if recorded). Ex.1: While playing an MP3 file in Directory 01 (see the illustration on page 16) Ex.2: While playing an MP3 file in Directory 04 (see the illustration on page 16)
Page 20
To play back files repeatedly (Repeat Play) You can play back the current file or all the files in the current directory repeatedly. Each time you press SCAN RPT SCAN (scan/repeat) while playing an MP3 disc, the repeat play mode changes as follows: RPT1 Canceled...
Adjusting the sound You can adjust the sound characteristics to your preference. Select the item you want to adjust. Each time you press the button, the adjustable items change as follows: (bass) (treble) (volume) Indication To do: Adjust the bass. Adjust the treble.
Using the sound control memory (SCM) You can select and store a preset sound adjustment suitable for each playback source (Advanced SCM). Selecting and storing the sound modes Once you select a sound mode, it is stored in memory. It will be recalled every time you select the same source and will be shown on the display.
Storing your own sound adjustments You can adjust the sound modes (BEAT, SOFT, POP) to your preference and store your own adjustments in memory. • There is a time limit in doing the following procedure. If the setting is canceled before you finish, start from step 1 again.
OTHER MAIN FUNCTIONS Setting the clock Press and hold SEL (select) for more than 2 seconds. “CLOCK H,” “CLOCK M,” “SCM LINK,” “LEVEL”,“SCROLL” or “TAG DISP” appears on the display. Set the hour. 1 Select “CLOCK H (hour)” if not shown on the display.
Canceling Advanced SCM —SCM LINK You can cancel the Advanced SCM (Sound Control Memory), and unlink the sound modes and the playback sources. When shipped from the factory, a different sound mode can be stored in memory for each source so that you can change the sound modes simply by changing the sources.
Select the desired mode—“AUDIO 1,” “AUDIO 2” or “OFF.” AUDIO 1 Finish the setting. Selecting the scroll mode —SCROLL You can select the scroll mode for the disc information if it consists of more than 8 characters. When shipped from the factory, Scroll mode is set to “ONCE.”...
Detaching the control panel You can detach the control panel when leaving the car. When detaching or attaching the control panel, be careful not to damage the connectors on the back of the control panel and on the panel holder. Detaching the control panel Before detaching the control panel, be sure to turn off the power.
MAINTENANCE Handling CDs This unit has been designed to reproduce CDs and CD-Rs. • You can also play back your original CD-Rs (Recordable) and CD-RWs (Rewritable) either in audio CD format or in MP3 format. How to handle discs When removing a disc from its case, press down the center holder of the case and lift the disc out,...
What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms • Disc cannot be played back. • Sound is sometimes interrupted. • CD-R/CD-RW cannot be played back. • Tracks on the CD-R/CD- RW cannot be skipped.
Page 30
Symptoms • Disc cannot be played back. • Files skip, or 00’00” appears and the playback stops. • Noise is generated. • A longer readout time is required (“CHECK” keeps flashing on the display). • Files cannot be played back as you have intended them to play.
Selectivity: 35 dB Having TROUBLE with operation? Please reset your unit Refer to page of How to reset your unit CD PLAYER SECTION Type: Compact disc player Signal Detection System: Non-contact optical pickup (semiconductor laser) Number of channels: 2 channels (stereo)
