Cordless, Electric Hedge Trimmer
51595, 51596, and 51597 – 9900001 and Up
Operator's Manual
Para obtener una versión gratis de este manual en español, escriba a la dirección indicada
más abajo. Asegúrese de indicar el modelo y el número de serie de su producto.
The Toro Company, Attn: Parts Dept., 8111 Lyndale Ave S, Bloomington, MN 55420–1196.
FORM NO. 3321–822 Rev B
English (EN)
Advertisement
Table of Contents
Related Manuals for Toro 51595
Summary of Contents for Toro 51595
- Page 1 Para obtener una versión gratis de este manual en español, escriba a la dirección indicada más abajo. Asegúrese de indicar el modelo y el número de serie de su producto. The Toro Company, Attn: Parts Dept., 8111 Lyndale Ave S, Bloomington, MN 55420–1196. English (EN)
-
Page 2: Table Of Contents
Thank you for purchasing a Toro product. hazard, be extremely careful. All of us at Toro want you to be completely satisfied with DANGER signals an extreme hazard that will cause your new product, so feel free to contact your local... -
Page 3: Safety
Safety WARNING WARNING: Always follow these basic safety precautions POTENTIAL HAZARD when using electric hedge trimmers to reduce the risk of Use of trimmer can cause electric shock. fire, electric shock, and personal injury. WHAT CAN HAPPEN Read All Instructions Electric shock can cause serious personal injury or death. -
Page 4: Save These Instructions
1-800-237-2654 in the United States. See Do not attempt to remove cut material nor hold that only original Toro replacement parts are used. material to be cut when blades are moving. Ensure that the trigger is off and the lock–off button is not pressed Save These Instructions when clearing jammed material from blades. -
Page 5: Safety And Instruction Decals
Safety and Instruction Decals Safety decals and instructions are easily visible to the operator and are located near any area of potential danger. Replace any decal that is damaged or lost. ON BLADE ON CHARGER Installation Mounting the Charger (Model 51596 Only) The charger should be mounted indoors (such as a garage or other dry place), near a power outlet, and out of reach... -
Page 6: Operation
1. Place the charger against the wall and mark the two hole locations, through the top of the keyholes in the charger. 2. Drill pilot holes as follows: If installing the charger on wall board, plaster, or cement, drill two holes for the wall anchors (as m–4091 indicated by the wall anchor manufacturer) at the Figure 5... -
Page 7: Charging The Battery
If the light still does not come on, contact you local Authorized Toro Dealer. Blade Use the blade to cut hedges. Do not handle the blade without first ensuring that the lock–off button and trigger are off. - Page 8 If the light still light is lit, ensure that the power cord is completely does not come on, contact you local Authorized Toro inserted into the power outlet and that the power outlet is Dealer.
-
Page 9: Preparing For Operation
Preparing For Operation WARNING For your protection always wear work gloves, long pants, a long sleeved shirt, shoes (not sandals), and safety glasses POTENTIAL HAZARD when operating the trimmer (Fig. 10). Also, always Trimmer has sharp blades. operate the trimmer using both hands. WHAT CAN HAPPEN Contact with moving trimmer blades can cause serious personal injury or damage. -
Page 10: Trimming Techniques
Do not try to trim hedges which are above your normal reach. You must hold the trimmer with both hands at all times while operating. Trim the side of a hedge so that it will be slightly narrower at the top as shown in Figure 13. More of the hedge will be exposed when shaped this way and its growth will be more uniform. -
Page 11: Maintenance
For easier operation and longer blade life, lubricate the hedge trimmer blade before and after each use. POTENTIAL HAZARD Use of non-Toro replacement parts could cause 1. Ensure that the trimmer is off and the lock–off switch product damage. is not pressed. - Page 12 m–4169 Figure 15 m–4101 1. Battery cover 2. Screw Figure 17 2. Pull the battery out of the trimmer (Fig. 16). 1. Blade cover 2. Blade cover screws 3. Disconnect the the wire leads from the battery (Fig. 16). 5. Align the cams that are fitted in the blade loops by moving the blades slightly (Fig.
-
Page 13: Replacing The Battery
Please call 1–800–8–BATTERY for information on Ni–Cd battery recycling and disposal bans/restrictions in your area. Toro’s involvement in this program is part of our commitment to preserving our environment and conserving our natural resources. -
Page 15: Screw Location Template For Model 51596
Screw Location Template for Model 51596... -
Page 16: Warranty
The Toro Company warrants this TORO Product for two years against defects in material or workmanship. To receive a replacement or repair, at Toro’s option, just return the complete unit, postage prepaid, to the seller. (U.S. customers ONLY may return their unit, with proof of purchase, to any TORO Master Service Dealer or the TORO Service Center, 5300 Shoreline Blvd., Mound, MN 55364.) This warranty covers...
