Bosch Art 23 LI Original Instructions Manual
Bosch cordless trimmer original instructions
Hide thumbs
Also See for Art 23 LI:
- Original instructions manual (18 pages) ,
- Original instructions manual (16 pages) ,
- Original instructions manual (278 pages)
Table of Contents
Advertisement
OBJ_DOKU-8678-003.fm Page 1 Wednesday, October 27, 2010 3:55 PM
Robert Bosch GmbH
Power Tools Division
70745 Leinfelden-Echterdingen
Germany
www.bosch-garden.com
F 016 L70 778 (2010.10) O / 298 UNI
ART
23 LI | 26 LI
de Originalbetriebsanleitung
el Πρωτότυπο οδηγιών χρήσης
en Original instructions
tr Orijinal işletme talimat
fr Notice originale
pl Instrukcja oryginalna
es Manual original
cs Původní návod k používání
pt Manual original
sk Pôvodný návod na použitie
it
Istruzioni originali
hu Eredeti használati utasítás
nl Oorspronkelijke
ru Оригинальное руководст-
gebruiksaanwijzing
во по эксплуатации
da Original brugsanvisning
uk Оригінальна інструкція з
sv Bruksanvisning i original
експлуатації
no Original driftsinstruks
ro Instrucţiuni originale
fi
Alkuperäiset ohjeet
bg Оригинална инструкция
sr Originalno uputstvo za rad
sl Izvirna navodila
hr Originalne upute za rad
et Algupärane kasutusjuhend
lv Instrukcijas oriģinālvalodā
lt
Originali instrukcija
Advertisement
Table of Contents
Related Manuals for Bosch Art 23 LI
Summary of Contents for Bosch Art 23 LI
- Page 1 OBJ_DOKU-8678-003.fm Page 1 Wednesday, October 27, 2010 3:55 PM Robert Bosch GmbH Power Tools Division 70745 Leinfelden-Echterdingen Germany www.bosch-garden.com 23 LI | 26 LI F 016 L70 778 (2010.10) O / 298 UNI de Originalbetriebsanleitung el Πρωτότυπο οδηγιών χρήσης sr Originalno uputstvo za rad en Original instructions tr Orijinal işletme talimat...
- Page 2 OBJ_BUCH-520-003.book Page 3 Wednesday, October 27, 2010 11:52 AM d.c. XXX XX XX TYP XXXX XXX XXX XX.XV XXW XXXX min- 3A1 IPX X XXXX X.XX Kg Robert Bosch GmbH D-70745 Leinfelden-Echterdingen Made in China a.c. 11 12 Bosch Power Tools F 016 L70 778 | (27.10.10)
- Page 3 OBJ_BUCH-520-003.book Page 4 Wednesday, October 27, 2010 11:52 AM 17 18 F 016 L70 778 | (27.10.10) Bosch Power Tools...
- Page 4 OBJ_BUCH-520-003.book Page 5 Wednesday, October 27, 2010 11:52 AM Bosch Power Tools F 016 L70 778 | (27.10.10)
- Page 5 OBJ_BUCH-520-003.book Page 6 Wednesday, October 27, 2010 11:52 AM F 016 L70 778 | (27.10.10) Bosch Power Tools...
-
Page 6: Safety Notes
Never operate the cordless trimmer with damaged guards or shields or without guards or shields in position. Before using the machine and after impact, check for signs of wear or damage, and re- pair if necessary. F 016 L70 778 | (27.10.10) Bosch Power Tools... - Page 7 Ensure replacement parts fitted are Bosch risk of an electric shock. approved. Only charge Bosch lithium ion batteries or Use only Bosch battery packs intended spe- batteries installed in Bosch products with cifically for the machine. Use of any other the voltages listed in the technical data.
-
Page 8: Functional Description
– Adjustable handle (fitted) – Cutting disc – Blade – Operating instructions Battery and charger are included in certain exe- cutions. When parts are missing or damaged, please con- tact your dealer. F 016 L70 778 | (27.10.10) Bosch Power Tools... -
Page 9: Technical Data
OBJ_BUCH-520-003.book Page 21 Wednesday, October 27, 2010 11:52 AM English | 21 Technical Data Cordless Trimmer ART 23 LI ART 26 LI Article number 3 600 H78 K.. 3 600 H78 L.. No-load speed 7500 7400 Adjustable handle Trimmer-head angle adjustment/edging... -
Page 10: Noise/Vibration Information
2000/14/EC (1.60 m height, 1 m distance away). Typically the A-weighted noise levels of the product are: Sound pressure level 80 dB(A); Robert Bosch GmbH, Power Tools Division sound power level 88 dB(A). Uncertainty D-70745 Leinfelden-Echterdingen K =5 dB. -
Page 11: Product Assembly
Place the blade guard 11 on the trimmer head 9. Hook the blade guard onto the trimmer head and push it toward the rear. Press the blade guard downward until se- curely latched (click). Bosch Power Tools F 016 L70 778 | (27.10.10) -
Page 12: Operation
Tighten the handle screw 4 securely to fix blade rapidly. the adjustable handle 5 in the adjusted posi- For better control, use the plant protector 19 tion. (accessory) as a guide. (see figure K) F 016 L70 778 | (27.10.10) Bosch Power Tools... -
Page 13: Troubleshooting
18, push it down and pull it outward until it engages. Light conditions: up to 800 metres (ART 23 LI) Note: Only use Bosch replacement blades. They up to 1000 metres (ART 26 LI) have been developed specially for improved cut- ting and feed performance. -
Page 14: Maintenance And Service
Maintenance and Cleaning customer service agent for Bosch garden prod- ucts. Warning: Before any work on the machine itself, remove the battery from the ma- In all correspondence and spare parts orders, chine. -
Page 15: After Use/Storage
8. Australia, New Zealand and Pacific Islands Turn the machine on its side and clean the cut- Robert Bosch Australia Pty. Ltd. ting guard 11 inside. If grass cuttings are com- Power Tools pacted, remove with a wooden or plastic imple- Locked Bag 66 ment. - Page 16 Batteries no longer suitable for use can be directly returned at: Great Britain Robert Bosch Ltd. (B.S.C.) P.O. Box 98 Broadwater Park North Orbital Road Denham Uxbridge UB 9 5HJ Tel.
