RX-V596/HTR-5250
CONTENTS
To Service Personnel ........................................... 1
Remote Control Panels ....................................... 1
FRONT PANELS ............................................................. 2
REAR PANELS ........................................................... 3~4
Specifications ....................................................... 5~6
Internal View ............................................................ 7
Disassembly ProcedureS .................................... 7
Self Diagnosis Function ................................ 8~19
Factory Preset ...................................................... 20
1 0 0 7 1 6
RX-V596RDS
SERVICE MANUAL
This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA
Products, are already known and understood by the users, and have therefore not been restated.
WARNING:
Failure to follow appropriate service and safety procedures when servicing this product
may result in personal injury, destruction of expensive components, and failure of the
product to perform as specified. For these reasons, we advise all YAMAHA product
owners that any service required should be performed by an authorized YAMAHA
Retailer or the appointed service representative.
IMPORTANT:
The presentation or sale of this manual to any individual of firm does not constitute
authorization, certification or recognition of any applicable technical capabilities,
or establish a principle-agent relationship of any form.
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research,
engineering, and service departments of YAMAHA are continually striving to improve YAMAHA products.
Modifications are, therefore, inevitable and specifications are subject to change without notice or obligation
to retrofit. Should any discrepancy appear to exist, please contact the distributor's Service Division.
WARNING:
Static discharges can destroy expensive components. Discharge any static electricity
your body may have accumulated by grounding yourself to the ground buss in the unit
(heavy gauge black wires connect to this buss).
IMPORTANT:
Turn the unit OFF during disassembly and part replacement. Recheck all work before
you apply power to the unit.
Amp Adjustment ..................................................... 21
Tuner Adjustment ........................................... 22~25
Ic Data .................................................................. 26~34
Display Data ........................................................... 35
Block Diagram .................................................. 36~39
PRINTED CIRCUIT BOARD ................................... 40~59
Schematic Diagram ......................................... 60~67
Parts List ............................................................ 68~86
REMOTE CONTROL TRANSMITTER ................... 87~88
AV RECEIVER
IMPORTANT NOTICE

Advertisement

Table of Contents
loading

Summary of Contents for Yamaha RX-V596

  • Page 1 SERVICE MANUAL IMPORTANT NOTICE This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel. It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already known and understood by the users, and have therefore not been restated.
  • Page 2: To Service Personnel

    RX-V596/HTR-5250/RX-V596RDS TO SERVICE PERSONNEL 1. Critical Components information Components having special characteristics are marked and must be replaced with parts having specifications equal to those originally AC LEAKAGE installed. WALL EQUIPMENT TESTER OR 2. Leakage Current Measurement (For 120V Model only)
  • Page 3: Rx-V596/Htr

    RX-V596/HTR-5250/RX-V596RDS SPECIFICATIONS AUDIO SECTION RIAA Equalization Deviation PHONO (MM) 0±0.5dB Minimum RMS Output Power Per Channel Total Harmonic Distortion(20Hz to 20kHz) (Power Amp. Section) PHONO (MM) to REC OUT (1V) 0.02% U, C models CD etc.(EFFECT OFF) to MAIN SP OUT(35W/8Ω) MAIN L/R, REAR L/R 0.06%...
  • Page 4 RX-V596/HTR-5250/RX-V596RDS DIMENSIONS AM SECTION Tuning Range U, C models 530 to 1710kHz R, T models (Frequency Step : 10kHz) 530 to 1710kHz (Frequency Step : 9kHz) 531 to 1611kHz A, B, G, L models 531 to 1611kHz Usable Sensitivity 300µV/m...
  • Page 5: Front Panels

    RX-V596/HTR-5250/RX-V596RDS INTERNAL VIEW POWER TRANSFORMER P.C.B. POWER (2) P.C.B. POWER (7) (U,C,A,B,G,L models only) P.C.B. MAIN (3) P.C.B. POWER (6) (R,T models only) P.C.B. MAIN (4) P.C.B. POWER (4) (R,T models only) P.C.B. MAIN (2) P.C.B. MAIN (1) P.C.B. POWER (3) P.C.B.
  • Page 6: Self Diagnosis Function

    SELF DIAGNOSIS FUNCTION 1. PURPOSE AND OPERATION The RX-V596/HTR-5250/RX-V596RDS has a Self Diagnosis Function to locate a faulty part, if any, by inspecting and taking measurements. There are 12 main items in the diagnostic menu and sub-menu items as listed below.
  • Page 7 RX-V596/HTR-5250/RX-V596RDS 2. BEGINNING AND CANCELLATION (1) Starting up the function and the display After starting up, main-menu No.1 is selected. A. How to start diagnostic program Using the front panel keys of the main unit. Plug in the AC power cord. With the Power OFF, hold down the "PRESET/TUNING "...
  • Page 8 RX-V596/HTR-5250/RX-V596RDS FL display at start-up of diagnostic program When the diagnostic program has started, the check sum of the main microcomputer or the protection history (*1) is displayed. If the protection function has been activated in the past, the type and voltage value are displayed. After a few seconds the diagnosis function menu will appear.
  • Page 9 RX-V596/HTR-5250/RX-V596RDS 3. OPERATION AND DISPLAY WHEN STARTING DIAGNOSIS FUNCTION (1) Selection of diagnostic menu The diagnostic menu and the sub-menu can be selected by using the front panel keys of the main unit or the remote control unit. Selection by using the front panel keys of the main unit The main menu can be changed cyclically by using the "PROGRAM...
  • Page 10 RX-V596/HTR-5250/RX-V596RDS 4. CONTENTS OF DIAGNOSIS FUNCTION This section describes the contents of the Self Diagnosis Function in detail. No.1 ANALOG THROUGH The input is fixed to analog (A/D). There are two sub-menus. 1 MA I N B Y P A S S 1.
  • Page 11 RX-V596/HTR-5250/RX-V596RDS No.2 DSP THROUGH The input is automatically discriminated by signal detection and switched with priorities Coaxial>Optical>Analog. There are the following three sub-menus. 2 Y S S + S R AM M 1. YSS+SRAM The L/R signals are output without being processed to the MAIN L/R through the AC3D2av.
  • Page 12 RX-V596/HTR-5250/RX-V596RDS No.3 AC-3/DTS THROUGH The input is digital signal only. AC-3 (DOLBY DIGITAL) or DTS Digital Surround decoding operation is executed, according to the input source. bit 7 bit 1 3 S T : 1 0 0 0 1 0 0 1 1.
  • Page 13 RX-V596/HTR-5250/RX-V596RDS No.5 SPEAKERS SET The input is automatically discriminated by signal detection and switched with priorities Coaxial>Optical>Analog. The L/R signals are output to channels specified by the sub-menu without being processed. There are the following nine sub-menus items. Signal routes of the sub-menu 1-4 are the same as EFFECT OFF.
  • Page 14 RX-V596/HTR-5250/RX-V596RDS No.6 DISPLAY CHECK Check program for FL display. The display status will change as follows with sub-menu operation. signal route is the same as "2. EFFECT OFF" of "No. 4 PRO LOGIC". 6 V F D C H C K...
  • Page 15 RX-V596/HTR-5250/RX-V596RDS No.9 AD DATA CHECK The A/D conversion values of the microcomputer which detects key scan port, protection detection port, etc. are displayed in % (100%:5V). Signal route is the same as "2. EFFECT OFF" of "No. 4 PRO LOGIC".
  • Page 16: Specifications

    RX-V596/HTR-5250/RX-V596RDS No.10 STATUS INFORMATION FROM DSP The status data from the DSP block is sequentially displayed in a hexadecimal number. Signal route is the same as "2. EFFECT OFF" of "No. 4 PRO LOGIC". High 1 0 C P U / 1 0 0 0 0...
  • Page 17 R X - V A B G L The model type and the destination are displayed. RX-V: Model type. DSP-A= DSP-A5 Model type Destination RX-V = RX-V596, HTR-5250 RDS = RX-V596RDS ABGL: Destination. = J model = U and C models ABGL = A,B,G and L models...
  • Page 18: Factory Preset

    RX-V596/HTR-5250/RX-V596RDS FACTORY PRESET All of the system settings are initially set from the factory as follows. INPUT SELECTOR EFFECT LEVEL INPUT FACTORY PRESET PROGRAM EFFECT CHANNEL PRESET VALUE PHONO CONCERT HALL CENTER 0 dB DISCO RIGHT SURROUND 0 dB TUNER...
  • Page 19: Amp Adjustment

    RX-V596/HTR-5250/RX-V596RDS AMP ADJUSTMENT Confirmation of Idling Current of Main Amplifier • Right after power is turned on, confirm that the voltage across the terminals of R688(Main Lch),R690(Main Rch), R692(Center), R694(Rear Lch), R696(Rear Rch) are between 0.1mV and 10.0mV. • If it exceeds 10.0mV, open (cut off) R571 (Main Lch), R577 (Main Rch), R583 (Center), R589 (Rear Lch), R595 (Rear Rch) and reconfirm the voltage.
  • Page 20: Tuner Adjustment

    RX-V596/HTR-5250/RX-V596RDS TUNER ADJUSTMENT Measuring Instruments Dummy antenna 1) FM signal generator (FM SG) FM dummy antenna 2) Stereo signal generator (SSG) 3) AM signal generator (AM SG) 10Ω 45Ω 4) Distortion meter (DIST. M) FM SG RECEIVER 5) AC Voltmeter (ACVM) (75Ω)
  • Page 21 RX-V596/HTR-5250/RX-V596RDS FM Adjustment 4) Set each switch to the following position unless otherwise Before Adjustment 1) For dBµ, 1µV=0dBµ applies. specified. Example : 60dBµ=1mV INPUT SELECTOR ..TUNER 2) 100% modulation means that the frequency deviation is TUNING MODE ..... AUTO ±75kHz.
  • Page 22 RX-V596/HTR-5250/RX-V596RDS See page 22 for TP locations & adjustment points. Reception Adjustment Step Adjustment item Signal (ANT IN) Test point Rating frequency point Adjustment of FM ANT (75Ω) 98.1MHz Front end IFT Pin 16 of IC1 Adjust so that the meter is front end IFT 98.1MHz...
  • Page 23 RX-V596/HTR-5250/RX-V596RDS AM Adjustment (This should be done after FM adjustment.) Connection diagram (Measuring instruments) 1) Adjustment of sensitivity. AM loop antenna AM ANT ACVM TUNER AM SG dummy P.C.B antenna DIST. M Oscilloscope See page 22 for TP locations & adjustment points.
  • Page 24: Top View

    RX-V596/HTR-5250/RX-V596RDS IC DATA IC501 : M30217MA-A203FP 16-bit Microcomputer P67/FL07 P24/FL36 P66/FL06 P25/FL37 P65/FL05 P26/FL38 P64/FL04 P27/FL39 P63/FL03 P30/FL40 P62/FL02 P31/FL41 P61/FL01 P32/FL42 P60/FL00 P33/FL43 P34/FL44 P107/AN7 P35/FL45 TOP VIEW P106/AN6 P36/FL46 P105/AN5 P37/FL47 P104/AN4 P40/FL48 P103/AN3 P41/FL49 P102/AN2 P42/FL50 P101/AN1...
  • Page 25 RX-V596/HTR-5250/RX-V596RDS IC501 : M30217MA-A203FP 16-bit Microcomputer Port Function Port Function Name Name O Serial Clock output For Input 31 P47/FL55 F-CE O Chip enable output selector Tuner, flash µ-COM O Serial Data output 32 P46/FL54 F-CK O Serial clock output etc.
  • Page 26 RX-V596/HTR-5250/RX-V596RDS IC501 : M30217MA-A203FP 16-bit Microcomputer Port Function Port Function Name Name 67 P05/FL21 O Segment 1 for FL display 85 P63/FL03 O Segment 19 for FL display 68 P04/FL20 O Segment 2 for FL display 86 P62/FL02 O Segment 20 for FL display...
  • Page 27 RX-V596/HTR-5250/RX-V596RDS IC3 : YSD917 (DIR5) Digital Format Interface Receiver AVDD STANDARD SDMCK CLOCK AVSS CLOCK OUTPUT GENERATION SDWCK SYSTEM CLOCK SDBCK GENERATION SELECTION DDIN DDIN SYNC TEST FS128 OUTPUT /LOCK SELECTION TOP VIEW DATA BUS SERIAL FRAME CONVERSION BUFFER EACH CONTROL...
  • Page 28 RX-V596/HTR-5250/RX-V596RDS IC4 : YSS918D-F (AC3D2av) DSP + AC-3(Dolby Digital)/ Pro Logic/ DTS Digital Surround Decoder PVSS SDWCK0 SDWCK1 SDBCK0 SDBCK1 SDIA0 SDOB0 SDIA1 SDOB1 RAMA1 SDOB2 RAMA0 RAMA7 RAMWEN RAMA8 RAMOEN RAMA9 TOP VIEW VDD2 IPORT7 OPORT7 IPORT6 OPORT6 IPORT5...
  • Page 29 RX-V596/HTR-5250/RX-V596RDS IC4 : YSS918D-F (AC3D2av) DSP + AC-3(Dolby Digital)/ Pro Logic/ DTS Digital Surround Decoder Name Function VDD1 +5V power supply RAMCEN RAM chip enable output terminal (normally unconnected) RAMA16 RAM address output terminal 16, connected to external 1M SRAM address...
  • Page 30 RX-V596/HTR-5250/RX-V596RDS IC4 : YSS918D-F (AC3D2av) DSP + AC-3(Dolby Digital)/ Pro Logic/ DTS Digital Surround Decoder Name Function VDD2 +3V power supply NONPCM Non-PCM data output terminal, non-PCM data detect output CRC output terminal (normally unconnected) MUTE Mute output terminal, connected to external microcomputer data mute detect input...
  • Page 31 RX-V596/HTR-5250/RX-V596RDS IC5 : IS61C1024-20J (1M SRAM) 131072-word x 8-bit High Speed Static RAM 27,28 131072-word x 8-bit MEMORY ARRAY A0-A16 2-12, DECODER 23,25 (512-row x 2048-column) I/O DATA 13-15, D1-D8 COLUMN I/O 17-21 TOP VIEW CONTROL /CE1 /CE1 CONTROL CIRCUIT...
  • Page 32 RX-V596/HTR-5250/RX-V596RDS IC6 : AK4526A-VQ (CODEC. ADC/DAC) 20-bit 6-channel A/D, D/A Converter LIN+ Audio LIN– Clock Gen. RIN+ MCLK SDOS VREFL RIN– LRCK OCKS RIN+ BICK RIN– LOUT1 DAUX BICK LIN+ LRCK DEM0 LRCK LIN– ROUT1 DEM1 BICK TOP VIEW SDTI1...
  • Page 33: Display Data

    RX-V596/HTR-5250/RX-V596RDS DISPLAY DATA V501 : 16-BT-71GK (V4193300) PATTERN AREA • PIN CONNECTION Pin No. CONNECTION Pin No. CONNECTION NOTE 1) F1, F2..Filament Pin No. 2) NP....No pin CONNECTION 3) P1~P22 ..Segment 4) 1G~16G..Grid 5) Fd terminals are to be supplied through 51kΩ...
  • Page 34: Block Diagram

    RX-V596/HTR-5250/RX-V596RDS BLOCK DIAGRAM (1/2) • See page 64 → SCHEMATIC DIAGRAM • See page 61 → SCHEMATIC DIAGRAM [INPUT (2/2)] • See page 63 → SCHEMATIC DIAGRAM [DSP] • See page 65 • See page 62 INPUT SELECTOR INPUT SELECTOR [MAIN (1/2)] →...
  • Page 35 RX-V596/HTR-5250/RX-V596RDS BLOCK DIAGRAM (2/2) U,C,R,T models FM DET AM/FM IF DET. COIL CERAMIC CERAMIC LA1266 LA3401 A,B,G,L L.P.F. FILTER FILTER models Fi 1 IF AMP Fi 2 FM IF POST AMP RF AMP TUNER FM ANT FM/AM DECODER MUTING Q1,2...
  • Page 36: Parts List

    RX-V596/HTR-5250/RX-V596RDS WARNING PARTS LIST Components having special characteristics are marked and must be replaced with parts having specifications equal to those originally installed. ELECTRICAL PARTS Carbon resistors (1/6W or 1/4W) are not included in the ELECTRICAL PARTS List. For the part Nos. of the carbon resistors,refer to page 86.
  • Page 37 RX-V596/HTR-5250/RX-V596RDS P. C. B. DSP Schm Schm PART NO. Description PART NO. Description V4800100 P.C.B. UB245100 C.CE.M.CHP 0.1uF VQ044300 CN.BS.PIN UB245100 C.CE.M.CHP 0.1uF VQ044900 CN.BS.PIN UB245100 C.CE.M.CHP 0.1uF VQ044600 CN.BS.PIN VG286200 C.EL 100uF UB245100 C.CE.M.CHP 0.1uF UB245100 C.CE.M.CHP 0.1uF UB052100 C.CE.M.CHP...
  • Page 38 RX-V596/HTR-5250/RX-V596RDS P. C. B. DSP & P. C. B. OPERATION Schm Schm PART NO. Description PART NO. Description C138 UB245100 C.CE.M.CHP 0.1uF XV951A00 AK4526A-VQ C139 UB052100 C.CE.M.CHP 100pF XT955A00 AK4324-VF-E2 C140 UB052100 C.CE.M.CHP 100pF XF291A00 uPC4570G2 C141 UB052100 C.CE.M.CHP 100pF...
  • Page 39 RX-V596/HTR-5250/RX-V596RDS P. C. B. OPERATION & P. C. B. INPUT Schm Schm PART NO. Description PART NO. Description C509 VJ599100 C.CE.TUBLR 0.1uF Q502 iA093320 2SA933S Q,R C510 UR847100 C.EL 10uF Q503 VG722000 TR.DGT DTC144ES C511 VJ599100 C.CE.TUBLR 0.1uF Q504 iA093320...
  • Page 40 RX-V596/HTR-5250/RX-V596RDS P. C. B. INPUT Schm Schm PART NO. Description PART NO. Description CB303 VQ047100 CN.BS.PIN C151 VG287200 C.EL 10uF CB331 Vi878900 CN.BS.PIN C152 VG288500 C.EL 10uF CB351 Vi878800 CN.BS.PIN C153 VG287200 C.EL 10uF CB371 V5478200 CN.PHOT.SN 1P GP1FA551RZ C154 UA952220 C.MYLAR...
  • Page 41 RX-V596/HTR-5250/RX-V596RDS P. C. B. INPUT Schm Schm PART NO. Description PART NO. Description C302 VF466800 C.CE.TUBLR 100pF D102 VM975300 DIODE.ZENR HZS11B2TD 11V C303 UR837470 C.EL 47uF D103 VM975300 DIODE.ZENR HZS11B2TD 11V C304 UR837100 C.EL 10uF D104 VM975300 DIODE.ZENR HZS11B2TD 11V...
  • Page 42 RX-V596/HTR-5250/RX-V596RDS P. C. B. INPUT & P. C. B. POWER Schm Schm PART NO. Description PART NO. Description Q121 VG721700 TR.DGT DTA144ES C414 VM645200 C.PP 560pF 100V Q124 VG721700 TR.DGT DTA144ES C416 VG277000 C.CE.TUBLR 33pF 50V(BGL) Q125 VG721700 TR.DGT DTA144ES...
  • Page 43 RX-V596/HTR-5250/RX-V596RDS P. C. B. POWER & P. C. B. MAIN Schm Schm PART NO. Description PART NO. Description C804 VL884600 C.PP 0.01uF 100V T801 XW607A00 TRANS.PWR (RT) C805 UR896470 C.EL 4.7uF 100V(RT) T801 XW608A00 TRANS.PWR (ABGL) C806 Vi716700 C.MYLAR 0.01uF...
  • Page 44 RX-V596/HTR-5250/RX-V596RDS P. C. B. MAIN Schm Schm PART NO. Description PART NO. Description C526 FU451150 C.MICA 15pF 500V C583 UA954100 C.MYLAR 0.01uF 50V(RATBGL) C527 VG291200 C.EL 47uF C584 UA954100 C.MYLAR 0.01uF 50V(RATBGL) C528 VP918000 C.PP 3300pF 100V C585 UA954100 C.MYLAR 0.01uF...
  • Page 45 RX-V596/HTR-5250/RX-V596RDS P. C. B. MAIN Schm Schm PART NO. Description PART NO. Description D528 VG440300 DIODE.ZENR MTZJ12C 12V Q530 V4096100 2SC4614 S,T(UC) D529 VG440300 DIODE.ZENR MTZJ12C 12V Q530 VP872700 2SC4488 ST(RATBGL) D530 VG440300 DIODE.ZENR MTZJ12C 12V Q531 VR355900 TR.PAIR 2SA1695/C4468 OPY...
  • Page 46 RX-V596/HTR-5250/RX-V596RDS P. C. B. MAIN Schm Schm PART NO. Description PART NO. Description R578 V3945500 R.MTL.OXD 820Ω 0.5W R662 VP940800 R.MTL.OXD 470Ω 1W(RATBGL) R579 VP941500 R.MTL.OXD 4.7KΩ 1W(RATBGL) R662 VP940900 R.MTL.OXD 560Ω 1W(UC) R579 VP941600 R.MTL.OXD 5.6KΩ 1W(UC) R663 HV755100 R.CAR.FP...
  • Page 47 RX-V596/HTR-5250/RX-V596RDS P. C. B. TUNER • Lead Type Schm Schm PART NO. Description PART NO. Description V2518600 P.C.B. TUNER/TU-01NC(UC) VL884100 C.PP 3900pF 100V(RDS BG) V2518700 P.C.B. TUNER/TU-01NC(RT) VE020000 C.EL 3.3uF 50V(RDS BG) V2518800 P.C.B. TUNERTU-01NC(ABGL) VG290700 C.EL 3.3uF V2518900 P.C.B.
  • Page 48 RX-V596/HTR-5250/RX-V596RDS P. C. B. TUNER P. C. B. TUNER Chip Resistors Schm Schm Schm Schm PART NO. Description PART NO. Description PART NO. Description PART NO. Description VU477800 TERM.ANT AJ-2038-040 UM415470 C.EL 0.47uF V2716700 TUNER.PK ENV-172A4G1(ABGL) RD254470 R.CAR.CHP 47Ω 1/10W VT969000 PIN.TEST...
  • Page 49 RX-V596/HTR-5250/RX-V596RDS Ref. PART NO. Description Remarks Markets V2518700 P.C.B. ASS’Y TUNER/TU-01 NC (RT) V2518800 P.C.B. ASS’Y TUNER/TU-01 NC (AL) V2518900 P.C.B. ASS’Y TUNER/TU-01RDS NC (BG) V4800300 P.C.B. ASS’Y INPUT (UCRT) V4800400 P.C.B. ASS’Y INPUT (ABGL) V4801600 P.C.B. ASS’Y POWER (UC) V4801700 P.C.B.
  • Page 50 RX-V596/HTR-5250/RX-V596RDS Ref. PART NO. Description Remarks Markets V4172800 KNOB D30 ENC V4172000 KNOB V4172100 KNOB V4172200 KNOB V2918800 BUTTON V2918900 BUTTON V4562700 BUTTON V2469400 SHEET, WINDOW V4170300 PLATE SIDE L V4170400 PLATE SIDE L V4170500 PLATE SIDE L V4170600 PLATE SIDE R...
  • Page 51 RX-V596/HTR-5250/RX-V596RDS Parts List for Carbon Resistors Value 1/4W Type Part No. 1/6W Type Part No. Value 1/4W Type Part No. 1/6W Type Part No. 1.0 Ω 3100 7100 3100 10 kΩ 7100 HJ35 HF85 HF45 HF45 1.8 Ω 3180 7110 11 kΩ...
  • Page 52: Schematic Diagram

    RX-V596/HTR-5250/RX-V596RDS (RAV210 or RAV211) • U,C,R,T,A and L models → RAV210 REMOTE CONTROL TRANSMITTER • B and G models → RAV211 Key Arrangement SCHEMATIC DIAGRAM ROTARY SWITCH AMP/TUNER P46/KR6 TAPE/MD P47/KR7 JRS1901 ROTARY SWITCH 2N3904 CABLE/SAT VBAT 38 VDD 17 VDD...
  • Page 53 RX-V596/HTR-5250/RX-V596RDS List of the Yamaha Code (NEC Format) DVD MENU Name Yamaha 0008 Yamaha 0008 Yamaha 0007 Yamaha 0005 Yamaha 0015 7C-94 7C-94 7C-17 79-11 79-11 7C-95 7C-95 7C-18 79-12 79-12 7C-96 7C-96 7C-19 79-13 79-13 7C-97 7C-97 7C-1A 79-14...
  • Page 54 RX-V596/HTR-5250/RX-V596RDS...
