Page 1: Table Of Contents
Refrigerator ....14 Reversing the Door Swing . . . 18–24 Water Line Installation ..15–18 Troubleshooting Tips Before You Call For Service . .25–27 Normal Operating Sounds .
Page 2: Proper Disposal
DANGER! RISQUES POUR LES ENFANTS COMMENT VOUS DÉBARRASSER CONVENABLEMENT DE VOTRE ANCIEN RÉFRIGÉRATEUR Les enfants pris au piège ou morts d’asphyxie sont Se débarrasser du CFC toujours d’actualité. Les réfrigérateurs abandonnés Votre ancien réfrigérateur a un système de sont toujours aussi dangereux, même si on n’attend...
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. www.GEAppliances.com WARNING! Use this appliance only for its intended purpose as described in this Owner’s Manual. SAFETY PRECAUTIONS When using electrical appliances, basic safety precautions should be followed, including the following: This refrigerator must be properly installed Be careful closing doors when children are and located in accordance with the Installation in the area.
Page 4: Connecting Electricity
IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. WARNING! HOW TO CONNECT ELECTRICITY Do not, under any circumstances, cut or remove the third (ground) prong from the power cord. For personal safety, this appliance must be properly grounded. The power cord of this appliance is equipped This provides the best performance and also with a 3-prong (grounding) plug which mates prevents overloading house wiring circuits which...
Page 5: Extension Cords
à 3 fils avec mise à la terre pour appareils électroménagers homologué UL (aux États-Unis) ou certifié CSA (au Canada), pourvu d’une fiche et d’une prise mises à la terre de 15 ampères (minimum) et de 120 volts.
Page 6: Adapter Plugs
IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. USE OF ADAPTER PLUGS (Adapter plugs not permitted in Canada) Because of potential safety hazards under certain conditions, we strongly recommend against the use of an adapter plug. However, if you must use an adapter, where local If the adapter ground terminal breaks, DO NOT codes permit, a temporary connection may be made USE the refrigerator until a proper ground has...
Page 7: Temperature Controls
About the temperature control dial. www.GEAppliances.com Turning the dial to 0 stops cooling in both compartments—fresh food and freezer. It does not shut off power to the refrigerator. Control Settings Temperature Control Dial The temperature control dial has nine settings plus 0 . 1 is the warmest. 9 is the coldest. At first, set the dial at 5 .
Page 8 About the fresh food compartment shelves. Shelf supports at various levels allow you to custom-space your shelves. Not all features are on all models. Half-Width Shelves One end of the shelf rests on a molded NOTE: The shelf to the right of the track is 2 Lift up and out side-wall support;...
Page 9: Storage Drawers
About the freezer compartment shelves. www.GEAppliances.com Some models have an ice-tray shelf and some have a full-width step shelf. Ice-Tray Shelf Plug Supports To remove the ice-tray shelf, lift the left side of the shelf off its supports, then pull the shelf to the left to free it of the plug supports.
Page 10 About storage drawer and cover removal. Not all features are on all models. Drawer and Cover Removal Drawers can be removed easily by grasping the sides and lifting up slightly while pulling drawers past the stop location. Full-Width Drawer with Plastic Cover To remove the cover, lift it off its supports, pull it forward, tilt it and take it out.
Page 11: Automatic Icemaker
About the automatic icemaker. www.GEAppliances.com A newly-installed refrigerator may take 12 to 24 hours to begin making ice. Automatic Icemaker (on some models) Power Switch Icemaker The icemaker will produce seven cubes When the bin fills to the level of the per cycle—approximately 100–130 cubes feeler arm, the icemaker will stop in a 24-hour period, depending on...
Page 12: Care And Cleaning
Manipuler les tablettes en verre avec Use warm water and baking soda solution— précaution. Le verre trempé soumis à un choc about a tablespoon (15 ml) of baking soda to a quart (1 liter) of water. This both risque de se fracasser.
Page 13 If the temperature can drop below baking soda solution of one tablespoon freezing, have a qualified servicer drain (15 ml) of baking soda to one quart the water supply system (on some (1 liter) of water. Leave the doors open.
Page 14: Installation Instructions
Installation Refrigerator Instructions Models 15, 16, 17, 18 If you have questions, call 1-800-GECARES www.GEAppliances.com visit our Website at: BEFORE YOU BEGIN CLEARANCES Allow the following clearances for ease of installation, Read these instructions completely and carefully. proper air circulation and plumbing and electrical IMPORTANT –...
Page 15: Water Line Installation
Installation Instructions INSTALLING THE WATER LINE BEFORE YOU BEGIN This water line installation is not warranted by the refrigerator or icemaker manufacturer. Follow these instructions carefully to minimize the risk of expensive water damage. Water hammer (water banging in the pipes) in house •...
Page 16 Installation Instructions INSTALLING THE WATER LINE (CONT.) Install the shutoff valve on the nearest frequently used drinking water line. FASTEN THE SHUTOFF VALVE Fasten the shutoff valve to the cold water pipe with the pipe clamp. SHUT OFF THE MAIN WATER SUPPLY Pipe Clamp Turn on the nearest faucet long enough to clear the...
Page 17 Installation Instructions CONNECT THE TUBING TO THE CONNECT THE TUBING TO THE VALVE REFRIGERATOR (CONT.) Place the compression nut and ferrule (sleeve) 9.2 Remove the plastic flexible cap from the onto the end of the tubing and connect it to the water valve.
Page 18: Reversing The Door Swing
Set the icemaker power switch to the ON position. The icemaker will not begin to operate until it Tighten any connections that leak. reaches its operating temperature of 15°F (–9°C) or below. It will then begin operation automatically if the icemaker power switch is in the ON position.
Page 19: Before You Start
Installation Instructions BEFORE YOU START REMOVE THE FREEZER DOOR (CONT.) 1.1 Unplug the refrigerator from its electrical outlet. 2.3 Lift the hinge (and the shim glued to it) straight up to free the hinge pin from the socket in the top of the door and set it aside, along with its screws.
Page 20 Installation Instructions REVERSING THE DOOR SWING (CONT.) REMOVE THE FRESH FOOD REMOVE THE FRESH FOOD DOOR DOOR (CONT.) 3.1 Tape the door shut with masking tape. 3.4 Set the door outside-up on a non-scratching surface. 3.5 Using a Torxdriver, transfer the two screws from the opposite side of the cabinet to the screw holes 3.2 Using a 5/16″...
Page 21: Reversing The Door Handles
Installation Instructions REVERSING THE HARDWARE REVERSING THE DOOR HANDLES 4.1 Remove the base grille (if your refrigerator has 5.1 Transfer fresh food door handle one) by pulling it straight out. 5.1.1 Remove the handle plug using a tape-tipped putty knife under the edge, and remove the screw underneath.
Page 22 Installation Instructions REVERSING THE DOOR SWING (CONT.) 5.2 Transfer door stop REVERSING THE DOOR HANDLES (cont.) 5.2.2 Move any screws from the left end to (CONT.) the right end. 5.1 Transfer fresh food door handle Right Side (cont.) 5.1.5 Pull the plug button from the front of the door and transfer it to the opposite side.
Page 23 Installation Instructions 5.4 Transfer Freezer Door Handle 5.4 Transfer Freezer Door Handle (cont.) 5.4.1 Remove the screw holding the handle to the 5.4.4 Transfer the door stop as shown on the top of the door and the two screws holding preceding page.
Page 24: Rehanging The Doors
Installation Instructions REVERSING THE DOOR SWING (CONT.) REHANGING THE DOORS (CONT.) REHANGING THE DOORS 6.2 Rehang the freezer door 6.1 Rehang the fresh food door 6.2.1 Lower the freezer door onto the center 6.1.1 Lower the fresh food door onto the hinge pin.
Page 25: Troubleshooting Tips
Normal operating sounds. www.GEAppliances.com Depending on the placement of the refrigerator in your kitchen, you may want to place a piece of rubber-backed carpet under the refrigerator to reduce noise. The fan circulating air inside the freezer which keeps the temperatures even. Boiling water or a gurgling noise.
Page 26 Before you call for service… Problem Possible Causes What To Do • Wait 24 hours for the refrigerator to completely Motor operates for Normal when refrigerator cool down. long periods or cycles is first plugged in. on and off frequently. •...
Page 27 www.GEAppliances.com Problem Possible Causes What To Do •Wipe surface dry and reset temperature control dial Moisture forms on Not unusual during one setting colder. cabinet surface periods of high humidity. between the doors Moisture collects inside Too frequent or too (in humid weather, air long door openings.
Page 28: Warranty For Canadian Customers
CONSUMER WARRANTY (for customers in Canada) Your refrigerator is warranted to be free of defects in material and workmanship. What is covered How Long Warranted Parts Labour (From Date of Sale) Repair or Replace at Camco’s Option Compressor Five (5) Years Five (5) Years Five (5) Years Sealed System (including...
Page 29: Product Registration
You can rest easy, knowing that all your valuable household products are protected against expensive repairs. 800-626-2224 Place your confidence in GE and call us in the U.S. toll-free at for more information. *All brands covered, up to 20 years old, in the continental U.S.
Page 30: Model Number
Our service number in safety modification. the USA is: 800 GE CARES (800-432-2737). In Canada: 1-888-880- 3030. Model Number Serial Number Important: If you did not get a registration card with your...
Page 31: Warranty For U.s. Customers
From the date of the During this additional four-year warranty, GE will also provide, free of charge, all labor and original purchase in-home service to replace the defective part.
Page 32: Consumer Support
Contact Us www.GEAppliances.com If you are not satisfied with the service you receive from GE, contact us on our Website with all the details including your phone number, or write to: General Manager, Customer Relations GE Appliances, Appliance Park...
