FILE NO. A09-011

SERVICE MANUAL

AIR-CONDITIONER
SPLIT TYPE
RAS-M10PKVP-E, RAS-M13PKVP-E,
RAS-M16PKVP-E, RAS-M18PKVP-E /
RAS-5M34UAV-E
R410A
PRINTED IN JAPAN, Feb, 2010
ToMo

Advertisement

Table of Contents
loading

Related Manuals for Toshiba RAS-M16PKVP-E

Summary of Contents for Toshiba RAS-M16PKVP-E

  • Page 1: Service Manual

    FILE NO. A09-011 SERVICE MANUAL AIR-CONDITIONER SPLIT TYPE RAS-M10PKVP-E, RAS-M13PKVP-E, RAS-M16PKVP-E, RAS-M18PKVP-E / RAS-5M34UAV-E R410A PRINTED IN JAPAN, Feb, 2010 ToMo...

  • Page 2: Table Of Contents

    CONTENTS 1. SAFETY PRECAUTIONS ............3 2. SPECIFICATIONS ................ 5 3. REFRIGERANT R410A ............. 26 4. CONSTRUCTION VIEWS ............34 5. WIRING DIAGRAM ..............36 6. SPECIFICATIONS OF ELECTRICAL PARTS ......38 7. REFRIGERANT CYCLE DIAGRAM........... 39 8. CONTROL BLOCK DIAGRAM ..........46 9.

  • Page 3: Safety Precautions

    1. SAFETY PRECAUTIONS The important contents concerned to the safety are described on the product itself and on this Service Manual. Please read this Service Manual after understanding the described items thoroughly in the following contents (Indications/Illustrated marks), and keep them. [Explanation of indications] Indication Explanation...
  • Page 4 CAUTION TO DISCONNECT THE APPLIANCE FROM THE MAIN POWER SUPPLY A switch or circuit breaker that can disconnect all poles must be included in the fixed wiring. Be sure to use an approved circuit breaker or switch. DANGER • Ask an authorized dealer or qualified installation professional to install/maintain the air conditioner. INAPPROPRIATE SERVICING MAY RESULT IN WATER LEAKAGE, ELECTRIC SHOCK OR FIRE.

  • Page 5: Specifications

    Be sure to connect indoor units in two or more. The contents noted in this service manual limit the indoor units to the RAS-M10PKVP-E, RAS-M13PKVP-E, RAS-M16PKVP-E, RAS-M18PKVP-E. For other indoor units that can also be used in combination, see the Service Manual of each indoor unit.

  • Page 6: Unit

    2-1. Specifications <Heat Pump Models> RAS-M10PKVP-E,RAS-M13PKVP-E,RAS-M16PKVP-E,RAS-M18PKVP-E / RAS-5M34UAV-E Indoor RAS- M10PKVP-E, M13PKVP-E, M16PKVP-E, M18PKVP-E Unit model Outdoor RAS- 5M34UAV-E Cooling Capacity (kW) 10.0 Cooling Capacity range (kW) 11.0 Heating Capacity (kW) 12.0 Heating Capacity range (kW) 14.0 Power supply 220-240V 1Ph 50Hz / 220V 1Ph 60Hz...

  • Page 7: Unit

    2-2. Specifications of Performance When Each Indoor Unit is Combined with Other Unit Outdoor Unit : RAS-5M34UAV-E <Cooling/220V> Indoor unit Unit Capacity Total Power supply Operating Outdoor noise status (dB) Cooling capacity (kW) Power consumption (W) Operating current (A) 3.84 1 unit —...

  • Page 8: Unit

    <Cooling/220V> (Continued) Indoor unit Unit Capacity Total Power supply Operating Outdoor noise status (dB) Cooling capacity (kW) Power consumption (W) Operating current (A) 2450 11.72 4 units — 1.95 1.95 1.95 1.95 — (4.0 – 8.7) (930 – 2800) (4.70 – 12.99) 2450 11.72 —...
  • Page 9 <Cooling/220V> (Continued) Indoor unit Unit Capacity Total Power supply Operating Outdoor noise status (dB) Cooling capacity (kW) Power consumption (W) Operating current (A) 2865 13.71 5 units 1.96 1.96 1.96 1.96 1.96 (3.7 – 10.8) (950 – 3630) (4.80 – 16.84) 2894 13.85 2.50...
  • Page 10 Outdoor Unit : RAS-5M34UAV-E <Cooling/230V> Indoor unit Unit Capacity Total Power supply Operating Outdoor noise status (dB) Cooling capacity (kW) Power consumption (W) Operating current (A) 3.67 1 unit — — — — — — — — (1.4 – 2.5) (640 –...
  • Page 11 <Cooling/230V> (Continued) Unit Capacity Total Indoor unit Power supply Operating Outdoor noise status (dB) Cooling capacity (kW) Power consumption (W) Operating current (A) 2450 11.21 4 units — 1.95 1.95 1.95 1.95 — (4.0 – 8.7) (930 – 2800) (4.49 – 12.42) 2450 11.21 —...
  • Page 12 <Cooling/230V> (Continued) Unit Capacity Total Indoor unit Power supply Operating Outdoor noise status (dB) Cooling capacity (kW) Power consumption (W) Operating current (A) 2865 13.11 5 units 1.96 1.96 1.96 1.96 1.96 (3.7 – 10.8) (950 – 3630) (4.59 – 16.10) 2894 13.24 2.50...
  • Page 13 Outdoor Unit : RAS-5M34UAV-E <Cooling/240V> Indoor unit Unit Capacity Total Power supply Operating Outdoor noise status (dB) Cooling capacity (kW) Power consumption (W) Operating current (A) 3.52 1 unit — — — — — — — — (1.4 – 2.5) (640 –...
  • Page 14 <Cooling/240V> (Continued) Indoor unit Unit Capacity Total Power supply Operating Outdoor noise status (dB) Cooling capacity (kW) Power consumption (W) Operating current (A) 2450 10.75 4 units — 1.95 1.95 1.95 1.95 — (4.0 – 8.7) (930 – 2800) (4.31 – 11.90) 2450 10.75 —...
  • Page 15 <Cooling/240V> (Continued) Indoor unit Unit Capacity Total Power supply Operating Outdoor noise status (dB) Cooling capacity (kW) Power consumption (W) Operating current (A) 2865 12.57 5 units 1.96 1.96 1.96 1.96 1.96 (3.7 – 10.8) (950 – 3630) (4.40 – 15.43) 2894 12.69 2.50...
  • Page 16 Outdoor Unit : RAS-5M34UAV-E <Heating/220V> Indoor unit Unit Capacity Total Power supply Operating Outdoor noise status (dB) Heating capacity (kW) Power consumption (W) Operating current (A) 4.70 1 unit — — — — — — — — (0.8 – 3.7) (300 –...
  • Page 17 <Heating/220V> (Continued) Total Indoor unit Unit Capacity Power supply Operating Outdoor noise status (dB) Heating capacity (kW) Power consumption (W) Operating current (A) 2100 10.05 4 units — 2.20 2.20 2.20 2.20 — (2.2 – 10.8) (450 – 2810) (2.56 – 13.03) 2100 10.05 —...
  • Page 18 <Heating/220V> (Continued) Indoor unit Unit Capacity Total Power supply Operating Outdoor noise status (dB) Heating capacity (kW) Power consumption (W) Operating current (A) 11.4 2690 12.87 5 units 2.28 2.28 2.28 2.28 2.28 (3.4 – 13.4) (775 – 4020) (4.40 – 18.65) 11.7 2762 13.22...
  • Page 19 Outdoor Unit : RAS-5M34UAV-E <Heating/230V> Indoor unit Unit Capacity Total Power supply Operating Outdoor noise status (dB) Heating capacity (kW) Power consumption (W) Operating current (A) 4.50 1 unit — — — — — — — — (0.8 – 3.7) (300 –...
  • Page 20 <Heating/230V> (Continued) Indoor unit Unit Capacity Total Power supply Operating Outdoor noise status (dB) Heating capacity (kW) Power consumption (W) Operating current (A) 2100 9.61 4 units — 2.20 2.20 2.20 2.20 — (2.2 – 10.8) (450 – 2810) (2.45 – 12.47) 2100 9.61 —...
  • Page 21 <Heating/230V> (Continued) Unit Capacity Total Indoor unit Power supply Operating Outdoor noise status (dB) Heating capacity (kW) Power consumption (W) Operating current (A) 11.4 2690 12.31 5 units 2.28 2.28 2.28 2.28 2.28 (3.4 – 13.4) (775 – 4020) (4.21 – 17.83) 11.7 2762 12.64...
  • Page 22 Outdoor Unit : RAS-5M34UAV-E <Heating/240V> Indoor unit Unit Capacity Total Power supply Operating Outdoor noise status (dB) Heating capacity (kW) Power consumption (W) Operating current (A) 4.31 1 unit — — — — — — — — (0.8 – 3.7) (300 –...
  • Page 23 <Heating/240V> (Continued) Indoor unit Unit Capacity Total Power supply Operating Outdoor noise status (dB) Heating capacity (kW) Power consumption (W) Operating current (A) 2100 9.21 4 units — 2.20 2.20 2.20 2.20 — (2.2 – 10.8) (450 – 2810) (2.34 – 11.95) 2100 9.21 —...
  • Page 24 <Heating/240V> (Continued) Unit Capacity Total Indoor unit Power supply Operating Outdoor noise status (dB) Heating capacity (kW) Power consumption (W) Operating current (A) 11.4 2690 11.80 5 units 2.28 2.28 2.28 2.28 2.28 (3.4 – 13.4) (775 – 4020) (4.04 – 17.09) 11.7 2762 12.11...

  • Page 25: Operation Characteristic Curve

    2-2-1. Operation Characteristic Curve <Cooling> <Heating> • Conditions 220V • Conditions 220V Indoor : DB27˚C/WB19˚C Indoor : DB20˚C Outdoor : DB35˚C Outdoor : DB7˚C / WB6˚C Air flow : High Air flow : High Pipe length : 5m × 5 Pipe length : 5m ×...

  • Page 26: Refrigerant R410A

    3. REFRIGERANT R410A This air conditioner adopts the new refrigerant HFC 6. When an air conditioning system charged with a (R410A) which does not damage the ozone layer. large volume of refrigerant is installed in a small room, it is necessary to exercise care so that, The working pressure of the new refrigerant R410A even when refrigerant leaks, its concentration is 1.6 times higher than conventional refrigerant...
  • Page 27 Table 3-2-1 Thicknesses of annealed copper pipes Thickness (mm) Nominal diameter Outer diameter (mm) R410A 6.35 0.80 0.80 9.52 0.80 0.80 12.70 0.80 0.80 15.88 1.00 1.00 2. Joints For copper pipes, flare joints or socket joints are used. Prior to use, be sure to remove all contaminants. a) Flare Joints Flare joints used to connect the copper pipes cannot be used for pipings whose outer diameter exceeds 20 mm.
  • Page 28 d) Flare Processing Make certain that a clamp bar and copper pipe have been cleaned. ØD By means of the clamp bar, perform the flare processing correctly. Use either a flare tool for R410A or conven- tional flare tool. Flare processing dimensions differ according to the type of flare tool.
  • Page 29 Table 3-2-6 Flare and flare nut dimensions for R22 Dimension (mm) Nominal Outer diameter Thickness Flare nut width diameter (mm) (mm) (mm) 6.35 9.52 13.0 13.5 12.70 16.2 16.0 12.9 15.88 19.7 19.0 16.0 19.05 23.3 24.0 19.2 Fig. 3-2-2 Relations between flare nut and flare seal surface 2.
  • Page 30 3-3. Tools 3-3-1. Required Tools The service port diameter of packed valve of the outdoor unit in the air-water heat pump using R410A is changed to prevent mixing of other refrigerant. To reinforce the pressure-resisting strength, flare processing dimensions and opposite side dimension of flare nut (For Ø12.7 copper pipe) of the refrigerant piping are lengthened.

  • Page 31: Recharging Of Refrigerant

    3-4. Recharging of Refrigerant When it is necessary to recharge refrigerant, charge the specified amount of new refrigerant according to the following steps. Recover the refrigerant, and check no refrigerant remains in the equipment. When the compound gauge’s pointer has indicated –0.1 Mpa (–76 cmHg), place the handle Low in the fully closed position, and turn off the vacuum pump’s power switch.
  • Page 32 1. Be sure to make setting so that liquid can be charged. 2. When using a cylinder equipped with a siphon, liquid can be charged without turning it upside down. It is necessary for charging refrigerant under condition of liquid because R410A is mixed type of refrigerant. Accordingly, when charging refrigerant from the refrigerant cylinder to the equipment, charge it turning the cylinder upside down if cylinder is not equipped with siphon.
  • Page 33 2. Characteristics required for flux 3-5-3. Brazing • Activated temperature of flux coincides with As brazing work requires sophisticated techniques, the brazing temperature. experiences based upon a theoretical knowledge, it must be performed by a person qualified. • Due to a wide effective temperature range, flux is hard to carbonize.

  • Page 34: Construction Views

    4. CONSTRUCTION VIEWS 4-1. Indoor Unit RAS-M10PKVP-E, RAS-M13PKVP-E, RAS-M16PKVP-E, RAS-M18PKVP-E (At the time of operation) 296.2 Moving panel Plasma ion charger Front panel (At the time of a stop) Piping port from Air filter Piping port from left/right sides left/right sides...
  • Page 35 4-2. Outdoor Unit RAS-5M34UAV-E – 35 –...

  • Page 36: Wiring Diagram

    5. WIRING DIAGRAM 5-1. Indoor Unit RAS-M10PKVP-E, RAS-M13PKVP-E, RAS-M16PKVP-E, RAS-M18PKVP-E Air purifier electrode 3 2 1 Indoor terminal block Power supply Micro SW Sheet metal GRN&YEL CN501 CN03 CN01 CN21 CN401 CN382 (WHI) (RED) DC5V (TC) Power supply DC12V circuit...

  • Page 37: Outdoor Unit

    5-2. Outdoor Unit RAS-5M34UAV-E POWER SUPPLY CIRCUIT – 37 –...

  • Page 38: Specifications Of Electrical Parts

    6. SPECIFICATIONS OF ELECTRICAL PARTS 6-1. Indoor Unit RAS-M10PKVP-E, RAS-M13PKVP-E, RAS-M16PKVP-E, RAS-M18PKVP-E Parts name Type Specifications E: ICF-340-30-4 Fan motor (for indoor unit) DC 280–340 V, 30 W ND: ICF-340-30-4A Room temp. sensor (TA-sensor) ( – ) 10 k: at 25°C Heat exchanger temp.

  • Page 39: Refrigerant Cycle Diagram

    7. REFRIGERANT CYCLE DIAGRAM RAS-M10PKVP-E, RAS-M13PKVP-E, RAS-M16PKVP-E, RAS-M18PKVP-E / RAS-5M34UAV-E NOTE : Gas leak check position Refrigerant flow (Cooling) Refrigerant flow (Heating) NOTE : • You need not add refrigerant if the piping length is 40m or less. • If the length exceeds 41m, add 20g of refrigerant per 1 meter over.

  • Page 40: Operation Data

    7-2. Operation Data Outdoor Unit : RAS-5M34UAV-E <Cooling> Temperature Standard Heat exchanger Compressor No. of Indoor unit condition pressure pipe temperature Indoor Outdoor revolution operating units (rps) Indoor Outdoor P (MPa) T1 (°C) T2 (°C) 1 unit — — — —...
  • Page 41 <Cooling> (Continued) Temperature Standard Heat exchanger Compressor No. of Indoor unit condition pressure pipe temperature Indoor Outdoor revolution operating units (rps) Indoor Outdoor P (MPa) T1 (°C) T2 (°C) 4 units — 0.9 to 1.1 12 to 14 51 to 53 High —...
  • Page 42 <Cooling> (Continued) Temperature Standard Heat exchanger Compressor No. of Indoor unit condition pressure pipe temperature Indoor Outdoor revolution operating units (rps) Indoor Outdoor P (MPa) T1 (°C) T2 (°C) 5 units 1.0 to 1.2 15 to 17 51 to 53 High High 1.0 to 1.2...
  • Page 43 Outdoor Unit : RAS-5M34UAV-E <Heating> Temperature Standard Heat exchanger Compressor No. of Indoor unit condition pressure pipe temperature Indoor Outdoor revolution operating units (rps) Indoor Outdoor P (MPa) T1 (°C) T2 (°C) 1 unit — — — — 2.1 to 2.3 36 to 38 3 to 5 High...
  • Page 44 <Heating> (Continued) Temperature Standard Heat exchanger Compressor No. of Indoor unit condition pressure pipe temperature Indoor Outdoor revolution operating units (rps) Indoor Outdoor P (MPa) T1 (°C) T2 (°C) 4 units — 2.5 to 2.7 35 to 37 –2 to 0 High —...
  • Page 45 <Heating> (Continued) Temperature Standard Heat exchanger Compressor No. of Indoor unit condition pressure pipe temperature Indoor Outdoor revolution operating units (rps) Indoor Outdoor P (MPa) T1 (°C) T2 (°C) 5 units 2.0 to 2.2 32 to 35 –2 to 0 High 2.0 to 2.2 32 to 35...

  • Page 46: Control Block Diagram

    8. CONTROL BLOCK DIAGRAM 8-1. Indoor Unit RAS-M10PKVP-E, RAS-M13PKVP-E, RAS-M16PKVP-E, RAS-M18PKVP-E Indoor Unit Control Unit M.C.U. Humidity sensor Louver Functions Motor Heat Exchanger Sensor (Tcj) • Cold Draft Preventing Function Louver Motor Heat Exchanger Sensor (Tc) • 3-minute Delay at Restart for Compressor Drive Control •...

  • Page 47: Outdoor Unit (Inverter Assembly)

    8-2. Outdoor Unit (Inverter Assembly) RAS-5M34UAV-E Outdoor air temp. sensor Gas side pipe temp. sensor Suction temp. sensor Evaporator temp. sensor Discharge temp. sensor MCC-5071 (CONTROL P.C. B) A unit P.M.V. M.C.U A unit serial signal communication circuit • Inverter outdoor frequency control B unit P.M.V.

  • Page 48: Operation Description

    9. OPERATION DESCRIPTION • Detection of inverter input current and current 9-1. Outline of Air Conditioner Control release operation This air conditioner is a capacity-variable type air • Over-current detection and prevention operation conditioner, which uses DC motor for the indoor fan to IGBT module (Compressor stop function) motor and the outdoor fan motor.
  • Page 49 9-2. Operation Description 1. Basic operation ........................50 1. Operation control ....................... 50 2. Operating mode selection when performing 2-room operation ......... 51 3. Cooling/Heating operation ....................51 4. AUTO operation ......................... 52 5. DRY operation ........................52 2. Indoor fan motor control ......................53 <In cooling operation>...

  • Page 50: Basic Operation

    Item Operation flow and applicable data, etc. Description 1. Basic 1. Operation control operation Receiving the user’s operation condition setup, the operation statuses of indoor/outdoor units are controlled. 1) The operation conditions are selected by the remote controller as shown in the below. 2) A signal is sent by ON button of the remote controller.

  • Page 51: Operating Mode Selection When Performing 2-Room Operation

    Item Operation flow and applicable data, etc. Description 1. Basic 2. Operating mode selection when performing 2-room operation operation 1) The outdoor unit operating mode conforms to the instructions of the indoor unit that was pushed first. 2) When combined operation consisting of cooling (dry) and heating, fan (air purification) and heating, or cleaning operation and heating is performed, operation conforms to the instructions of the indoor unit that was pushed first as shown in the following table.

  • Page 52: Auto Operation

    Item Operation flow and applicable data, etc. Description 1. Basic 4. AUTO operation 1) Detects the room temperature (Ta) when operation the operation started. Selection of operation mode As shown in the following figure, the operation starts by 2) Selects an operation mode from Ta in selecting automatically the status of room temperature the left figure.

  • Page 53: Indoor Fan Motor Control

    W2 (20 seconds) to 0 rpm (Linear approximation from M+ and L) (40 seconds). (Table 1) Indoor fan air flow rate (Cooling, Dry) RAS-M10PKVP-E RAS-M13PKVP-E RAS-M16PKVP-E RAS-M18PKVP-E Fan speed level Fan speed Air flow rate Fan speed Air flow rate Fan speed Air flow rate...

  • Page 54: In Heating Operation> (Heat Pump Model)

    Item Operation flow and applicable data, etc. Description 2. Indoor fan <In heating operation> (Heat pump model) 1) When setting the fan speed to L, motor control L+, M, M+ or H on the remote (This operation controls the fan speed at indoor unit side.) (Continued) controller, the operation is The indoor fan (cross flow fan) is operated by the phase...
  • Page 55 • Room temp. t Set temp. –3.5°C FAN Manual • Room temp. < Set temp. –4°C (Table 2) Indoor fan air flow rate (Heating) RAS-M10PKVP-E RAS-M13PKVP-E RAS-M16PKVP-E RAS-M18PKVP-E Fan speed level Fan speed Air flow rate Fan speed Air flow rate Fan speed Air flow rate...

  • Page 56: Outdoor Fan Motor Control

    Item Operation flow and applicable data, etc. Description 3. Outdoor fan The blowing air volume at the outdoor unit side is controlled. 1) The operation command sent motor control from the remote controller is Receiving the operation command from the controller of indoor processed by the indoor unit unit, the controller of outdoor unit controls fan speed.

  • Page 57: Capacity Control

    Item Operation flow and applicable data, etc. Description 4. Capacity 1) Four indoor units from A to E determine the respective instruction revolutions from the difference control between the remote controller setting temperature (Ts) and the indoor temperature (Ta), and transmit this to the outdoor unit.

  • Page 58: Release Protective Control By Temperature Of Indoor Heat Exchanger

    Item Operation flow and applicable data, etc. Description 6. Release protective <In cooling/dry operation> 1) When temperature of the indoor control by heat exchanger drops below 5°C, (Prevent-freezing control for indoor heat exchanger) temperature of indoor the compressor speed is re- In cooling/dry operation, the sensor of indoor heat heat exchanger duced.

  • Page 59: Winding/Coil Heating Control

    Item Operation flow and applicable data, etc. Description 7. Winding/Coil When the outdoor temperature is low, the windings/ Winding/Coil heating is performed when heating control coils are heated to ensure compressor reliability. the following conditions are met. Condition 1 : Outdoor temperature To Winding/Coil When the discharge sensor temperature...

  • Page 60: Louver Control

    Item Operation flow and applicable data, etc. Description 10. Louver control This function controls the air direction of the indoor unit. 1) Louver • The position is automatically controlled according to the operation mode (COOL/HEAT). position • The set louver position is stored in memory by the microcomputer, and the louver returns to the stored position when the next operation is performed.

  • Page 61: Sleep Mode Operation

    Item Operation flow and applicable data, etc. Description 11. SLEEP MODE When pushing [SLEEP MODE] button on the remote operation controller, a quiet and mild operation is performed by reducing the fan speed and the compressor speed. <Cooling operation> <Cooling operation> This function operates the air conditioner with the differ- 1) The indoor fan speed is controlled ence between the set and the room temperature as shown...

  • Page 62: Temporary Operation

    Item Operation flow and applicable data, etc. Description 12. Temporary Pushing [RESET] button starts the temporary 1) When pushing [RESET] button, the operation operation of [AUTO] operation. When keeping temporary [AUTO] operation starts. [RESET] button pushed for 10 seconds or more, 2) When keeping [RESET] button pushed for the temporary [COOL] operation is performed.

  • Page 63: Description

    Item Operation flow and applicable data, etc. Description 13. Air purifying 2. Description control Error is determined to have occurred (Continued) (indicated by the PURE indicator (Orange) in the following two cases. 1) When the panel switch has been set to Air purifying operation OFF by the opening of the air inlet grill, etc.

  • Page 64: Discharge Temperature Control

    Item Operation flow and applicable data, etc. Description 14. Discharge 1. Purpose temperature This function detects error on the control refrigerating cycle or error on the compressor, and performs protective control. Td value Control operation 2. Operation Judges as an error and stops the compressor. •...

  • Page 65: Clean Operation

    Item Operation flow and applicable data, etc. Description 16. Clean operation 1. Purpose The clean operation is to minimize the growth of mold, bacteria etc. by running the fan and drying so as to keep the inside of the air conditioner clean. Unit now performing cooling or dry operation Clean operation When the cooling or dry operation shuts...

  • Page 66: Clean Operation Cancel

    Item Operation flow and applicable data, etc. Description 17. Clean operation Setting the clean operation cancel CAUTION J231 will be near the MCU so take steps to ensure that it will Add J231 of the wireless unit P.C. board assembly. not be exposed to excessive ∗...

  • Page 67: Select Switch On Remote Controller

    Item Operation flow and applicable data, etc. Description 18. Select switch on 1. Purpose remote controller This operation is to operate only one indoor unit using one remote controller. Push the operation button 2. Description on the remote controller. When operating one indoor unit in a situation where two indoor units have been installed in the same room or nearby rooms, this operation prevents the...

  • Page 68: Set Temperature Correction

    Item Operation flow and applicable data, etc. Description 19. Set temperature Indoor Control P.C. Board (Factory Default) 1. Purpose correction When the difference between the set temp. of the remote controller and the room temp. Jumper wire is wide due to the installation condition, etc, J804 the set temp.

  • Page 69: Auto Restart Function

    9-3. Auto Restart Function This indoor unit is equipped with an automatic restarting function which allows the unit to restart operating with the set operating conditions in the event of a power supply being accidentally shut down. The operation will resume without warning 3 minutes after power is restored. This function is not set to work when shipped from the factory.

  • Page 70: Cancel The Auto Restart Function

    9-3-2. Cancel the Auto Restart Function To cancel auto restart function, proceed as follows : Repeat the setting procedure : the unit receives the signal and beeps 3 times. The unit will be required to be turned on with the remote controller after the main power supply is turned off. •...

  • Page 71: Remote Controller And Its Functions

    9-4. Remote Controller and Its Functions 9-4-1. Parts Name of Remote Controller Auto louver button (SWING) Each time you push the SWING button, you can change the swing mode. (A receiving beep is heard.) (Vertical swing o Horizontal swing o Vertical and Horizontal swing o Stop swinging) Push the button again to stop the swinging mode.

  • Page 72: Name And Functions Of Indications On Remote Controller

    9-4-2. Name and Functions of Indications on Remote Controller [Display] All indications, except for the clock time indicator, are displayed by pushing the button. Transmission mark (MEMORY) indicator This transmission mark indicates when the remote Flashes for 3 seconds when the MEMO button is controller transmits signals to the indoor unit.

  • Page 73: Hi Power Mode

    9-5. Hi POWER Mode When [Hi POWER] button is pushed while the indoor unit is in Auto, Cooling or Heating operation, Hi POWER mark is indicated on the display of the remote controller and the unit operates according to the present opera- tion mode as described below.

  • Page 74: Installation Procedure

    10. INSTALLATION PROCEDURE 10-1. Safety Cautions The indoor unit shall be installed so that the top of the indoor unit is positioned For the rear left and left piping at least 2 m high. Also, avoid putting anything on the top of the indoor unit. Wall Hook 70 mm or more...
  • Page 75 Indoor unit name (Outer diameter) (Outer diameter) 1 ea. RAS-M10PKVP-E, RAS-M13PKVP-E 6.35 mm 9.52 mm RAS-M16PKVP-E, RAS-M18PKVP-E 6.35 mm 12.7 mm Shield pipe (for extension drain hose) (polyethylene foam, 8 mm thick) 10-2-2. Accessory and Installation Parts Part No. Part name (Q’ty) Part No.
  • Page 76 10-2-3. Installation/Servicing Tools Changes in the product and components In the case of an air conditioner using R410A, in order to prevent any other refrigerant from being charged accidentally, the service port diameter of the outdoor unit control valve (3-way valve) has been changed. (1/2 UNF 20 threads per inch) •...

  • Page 77: Remote Controller

    10-3. Indoor Unit 10-3-2. Drilling and Mounting Installation Plate K Drilling 10-3-1. Installation Place • A place which provides enough spaces around When installing the refrigerant pipes from the rear. the indoor unit as shown in the diagram. • A place where there are no obstacle near the air inlet and outlet.
  • Page 78 K Mounting the installation plate directly 10-3-3. Electrical Work on a wall 1. The supply voltage must be the same as the rated voltage of the air conditioner. 1) Securely fit the installation plate onto the wall by screws with the upper and lower catches. 2.
  • Page 79 10-3-4. Wiring Connection K Connecting cable Wiring the connecting cable can be carried out without removing the front panel. Termin l cov r Screw Terminal block 1. Remove the air inlet grille. Open the air inlet grille upward and pull it toward you.
  • Page 80 10-3-5. Piping and Drain Hose Installation 4) Attach the drain cap • Insert hexagonal wrench (4 mm). K Piping and drain hose forming Since condensation results in machine trouble, make sure to insulate both the connecting pipes separately. (Use polyethylene foam as insulating material.) Rear right 4 mm Rear left...
  • Page 81 K Piping on the bottom right or the CAUTION bottom left • Bind the auxiliary pipes (two) and connecting • After making slits on the front panel with a cable with facing tape tightly. knife or similar tool, cut them out with a pair of nippers or an equivalent tool.
  • Page 82 10-3-6. Indoor Unit Installation 10-3-7. Drainage 1. Pass the pipe through the hole in the wall, and 1. Run the drain hose at a downward sloped angle. hook the indoor unit on the installation plate at the upper hooks. NOTE 2.
  • Page 83 10-4. Outdoor Unit 10-4-1. Accessory and Installation Parts Rubber cap CD-ROM Installation manual (Installation manual) (Water-proof) F-GAS label Drain nipple 10-4-2. Refrigerant Piping • Piping kit used for the conventional refrigerant cannot be used. • Use copper pipe with 0.8 mm or more thickness. •...
  • Page 84 10-4-5. Installation 1. Piping connections to the outdoor unit should be arranged in the sequence A, B, C, D, E starting NOTE from the bottom. (For each piping connection, the gas pipe is on For installation, at least 3 dimensions should be the bottom and the liquid pipe is on the top.) kept free from obstacles (walls).

  • Page 85: Tightening Connection

    K How to remove the front panel • Tightening torque of flare pipe The pressure of R410A is higher than R22. 1. Remove 5 screws of the front panel. (Approx. 1.6 times) 2. Pull the front panel downward. Therefore securely tighten the flare pipes which connect the outdoor unit and indoor unit with the specified tightening torque using a torque wrench.

  • Page 86: Air Purge

    \ 1 0-4-6. Refrigerant Piping Connection 10-4-7. Evacuating After the piping has been connected to all indoor unit(s), CAUTION you can perform the air purge together at once. KEEP IMPORTANT 4 POINTS FOR PIPING WORK AIR PURGE 1. Keep dust and moisture from entering the pipes. Evacuate the air in the connecting pipes and in the 2.

  • Page 87: Wiring Connection

    K Packed valve handling precautions 3 units (A + B + C) Multi • Open the valve stem all the way out ; do not try to open it beyond the stopper. • Securely tighten the valve stem cap in torque is as follows : Gas side (Ø12.7 mm) 50 to 62 N•m (5.0 to 6.2 kgf•m)
  • Page 88 10-4-8. Check and Test Operation 10-4-9. Miswiring (Mispiping) Check Make sure that the wiring and piping for each room have the same alphabetical codes (A, B, C, D, E). For R410A, use the leak detector exclusively manu- Connect and secure the power cord. factured for HFC refrigerant (R410A, R134a, etc.).
  • Page 89 ¥ ¤ : LED ON, : LED OFF, : LED Flash Description D800 D801 D802 D803 D804 D805 ¤ Before check Normal operation (no error) ¥ ¥ Checking A unit ¥ ¥ Checking B unit ¥ ¥ During check Checking C unit ¥...
  • Page 90 10-5. Test Operation 10-5-4. Select Switch on Remote Controller • If two indoor units are installed in the same room 10-5-1. Gas Leak Test or adjoining rooms, when the user tries to operate Check the flare nut connections for gas leaks with a only one unit, both units may receive the same gas leak detector and/or soapy water.
  • Page 91 10-6. Removing the Main Parts 10-6-2. Removing the Moving Panel 1) Open the moving panel, and support the moving Normally, the front panel, moving panel, and air flow panel by the panel support on the right side. louvres do not need to be removed. 2) Remove the lead wire cover on the right side.
  • Page 92 10-6-3. Attaching the Moving Panel 3) Insert a flathead screwdriver into the gap of the louver fixture on the right and left ends of the 1) Grasp both sides of the moving panel, and insert vertical air flow louver, and turn in the counter- the right-side joint first.

  • Page 93: How To Diagnose The Trouble

    11. HOW TO DIAGNOSE THE TROUBLE The pulse modulating circuits are mounted to both indoor and outdoor units. Therefore, diagnose troubles according to the trouble diagnosis procedure as described below. (Refer to the check points in servicing written on the wiring diagrams attached to the indoor/outdoor units.) Table 11-1 Troubleshooting Procedure Page...

  • Page 94: First Confirmation

    11-1. First Confirmation 11-1-3. Operation Which is not a Trouble (Program Operation) 11-1-1. Confirmation of Power Supply For controlling the air conditioner, the program Confirm that the power breaker operates (ON) operations are built in the microcomputer as normally. described in the following table. If a claim is made for running operation, check 11-1-2.
  • Page 95 11-2. Primary Judgment To diagnose the troubles, use the following methods. 1) Judgment by flashing LED of indoor unit 2) Self-diagnosis by service check remote controller 3) Judgment of trouble by every symptom Firstly use the method (1) for diagnosis. Then, use the method (2) or (3) to diagnose the details of troubles. For any trouble occurred at the outdoor unit side, detailed diagnosis is possible by 6-serial LED on the control P .C.
  • Page 96 11-4. Self-Diagnosis by Remote Controller (Check Code) 1. If the lamps are indicated as shown B to E in Table 11-3-1, execute the self-diagnosis by the remote controller. 2. When the remote controller is set to the service mode, the indoor controller diagnoses the operation condition and indicates the information of the self-diagnosis on the display of the remote controller with the check codes.
  • Page 97 11-4-2. Check Code 1. After servicing, push the START/STOP button to return to the normal mode. 2. After servicing by the check code, turn off breaker of the power supply, and turn on breaker of the power supply again so that memory in the microcomputer returns the initial status. However, the check codes are not deleted even if the power supply is turned off because they are stored in the fixed memory.
  • Page 98 Block distinction Operation of diagnosis function Judgment and action Check Check Block Cause of operation conditioner Remarks code code status Outdoor P .C. Inverter over-current All off Displayed when Even if trying operation again, all board protective circuit operates. error is detected. operations stop immediately.
  • Page 99 11-5. Judgment of Trouble by Symptom 11-5-1. Indoor Unit (Including Remote Controller) (1) Power of indoor unit does not turned on <Primary check> 1. Is the supply voltage normal? 2. Is the normal voltage provided to the outdoor unit? 3. Is the crossover cable connected properly? Operation 4.
  • Page 100 (3) Only the indoor motor fan does not operate <Primary check>  ‚ 1. Is it possible to detect the power supply voltage (AC220–240V) between on the terminal block? 2. Does the indoor fan motor operate in cooling operation? (In heating operation, the indoor fan motor does not operate for approximately 10 minutes after it is turned on, to prevent a cold air from blowing in.) Turn off power supply once, and...
  • Page 101 (4) Indoor fan motor automatically starts to rotate by turning on power supply <Cause> The IC is built in the indoor fan motor. Therefore the P .C. board is also mounted to inside of the motor. If the P .C. board is soldered imperfectly or the IC is defective, the fan motor may automatically rotate by turning on power supply.
  • Page 102 (5) Troubleshooting for remote controller <Primary check> Check that A or B selected on the main unit is matched with A or B selected on the remote controller. The unit does not beep at all. Push the START/STOP button. Operation lamp on indoor unit is not indicated.
  • Page 103 11-5-2. Wiring Failure (Interconnecting and Serial Signal Wire) (1) Outdoor unit does not operate ‚ ƒ 1) Is the voltage between of the indoor terminal block varied? 2) Confirm that transmission from indoor unit to outdoor unit is correctly performed based upon the following diagram.
  • Page 104 Service Support Function (LED Display, Switch Operation) 1. Outline A various setup and operation check can be performed by DIP switches at 2 positions (SW801, SW802) and the pushdown button switches (SW800) on the outdoor control P .C. board MCC-5071. Operation part Part No.
  • Page 105 11-6. Trouble Diagnosis by Outdoor LED For the outdoor unit, the self-diagnosis is possible by LED (Green) and five LEDs (Red). LED (Green)(D800) and LEDs (Red)(D801 to D805) are provided on the control P .C. board MCC-5071. 1. If there is an error, LED (Red or Green) goes on or flashes according to the error as described in the below table. 2.
  • Page 106 Check Outdoor Check and troubleshooting code LED display (Item without special mention indicates part of outdoor unit.) llll ¡ [07] [Case thermo operation, Power supply error ] Is AC mains voltage correct? Confirm power supply (198 to 264V) construction. etc. Are CN609 of P.C.
  • Page 107 Check Outdoor Check and troubleshooting code LED display (Item without special mention indicates part of outdoor unit.) There is a possibility that it is one of the following errors. [18] Confirm LED on outdoor P .C. board to judge which error it is. Heat exchanger temp.
  • Page 108 Check Outdoor Check and troubleshooting code LED display (Item without special mention indicates part of outdoor unit.) There is a possibility that it is one of the following errors. [1C] Confirm LED on outdoor P .C. board to judge which error it is. Compressor system error, Compressor lock, Gas side temp.
  • Page 109 Check Outdoor Check and troubleshooting code LED display (Item without special mention indicates part of outdoor unit.) ¡¡¡¡ [1C] [A room gas side temp. sensor (TGa) error] (Continued) Is connection of CN604 Correct connector. on P.C.B MCC-5071 correct? Sensor error → Replace. Is resistance value of TGa sensor correct? Check outdoor P.C.B.
  • Page 110 Check Outdoor Check and troubleshooting code LED display (Item without special mention indicates part of outdoor unit.) ¡¡ ¡¡ [1C] [Communication error between MCUs] ¡ ¡¡¡ (Continued) Are connections of CN802 on P.C.B MCC-5071 Correct connection. and CN802 on P.C.B MCC-1571 correct? Check outdoor P.C.
  • Page 111 Check Outdoor Check and troubleshooting code LED display (Item without special mention indicates part of outdoor unit.) ¡¡ ¡ [1F] [Compressor break down] Is AC mains voltage correct? Check wiring construction. (198 to 264V) Ask repair of power supply. Is wire connection correct? Compressor lead Check wire connection (Board side, Compressor Side),...
  • Page 112 Check Outdoor Check and troubleshooting code LED display (Item without special mention indicates part of outdoor unit.) ¥ ¡ [20] [PMV error for D room] (Continued) Repair defective position. Is PMV under correct conditions? Replace defective part. Error Check temp. sensor of D room indoor unit? Correct connector.

  • Page 113: Troubleshooting

    11-7. Troubleshooting 11-7-1. How to Check Whether the Air Purifier is Good or Not Turn off the power breaker once, and turn on again after 10 seconds. Does the OPERATION indicator flash? To item “Power supply is not turned on” Turn off the power breaker and remove CN401 (Micro switch connector).
  • Page 114 11-8. Inspection of the Main Parts 11-8-1. Inspection of the P.C. Board (Indoor Unit) CAUTION (1) Operating precautions 1) When removing the front panel or the P.C. board, be sure to shut off the power supply breaker. 2) When removing the P .C. board, hold the edge of the P.C. board and do not apply force to the parts. 3) When connecting or disconnecting the connectors on the P .C.
  • Page 115 (3) Check procedures Table 11-8-1 Procedure Check points Causes Turn off the power supply breaker Check whether or not the fuse (F01) Impulse voltage was applied or the and remove the P.C. board is blown. indoor fan motor short-circuited. assembly from electronic parts base.
  • Page 116 11-8-2. P.C. Board Layout +12V IC801 DB01 T101 [1] Sensor characteristic table : Discharge temp. sensor : Room temp. sensor TC, TCj : Heat exchanger temp. sensor : Outdoor temp. sensor : Outdoor heat exchanger temp. sensor : Suction temp. sensor TGa to TGe : Gas side temp.
  • Page 117 11-8-3. Indoor Unit (Other Parts) Part name Checking procedure Room temp. (TA) sensor Disconnect the connector and measure the resistance value with tester. Heat exchanger (TC) sensor (Normal temp.) Heat exchanger (TCj) sensor Temperature 10°C 20°C 25°C 30°C 40°C Sensor TA, TC, TCj (k:) 20.7 12.6...
  • Page 118 11-9. How to Simply Judge Whether Outdoor Fan Motor is Good or Bad 1. Symptom • Outdoor fan motor does not rotate. • Outdoor fan motor stops within several tens seconds though it started rotating. • Outdoor fan motor rotates or does not rotate according to the position where the fan stopped, etc. Remote controller check code “02 : Outdoor block, 1A : Outdoor fan drive system error”...
  • Page 119 <MCC-1571> Electrolytic capacitors Reactor connecting connectors (760μF/400V) Lead wire for grounding P09 (Black) Power supply connecting lead wire P01 (Red) P02 (White) Compressor Compressor Compressor Power supply protective fuse output terminals output terminals output terminals F01 (250V, 25A) CN200 CN200 CN200 CN201 CN201...
  • Page 120 <MCC-5071> Power supply Indoor/Outdoor communication wire connecting connector Protective fuse CN01 (Red) F01 (250V, 3.15A ,plastic case) Indoor/Outdoor communication signal LED Lead wire for Indoor/ D502, D511, D517, D524, D531 Outdoor communication (Orange,Indoor → Outdoor) P01 (Yellow) D501, D508, D515, D520, D527 P02 (Red) (Green,Outdoor →...

  • Page 121: How To Replace The Main Parts

    12. HOW TO REPLACE THE MAIN PARTS 12-1. Indoor Unit WARNING Since high voltages is applied to electrical parts, turn off the power without fail before starting replacement work. After repairs have been completed and the front panel and cabinet have been attached, perform test run and check for smoke, unusual sound, and other abnormalities.
  • Page 122 12-1-2. Fixing Frame Assembly 12-1-3. Electric Parts Cover Detached 1) Detach the two air filters. 1) Perform work of Detachment 12-1-1. Removing the Front Panel and Moving Panel. 2) Disconnect the plasma ion charger connector and the earth lead (black). (The earth lead is 2) Remove the screw beside the screw that se- connected to the heat exchanger with a screw.) cures the electric parts box assembly.
  • Page 123 12-1-4. Microcomputer P.C. Board 12-1-5. Louver 1) Remove the electric parts cover screw. 1) Open the moving panel, and support it with the panel support. 2) Detach the metal electric parts cover. 2) Open the vertical air flow louver. 3) Disconnect the connectors from the P .C. board. 3) Insert a flathead screwdriver into the gap of the 4) Disconnect the solderless terminals from the P .C.
  • Page 124 12-1-6. Heat Exchanger 12-1-7. Fan Motor 1) Perform work of Detachment 12-1-1. Removing 1) Perform work of Detachment 12-1-1. Removing the Front Panel and Moving Panel and the Front Panel and Moving Panel and 12-1-2. Fixing Frame Assembly. 12-1-3. Electric Parts Cover Detached. 2) Remove the pipe holder at the rear of the unit.
  • Page 125 12-1-8. Cross Flow Fan 1) Perform work of Detachment 11-1-1. Removing Keep 27mm distance between the support shaft at the rear centre of the unit and the immediate the Front Panel and Moving Panel and 11-1-2. right joint-section of the cross flow fan. Fixing Frame Assembly.
  • Page 126 12-2. Plasma Ion Charger 12-2-3. High-voltage Power Supply Unit and Discharger Unit 12-2-1. Common Procedure 1) Perform work of Detachment 12-1-1. Removing 1) Perform work of Detachment 12-1-1. Removing the Front Panel and Moving Panel. the Front Panel and Moving Panel for the indoor 2) Disconnect the 4P connector on the high-voltage unit.
  • Page 127 12-3. Outdoor Unit Part name Procedure Remarks CAUTION Common Front panel procedure Never forget to put on the gloves at working time; otherwise an injury will be caused by the parts etc. 1. Detachment 1) Stop operation of the air conditioner, and turn off the switch of the breaker.
  • Page 128 Part name Procedure Remarks 1. Detachment Discharge port cabinet 1) Perform work of Detachment 1 of 2) Take off screws for the discharge port cabinet and the partition plate. (ST1T Ø4 × 8, 3 pcs.) Heat exchanger 3) Take off screws for the discharge port cabinet Fin guard Motor base and the bottom plate.
  • Page 129 Part name Procedure Remarks Inverter 1) Perform works Detachment 1 of 1 and 3 . Inverter fixed board Fixing assembly screw WARNING Never disassemble the inverter until 5 minutes after the power supply was turned off because there is a fear that an electric shock may occur. NOTE) When working, be sure to use the insulate tools and put on the insulated gloves.
  • Page 130 Part name Procedure Remarks Inverter 8) Remove the soundproof plate (upper). Soundproof plate (upper) assembly 9) Remove the terminal cover of the compressor (Continued) and then remove the compressor lead of the compressor. 10) Pull up the inverter assembly and then remove it. Reactor cover side Compressor lead Case thermo...
  • Page 131 Part name Procedure Remarks CDB P .C. board 1) Perform works of Detachment 1 of 1 and 4) Power supply Terminal relay connector connector CDB P.C. board CAUTION Never disassemble the inverter until 5 minutes after the power supply was turned off because there is a fear that an electric shock may occur.
  • Page 132 Part name Procedure Remarks DI P .C. board 7) Remove the earth wire of DI P .C. board. Fixing screws Earth screw (Truss head B tight screw Ø4 × 6, 1 pc.). (Continued) for element 8) Take off fixing screws for DI P .C. board. (7 positions) (Flange nut to fix element Ø3 ×...
  • Page 133 Part name Procedure Remarks 1. Reactor to be attached to the inverter Replacement Reactor cover Reactor of reactor assembly relay connector 1) Perform works of Detachment 1 of 2) Remove the relay connector of the reactor. 3) Remove the reactor cover. (Truss head B tight screw Ø4 ×...
  • Page 134 Part name Procedure Remarks Fan motor 1) Perform works of Detachment 1 of 1 and 2 . Propeller fan 2) Take off flange nut which fixes the fan motor and the propeller fan. Loosened by Loosened by Loosened by The flange nut is loosened by turning it clockwise. turning clockwise turning clockwise turning clockwise...
  • Page 135 Part name Procedure Remarks 1. Removal of defective compressor Compressor assembly 1) Perform work of Detachment 1 of 2) Recover the refrigerant gas from the outdoor unit. 3) Perform works of 4) Remove the soundproof plate and TD sensor. 5) Take off fixing screw for the anchor board and the partition plate.
  • Page 136 Part name Procedure Remarks 1. Detachment Fan guard 1) Perform works of Detachment 1 of Discharge Bell mouth port cabinet CAUTION Work on the cardboard, cloth, and etc. in order to prevent damage on the product. 2) Take off the discharge port cabinet and put it as the fan guard side directs downward.
  • Page 137 Part name Procedure Remarks Attachment 4-way valve coil Mount 4-way valve coil so that the label side directs upper side of the cabinet. Detail A Detail A Detail A Detail A 4-way valve unit 4-way valve unit 4-way valve unit Label Label Label...
  • Page 138 Part name Procedure Remarks Attachment TE sensor (Outdoor heat Mount TE sensor on the straight part of the exchange condenser discharge port pipe so that the lead Detail F temperature) wire directs upward and the sensor directs the liquid store tank. Detail C Attachment TS sensor...
  • Page 139 Part name Procedure Remarks Attachment TG sensor TGe: Black Mount these sensors on the directly arranged TGd: Blue part of the header connecting pipe at gas side TGc: Green so that the cabinet turns toward the front side TGb: Red and the sensors turn toward upper cabinet.
  • Page 140 Part name Procedure Remarks Bind TS sensor, TE sensor and TO sensor with Sensor wiring Inverter fixing board process the bundling band. Pass TE sensor and TO sensor through upper (Continued) part of the inverter fixing board and then bind them with the bundling band.

  • Page 141: Exploded Views And Parts List

    13. EXPLODED VIEWS AND PARTS LIST 13-1. Indoor Unit RAS-M10PKVP-E, RAS-M13PKVP-E, RAS-M16PKVP-E, RAS-M18PKVP-E 214, 215 238 234 221, 222, 223 212, 213 The parts in the following parts list are conformed to RoHS. Therefore be sure to use the following parts for repairing and replacing.
  • Page 142 13-2. Microcomputer P.C. Board RAS-M10PKVP-E, RAS-M13PKVP-E, RAS-M16PKVP-E, RAS-M18PKVP-E 417, 418, 419, 420 The parts in the following parts list are conformed to RoHS. Therefore be sure to use the following parts for repairing and replacing. Location Part Location Part Description...
  • Page 143 13-3. Outdoor Unit 49 Holder, Sensor, 9.52, TE, TG 50 Holder, Sensor, 9.52, TD 51 Holder, Sensor, 12.7, TG 42 35 53 36 32 33 39, 40 23, 24 14, 17, 20 (O.D.6.35mm) 15, 18, 21 (O.D.9.52mm) 28, 29 12, 47 (O.D.9.52mm) 13, 46, 48 16, 19, 22...
  • Page 144 43196113 Bushing 4314N025 Coil, PMV, UKV-A038 4301L506 Mark, TOSHIBA, IMS No. 24 Coil, P.M.V. : For standardization of the servicing parts, one type only is provided. Therefore, color of the connector may be different in replacement work. – 144 –...
  • Page 145 13-4. Inverter Assembly RAS-5M34UAV-E The parts in the following parts list are conformed to RoHS. Therefore be sure to use the following parts for repairing and replacing. Location Part Location Part Description Description 43160610 Terminal Block, 9P (A) 43155188 Reactor, CH-56-2Z-T 43160611 Terminal Block, 9P (B) 43160589...
  • Page 146 TOSHIBA CARRIER CORPORATION 23-17, TAKANAWA 3 CHOME, MINATOKU, TOKYO, 108-8580, JAPAN Copyright © 1999 to 2009 TOSHIBA CARRIER CORPORATION, ALL Rights Reserved. – 3 –...

This manual is also suitable for:

Ras-m13pkvp-eRas-m10pkvp-eRas-m18pkvp-eRas-5m34uav-eRas-5m34uav-e1

Table of Contents
