Summary of Contents for Philips AZ127
Page 1
Always there to help you Register your product and get support at www.philips.com/support AZ127 Question? Contact Philips User manual...
Page 2
Release notes This user manual has the following changes compared with V1.0 user manual: Operation power consumption changes to 10W. The dimension(W x H x D) of the CD sound machine is updated to 300 x 134 x 240 mm. The weight of the CD sound machine is updated to 1.5 kg.
Contents 1 Important Mains fuse 2 Your CD Soundmachine Introduction What's in the box Overview of the main unit 3 Get started Connect power Turn on Turn off 4 Play Play a CD Play from an external device Play tape Tune to FM radio stations 5 Play options Control play...
1 Important • CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. • The unit shall not be exposed to dripping • Read these instructions. or splashing. • Follow all instructions. • Do not place any sources of danger on •...
2 Your CD What's in the box Soundmachine Check and identify the contents of the package: • CD sound machine • Power plug • Short User Manual Introduction With this CD Soundmachine, you can: • listen to FM radio; • enjoy audio from discs, tapes, and other external audio devices;...
Overview of the main unit e OPEN•CLOSE a DBB • Open or close the disc compartment. • Turn dynamic bass boost on/off. f Tape controls b REPEAT • • Play a track or all tracks repeatedly. Start tape play. • Fast rewind or fast forward the tape.
Page 7
g SHUFFLE • Play tracks randomly. h PROG • Program the play sequence of tracks. • Skip to the previous or next track. • Search within a track. j Display panel • Display current status. k FM antenna • Improve FM reception. l TUNING +/- • Tune to FM radio stations.
Always follow the instructions in this chapter in sequence. If you contact Philips, you will be asked for the Option 2: Battery power model and serial number of your apparatus. The model number and serial number are on the bottom of your apparatus.
4 Play Turn on Press . » When the source selector is in the AUDIO-IN/CD position, displayed. Play a CD Switch to standby mode Note • The unit switches to standby mode automatically when there is no audio • You cannot play CDs encoded with copyright detected for over 15 minutes.
Play from an external device Play tape Note You can also listen to an external audio device through this unit. • The unit will turns off automatically after an elapsed time of inactivity at tape mode. Switch the source selector to AUDIO-IN/ Slide the source selector to TAPE.
5 Play options Tune to FM radio stations Note • For optimal reception, fully extend and adjust the position of the FM antenna. Control play Switch the source selector to FM. In CD mode, you can control play through the Rotate TUNING to select a station.
Press to stop playback. Press PROG to activate the program mode. » [PROG] (program) begin to blink. Press to select a track number, then press PROG to confirm. Repeat steps 3 to program more tracks. Press to play the programmed tracks. » During play, [PROG] (program) is displayed.
6 Product Tape deck information Frequency response 125 - 8000 Hz (8 dB) - Normal tape (type I) Signal-to-noise ratio 35 dBA - Normal tape (type I) Note Wow and flutter ≤ 0.4% • Product information is subject to change without prior notice. General Power supply 220-240V~, Specifications 50/60 Hz; - AC Power 9 V, 6 x 1.5 V - Battery type: R14/UM2/C...
After prolonged use, dirt or dust may Never remove the casing of this device. accumulate at the disc lens. To ensure good play quality, clean the disc lens with Philips To keep the warranty valid, never try to repair CD lens cleaner or any commercially the system yourself.
Page 15
• Wait until the moisture condensation at the lens has cleared. • Replace or clean the disc. • Use a finalized CD or correct format disc. Poor radio reception • Increase the distance between the unit and your TV or VCR. • Fully extend the FM antenna.
8 Notice packaging materials, exhausted batteries and old equipment. This apparatus includes these labels: This product complies with the radio interference requirements of the European Community. Class II equipment symbol Any changes or modifications made to this device that are not expressly approved by WOOX Innovations may void the user’s authority to operate the equipment.
