- Page 1 AIR CONDITIONER (SPLIT TYPE) Owner’s Manual Indoor Unit Model name: Ceiling Type RAV-SM564CT-E RAV-SM804CT-E RAV-SM1104CT-E RAV-SM1404CT-E English Owner’s Manual...
-
Page 2: Table Of Contents
Toshiba Carrier Corporation or, alternatively, he or she has been instructed in such matters by an individual or individuals who have been trained and is thus thoroughly acquainted with the knowledge related to this work. -
Page 3: Precautions For Safety
Owner’s Manual Owner’s Manual Ceiling type Ceiling type Precautions for Safety Warning indications on the air conditioner unit The manufacturer shall not assume any liability for the damage caused by not observing the description of this Warning indication Description manual. WARNING WARNING WARNING... - Page 4 Owner’s Manual Owner’s Manual Ceiling type Ceiling type – 3 – Operation CAUTION • Before opening the intake grille of the indoor unit or service panel of the outdoor unit, set the circuit breaker to the OFF position. Failure to set the circuit breaker to the OFF position may result in electric shocks through contact with To disconnect the appliance from the mains supply.
-
Page 5: Part Names
Owner’s Manual Owner’s Manual Ceiling type Ceiling type Part Names Information on the transportation, handling and storage of the carton Indoor unit ◆ Examples of indication on the carton Horizontal louver / Vertical grille / Air discharge Symbol Description Symbol Description The air discharge direction can be changed. -
Page 6: Wired Remote Controller
Owner’s Manual Owner’s Manual Ceiling type Ceiling type – 5 – Wired Remote Controller This remote controller can control the operation of up to 8 indoor units. Display section In the display illustration below all the icons are shown. When the unit is in operation, only relevant icons will be displayed. -
Page 7: Correct Usage
Owner’s Manual Owner’s Manual Ceiling type Ceiling type Correct Usage Operation section Push each button to select a desired operation. When the air conditioner is used for the first time or when the setting is changed, follow the steps below. Settings •... -
Page 8: Timer Operation
Owner’s Manual Owner’s Manual Ceiling type Ceiling type – 7 – Timer Operation NOTE Auto Changeover • Three timer modes are available: (Setting of up to 168 hours is enabled.) • During Auto Mode, the unit selects the operating mode (cooling, heating or fan only) based on the user set point Off timer : The unit stops when the set time is reached. -
Page 9: Adjustment Of Wind Direction
Owner’s Manual Owner’s Manual Ceiling type Ceiling type Adjustment of Wind Direction ◆ How to start swinging ◆ Unit select button • When multiple indoor units are controlled with one Push , set the louver (adjustment plate For best cooling and heating performance, adjust the remote controller, wind direction can be set for each of up / down wind direction) direction to the louvers (adjustment plates of up / down wind direction) -
Page 10: Power Saving Mode
Owner’s Manual Owner’s Manual Ceiling type Ceiling type – 9 – Power Saving Mode Push TIME buttons, to adjust the power saving mode setting. • Each push of the button changes the power level by 1 % within the range from 100 % to 50 %. •... -
Page 11: Maintenance
Owner’s Manual Owner’s Manual Ceiling type Ceiling type Maintenance ◆ Check periodically • If the unit is used for a long time, parts may deteriorate and cause malfunction or bad drainage of dehumidified water depending on the heat, humidity, or dust. WARNING •... -
Page 12: Troubleshooting
Owner’s Manual Owner’s Manual Ceiling type Ceiling type – 11 – Troubleshooting Confirmation and check Confirmation of error log When an error occurred in the air conditioner, an error When an error occurred on the air conditioner, the error Check the points described below before requesting repair. code and indoor UNIT No. -
Page 13: Operations And Performance
Owner’s Manual Owner’s Manual Ceiling type Ceiling type Operations and Performance ▼ Attention to snowfall and freeze on the outdoor unit • In snowy areas, the air intake and air discharge of the outdoor unit are often covered with snow or frozen up. If snow or freeze on the outdoor unit is left as it is, it may cause machine failure or poor warming. -
Page 14: Installation
Cooling Heating such place, noise transmitted from the air conditioner affects the operation of these appliances. RAV-SM564CT-E • Do not install the air conditioner near a high frequency appliance (sewing machine or massager for business use, RAV-SM804CT-E etc.), otherwise the air conditioner may malfunction. -
Page 15: Declaration Of Conformity
Manufacturer: Toshiba Carrier Corporation 336 Tadehara, Fuji-shi, Shizuoka-ken 416-8521 JAPAN Authorized Nick Ball Representative / Toshiba EMEA Engineering Director TCF holder: Toshiba Carrier UK Ltd. Porsham Close, Belliver Industrial Estate, PLYMOUTH, Devon, PL6 7DB. United Kingdom Hereby declares that the machinery described below:... - Page 16 (Name of the manufacturer) TOSHIBA CARRIER CORPORATION 336 Tadehara, Fuji-shi, Shizuoka-ken (Address, city, country) 416-8521 Japan (Name of the Importer / Distributor in EU) Toshiba Carrier UK Ltd. Porsham Close, Belliver Industrial Estate, PLYMOUTH, (Address, city, country) Devon, PL6 7DB. United Kingdom...
