System Configuration and order-information Guide
TX200 S2
January 2006

Advertisement

loading

Related Manuals for Fujitsu Primergy TX200 S2

Summary of Contents for Fujitsu Primergy TX200 S2

  • Page 1 ® System Configuration and order-information Guide TX200 S2 January 2006...

  • Page 2: Front View

    PRIMERGY TX200 S2 Front View 5 inch Bay CD-ROM Drive Floppy Disk Drive Hard Disk Bay Inside View Back View Power Supply DIMM Slot Keyboard Mouse Serial Port 5 inch Bay Display 10/100/1000 Base T Connector Parallel Port PCI Slot...
  • Page 3 PRIMERGY TX200 S2 Instruction This document contains basic product and configuration information that will enable you to configure your system. Only these tools will ensure a fast and proper configuration of your PRIMERGY server or your complete PRIMERGY Rack system.
  • Page 4 PRIMERGY TX200 S2 Disk array configuration Physical pack A collection of physical HDDs composing a RAID. Logical drive The logical drive (e.g. D: ) as seen by the Operating System. Partition One of the logical access units into which a logical drive is divided...
  • Page 5 PRIMERGY TX200 S2 RAID Controller / SCSI Controller Restrictions and Notes of RAID Controller Card Here are the restrictions and notes of RAID Controller Cards. Please be sure to use products along with these conditions as follows; [PG-140D1] 1. One Controller Card can be mounted in a server 2.
  • Page 6 PRIMERGY TX200 S2 Memory OS Compatibility List Memory Capacity Windows Server 2003, Standard Edition Windows Server 2003, Enterprise Edition 32GB 32GB Windows Server 2003, Standard x64 Edition Windows Server 2003, Enterprise x64 Edition Windows® 2000 Server Windows® 2000 Advanced Server Windows®...
  • Page 7 PRIMERGY TX200 S2 Data Sheet Type Dual-Processor Tower Server Base Units Xeon 3EGHz/2M 512MB 73GB PGQT2023G Xeon 3.2EGHz/2M 512MB PGQT2025A Xeon 3.6EGHz/2M 512MB PGQT2027A Frequencies 64-bit Intel® Xeon® 3.60EGHz/3.20EGHz/3EGHz Second-Level-Cache Multi Processor 1 (Max. 2) Front-Side-Bus 800MHz Chipset Intel® E7320...

  • Page 8: Configuration Diagram

    PRIMERGY TX200 S2 Configuration Diagram 5 inch Bay 3 Power Supply Unit Hard Disk 3.5inch Bay (hot plug) 5 inch Bay 2 Standard Drive Cage 5 inch Bay 1 CD-ROM Drive / FDD Bay 6 Bay 5 Bay 4 Bay 2...
  • Page 9 PRIMERGY TX200 S2 Connection Table Form factor conversion (Pedestal to Rackmount) Rack Conversion kit for TX200S2 (Pedestal to Rackmount (4U)) PG-R1CK18 Max: 2 CPU Processor Xeon 3.0GHz/2MB PG-FG232 Slot *. This option is available when the processor of the base unit is Processor Xeon 3.0GHz/2MB.
  • Page 10 HDD, Backup Device (Wide/Narrow) Ultra320 B If you would like to order internal HDDs and internal backup devices, please order optional cards/cables according to the following table. Type of HDD connection Internal Backup Devices PRIMERGY TX200 S2 Connection Drive Cage Interface...
  • Page 11 PRIMERGY TX200 S2 Internal backup device Max: 2 devices Onboard SCSI Controller (Wide) Tape Drv DAT72 36GB internal PG-DT501 SCSI Cable 1.54m PG-CBLS023 Tape Drv LTO2 Ultrium2 200GB PCI Bus PG-LT201 SCSI Ctrl U160 PG-128 Tape Drv VXA-2 80GB PG-VX201 If you would like to order internal backup devices, please order necessary SCSI cards/SCSI cables according to the following table.
  • Page 12 PRIMERGY TX200 S2 LAN Card (Standard PCI Slot) Eth. Ctrl 1000-BASE-SX Fibre LC Multi Mode Fibre Channel Cable PG-1882 PCI Bus Eth. Ctrl 1000-BASE-T Cu Twist Pair Cable PG-1892 *for PCI-X Eth. Ctrl 2x 1000-BASE-T Cu PG-1862 *Dual port Eth. Ctrl 1000-BASE-T Cu...
  • Page 13 PRIMERGY Rackmount 19 inch Rack Standard Rack 40U Standard Rack 40U and Rack Coupling kit PG-R6RC1 PG-R6RC2 Standard Rack 24U Standard Rack 24U and Rack Coupling kit PG-R4RC3 PG-R4RC4 Stabilizer PG-R3ST1 Product Name Product ID No. of units required W x D x H Cooling Weight Installable Weight...
  • Page 14 Product ID PG-R4RC3 24U + 2U PG-R4RC4 Rack Conversion kit for TX150 S2/S4 PRIMERGY TX150 S2 (PG-R1CK15) Rack Conversion kit for TX200 S2 PRIMERGY TX200 S2 (PG-R1CK18) Base Unit PRIMERGY TX200FT S2 ○ ○ PRIMERGY RX100 S3 ○ PRIMERGY RX200 S2 ○...
  • Page 15 PRIMERGY Rackmount Hard Disk Cabinet TX200 S2 RX600 S2 TX150 S2 RX300 S2 RX200 S2 RX100 S3 PRIMERGY SX30 RH PG-R1DC7 PCI Bus PCI Bus RAID Ctrl 2-channnel SCSI cable *MAX. 14 HDDs PG-142E3 PG-CBLS004 (2m) RX600 S2 TX200 S2 RX300 S2 PGB142E3 (for CTO) PG-CBLS005 (5m)
  • Page 16 PRIMERGY Rackmount Internal Backup Devices with PRIMERGY SX10 TX200 S2 RX600 S2 TX150 S2 RX300 S2 RX200 S2 RX100 S3 for 1st server PCI Bus for 2nd server SCSI Ctrl U160 SCSI Cable HDCI 1.5m : PG-CBLS001 PRIMERGY SX10 *1 TX200 S2 RX600 S2 PG-128...
  • Page 17 Specifications are subject to change without notice. For the latest detailed information, contact your local representative. All brand names and product names are trademarks and registered trademarks of their respective holders. ©2006 Fujitsu Limited. All rights reserved. Printed in Japan. Global Business Development & Marketing Business Strategy &...
