Base View - Acer Aspire Series Quick Manual

10
Information on USB 3.0
•
Defined by the USB 3.0 (SuperSpeed USB) specification.
•
Devices without USB 3.0 certification may not be compatible.

Base view

# Icon Item
1 Battery bay
Battery release latch/
2
lock
Memory compartment Houses the computer's main memory.
3
Hard disk bay
Environment
•
Temperature:
•
Operating: 5 °C to 35 °C
•
Non-operating: -20 °C to 65 °C
•
Humidity (non-condensing):
•
Operating: 20% to 80%
•
Non-operating: 20% to 80%
1
2
Description
Houses the computer's battery pack.
Releases the battery for removal.
Insert a suitable tool into the latch and slide
to release.
Houses the computer's hard disk (secured
with screws).
3
