- Page 1 DDX155 DDX1035 DDX1035M MONITOR WITH DVD RECEIVER INSTRUCTION MANUAL © 2013 JVC KENWOOD Corporation B5A-0028-00/01 (M2)
-
Page 2: Table Of Contents
Contents Before use ........... 3 How to reset your unit ..........3 INTRODUCTIONS Overview Of The Main Unit ....5 Overview Of The Remote Control ..6 Setting the clock ......... 8 AV SOURCE OPERATIONS Selecting the playback source ..9 Disc operations .........10 Inserting a disc .............10 Ejecting a disc ...............10... -
Page 3: Before Use
Before use WARNINGS: Temperature inside the car... (To prevent accidents and damage) If you have parked the car for a long time in hot or cold weather, wait until the • DO NOT install any unit or wire any cable in temperature in the car becomes normal a location where; before operating the unit. – it may obstruct the steering wheel and gearshift lever operations. How to reset your unit – it may obstruct the operation of safety devices such as air bags. - Page 4 The marking of products using lasers The label is attached to the chassis/case and says that the component uses laser beams that have been classified as Class 1. It means that the unit is utilizing laser beams that are of a weaker class. There is no danger of hazardous radiation outside the unit. English...
-
Page 5: Introductions Overview Of The Main Unit
INTRODUCTIONS Overview Of The Main Unit Screen (Touch panel) Monitor panel 7 USB input terminal 1 Loading slot 8 iPod/AV IN2 input terminal 9 Remote sensor (Eject) button • Ejects the disc. 3 Reset button/Power indicator indicator • Resets the unit. (+ page 3) • Lights up while the unit is turned on. MENU button • Turns off the power. (Hold) • Turns on the power. (Press) • Displays the <Top Menu> screen. (Press) 5 AUD button • Displays the <Equalizer> screen. -
Page 6: Overview Of The Remote Control
Overview Of The Remote Control CAUTION • Keep battery out of reach of children and in original package until ready to use. Dispose of used batteries promptly. If swallowed contact physician immediately • Do not leave the battery near fire or under direct sunlight. A fire, explosion or excessive heat generation may result. • Do not set the remote ontrol in hot places such as on the dashboard. • The Lithium battery is in danger of explosion if replaced incorrectly. Replace only with the same or equivalent type. How to install the battery • Aim the remote control directly at the remote sensor on the faceplate. • DO NOT expose the remote sensor to bright light (direct sunlight or artificial lighting). - Page 7 Button Operations Button Operations Turns the power on/off. Exits from the menu. MENU Displays the top menu Mutes/restores the screen. sound. 5/∞/2/3 Selects an item. SOURCE Selects a source. ENTER Confirms the selection. LIST Displays the item list for the selected source. VOLUME +/− Adjusts the volume level. Stops playback.
-
Page 8: Setting The Clock
Setting the clock 1 Display the <Top Menu> screen. 5 Select the hour or minute. On the source control screen: 6 Set the clock time. 2 Display the <SETUP> screen. 7 Finish the procedure. 3 Display the <General> screen. 4 Display the <Clock> screen. English... -
Page 9: Av Source Operations Selecting The Playback Source
AV SOURCE OPERATIONS Selecting the playback source DISC (+ page 10) Plays a disc. TUNER (+ page 22) Switches to the radio broadcast. Plays an iPod/iPhone. iPod * (+ page 19) USB (+ page 16) Plays files on a USB device. AV IN1/AV IN2 * Switches to an external component connected to AV IN1 and (+ page 23) iPod/AV IN2 input terminals. Select an appropriate input setting on <AV IN SETUP>. ( page 28) Displaying the source control screen On video playback screen • The operation buttons disappear by touching the screen. -
Page 10: Disc Operations
Disc operations Playing a disc • If a disc does not have a disc menu, all tracks on it will be played repeatedly until you change the source or eject the disc. Ejecting a disc Inserting a disc Label side • You can eject a disc when playing another AV source. • If the ejected disc is not removed within The source changes to “DISC” and playback 15 seconds, the disc is automatically starts. inserted again into the loading slot to protect it from dust. - Page 11 Playable disc types Disc type Recording format, file type, etc. Playable DVD-Video * Region Code: • For DDX155: 5 • For DDX1035: 3 • For DDX1035M: 2 DVD-Audio/DVD-ROM DVD Recordable/ DVD-Video Rewritable MPEG1/MPEG2/MPEG4 (DVD-R/-RW , +R/+RW * • DVD Video: UDF bridge JPEG • MPEG1/MPEG2/MPEG4/ MP3/WMA JPEG/MP3/WMA: ISO 9660 level 1, level 2, DVD-VR/DVD+VR/DVD-RAM/DivX/WAV/AAC Romeo, Joliet...
- Page 12 Playback operations To display the source control screen, + page 9. For DVD/VCD/MPEG1/MPEG2/MPEG4/JPEG Media type • DVD Video: Title no./Chapter no. • MPEG1/MPEG2/MPEG4: Folder no./Track no. • JPEG: Folder no./File no. • VCD: Track no. Playing time [EQ] Enters the <Equalizer> • Selects a chapter/track. settings. (+ page 24) ¢ (Press) • Reverse/forward search.* [BASS] Activates/deactivate Bass Sound. (Hold) Displays the <Set Up>...
- Page 13 For CD/MP3/WMA • MP3/WMA: Folder no./Track no. • CD: Track no. Track/file information Playing time Playback mode [EQ] Enters the <Equalizer> • Selects a track. (Press) settings. (+ page 24) ¢ • Reverse/forward search.* [BASS] Activates/deactivate Bass (Hold) Sound. Displays the <Set Up> [DIM] Activates/deactivate screen. (+ page 28) dimmer. Displays the folder/track list. [ ] * Mutes/restores the sound. (+ below) Displays the <Top Menu> [FNC] Enters the <Function> [MENU] settings.
-
Page 14: Video Menu Operations
Video menu operations • To select a title, chapter, or time directly Selects title search/ You can display the video menu screen Returns to the chapter search/ during video playback. previous screen time search • Available items on the screen differ depending on the types of the loaded disc and playback files. • The operation buttons disappear by touching the screen. – When you enter a wrong number, press [X] to delete the last entry. Press [CLR] to delete the all entry. Setting the functions For DVD Selects view angle • Each time you press the button, the... - Page 15 Setting <Repeat> For CD/MPEG1/MPEG2/MPEG4/MP3/WMA Display Playback mode Repeats current chapter. Repeats current title/ program. Repeats all title/program. Cancel all the repeat function. Setting <Video Setting> • You can change the setting for video playback. (+ page 26) • Each time you press the button, the playback mode changes. For VCD – Available items differ depending on the types of loaded disc and playback file. Setting <Repeat> Display Playback mode Repeats the current track. Folder Repeats all tracks in the Selects the audio channel current folder. (except for (Stereo/ Left/ Right) Repeats all tracks.
-
Page 16: Usb Operations
USB operations Playing a USB device Cautions: • This unit can play JPEG/MPEG1/MPEG2/ MPEG4/MP3/WMA files stored in a USB • This unit may not play back files in a mass storage class device. USB device properly when using a USB • This unit can recognize a total of 9 999 files extension cable. and 999 folders (a maximum of 9 999 files • USB devices equipped with special per folder). functions such as data security functions • Make sure all important data has been cannot be used with the unit. backed up to avoid losing the data. • Do not use a USB device with 2 or more partitions. - Page 17 • To display the source control screen, + page 9. • To change settings for video playback, + page 14. • MPEG1/MPEG2/MPEG4/MP3/WMA: Folder no./Track no. • JPEG: Folder no./File no. Track/file information (for MP3/WMA) Playing time Playback mode [EQ] Enters the <Equalizer> • Selects a track. (Press) settings. (+ page 24) ¢ • Reverse/forward search.* [BASS] Activates/deactivate Bass (Hold) Sound. Displays the <Set Up> [DIM] Activates/deactivate screen.
- Page 18 Setting the functions For photo/movie For music Activates/deactivates slide show Setting <Repeat> Setting <Repeat> Display Playback mode Display Playback mode Repeats the current track. Repeats current songs. Folder Repeats all tracks in the Folder Repeats all tracks in the current folder. current folder. Repeats all tracks. Repeats all songs. Setting <Random> Setting <Video Setting> Display Playback mode • You can change the setting for video Randomly plays all tracks.
-
Page 19: Listening To The Ipod/Iphone Device
Listening to the iPod/iPhone device Preparation Settings for iPod playback When the source is “iPod”... • Connect iPod/iPhone. (+ page 37) – When connecting iPhone/iPod touch, turn off App beforehand; otherwise the playback may not be started after connection. • Use the following cables: – To watch the video and to listen to the music (digital): USB Audio and Video cable for iPod/iPhone—KCA-iP22F (sold separately) – To listen to the music (digital): USB Audio cable for iPod/iPhone—USB 2.0 cable (accessory of the iPod/iPhone) • Select appropriate input settings on <AV... - Page 20 (+ page 28) : C ontrol playback from the iPod/iPhone.* Displays the music/video [ ] : C ontrol playback from file list. (+ page 21) the unit. Displays the <Top Menu> [MENU] Mutes/restores the sound. screen. [FNC] Enters the <Function> settings. (+ page 21) Resume playback is unavailable for video files. When using iPod with video, you can control playback only from the unit. • When you turn on this unit, the iPod/iPhone is charged through the unit. • The text information may not be displayed correctly. • For some iPod/iPhone models, the performance may be abnormal or unstable during operation. In this case, disconnect the iPod/iPhone device, then check its condition. If the performance is not improved or is slow, reset your iPod/iPhone. • For the latest compatible list and software version of iPod/iPhone, see: www.kenwood.com/cs/ce/ipod English...
- Page 21 Selecting an music/video file Setting the functions from the menu Setting <Repeat> Display Playback mode Repeats current songs. Repeats all songs. Cancel all the repeat function. 3 Select a category, then a desired item. • Select the item in the selected layer Setting <Random> until a desired file starts playing. Display Playback mode Music menu:...
-
Page 22: Listening To The Radio
Listening to the radio Indicate RDS station name (if available) Band no./the station frequency currently tuned in [EQ] Enters the <Equalizer> Searches for a station. ¢ settings. (+ page 24) • Auto Search (Press) • Manual Search (Hold) [BASS] Activates/deactivate Bass Sound. [BAND] Selects the band. [DIM] Activates/deactivate dimmer. [1] – [6] • Selects a stored station. Displays the <Set Up> (Press) screen. -
Page 23: Using Other External Components
Using other external components AV IN To display the source control screen, + page 9. [EQ] Enters the <Equalizer> settings. (+ page 24) [BASS] Activates/deactivate Bass Sound. [DIM] Activates/deactivate dimmer. Mutes/restores the sound. Displays the <Set Up> screen. (+ page 28) Displays the <Top Menu> screen. [MENU] You can connects external components to the AV IN1 and iPod/AV IN2 input terminals. Preparation: If you want to use “AV IN2”, select [AV IN2] for <AV IN SETUP> setting. (+page 28) • No preparation is required for “AV IN1”. 1 Connect external components to AV IN1 3 Turn on the connected component and and iPod/AV IN2 input terminals. -
Page 24: Sound Adjustment
Sound adjustment Using the sound equalization • You cannot adjust the sound when the unit is in standby. Selecting a preset sound 2 Adjust the level of each band. Reset to default setting mode 1 On <Top Menu>: Bass -15 dB – +15 dB Middle -15 dB – +15 dB Treble -15 dB – +15 dB The adjustments are stored and <User> is activated. 3 Select a sound mode. Storing your own adjustment Customizing preset sound mode 1 Select a sound mode. -
Page 25: Adjust Audio Setting
Adjust Audio Setting Speaker settings Subwoofer settings 1 On <Top Menu>: 1 On <Top Menu>: Activates/deactivate Reset to default Reset to default setting the subwoofer. setting To subwoofer settings To speaker settings Fader -12 – +12 Level -6 dB – +6 dB Balance -12 – +12 LPF (low 80Hz/ 120Hz/ 160Hz pass filter) English... -
Page 26: Setting For Video Playback
Setting for video playback You can change the setting for video playback. Screen adjustment Changing the aspect ratio You can adjust the picture quality. You can change the aspect ratio for video 1 Select [Video Setting]. playback. 2 Adjust the picture (00 to 08). 16:9 For 16:9 original pictures For 4:3LB original Adjusts the Adjusts the pictures brightness color For 4:3 Adjusts the Reset to original contrast default setting pictures Zooming picture You can zoom the picture (<X2>/ <X3>/... -
Page 27: Using A Rear View Camera
Using a rear view camera • To use a rear view camera, the REVERSE lead connection is required. For connecting a rear view camera, + page 36. Displaying the picture from the rear view camera The rear view screen is displayed when you shift the gear to the reverse (R) position. • To erase the caution message, touch the screen. English... -
Page 28: System Setup
♦ iPod : Select when connecting the iPod/iPhone using the USB Audio and Video cable for iPod/iPhone. (+ page 37) Beep ♦ ON : Activates the key-touch tone. ♦ OFF : Cancels. Clock Mode ♦ 12H : 12 hours. ♦ 24H : 24 hours. Clock Adjust Adjust the clock time. (+ page 8) Language Select the text language used for on-screen information. ♦ for DDX155: English/Russian for DDX1035/ DDX1035M: English/Arabic Calibration Adjust the touch position of the buttons on screen. (+ next page) English... - Page 29 Adjusting the touch position You can adjust the touch position on the touch panel if the position touched and the operation performed do not match. 1 On <SETUP>: 2 Touch the center of the marks at the 5 steps(point) for calibration. English...
-
Page 30: Reference Maintenance
REFERENCE Maintenance Caution on cleaning the unit To keep discs clean Do not use A dirty disc may not play correctly. any solvent If a disc does become dirty, wipe (for example, it with a soft cloth in a straight line thinner, benzine, from center to edge. etc.), detergent, • Do not use any solvents (for or insecticide. This may damage the monitor example, conventional record cleaner,... -
Page 31: More About This Unit
More about this unit File playback Playing MP3/WMA files • This unit can play back files with the Playing MPEG1/MPEG2/MPEG4 files extension code <.mp3> or<.wma> • This unit can play back MPEG1/MPEG2/ (regardless of the letter case—upper/ MPEG4 files with the extension code lower). <.mpg>, <.mpeg> or <.avi>. • This unit can play back the files meeting • The stream format should conform to the conditions below: MPEG system/program stream. – Bit rate: The file format should be MP@ML (Main 32 kbps – 320 kbps Profile at Main Level)/SP@ML (Simple Profile – Sampling frequency: at Main Level)/MP@LL (Main Profile at Low 8 kHz – 48 kHz Level)/ MPEG-4 SP (Simple Profile). • This unit can show ID3 Tag Version • Audio streams should conform to MPEG1 1.0/1.1/2.2/2.3/2.4 (for MP3). -
Page 32: Troubleshooting
Troubleshooting What appears to be trouble is not always serious. Check the following points before calling a service center. • For operations with the external components, refer also to the instructions supplied with the adapters used for the connections (as well as the instructions supplied with the external components). If there seems to be a problem Symptom Remedy/Cause No sound comes out of the • Adjust the volume to the optimum level. speakers. • Check the cords and connections. The unit does not work at all. Reset the unit. (+ page 3) The remote controller does not Replace the battery. work. AME automatic presetting does Store stations manually. (+ page 22) not work. Static noise while listening to Connect the antenna firmly. - Page 33 Symptom Remedy/Cause No sound comes out of the • Disconnect the iPod/iPhone, then connect it speakers. again. • Select another source and then reselect “iPod”. The iPod/iPhone does not turn • Check the connecting cable and its connection. on or does not work. • Update the firmware version. • Charge the battery. • Check whether the iPod/iPhone control mode is correctly selected. (+ page 20) • Reset the iPod/iPhone. Sound is distorted. Deactivate the equalizer either on this unit or the iPod/iPhone. A lot of noise is generated. Turn off (uncheck) the “VoiceOver” feature of the iPod. For details, visit <http://www.apple.com>. Select <iPod> for <AV IN SETUP>. (+ page 28) Sound does not synchronize with the video.
-
Page 34: Accessories/Installation Procedure
Always connect those wires to the power source running through the fuse box. • Do not cut out the fuse from the ignition wire (red) and the battery wire (yellow). The ..1 ..6 (M5x7mm) power supply must be connected to the DDX1035/DDX1035M wires via the fuse. only. DDX155 only. ¤ • Mounting and wiring this product requires skills and experience. For best safety, ..1 (2m) leave the mounting and wiring work to professionals. • Make sure to ground the unit to a negative 12V DC power supply. • Do not install the unit in a spot exposed ..1 to direct sunlight or excessive heat or humidity. - Page 35 • Connect the speaker wires correctly to the terminals to which they correspond. The unit may be damaged or fail to work if you share the · wires or ground them to any metal part in the car. • When only two speakers are being connected to the system, connect the connectors either to both the front output terminals or to both the rear output terminals (do not use one from each). For example, if you connect the ª connector of the left speaker to a front output terminal, do not connect the · connector to a rear output terminal. • After the unit is installed, check whether the brake lamps, blinkers, wipers, etc. on the car are working properly.
-
Page 36: Connecting Wires To Terminals
Connecting Wires to Terminals Audio Video input 1 (AV IN1) • Video input (Yellow) Change the FUSE location to switch • Audio left input (White) ACC and B+ pin location on the ISO • Audio right input (Red) connector. Rear Preout • Audio left output (White) • Audio right output (Red) Front Preout • Audio left output (White) Video Output • Audio right output (Red) Purple/White (Reverse... -
Page 37: Connecting A Usb Device/Ipod/Iphone
Connecting a USB device/iPod/iPhone iPod/iPhone except for iPhone 5/ iPod touch (5th Generation)/ iPod nano (7th Generation) (sold separately) KCA-iP102 (0.8 m) (Sold separately) USB terminal KCA-iP22F (0.8 m) iPod/Audio Visual (Sold separately) input 2 (iPod/AV IN2) (iPod/AV Input 2 switchable) iPhone 5/iPod touch (5th Generation)/ iPod nano (7th Generation) (sold... -
Page 38: Installing/Removing The Unit
Installing/Removing the Unit Installing the Unit (DDX155 Installing the Trim Plate only) 1 Attach accessory 4 to the unit. Bend the tabs of the mounting sleeve with a screwdriver or similar utensil and attach it in place. Removing the Trim Plate ⁄ 1 Remove accessory 4 to the unit. - Page 39 Removing the Unit (DDX155 only) 1 Remove the trim plate by referring to the removal procedure in the section “Removing the Trim Plate”. 2 Insert the two extraction keys 5 deeply into the slots on each side, as shown. (The protrusion at the tip of the extraction key must face toward the unit.) 3 Pull out the unit halfway. ⁄ • Be careful to avoid injury from the catch pins on the removal tool.
-
Page 40: Specifications
Specifications Monitor section USB interface section Picture Size USB Standard : 6.2 inches (diagonal) wide : USB 2.0 Full Speed File System 137.40 mm (W) × 77.28 mm (H) : FAT 16/32 Display System Maximum Power Supply Current : Transparent TN LCD panel : DC 5 V Drive System D/A Converter : TFT active matrix system : 24 Bit Number of Pixels Video Decoder : 1,152,000 (800H × 480V × RGB) : MPEG1/MPEG2/MPEG4 Effective Pixels... - Page 41 Installation Dimensions (W × H × D) Video Output Level (RCA jack) : 183.0 × 112.0 × 158.7 mm : 1 Vp-p/75 Ω (DDX155) 178.0 × 100.8 × 160.0 mm Video input Level (RCA jack) (DDX1035/DDX1035M) : 1 Vp-p/75 Ω Weight Color System of DVD Video Output : 2.1 kg (DDX155) : NTSC 1.9 kg (DDX1035/DDX1035M) Audio section • Although the effective pixels for the liquid Maximum Power (Front & Rear) crystal panel is given as 99.99% or more, : 40 W × 4 0.01% of pixels may not light or may light Full Bandwidth Power (Front & Rear) incorrectly.
- Page 42 • “DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation registered in the US, Japan and other countries. • Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. • Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. • “Made for iPod, ” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod or iPhone may affect wireless performance. iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple Inc., registered in the U.S.
