D-Link DWS-3160-24TC Brochure & Specs

Product Highlights
Unified Network Architecture
· Manages up to 48 D-Link Unified Access Points (192
Access Points in a cluster)
Robust Wired/Wireless Security
· With Access Control Lists, Captive Portal, Rogue AP
detection and mitigation
Seamless Mobility
· Fast roaming for continuous connectivity
Advanced switching and routing
· Support for RIP v1/v2 routing protocol
Simplified Management
· Web GUI for easy configuration
DWS-3160 Series
Gigabit Layer 2+ Unified Switches

Key Features

Interfaces
• 20x 10/100/1000Base-T ports
• 4x Combo 10/100/1000Base-T/SFP slots
• 1x Console (RJ-45) port
• 1x SD Card slot (max. 32 GB)
Managed Unified Access Points
• DWL-2600AP
• DWL-3600AP
• DWL-6600AP
• DWL-8600AP
Wireless Management
• Management of up to 12 Access Points per switch
• Upgrade licenses for up to 48 Access Points per switch
• Up to 192 APs per Switch Cluster
• Automatic AP RF Channel Adjustment
• Automatic AP Transmit Output Power Adjustment
• Centralised AP Firmware Upgrade
Overview
The DWS-3160 is D-Link's latest Unified L2+ Gigabit Wired/Wireless Switch.
Designed to be the ideal mobility solution for medium-sized and large enterprises
and service providers, the DWS-3160 empowers administrators to exercise total
control over their wireless networks by centralising all aspects of provisioning and
management. Able to manage up to 48 D-Link Unified Access Points by itself and
up to 192 in a switch cluster, the DWS-3160 can be configured to act either as a
Wireless Controller in the core network, or as an L2+ Gigabit Switch at the edge,
enabling it to be seamlessly integrated into any existing network infrastructure.
Simplified Management
The DWS-3160 is able to centralise all critical WLAN management, thereby eliminating
the need to manage Access Points (AP) individually. The administrator simply assigns a
profile to an individual D-Link Unified AP, and the configuration corresponding to that
profile would be applied onto that AP automatically. In addition, the DWS-3160 can
apply new firmware to all D-Link Unified Access Points on the network, thus greatly
simplifying the upgrade process.
Besides its wireless capabilities, the DWS-3160 also excels as an advanced L2+ switch.
Complete with RIPv1/v2 dynamic routing, ACL security, multilayer QoS, comprehensive
VLAN support, as well as Multicast Snooping capabilities, the DWS-3160 enables easy
and flexible deployment. Furthermore, multiple DWS-3160s can form a Switch Cluster,
which enables the administrator to configure all switches from one single Cluster Mas-
ter. As the size of the cluster grows, so can the number of D-Link Unified Access Points
being managed. Up to 192 D-Link Unified Access Points may be managed by the Switch
Cluster. This helps to significantly simplify management and reduce maintenance efforts
when a network is scaled up
