Hitachi CP-X4020 Specifications

CP-X4020
AMX Device Discovery
• 4,000 ANSI Lumens
• Native XGA Resolution
• 2000:1 Contrast Ratio Using
Active IRIS
• 9.2 lbs.
• 2 RGB Inputs / Composite /
S-Video
• 16W Speaker Output
Screen Size 4:3
Diagonal* Width*
30 24
60 48
80 64
100 80
120 96
150 120
200 160
300 240
Throw Ratio: 1.5 - 1.8:1 (distance : width)
*Measured in inches
For sales information, please call 800.225.1741
Printed 06.09
Closed Captioning
• Security Bar and Transition Detector
• 29 dB (Eco Mode)
• Easily Accessible Hybrid Filter
(5,000 Hours between Maintenance)
• Instant On/Off
• Audio Pass Through
• Template Function
• Power Saving Mode
Throw Distance
Min* Max*
34 41
70 83
94 112
118 140
142 168
177 211
237 281
356 422

Specifications

Model Name
Liquid Crystal Panel Structure
Number of Pixels
Resolution Video
RGB
Colors
Aspect Ratio
Lens
Throw Ratio (distance : width)
Lamp
Brightness
Expected lamp Life
Contrast Ratio
Speaker Output
Power Supply
Power Consumption
Operating Temperature
Input Signals RGB
Composite Video
Component Video
Acoustic Noise Level
H-Sync
V-Sync
Vertical Keystone
Approvals
RGB Input Analog RGB
RGB Output RGB
Video Input S-Video
Composite Video
Component Video
Audio Input
Output
Control Terminals
Dimensions (W x D x H)
Weight
Additional Features
Supplied Accessories
Lamp
Remote Control
Filter
CP-X4020 Series
0.63" polysilicon active-matrix TFT x 3
786,432 pixels
540 TV lines
1024 dots X 768 lines
16.7 million colors
Native 4:3/16:9 compatible
manual zoom x 1.2
1.5 - 1.8 : 1
260W UHB
4,000 ANSI Lumens
Approximately 2,000 hours (normal) 4,000 hours (whisper)
2000 : 1 using active IRIS
16W
AC100 - 120V / AC220 - 240V 50/60 Hz
390W
5˚C - 35˚C (41˚F - 95˚F)
VGA, SVGA, XGA, WXGA, SXGA, SXGA+, UXGA, MAC 16"
NTSC, NTSC4.43, PAL, SECAM, PAL-M, PAL-N, PAL60
480i, 480p, 576i, 576p, 720p, 1080i, 1080p
35 dB (29 dB in Eco Mode)
15 kHz - 106 kHz
50 kHz - 120 kHz
+ / - 40˚
UL, C-UL, FCC, CE, RoHS
15pin Mini-Dsub x 2
15pin Mini-Dsub x 1
Mini DIN 4-pin connector x 1
RCA jack x 1
RCA jack x 1
Stereo Mini jack x 2, RCA(L/R) x 1 pair
RCA(L/R) x 1 pair
9-pin D-sub connector x 1 (RS-232 control)
15.7" x 12.5" x 4.5"
9.2 lbs.
My Screen, My Memory, My Button, Blackboard/Whiteboard
mode, Daytime Mode, Input Source Naming(English), Reso-
lution Setting, My Text, My Source & Doc Camera Button on
Remote Control, Template, Saving Mode
Remote Control, Batteries (AA), RGB cable, US Power Cord,
Multiple language operator / Safety Manual, Security Label
CPX4020LAMP (DT01051)
HL02483
MU06641
All specifications subject to change without notice
