Section 10 “COMMANDS”. Using an external CONTROLLER or SWITCHER, etc., inputs can be switched and the power can also be turned on and off. In the following paragraphs, “CONTROLLER” means an external device such as a PC which controls projector using these commands. VPL-FE110U/FE110M...
. Half duplex (4-wire) PROJECTOR dedicated communication channels . Start/stop system bit serial word serial digital signal . Baud rate: 38.4 k, 19.2k, 9600 bps (bits per second). . Refer to “2-1. RS-232C Communication Signal” for details on the bit configuration. VPL-FE110U/FE110M...
B15 *128 + B16 Check Data Length Data Length Bn = B (16 + 1) Data (n + 1,2,3,4...) Data (n) Bm = B (16 + Total Data Length) Data B (m + 1) Check SUM B (m + 2) End Code VPL-FE110U/FE110M...
(B16 + 2 hex) Data Size Note : Error when 00,01 and 82 to FF hex codes are included. 4 Data Size (B15 *80 hex) Data Size Data Length 2 00 – 10 Note : Error when 11 to FF hex codes are included. VPL-FE110U/FE110M...
Page 9
10100101 (165) 10100101 (165) Answer 00000000 When 0XA5 (165) and 0X5A (90) are calculated by XOR ; Answer 10100101 (165) 01011010 (90) Answer 11111111 (255) 8 End Condition B (m + 2) END Code No Data in some cases VPL-FE110U/FE110M...
PJ COM again. Basic operations at PJ COM are the same. The data input to the unit once is checked that there are no errors, and is transmitted to RS-232C/422A again. The unit serves as a communication bridge. VPL-FE110U/FE110M...
Conversion tool Connector : 9 Pin D-subminiature female (D-9S) If CONTROLLER is wired with RS-232C and PROJECTOR is with RS-422A, the following connection is recommended. CONTROLLER PROJECTOR Controller Projector or Switcher signal RX DA TX DA MAX202E MAX489 ECSD MAX232E VPL-FE110U/FE110M...
System consisting of two SWITCHERs and two PROJECTORs. Projector Controller No.1 PJ COM RS-232C Projector In T Switcher No.2 RS-422A No.1 Switcher No.2 Connect CONTROLLER to the RS-232C Port of the nearest unit. Connect PROJECTOR and SWITCHER using the PJ COM Port. VPL-FE110U/FE110M...
In some cases, CONTROLLER may receive data from DEVICE even though it has not sent a command. (For example, during SYS setting, SIRCS command, and switcher information when switcher is selected.) Note : When All (00 hex) is specified for the INDEX No., return data may not be returned in some cases. VPL-FE110U/FE110M...
(value) will not be incorporated. . When INDEX specified SIRCS direct command (CMD1 = 17 hex) is transmitted, leave an interval of 45 mSec until the next transmission. (Do not return the return data (ACK, NAK) when the SIRCS direct command is received.) VPL-FE110U/FE110M...
APPROXIMATE RETURN WAITING TIMES CMD2 (hex) TIME (mSec) Note : The times shown in this table are when communication is performed one to one between CONTROLLER and DEVICE, and in the condition that it will not be interrupted by some reason. VPL-FE110U/FE110M...
00 OFF 00 NOT ERROR 00 OFF 00 NOT ERROR 00 OFF 00 NOT ERROR 01 ON 01 ERROR 01 ON 01 ERROR 01 ON 01 ERROR 01 ON 01 ERROR 02 WARNING 02 WARNING 02 WARNING 02 WARNING VPL-FE110U/FE110M...
Page 18
00 ON 01 OFF SPEAKER SETTING SENSE PROJ RETURN DATA PROJ SPEAKER 00 ON 01 OFF OSD LANGUAGE SETTING SENSE PROJ RETURN DATA PROJ OSD LANGUAGE 00 ENGLISH 01 FRENCH 02 GERMAN 03 ITALIAN 04 SPANISH 05 JAPANESE 06 CHINESE VPL-FE110U/FE110M...
Page 19
OPERATION TIME STATUS SENSE PROJ RETURN DATA PROJ DATA #1 DATA #2 DATA #3 DATA #4 SET ACTIVE TIME 4 Bytes (hour) LAMP TIMER STATUS SENSE PROJ RETURN DATA PROJ DATA #1 – DATA #4 DATA #5–8 DATA #9–12 DATA #13–16 VPL-FE110U/FE110M...
Page 20
01 S VIDEO 02 INPUT A 03 INPUT B 04 INPUT C XX (PC-3000 Channel is selectable only by SIRCS format command) COLOR SYS SETTING SELECT PROJ COLOR SYS 00 AUTO 01 NTSC 02 PAL 03 SECAM 04 NTSC443 05 PALM VPL-FE110U/FE110M...
Page 21
INPUT A 20 COMPUTER 30 COMPONENT 40 DTV-YPBPR 41 DTV-GBR INPUT B INPUT B SETTING SELECT PROJ 10 VIDEO 11 SVIDEO 20 COMPUTER 30 COMPONENT 40 DTV-YPBPR 41 DTV-GBR LENS CONTROL SETTING SELECT PROJ LENS CONTROL 00 ON 01 OFF VPL-FE110U/FE110M...
Page 22
DATA #1 DATA #2 DATA #3 REUTRN DATA PROJ BIAS R BIAS G BIAS B ACTIVE MEMORY CONTRAST DATA WRITE PROJ CONTRAST WRITE BRIGHTNESS DATA WRITE PROJ BRIGHTNESS <CMD1=32 hex> COLOR DATA WRITE PROJ COLOR HUE DATA WRITE PROJ VPL-FE110U/FE110M...
Page 23
ACTIVE COLOR DATA RESET PROJ COLOR MODE <CMD1=70 hex> 00 CONTRAST DATA SET TO 80 01 BRIGHTNESS DATA SET TO 50 02 COLOR DATA SET TO 50 03 HUE DATA SET TO 50 04 SHARPNESS DATA SET TO 50 05 ALL VPL-FE110U/FE110M...
Page 24
GP INDEX GP INDEX1 GP INDEX 2 GP INDEX 3 GP INDEX 4 GP INDEX 5 GP INDEX 6 GP INDEX 7 GP INDEX 8 GP INDEX 9 0 (ALL) DOT PHASE LENS ZOOM LENS SHIFT LENS FOCUS FUNCTION VPL-FE110U/FE110M...
