  • Page 1 NETWORK VIDEO DECODER User Manual SPD-400...

  • Page 2: User Manual

    Disclaimer Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility.

  • Page 3: Important Safety Instructions

    overview IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.
  • Page 4 overview WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PROCUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT. Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
  • Page 5 Class construction An apparatus with CLASS construction shall be connected to a MAINS socket outlet with a protective earthing connection. Battery Batteries(battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like. It is essential that when changing the battery in the unit, the replacement battery must be of the same type otherwise there may be a possibility of an explosion.
  • Page 6 overview Please read the following recommend safety precautions carefully.  Do not Place this apparatus on an uneven surface.  Do not install on a surface where it is exposed to direct sunlight, near heating equipment or heavy cold area. ...

  • Page 7: Table Of Contents

    CONTENTS OVERVIEW Important Safety Instructions Product Features Recomended PC Specifications What’s Included At a Glance Connecting with other Device INSTALLATION & CONNECTION NETWORK CONNECTION Configuring Network Video Decoder in LAN Environments AND SETUP Connecting the Network Video Decoder Directly to DHCP-Based DSL/Cable Modem Connecting the Network Video Decoder and Broadband Router that...

  • Page 8: Overview

    overview WEB VIEWER Accessing the Network Video Decoder Login Setup SETUP SCREEN Audio & Video Setup Network Setup System Setup Specification APPENDIX Product Overview Troubleshooting Open Source Announcement GPL/LGPL Software License 8_ overview...

  • Page 9: Product Features

    PRODUCT FEATURES  Supports Multi-format decoding The network video decoder employs H.264/MPEG-4/MJPEG multi-format decoder to decode and display up to 4 video streams transferred through network.  Supports Full-HD Video Display The maximum supported output resolution is 1920x1080, and provides HDMI, VGA and CVBS (BNC) output ports for display.

  • Page 10: What's Included

    WHAT’S INCLUDED Please check if your network video decoder and accessories are all included in the product package. Appearance Item Name Quantity Description SPD-400 VIDEO OUT AUDIO OUT HDMI User Manual CD Quick Guide Used for installation on the wall...

  • Page 11: At A Glance

    AT A GLANCE Front Side VIDEO OUT AUDIO OUT HDMI Item Description This port outputs selected audio from the device connected through the AUDIO OUT network, according to the settings. A BNC output port for display. VIDEO (CVBS) OUT This port outputs video only if CVBS mode is selected. An HDMI output port for display.
  • Page 12 overview Rear Side LINK MONITOR RESET POWER – NO1 CM1 NC1 NO2 CM2 NC2 G S1 D+ D– NETWORK DC 12V RELAY OUT SENSOR RS-485 Item Description NETWORK Used to connect a LAN cable. This function is not currently available. RS-485 D+/D- This function is not currently available.
  • Page 13 Item Description Indicates the video output mode. Green : HDMI or VGA output mode. Yellow : CVBS output mode. MONITOR  To change the video output mode, change it in Web Power, Viewer’s video settings or press the [RESET] button Monitor LED for about 1 second.

  • Page 14: Installation & Connection

    installation & connection CONNECTING WITH OTHER DEVICE Microphone Camera Network Speaker Monitor Monitor Monitor Connecting Video Out Connect a monitor to the preferred video output of the network video decoder.  It outputs video through the port according to the setting configured in the Web Viewer’s “Display Setup >...
  • Page 15 Connecting Audio In/Out 1. Connect a microphone to the network camera or encoder, and set Audio setting of corresponding device to <ON>. 2. Set Network AUDIO SETUP to ON in Video Decoder’s single layout settings, and select its output from Line Out and HDMI out in Audio Settings. Note that HDMI OUT for audio output can be selected only when the monitor out is set to HDMI.

  • Page 16: Connection

    installation & connection LINK MONITOR RESET POWER – NO1 CM1 NC1 NO2 CM2 NC2 G S1 D+ D– NETWORK DC 12V RELAY OUT SENSOR RS-485 Ethernet Power Ethernet Connection Connect the Ethernet cable to the local network or to the Internet. Power Supply Use the screwdriver to connect each line (+, –) of the power cable to the corresponding power port of the network encoder.
  • Page 17 Connecting to the I/O port box Connect the Alarm I/O signal to the corresponding port of the rear port box. LINK MONITOR RESET POWER – NO1 CM1 NC1 NO2 CM2 NC2 G S1 D+ D– NETWORK DC 12V RELAY OUT SENSOR RS-485 NO1 CM1 NC1 NO2 CM2 NC2 G...

  • Page 18: Connection

    installation & connection Alarm I/O Wiring Diagram 3.3V ALARM IN (12mA sink) ALARM OUT ALARM COM (24VDC 1A, 125VAC 0.5A MAX) ALARM OUT ALARM OUT ALARM COM (24VDC 1A, 125VAC 0.5A MAX) ALARM OUT 18_ installation & connection...

  • Page 19: Network Connection And Setup

    network connection and setup You can configure the Network Video Decoder’s network settings to your preference. CONFIGURING NETWORK VIDEO DECODER IN LAN ENVIRONMENTS Accessing the Network Video Decoder from a PC within the same LAN 1. Launch an Internet browser on the local PC. 2.

  • Page 20: Connecting The Network Video

    network connection and setup CONNECTING THE NETWORK VIDEO DECODER DIRECTLY TO DHCP-BASED DSL/CABLE MODEM INTERNET DSL/Cable Modem Network Video Decoder Network Camera DDNS Server (Data Center, KOREA) 1. Use a cross cable to connect a computer and the Network Video Decoder. 2.

  • Page 21: Connecting The Network Video Decoder And Broadband Router That

    CONNECTING THE NETWORK VIDEO DECODER AND BROADBAND ROUTER THAT IS CONNECTED TO THE CABLE MODEM This is for a small network environment such as homes, SOHO and ordinary shops. Network Video Decoder INTERNET Cable Modem Cable Modem Network Camera Broadband Network Camera Router DDNS Server...

  • Page 22: Buttons Used In Ip Installer

    network connection and setup BUTTONS USED IN IP INSTALLER Item Description Model name of the connected network device. Device Name Click the column to sort the list by model name. However, search will be stopped if clicked during the search. Alias This function is not currently implemented.

  • Page 23: Static Ip Setup

     For the IP installer, use only the installer version provided in the installation CD or use the latest one if available. You can download the latest version from the Samsung web site (www.samsungipolis.com). STATIC IP SETUP Manual Network Setup Run <IP Installer_vX.XX.exe>...
  • Page 24 network connection and setup 3. In the <Address> pane, provide the necessary information.  MAC (Ethernet) Address : The MAC (Ethernet) address of the applicable network device will be set automatically so you don’t need to input it manually.  You can configure the static IP settings only if the DHCP checkbox is unchecked.
  • Page 25 If using a Broadband Router  IP Address : Enter an address falling in the IP range provided by the Broadband Router. ex) 192.168.1.2~254, 192.168.0.2~254, 192.168.XXX.2~254  Subnet Mask : The <Subnet Mask> of the Broadband Router will be the <Subnet Mask>...
  • Page 26 network connection and setup Auto Network Setup Run <IP Installer_vX.XX.exe> to display the network device search list. At the initial startup, both [Auto Set] and [Manual Set] will be grayed out.  For network devices found with the IPv6 setting, these buttons will be grayed out as the cameras do not support this function.

  • Page 27: Dynamic Ip Setup

    DYNAMIC IP SETUP Dynamic IP Environment Setup  Example of the Dynamic IP environment - If a Broadband Router, with a network device connected, is assigned an IP ad- dress by the DHCP server - Network device is connected to a DHCP based modem directly - If IPs are assigned by the internal DHCP server via the LAN Checking the Dynamic IP 1.

  • Page 28: Connecting To The Network Device From Ashared Local Pc

    network connection and setup CONNECTING TO THE NETWORK DEVICE FROM A SHARED LOCAL PC 1. Run the IP Installer. Searches for connected network devices and displays on the list. 2. Double click the desired network device to connect to. The Internet browser starts and connects to the network device.

  • Page 29: Accessing The Network Video Decoder

    web viewer ACCESSING THE NETWORK VIDEO DECODER Normally, you would 1. Launch the Internet browser. 2. Enter the Network Video Decoder’s IP address into the address field. ex) • IP address (IPv4) : 192.168.1.200  http://192.168.1.200 - the Login dialog should appear. •...

  • Page 30: Login

    web viewer LOGIN The default user ID is “admin”, and the default password is “4321”. 1. Enter “admin” in the <User Name> input box. 2. Enter “4321” in the <Password> input box. If the password is changed, enter the changed password instead. 3.

  • Page 31: Setup

    setup screen SETUP You can configure the audio & video, network, event and system settings of the network video decoder remotely.  Depending on the firmware version of network camera/encoder, registering such devices to the network video decoder may fail or work improperly. Visit www.samsungtechwin.com to download the latest firmware and update it.
  • Page 32 setup screen To add a single layout 1. Click the [Add video ( )] button. 2. Enter the network camera/encoder’s information. 3. Enter the IP address or DDNS URL of the device to be added into the <Address> field.  Up to 64 letters can be entered, and the layout list displays up to 9 letters and <…>...
  • Page 33 6. Enter the <Camera name> after the fetched information appears.  The camera name allows no blank space within the name.  Up to 15 letters can be entered, and the layout list displays up to 7 letters and <…> will appear for the rest.
  • Page 34 setup screen To edit existing layout 1. Click the checkbox to select an added device. 2. Edit the existing information.  Note that <Protocol> and <Address> fields are not allowed to edit. 3. Click [Save ( 4. To cancel, click the [Cancel ( button.
  • Page 35 To add a quad layout 1. Click the [Add quad layout ( button. 2. Select devices from the added single layouts to be assigned to each channel. 3. Enter the <Layout name>.  Up to 15 letters can be entered, and the layout list displays up to 7 letters and <…>...
  • Page 36 setup screen To edit a quad layout 1. Click the select checkbox of the desired layout from the list. 2. Make your changes with assigned channel or edit the layout name. 3. Click [Save ( 4. To cancel, click the [Cancel ( )] button.

  • Page 37: Display Setup

    To set a sequence 1. Press the [Sequence setup ( button. 2. Select layouts in the order you want to display in sequence. 3. Enter the interval of the layout transition. 4. When done, click [Apply ( 5. Set the sequence setup to <ON>. Selected layouts are displayed in the specified order, switched at the specified interval.

  • Page 38: Audio Setup

    setup screen  OSD position : Selects the position of the on-screen display menu. If you change the number of OSD positions it will be moved to set number based on the entire screen.  OSD display : Select types of OSD to be Gate1 01:01:01 displayed on the monitor.

  • Page 39: Network Setup

    NETWORK SETUP Interface 1. From the Setup menu, select the <Network ( )> tab. 2. Click <Interface>. 3. Set the <Connection mode> and <IPv6 setup> as necessary.  IP type : Select an IP connection type. - Manual : Specify the IP address, Subnet Mask, Gateway, DNS1, and DNS2.
  • Page 40 setup screen You can select a secure connection system or install the public certificate for this purpose. 1. From the Setup menu, select the <Network ( )> tab. 2. Click <SSL>. 3. Select a secure connection system.  When accessing the Network Video Decoder using secure HTTPS mode, enter the IP address into the address field as: https://<Network Decoder_IP>.

  • Page 41: Alarm Input

    Alarm input You can set the alarm input type, duration and action type of the Network Video Decoder’s alarm input port. 1. From the Setup menu, select the <Event ( )> tab. 2. Click <Alarm input>. 3. Select the input device type. ...
  • Page 42 setup screen Event input You can set the alarm duration and alarm’s action type of the network camera or encoder. 1. From the Setup menu, select the <Event ( )> tab. 2. Click <Event input>. 3. Specify an event input device. ...

  • Page 43: System Setup

    SYSTEM SETUP Product information 1. From the Setup menu, select the <System ( )> tab. 2. Click <Product information>. 3. Check the Network Video Decoder information, or provide details according to your network environment.  Device name : Enter the Network Video Decoder’s name.
  • Page 44 setup screen  System time setup : Specify the time and date that will be applied to your system. - Manual : Specify the time manually. - Synchronize with NTP server : Sync with the time of the specified server address. - Synchronize to PC Viewer : Synchronize the time with the connected PC.
  • Page 45 Upgrade/Reboot 1. From the Setup menu, select the <System ( )> tab. 2. Click <Upgrade/Reboot>. 3. Select a desired item and set it appropriately.  Upgrade : Performs upgrading the system.  Factory default : Resets the system to the factory default. - Except network parameter : Resets all settings except for the Network Parameters.
  • Page 46 setup screen To save the current settings and restore the backup settings 1. Click [Backup]. The Save As dialog should appear. 2. Specify the backup path with a proper file name, and click [Save]. The backup file will be saved to the specified path in the format of “.xml”.
  • Page 47 You can check the system log or event log. 1. From the Setup menu, select the <System ( )> tab. 2. Click <Log>. 3. Select a log type.  Syslog : You can check the system logs where any system changes are recorded including the time information.

  • Page 48: Specification

    appendix appendix SPECIFICATION Items Description 1) HDMI / VGA : Max 1920x1080p (same output resolution for HDMI, VGA) 1920x1080p, 1680x1050, 1600x900, 1440x900, 1280x1024, 1280x720p, 1024 x 768 Video Out 2) CVBS : NTSC : 1.0 Vp-p / 75Ω composite 704x480 PAL : 1.0 Vp-p / 75Ω...
  • Page 49 20 cameras, 8 layouts, 10 sequences Network ONVIF Conformance Not supported Samsung : SNV-3120, SNP-3430H, SNP-3120, 3120V, 3120VH, SNB-5000, SNB-7000 (Supports profiles of less than 2M), SND-5080/F, SNV-5080, SNV-5010, SPE-100,400, SPE-1600R/400B Axis : P3301, P3343, P3344, P1311, P1343, P1344, P1346, Supported Devices PTZ215, Q6032, Q7401, Q7404 (F/W ver : 5.x)

  • Page 50: Product Overview

    appendix PRODUCT OVERVIEW Unit : mm (inch) 170.0 (6.69”) 178.0 (7.00”) 50_ appendix...

  • Page 51: Troubleshooting

    TROUBLESHOOTING PROBLEM SOLUTION  If restarting the network video decoder does the same, press and hold [RESET] button for about 5 seconds to reset the Network Video Decoder’s settings. Cannot access the Network Video  Check to make sure that all network cables have been connected Decoder with an internet browser.

  • Page 52: Open Source Announcement

    Its advanced feature-set (FastCGI, CGI, Auth, Output-Compression, URL-Rewriting and many more) make lighttpd the perfect webserver- software for every server that suffers load problems. For more additional information, send email to help.cctv@samsung.com. Copyright (C) 2004, Kneschke, incremental All rights reserved.
  • Page 53 Copyright (c) 1998-2001 University College London All rights reserved. Redistribution and use in source and binary forms, with or without modification, is permitted provided that the following conditions are met : 1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.

  • Page 54: Gpl/Lgpl Software License

    GPL/LGPL. You may obtain the complete Corresponding Source code from us for a period of three years after our last shipment of this product by sending email to help.cctv@samsung.com If you want to obtain the complete Corresponding Source code in the physical medium such as CD-ROM, the cost of physically performing source distribution might be charged.
  • Page 55 original authors' reputations. you receive it, in any medium, provided that you conspicuously and appropriately Finally, any free program is threatened publish on each copy an appropriate constantly by software patents. We wish copyright notice and disclaimer of to avoid the danger that redistributors of a warranty;...
  • Page 56 to print an announcement.) of the corresponding source code, to be distributed under the terms These requirements apply to the modified of Sections 1 and 2 above on a work as a whole. If identifiable sections of medium customarily used for software that work are not derived from the Program, interchange ;...
  • Page 57 License will not have their licenses distribution of the Program. terminated so long as such parties remain If any portion of this section is held invalid in full compliance. or unenforceable under any particular 5. You are not required to accept this circumstance, the balance of the section License, since you have not signed it.
  • Page 58 have the option of following the terms and MAY MODIFY AND/OR REDISTRIBUTE conditions either of that version or of any DAMAGES, INCLUDING ANY later version published by the Free Software GENERAL, SPECIAL, INCIDENTAL OR Foundation. If the Program does not specify CONSEQUENTIAL DAMAGES ARISING a version number of this License, you may OUT OF THE USE OR INABILITY TO...
  • Page 59 See the GNU General Public License for this is what you want to do, use the GNU more details. Lesser General Public License instead of this License. You should have received a copy of the GNU General Public License along with this GNU GENERAL PUBLIC LICENSE program ;...
  • Page 60 you modify it: responsibilities to respect the could make it effectively proprietary. To freedom of others. prevent this, the GPL assures that patents cannot be used to render the program non- For example, if you distribute copies of free. such a program, whether gratis or for a fee, you must pass on to the recipients the The precise terms and conditions for same freedoms that you received.
  • Page 61 copyright notice, and (2) tells the user that and the source code for shared libraries and there is no warranty for the work (except dynamically linked subprograms that the work to the extent that warranties are provided), is specifically designed to require, such as by that licensees may convey the work under intimate data communication or control flow this License, and how to view a copy of this...
  • Page 62 applicable law fulfilling obligations under article any applicable section 7 additional terms, 11 of the WIPO copyright treaty adopted on to the whole of the work, and all its parts, 20 December 1996, or similar laws prohibiting regardless of how they are packaged. This or restricting circumvention of such measures.
  • Page 63 physical medium customarily used for a consumer product, doubtful cases shall be software interchange, for a price no more resolved in favor of coverage. For a particular than your reasonable cost of physically product received by a particular user, “normally performing this conveying of source, or (2) used”...
  • Page 64 communication across the network. original version; or Corresponding Source conveyed, and d) Limiting the use for publicity purposes Installation Information provided, in accord with of names of licensors or authors of the this section must be in a format that is publicly material;...
  • Page 65 License, then your license from a particular transferring control of an organization, or copyright holder is reinstated (a) provisionally, substantially all assets of one, or subdividing unless and until the copyright holder explicitly an organization, or merging organizations. and finally terminates your license, and (b) If propagation of a covered work results permanently, if the copyright holder fails to from an entity transaction, each party to that...
  • Page 66 contents of its contributor version. with a third party that is in the business of distributing software, under which you make In the following three paragraphs, a “patent payment to the third party based on the license” is any express agreement or extent of your activity of conveying the work, commitment, however denominated, not and under which the third party grants, to any...
  • Page 67 concerning interaction through a network will THE PROGRAM PROVE DEFECTIVE, YOU apply to the combination as such. ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION. 14. Revised Versions of this License. 16. Limitation of Liability. The Free Software Foundation may publish revised and/ or new versions of the GNU IN NO EVENT UNLESS REQUIRED BY General Public License from time to time.
  • Page 68 GPL. It also counts as the successor of the the recipients, so that they can relink them GNU Library Public License, version 2, hence with the library after making changes to the the version number 2.1.] library and recompiling it. And you must show them these terms so they know their Preamble rights.
  • Page 69 linking other code with the library. TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND We call this license the “Lesser” General MODIFICATION Public License because it does Less to protect the user’s freedom than the 0. This License Agreement applies to any ordinary General Public License.
  • Page 70 Library does and what the program that application does not supply it, the square uses the Library does. root function must still compute square roots.) These requirements apply to the 1. You may copy and distribute verbatim modified work as a whole. If identifiable copies of the Library’s complete source sections of that work are not derived code as you receive it, in any medium,...
  • Page 71 This option is useful when you wish to to be true is not precisely defined by law. copy part of the code of the Library into a If such an object file uses only numerical program that is not a library. parameters, data structure layouts 4.
  • Page 72 and/or source code, so that the user itself accompanies the executable. can modify the Library and then relink to It may happen that this requirement produce a modified executable containing contradicts the license restrictions of other the modified Library. (It is understood proprietary libraries that do not normally that the user who changes the contents accompany the operating system.
  • Page 73 not accept this License. Therefore, by induce you to infringe any patents or other modifying or distributing the Library (or property right claims or to contest validity of any work based on the Library), you any such claims; this section has the sole indicate your acceptance of this License purpose of protecting the integrity of the to do so, and all its terms and conditions...
  • Page 74 Software Foundation. OUT OF THE USE OR INABILITY TO USE THE LIBRARY (INCLUDING BUT 14. If you wish to incorporate parts of the NOT LIMITED TO LOSS OF DATA OR Library into other free programs whose DATA BEING RENDERED INACCURATE distribution conditions are incompatible OR LOSSES SUSTAINED BY YOU OR with these, write to the author to ask...
  • Page 75 You should have received a copy of the from this software without prior written GNU Lesser General Public License along permission. For written permission, please with this library; if not, write to the Free contact openssl-core@openssl.org. Software Foundation, Inc., 51 Franklin 5.
  • Page 76 written by Eric Young (eay@cryptsoft. com). product includes software written by Tim The implementation was written so as to Hudson (tjh@ cryptsoft.com)” conform with Netscapes SSL. This library is free for commercial and non-commercial THIS SOFTWARE IS PROVIDED BY ERIC use as long as the following conditions are YOUNG ‘‘AS IS AND ANY EXPRESS OR aheared to.
  • Page 77 Samsung Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products.
  • Page 78 SAMSUNG TECHWIN AMERICA Inc. SAMSUNG TECHWIN EUROPE LTD. 100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660 Samsung House, 1000 Hillswood Drive, Hillswood Business Toll Free : +1-877-213-1222 Direct : +1-201-325-6920 Park Chertsey, Surrey, UNITED KINGDOM KT16 OPS Fax : +1-201-373-0124 TEL : +44-1932-45-5300 FAX : +44-1932-45-5325 www.samsungcctvusa.com...
