User's Guide
L1510SF
M
ake sure to read the Important Precautions before using the product.
Keep the User's Guide(CD) in an accessible place for furture reference.
S
ee the label attached on the product and give the information to your
dealer when you ask for service.

Advertisement

Table of Contents
loading

Related Manuals for LG L1510SF

Summary of Contents for LG L1510SF

  • Page 1 User’s Guide L1510SF ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for furture reference. ee the label attached on the product and give the information to your dealer when you ask for service.

  • Page 2: Important Precautions

    Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential eletrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 3 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.

  • Page 4: Connecting The Display

    Connecting the Display Before setting up the product, please make sure the power to the product, PC, and other attached devices is turned off. Connecting the stand base Align the hooks on the stand base with the matching slots in the base of the product.

  • Page 5: Using The Computer

    Connecting the Display Using the Computer Connect the signal cable. When attached, tighten the thumbscrews to secure the connection. Connect the power cord into a proper power outlet that is easily accessible and close to the display. NOTE This is a simplified representation of the rear view. This rear view represents a general model;...
  • Page 6 1) Connect the USB cable for touch screen before installing the driver. 2) Insert the Hantouch touch screen driver installation CD. 3) Open the "My Computer -> LG Driver -> Drivers" folder, then select the driver appropriate for your OS.

  • Page 7: Control Panel Functions

    Control Panel Functions Front Panel Controls LightView Control Function Use this button to turn the display on or off. Power Button This Indicator lights up green when the display Power Indicator operates normally(On Mode). If the display is in Sleep Mode (Energy Saving) mode, this indicator color changes to amber.
  • Page 8 Control Panel Functions Control Direct Access Function This feature lets you easily select the best desired image condition optimized to the environment NIGHT (ambient illumination, image types etc). • DAY : Bright ambient illumination • NIGHT : Dark ambient illumination •...

  • Page 9: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD.
  • Page 10 On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub menu Reference To adjust the brightness, contrast PICTURE BRIGHTNESS and gamma of the screen CONTRAST GAMMA COLOR To customize the color of the PRESET 6500K screen...

  • Page 11: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. NOTE OSD (On Screen Display) menu languages on the product may differ from the manual.

  • Page 12: To Improve The Clarity And Stability Of The Screen

    On Screen Display(OSD) Selection and Adjustment To improve the clarity and stability of the screen OSD Adjust Description To minimize any vertical bars or CLOCK T R A C K I N G stripes visible on the screen background.The horizontal screen size will also change.

  • Page 13: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator Press the Power button.

  • Page 14: Display Image Is Incorrect

    Troubleshooting Display image is incorrect Display Position is Press the AUTO/SELECT button to incorrect. automatically adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. Check Control Panel -->...

  • Page 15: Usb Function

    Troubleshooting 000000000000000 Have you installed the display driver? Have you installed the Be sure to install the display driver from the display driver? display driver CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lge.com. Do you see an Please check if the video card in your PC "Unrecognized monitor,...

  • Page 16: Specifications

    Specifications 15 inches (38.016cm) Flat Panel Active matrix-TFT LCD Display Anti-Glare coating 15 inches viewable 0.297 mm pixel pitch Horizontal Freq. 30 - 63kHz (Automatic) Sync Input Vertical Freq. 56 - 75Hz (Automatic) Input Form Separate TTL, Positive/Negative Signal Input 15 pin D-Sub Connector Video Input Input Form...

  • Page 17: Preset Modes (Resolution)

    Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.468 640 x 350 31.468 720 x 400 31.469 640 x 480 VESA 35.000 640 x 480 66.67 37.861 VESA 640 x 480 72.8 37.500 VESA 640 x 480 VESA 35.156 800 x 600...
  • Page 18 Specifications VESA wall mounting Connect the monitor to the VESA compliant stand (wall-mount type or stand alone type). For further information, on mounting to different stands, call our service center or monut manufacturer. Kensington Security Slot- optional A security cable can be purchased and is available at many popular electronic retail stores.
  • Page 19 Digitally yours...
