HP ProLiant BL465c Quickspecs

HP ProLiant BL465c Quickspecs

Server blade
Hide thumbs Also See for ProLiant BL465c:

Advertisement

Quick Links

Download this manual See also: Troubleshooting Manual, Technical White Paper
QuickSpecs
Overview
1. Access Panel
2. Two mezzanine I/O expansion slots
3. Two multifunction Gigabit Ethernet network adapter ports
4. Up to two AMD Opteron™ 2000 Series processors
5. Eight PC2-5300 Registered DIMM (DDR2-667) memory slots
What's New
What's New
What's New
What's New
Support for HP NC532m Dual Port Flex-10 10GbE Multifunction BL-c Adapter
At A Glance
At A Glance
At A Glance
At A Glance
This document covers the HP ProLiant BL465c server blade only. For more information on HP BladeSystem c-Class Enclosures and
HP BladeSystem c-Class Interconnect Components, please see the following QuickSpecs:
HP BladeSystem c3000 Enclosure QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12790_div/12790_div.html
HP ProLiant BL465c Server Blade
HP ProLiant BL465c Server Blade
HP ProLiant BL465c Server Blade
HP ProLiant BL465c Server Blade
DA - 12578
Worldwide — Version 25 — October 31, 2008
HP ProLiant BL465c Server Blade
HP ProLiant BL465c Server Blade
HP ProLiant BL465c Server Blade
HP ProLiant BL465c Server Blade
6. Smart Array E200i storage controller (optional battery-backed
write cache)
7. Local I/O connector
8. Two small form factor (SFF) hot-plug hard drive bays
9. Internal USB connector
Page 1

Advertisement

loading

Related Manuals for HP ProLiant BL465c

Summary of Contents for HP ProLiant BL465c

  • Page 1 At A Glance At A Glance This document covers the HP ProLiant BL465c server blade only. For more information on HP BladeSystem c-Class Enclosures and HP BladeSystem c-Class Interconnect Components, please see the following QuickSpecs: HP BladeSystem c3000 Enclosure QuickSpecs: http://h18000.www1.hp.com/products/quickspecs/12790_div/12790_div.html...
  • Page 2 HP BladeSystem c7000 Enclosure QuickSpecs: http://h18000.www1.hp.com/products/quickspecs/12810_div/12810_div.html and HP BladeSystem c-Class Interconnect Components QuickSpecs: http://h18000.www1.hp.com/products/quickspecs/12524_div/12524_div.html The HP ProLiant BL465c delivers uncompromising performance and expandability, industry-leading management tools, and the latest technologies for dense compute environments. HP ProLiant BL465c server blade includes: Processor:...
  • Page 3 The HP BladeSystem c7000 rack enclosure is 10U high and holds up to 16 ProLiant BL465c servers plugged vertically. The HP BladeSystem c3000 rack enclosure is 6U high and holds up to 8 HP ProLiant BL465c servers plugged horizontally. The HP BladeSystem c3000 tower enclosure is designed with casters for sites without racks and holds up to 8 HP ProLiant BL685c servers plugged vertically.

  • Page 4: Standard Features

    QuickSpecs HP ProLiant BL465c Server Blade HP ProLiant BL465c Server Blade HP ProLiant BL465c Server Blade HP ProLiant BL465c Server Blade Standard Features NOTE: NOTE: NOTE: NOTE: For a brief, printer friendly data sheet that describes this product and informs you of the essential capabilities and specifications, please visit: http://h71028.www7.hp.com/ERC/downloads/4AA0-7493ENW.pdf...
  • Page 5 OS image from the iSCSI target disk. The iSCSI boot option ROM is supplied by HP at no cost. Additionally, the HP iSCSI boot solution includes scripts to significantly simplify the installation process.
  • Page 6 Compatible SAN HP ProLiant BL465c server blades are optimized for HP StorageWorks MSA, EVA, and XP HP ProLiant BL465c server blades are compatible with select 3rd party SANs (please see blade storage page for more details: http://h18000.www1.hp.com/products/servers/proliant-bl/c-Class/storage.html) DA - 12578 Worldwide —...
  • Page 7 HP's Linux products in HP ICLE and HP XC Clusters, while providing paths to the future with developing management technologies. HP Insight Control management suites and most HP ProLiant Essentials will include one year of 24 x 7 DA - 12578 Worldwide —...
  • Page 8 HP ProLiant BL465c Server Blade HP ProLiant BL465c Server Blade Standard Features HP Software Technical Support and Update Service ensuring rapid access to HP support staff and proactive delivery of software updates. From more information about this service, please visit: http://www.hp.com/services/insight.
  • Page 9 Management to deploy reliable and consistent server configurations. SmartStart 7.60 and later can now deploy the HP ProLiant BL465c using the I/O port with an attached USB CD-ROM device. To obtain a copy of SmartStart for your blade server order or download your copy from the SmartStart web site. For more information, please visit the SmartStart Web site at: http://www.hp.com/servers/smartstart.
  • Page 10 NOTE: NOTE: NOTE: The above is not a complete list of all HP Serviceguard for Linux product numbers For a detailed list of supported configuration/certification options for HP Serviceguard for Linux please refer to the HP Serviceguard for Linux Configuration & Ordering Guide available at: http://www.hp.com/go/sglx/info.
  • Page 11 Citrix XenServer NOTE: NOTE: NOTE: NOTE: For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization Software and latest listing of software drivers available for your server, please visit our Support Matrix at: http://www.hp.com/go/supportos. Integrated Manageability...
  • Page 12 IT and business needs. The HP Care Pack service for HP ProLiant BL c-Class server blades, cover the server blade and all HP branded hardware options qualified for the server, purchased at the same time or afterwards, internal to the server.
  • Page 13 QuickSpecs HP ProLiant BL465c Server Blade HP ProLiant BL465c Server Blade HP ProLiant BL465c Server Blade HP ProLiant BL465c Server Blade Standard Features http://www.hp.com/services/bladesystemservices http://www.hp.com/go/proliant/carepack DA - 12578 Worldwide — Version 25 — October 31, 2008 Page 13...
  • Page 14 HP ProLiant BL465c 2210 Form Factor Form Factor Form Factor Form Factor Up to 8 half-height blades supported in the HP BladeSystem c3000 HE DC, 1GB (1P) HE DC, 1GB (1P) HE DC, 1GB (1P) HE DC, 1GB (1P) Enclosure...

  • Page 15: Configuration Information - Factory Integrated Models

    NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO product offerings and requirements.
  • Page 16 NOTE: For additional options, including server blade enclosures interconnect options and power subsystem options; please see the following QuickSpecs: HP BladeSystem c3000 Enclosure QuickSpecs: http://h18000.www1.hp.com/products/quickspecs/12790_div/12790_div.html HP BladeSystem c7000 Enclosure QuickSpecs: http://h18000.www1.hp.com/products/quickspecs/12810_div/12810_div.html and HP BladeSystem c-Class Interconnect Components QuickSpecs: http://h18000.www1.hp.com/products/quickspecs/12524_div/12524_div.html. DA - 12578 Worldwide — Version 25 — October 31, 2008 Page 16...
  • Page 17 467799-B21 NOTE: NOTE: NOTE: NOTE: The NC532m network adapter card is required for each server blade connecting to a 10Gb interconnect in bays 3-8 (HP BladeSystem c7000 Enclosure) or bays 3-4 (HP BladeSystem c3000 Enclosure) NOTE: NOTE: NOTE: NOTE: The NC532m requires a minimum of 2 GB of server memory.
  • Page 18 NOTE: NOTE: Contains 1 license for each of RDP, PMP, VMM, VPM, IPM and iLO Select. Includes one year of 24 x 7 HP Software Technical Support and Update Service NOTE: NOTE: Customer will receive a printed license entitlement certificate and...
  • Page 19 The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support and Update Service. One certificate is shipped for each license.
  • Page 20 NOTE: Customer will receive a printed license entitlement certificate via physical shipment. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support and Update Service.
  • Page 21 QuickSpecs HP ProLiant BL465c Server Blade HP ProLiant BL465c Server Blade HP ProLiant BL465c Server Blade HP ProLiant BL465c Server Blade Options NOTE: NOTE: For additional license kits please see the QuickSpecs at: NOTE: NOTE: http://h18000.www1.hp.com/products/quickspecs/12328_div/12328_div.html NOTE: NOTE: NOTE: NOTE: Electronic licensing options are available for Insight Control suites and select ProLiant Essentials software products.
  • Page 22 SAS Enterprise (ENT) Drives 2.5" Drives, Hot Plug SAS Enterprise (ENT) Drives 2.5" Drives, Hot Plug SAS Enterprise (ENT) Drives 2.5" Drives, Hot Plug HP 72GB 3G SAS 15K SFF DP HDD 418371-B21 HP 72GB 3G SAS 15K SFF SP HDD...
  • Page 23 NOTE: NOTE: NOTE: The above is not a complete list of all HP Serviceguard for Linux product numbers For a detailed list of supported configuration/certification options for HP Serviceguard for Linux please refer to the HP Serviceguard for Linux Configuration &...
  • Page 24 The smallest capacity DIMMs must be populated in the bank physically nearest the processor. For optimal performance in most applications, populate the first memory bank for every populated processor socket. HP ProLiant BL465c Server Blade (1P Model) HP ProLiant BL465c Server Blade (1P Model)
  • Page 25 QuickSpecs HP ProLiant BL465c Server Blade HP ProLiant BL465c Server Blade HP ProLiant BL465c Server Blade HP ProLiant BL465c Server Blade Storage 2 x SFF SAS or SATA Hot Plug Hard Drives Hard Drives Hard Drives Hard Drives Hard Drives Hot Plug SFF SAS 2.5"...

  • Page 26: Technical Specifications

    12790_div.html HP BladeSystem c7000 Enclosure QuickSpecs: http://h18000.www1.hp.com/products/quickspecs/12810_div/ 12810_div.html To review typical system power ratings use the HP BladeSystem Power Sizer which is available via the online tool located at URL: http://www.hp.com/go/bladesystem/powercalculator System Inlet Temperature System Inlet Temperature System Inlet Temperature System Inlet Temperature Operating 10°...
  • Page 27 HP ProLiant BL465c Server Blade HP ProLiant BL465c Server Blade Technical Specifications Acoustic Noise Acoustic Noise For acoustic noise specifications, please see the HP BladeSystem c-Class Acoustic Noise Acoustic Noise Enclosures QuickSpecs located at URL: HP BladeSystem c3000 Enclosure QuickSpecs: http://h18000.www1.hp.com/products/quickspecs/12790_div/...
  • Page 28 AMD, the AMD Arrow logo, AMD Opteron™, and combinations thereof, are trademarks of Advanced Micro Devices, Inc. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
