2 electrolux Electrolux. Thinking of you. Share more of our thinking at www.electrolux.com CONTENTS Safety information Washing programmes Safety instructions Consumption values Product description Care and cleaning Special accessories for installation What to do if… Control panel Technical data First use...
3 • Obey the maximum load volume of 7 kg (refer to the “Pro- gramme chart” chapter). • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
4 electrolux • Before you connect the appliance to new CARE AND CLEANING pipes or pipes not used for a long time, Warning! Risk of injury or damage to let the water flow until it is clean. the appliance. • The first time you use the appliance, make sure that there is no leakage.
5 DETERGENT DISPENSER DRAWER Compartment for detergent used for prewash and soak phase or for stain re- mover used during the stain action phase (if available). The prewash and soak detergent is added at the beginning of the wash pro- gramme.
6 electrolux CONTROL PANEL Below is a picture of the control panel. It shows the programme selector dial as well as the temperature selector dial, the buttons and the pilot lights. These are presented by relevant numbers on the following pages.
Page 7
7 = End of cycle light = Washing phase light = Door locked light = Delay Start button PROGRAMME SELECTOR DIAL extra quantity of water (extra rinse), select this option. Some additional rinses will be It allows you to switch the appliance on/off performed.
8 electrolux FIRST USE • Ensure that the electrical and water ECO valve. Then run a cotton cycle connections comply with the installa- at the highest temperature without tion instructions. any laundry in the machine, to re- • Remove the polystyrene block and move any manufacturing residue any material from the drum.
Page 9
9 REDUCE THE SPIN SPEED OR SELECT 1. Select the programme and the required THE AVAILABLE FUNCTIONS BY options. TURNING THE SPIN SELECTOR DIAL 2. Select the delay start by pressing the button 7. 3. Press button 6: The spin speed dial allows you to select the –...
10 electrolux Before you make any change, you must few minutes the door can be opened (pay PAUSE the appliance by pressing the but- attention to the water level and temper- ton 6. ature!). Changing a running programme is possible After closing the door, it is necessary to se- only by resetting it.
Page 11
11 Remove persistent stains before washing. quantities to avoid waste and protect the Rub particularly soiled areas with a special environment. detergent or detergent paste. Although biodegradable, detergents contain Treat curtains with special care. Remove substances which, in large quantities, can hooks or tie them up in a bag or net.
12 electrolux ter hardness degree is medium or high we When the degree of hardness is soft, read- suggest you to add a water softener follow- just the quantity of the detergent. ing always the manufacturer’s instructions. WASHING PROGRAMMES Programme - Maximum and Minimum Temper-...
Page 13
13 Programme - Maximum and Minimum Temper- ature - Cycle Description - Maximum Spin Detergent Options Speed - Maximum Fabrics Load - Type of Laun- Compartment SPIN REDUCTION NO SPIN Wool / Handwash RINSE HOLD 40° - Cold Main wash - Rinses Maximum spin speed at 800 rpm Max.
Page 14
14 electrolux Programme - Maximum and Minimum Temper- ature - Cycle Description - Maximum Spin Detergent Options Speed - Maximum Fabrics Load - Type of Laun- Compartment Spin SPIN REDUCTION Drain and long spin Maximum spin speed at 800 rpm Max.
15 CONSUMPTION VALUES Programme Energy consumption Water consumption Programme duration (KWh) (litres) (Minutes) Cottons 60° 1.40 1.05 Cottons ECO 60° Cottons 40° 0.77 Synthetics 40° 0.60 Delicates 40° 0.60 Wool/ Handwash 30° 0.25 1) «Cottons Eco» at 60°C with a load of 7 kg is the reference programme for the data entered in the energy label, in compliance with EEC 92/75 standards.
Page 16
16 electrolux 2. Run a washing cycle without any wash- ing to clean off any cleaning agent resi- dues. Programme: Short Cotton Programme at maximum temperature and add ap- prox. 1/4 measuring cup of detergent. DOOR SEAL Check from time to time the door seal and eliminate eventual possible objects that could be trapped in the fold.
Page 17
17 2. Put a container below the recess of the 8. Make sure that the impeller of the drain pump to collect the water that pump can turn. If this does not occur, flows out. contact the service centre.
18 electrolux 3. Clean the filter in the hose using a hard 7. when the container is full of water, put bristle brush. the drainage duct back again and emp- ty the container; repeat this operation until water stops flowing out;...
Page 19
19 ones indicated below, this is related to a «Possible cause/Solutions» box and re- fault that you cannot solve. In this case, start the programme. contact your local Service Centre. • 2 flashes = «The machine does not Press simultaneously the buttons 5 and 6 empty and/or does not spin», follow...
Page 20
20 electrolux Problem Possible cause/Solution Too much detergent or unsuitable detergent (creates too much foam) has been used. • Reduce the detergent quantity or use another one. Check whether there are any leaks from one of the inlet hose fit- tings.
21 If you are unable to identify or solve the problem, contact our service centre. Before telephoning, make a note of the model, se- Mod..rial number and purchase date of your ma- Prod. No..
Page 22
22 electrolux 3. Unscrew the three bolts. POSITIONING Install the machine on a flat hard floor. Make sure that air circulation around the machine is not impeded by carpets, rugs etc. Check that the machine does not touch the wall or other kitchen units. Level the washing machine by raising or lowering the feet.
23 2. Do not place the inlet hose downwards. WATER DRAINAGE Angle the hose to the left or right de- The end of the drain hose can be posi- pending on the position of your water tioned in three ways.
Page 24
24 electrolux collection point for the recycling of electrical ECOLOGICAL HINTS and electronic equipment. By ensuring this To save water, energy and to help protect product is disposed of correctly, you will the environment, we recommend that you help prevent potential negative...
