TA-FE310R/FE510R

SERVICE MANUAL

Amplifier section
DIN power output
TA-FE510R: 80 W+80 W (4 ohms at 1 kHz)
60 W+60 W (8 ohms at 1 kHz)
TA-FE310R: 55 W+55 W (4 ohms at 1 kHz)
45 W+45 W (8 ohms at 1 kHz)
Frequency response
PHONO (20 Hz-20 kHz): RIAA equalization curve
±0.5 dB
TUNER, CD, AUX, TAPE1/DAT,
TAPE2/MD: 7 Hz-70 kHz dB
S/N (network A)
PHONO: 80dB
TUNER, CD, AUX, TAPE1/DAT,
TAPE2/MD: 105 dB
Output voltage/ impedance
REC OUT: 200 mV, 1 kilohm
PHONES: 5 mW (at 8 ohms)
Speakers impedance:
4-16 ohms, 8-16 ohms (SPEAKERS A+B)
Damping factor
80 (8 ohms, 1 kHz)
MICROFILM
Photo : TA-FE510R

SPECIFICATIONS

System
Power amplifier: Pure-complementary SEPP OCL
power amplifier with all stages directly coupled
Preamplifier. Low-noise, equalizer amplifier
Power requirements
Models not supplied with a voltage selector:
220-230 V AC, 50/60 Hz
Power consumption
TA-FE510R: 160 W
TA-FE310R: 120 W
Dimensions (approx.) (w/h/d):
430 105 300 mm
incl. projecting parts and controls
Mass (approx.)
TA-FE510R: 4.8 kg
TA-FE310R: 4.3 kg
Supplied accessories
Remote commander (remote) (1)
RM-S315
Sony batteries SUM-3 (NS) (2)
Design and specifications are subject to change without
notice.
INTEGRATED STEREO AMPLIFIER
AEP Model
TA-FE310R/FE510R
UK Model
TA-FE310R

Advertisement

Table of Contents
loading

Related Manuals for Sony TA-FE310R

Summary of Contents for Sony TA-FE310R

  • Page 1: Service Manual

    Power amplifier: Pure-complementary SEPP OCL 60 W+60 W (8 ohms at 1 kHz) power amplifier with all stages directly coupled TA-FE310R: 55 W+55 W (4 ohms at 1 kHz) Preamplifier. Low-noise, equalizer amplifier 45 W+45 W (8 ohms at 1 kHz)
  • Page 2 COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
  • Page 3 SECTION 2 DIAGRAMS 2-1. CIRCUIT BOARDS LOCATION 2-2. IC PIN FUNCTION DESCRIPTION CONTROL BOARD IC801 TMP47C103N (INPUT CONTROL, LED DRIVE) Pin No. Pin Name Function RELAY DC board RELAY AC board X OUT System clock. (4 MHz) X IN System clock. (4 MHz) RESET RESET input.

  • Page 10: Exploded Views

    1-769-983-11 WIRE (FLAT TYPE) (13 CORE) X-4948-254-1 PANEL ASSY, FRONT (BLACK) * 15 A-4398-021-A CONTROL BOARD, COMPLETE (FE510R) X-4948-418-1 PANEL ASSY, FRONT (SILVER) 4-963-404-21 EMBLEM (5-A), SONY * 15 A-4398-017-A CONTROL BOARD, COMPLETE (FE310R) * 16 1-665-592-11 EON BOARD (FE510R) 4-980-199-01 BUTTON (POWER)(BLACK) 4-980-189-01 KNOB (DIA.
  • Page 11 CHASSIS SECTION not supplied CN8 CN9 AEP, Germany not supplied AEP, Germany Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks X-4947-124-1 FOOT ASSY (F50150S)(SILVER) * 57 4-989-462-12 PANEL, BACK (FE310R:UK) X-4947-207-1 FOOT ASSY (F50150S)(BLACK) * 59 1-665-599-11 SP BOARD * 52 1-665-597-11 RELAY DC BOARD...

  • Page 12: Electrical Parts List

    SECTION 4 ELECTRICAL PARTS LIST AC SW CONTROL Note: • Due to standardization, replacements in the • RESISTORS When indicating parts by reference number, parts list may be different from the parts All resistors are in ohms. please include the board naame. specified in the diagrams or the components METAL: metal-film resistor used on the set.
  • Page 13 CONTROL FUNCTION SW MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R206 1-249-441-11 CARBON 100K 1/4W 1-665-592-11 EON BOARD (FE510R) R208 1-249-439-11 CARBON 1/4W ********** R251 1-249-433-11 CARBON 1/4W R252 1-249-421-11 CARBON 2.2K 1/4W F <...
  • Page 14 MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C105 1-162-282-31 CERAMIC 100PF C904 1-126-224-11 ELECT 4700uF C106 1-130-480-00 MYLAR 0.0056uF 5% (FE310R) C107 1-130-473-00 MYLAR 0.0015uF 5% C904 1-126-307-11 ELECT 6800uF C108 1-126-964-11 ELECT 10uF (FE510R) C109 1-126-964-11 ELECT...
  • Page 15 MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks < TRANSISTOR > R301 1-249-439-11 CARBON 1/4W R302 1-249-417-11 CARBON 1/4W F Q101 8-729-141-26 TRANSISTOR 2SC3622A-LK R303 1-249-415-11 CARBON 1/4W F Q102 8-729-119-77 TRANSISTOR 2SA1175-FEK R304 1-249-439-11 CARBON 1/4W Q103 8-729-620-05 TRANSISTOR 2SC2603-EF (FE510R)
  • Page 16 MAIN RELAY AC RELAY DC SIRCS Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R832 1-249-393-11 CARBON 1/4W F < DIODE > (FE510R) R902 1-247-750-11 CARBON 1/2W F D901 8-719-028-23 DIODE D3SBA20-4101 (FE310R) R903 1-247-750-11 CARBON 1/2W F D901 8-719-302-37 DIODE RBV-602 (FE510R)
  • Page 17 TA-FE310R/FE510R Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks ACCESSORIES & PACKING MATERIALS ******************************* 1-473-655-11 REMOTE COMMANDER (RM-S315) 3-860-499-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH,SPANISH,PORTUGUESE) 3-860-499-21 MANUAL, INSTRUCTION (GERMAN,DUTCH,SWEDISH,ITALIAN) (AEP,Germany) 4-981-643-01 COVER, BATTERY (FOR RM-S315) ************************************************************ ************** HARDWARE LIST...
