Sony CRX320AE Product Information

Introduction
❑ Features "Power-Burn conformed"
This product offers the following features.
technology to prevent buffer under-run
❑ An internal CD-RW/DVD-ROM drive
errors.
with ATAPI (EIDE) interface for PCs. "Power-Burn conformed" is used to refer to a
❑ Writes up to 52× speed on CD-R disc CD-R/RW that uses CD-R/RW recording
technology (ICs and/or firmware) other than
media.
Power-Burn, but provides performance equivalent
❑ Writes up to 32× speed on CD-RW disc
to that of Sony original Power-Burn technology
based on the Power-Burn concept.
media.
❑ Reads CD-ROM discs at up to 52×
Notes
speed.
❑ With the Turbo Boost function, easily
• Writing speed may automatically be adjusted
depending on the disc specified speed or disc
switch from the default 40× read/write
conditions such as weight imbalance and eccentricity.
speed to 52× speed.*
• 1× and 2× writing speed and discs are not supported.
❑ Reads DVD-ROM discs at up to 16×
• During startup, the drive may make a whirring noise
speed.
due to balls contained in the spindle motor. This is
normal and does not indicate a drive malfunction.
* For details, see "Turbo Boost Function" below.
System Requirements
❑ One empty 5-inch half-height drive bay
This CD-RW/DVD-ROM drive can be used
❑ One available internal +12 V/+5 V power
in systems with the following capabilities.
connector
❑ CPU: Pentium II 400 MHz or higher is
recommended. Notes
❑ PC/AT-compatible PC
• The above system configuration is given as a
❑ OS:
minimum requirement for a system on which basic
® CD-RW writing performance can be obtained. In
Windows 98 Second Edition
actual use, the requirements for the writing software
Windows ® 2000 Professional
and "Windows" also have to be taken into
®
Windows Millennium Edition
consideration. (Normally, these requirements will be
Windows ® XP Home Edition higher than the above specifications.)
®
Windows XP Professional • The drive cannot be assured to operate properly if
❑ 64 MB RAM or higher is recommended connected to an ATAPI interface adapter card (we
cannot guarantee compatibility or offer user support).
❑ At least 1 GB available hard disk space
❑ One available EIDE (ATAPI) interface
connection with DMA capability
Package Contents
Please verify that the package includes the following accessories with the drive when
unpacking.
If any of these items appears to be missing or damaged, please contact your supplier.
• CD-RW/DVD-ROM drive • 40-pin ATAPI (IDE) flat cable
• Screws (×4)
• Product Information (this document)
• Software Quick Start Guide
• Quick Start Guide (for ATAPI (EIDE) Interface Drive)
• Software disc
• Warranty cards
Note
To guard against possible loss or damage, be sure to make a backup copy of the provided software disc on a CD-R
disc or other media. The software disc is not sold separately.
Please Record Responsibly
Before copying anything onto a CD-R or CD-RW disc, make sure that you are not violating
copyright laws. Most software companies allow you to make a backup or archive copy of
software. Check your software license agreement for details.
Turbo Boost Function
2
The default CD-R and CD-ROM read/write Press the Eject button for five
speed of this drive is 40× speed. With a seconds.
single touch, you can activate the Turbo The Busy indicator blinks twice and the
Boost function, making the read/write speed speed switches to 52× speed. (The Turbo
52× speed. Boost function is active.)
CAUTION Notes
• On rare occasions, some discs may not be able to • When you want to write at 52× speed, insert the disc
tolerate 52× speed, causing them to break. We into the drive, activate the Turbo Boost function, and
recommend that you do not use deeply scratched, then start writing to the disc.
brittle, or other discs that may break at 52× speed.
• When writing with the Turbo Boost function, the Busy
• The Turbo Boost function does not increase read/write indicator blinks more rapidly than usual.
speed with CD-RW or DVD-ROM discs.
• When you open the disc tray, the speed reverts to its
default of 40× speed.
1
Insert a disc into the drive.
• The Turbo Boost function does not guarantee a 52×
The speed when you insert a disc is
write speed. Depending on the condition of the disc
normally 40× speed.
you are using, the speed may be lower.
Specifications
Compatible discs Buffer under-run error protection
CD-R CD-RW technology
CD-ROM CD-ROM XA
1)
CD-DA CD Extra (CD+)
Operating Environment
Video CD CD TEXT
5 to 40 °C
Photo CD
DVD-ROM DVD-Video
Power and Miscellaneous
Disc diameter 12 cm
8 cm (for horizontal use only)
DC +5 V 1.5 A (max.)
DC +12 V 1.5 A (max.)
1) This product is designed to playback discs that conform to the Compact
Size
Disc (CD) standard. Recently, various music discs encoded with copyright
Approx. 145.8 × 41.3 × 165 mm (W×H×D)
protection technologies are marketed by some record companies. Please
be aware that among those discs, there are some that do not conform to the
(excluding front bezel)
CD standard and may not be playable by this product.
Weight
When you use this unit as an audio CD player, please use compact discs
Approx. 0.9 kg (drive only)
with the following mark.
Interface
Drive interface
Writing Systems ATAPI (EIDE)-compliant
Track-at-once Disc-at-once
Session-at-once Packet writing
Drive Inquiry
SONY CD-RW CRX320EE
Drive
Data transfer rate
Buffer capacity
CD-ROM 7.8 MB/s (52× speed) 2) 3)
1.5 MB
DVD-ROM 22.1 MB/s (16× speed) 3)
Access time
Laser specifications
Average random stroke CD-ROM 120 ms
Type
DVD-ROM 140 ms
CD: RLD78PZW4
2)
When using the Turbo Boost function.
DVD: RLD65MZT2
3) The maximum data transfer rate depends on the
Wavelength
capabilities of the host PC.
CD: 784 ± 5 nm
DVD: 655 +5/–10 nm
Please note that specifications and
Output power (max.)
appearance may be subject to change
CD: 120 mW (CW)
without notice.
230 mW (Pulse)
DVD: 10 mW
DVD region codes
The playback of DVD-Video (DVD discs) is back DVD-Video whose region code
protected and controlled by a region code matches the one set the fifth time.
setting. For the drive to play back DVD-
Video, the region code on the DVD disc, the Do not attempt to make unauthorized
region code of the drive, and the region code changes to the region code. Any problems
of the DVD-Video software must all match. resulting from doing so are not covered by
the warranty.
With this drive, the region code can be set up
to five times, including the initial assignment Hint
(RPC phase 2 standard). After setting the You can change the region code of the drive on it's
properties dialog box accessible from the Device
region code five times, the setting becomes
Manager.
permanent and can no longer be changed.
From this point on, you are only able to play
Product and Support Information
Sony Global Sites Information (As of January, 2007)
Product purchased in the USA:* Product purchased in Taiwan:*
http://sony.storagesupport.com/ http://www.sony.com.tw/ds/
Product purchased in Canada: Product purchased in Korea:*
http://www.sony.ca/ http://www.sony.co.kr/cp
Product purchased in Australia or New Product purchased in Brazil:
Zealand: http://www.sony.com.br/eletronicos
http://www.sony.com.au/
Product purchased in the Middle East:
Product purchased in Europe:* http://www.sony-mea.com/
http://www.sonyisstorage.com/
* Local Web sites for computer peripheral products
Product purchased in Hong Kong:*
About the Bundled Writing Software
http://www.sony.com.hk/Electronics/cp Detailed information about the supplied
writing software is available on the Web
Product purchased in China:*
sites of the software manufacturers and
http://www.sony.com.cn/ed/cp/
software distributors. (Accessible from the
Product Purchase in Singapore:
links in each software application)
http://www.sony-asia.com/storage/
Technical Support
Local technical support is only
Please consult the Sony global sites listed
before calling with questions about using available in the specified sales
this product, or with technical questions
regions. The customers in these
about the drive or the supplied software. If
regions should be provided with a
using telephone or e-mail support, please
warranty card for this product.
have the following information available:
For contact information, refer to
• Model number: CRX320AE
the warranty card.
• Serial number
Note that technical support
• Date and place of purchase
conditions may vary according to
• Computer maker and model number
the locality, and that charges and/
• Computer specifications (CPU speed,
or limited service may apply in
memory size, OS version, etc.)
• Writing software used (version, etc.) some regions.
