Bosch D220 User Manual

Security system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Security Systems D220
User's Guide
National Security Systems Inc (800)457-1999

Advertisement

Table of Contents
loading

Related Manuals for Bosch D220

Summary of Contents for Bosch D220

  • Page 1 Security Systems D220 User’s Guide National Security Systems Inc (800)457-1999...

  • Page 2: Table Of Contents

    Table of Contents About This User’s Guide ................3 Introduction ....................3 Security System Basics ................4 Controlled Points ..................5 24-Hour Points ................... 6 Keypad Keys ....................6 Keypad Lights ..................... 7 Keypad Tones ..................... 8 System Events .................... 9 Silencing Alarms ..................

  • Page 3: About This User's Guide

    About This User’s Guide This user’s guide shows you how to use and maintain your security system. It covers basic system functions, such as turning the system on and off. The functions described in this guide are programmed by your security company.

  • Page 4: Security System Basics

    Security System Basics What is a Point? A “point” is a detection device, or group of devices connected to your security system. The keypad shows point status through the lights numbered 1 to 8 on the keypad display. Each point can represent a single door, window, motion sensor, smoke detector, or other detection device.

  • Page 5: Controlled Points

    Controlled Points Controlled points respond to alarm conditions depending upon whether the system is turned on or turned off. They are programmed to either respond instantly to alarm conditions or to provide a delay for you to reach the keypad and turn the system off. Various controlled points may be located throughout your house.

  • Page 6: 24-Hour Points

    24-Hour Points 24-hour points are always on, even when the system is turned off. There are two types of 24-hour points: Fire and Non-Fire points. Fire Points Fire points only monitor fire detection devices, such as smoke detectors. They are always on and cannot be turned off. Non-Fire 24-Hour Points Non-fire points are always on and cannot be turned off.

  • Page 7: Keypad Lights

    Keypad Lights The keypad uses lights to indicate various conditions, such as whether your system is on or off, the status of protective points, whether there is a system trouble, and whether there is an alarm. Light Function Lights when the system is All or Part On. Flashes during exit delay and when an alarm occurs No Delay Lights when the system is All or Part On without entry or...

  • Page 8: Keypad Tones

    Keypad Tones Your keypad emits several distinct tones and flashes keypad lights to alert you to system events. Additional bells or sirens may also be connected to your system. Bells or sirens mounted on the exterior of your premises alert neighbors to emergencies and provide an audible guide for police and fire fighters.

  • Page 9: System Events

    System Events Your system responds to four types of events. If more than one event occurs, your system sorts them into one of four groups. The groups (highest priority first) are: Fire Alarms, Burglary Alarms, Fire Troubles, and Non-Fire Troubles. Fire Alarms Fire alarms are the highest priority events.

  • Page 10: Silencing Alarms

    How Your System Reports Alarms Your security system may be programmed to automatically disconnect your telephones when sending reports to your security company. Once the report is completed, your security system returns the telephones to normal operation (check with your security company). Your system makes repeated attempts to send reports to your security company.

  • Page 11: Turning The System Off

    Turning the System Off You turn off your security system by entering your personal passcode. When the system is on, you must enter through a designated entry door to prevent an instant alarm condition. Opening a designated door starts entry delay time and the keypad emits a pulsing beep tone to remind you to turn the system off.

  • Page 12: Turning The System All On

    Turning the System All On Use this function to turn on the entire system. Once you press the [9] key, exit delay time starts to count down. You should leave before exit delay time expires. Leaving after exit delay expires causes an alarm event.

  • Page 13: Turning The System All On, With No Delay

    Turning the System All On, with No Delay I have this feature. I do not have this feature. Use this function to turn on the entire system, both All and Part without entry or exit delays. This function is useful when you stay home and you want your system Make sure all points are normal.

  • Page 14: Turning On Part Of The System (Part On)

    Turning On Part of the System (Part On) I have this feature. I do not have this feature. Part On turns on only a part of your system, leaving the rest of the system turned off. Refer to the Point Identification section of your keypad’s reference card to identify Part points.

  • Page 15: Turning The System Part On, With No Delay

    Turning the System Part On, with No Delay I have this feature. I do not have this feature. Use this function to turn on Part of the system without entry or exit delays. Make sure all points are normal. With your system’s display showing, press the [0] key twice.

  • Page 16: Turning The System On, With Points Open (Bypassing Points)

    Turning the System On, with Points Open (Bypassing Points) I have this feature. I do not have this feature. Use this feature to selectively exclude points you do not wish to turn on with the rest of the system. For example, you may wish to bypass the patio door while turning on the remainder of the system.

  • Page 17: Viewing Alarm Memory

    Viewing Alarm Memory After an alarm has been silenced and cleared from the display, you can still review the points that were in alarm. Ensure the system is turned off (On light is off). If there was an alarm, and the system dialed your alarm company, the OK light flashes.

  • Page 18: Resetting The System

    Resetting the System Use this feature to reset the system (including fire points) after an alarm and to clear alarm memory. Resetting the system takes about 20 seconds. The All, Part, and point lights go out during reset. If points do not reset, the OK light continues to blink.

  • Page 19: Selecting Watch Tone

    Selecting Watch Tone Your system gives you the ability to watch points when it’s turned off, meaning that it can be programmed to alert you to opened doors and windows. For example, parents with small children may want a tone to be sounded whenever a door or window is opened as a way of monitoring the whereabouts of the kids.

  • Page 20: Selecting Watch Points

    Selecting Watch Points Once you decide how your system responds to watched points (see Selecting Watch Tone on page 19), you need to decide which points in your system are to be watched. Use this feature to tell your system which points to watch.

  • Page 21: Checking System Troubles

    Checking System Troubles Your system emits a trouble tone and blinks the OK light to alert you to system trouble events, such as low batteries. Use this feature to learn what is causing the trouble and what steps to take to correct it. Make sure your system is off (On light is off).

  • Page 22: Changing Passcodes

    Changing Passcodes I have this feature. I do not have this feature. This feature lets you change your personal passcode at any time, without assistance from your alarm company. It is recommended that you write down your old passcode and the new one before you begin. Make sure your system is off (On light is off).

  • Page 23: Step Outside

    Step Outside I have this feature. I do not have this feature. Use the Step Outside feature to temporarily turn off protection to an entrance door (or doors) when your system is On with No Delay. You can exit and reenter without turning your system off. Use this feature to pick up the newspaper or to take the dog out.

  • Page 24: Exit Only

    Exit Only I have this feature. I do not have this feature. The Exit Only feature allows you to exit the premises when the system is On with No Delay. After exit delay expires, the door is returned to the system so that opening the door causes an alarm.

  • Page 25: Silencing The Trouble Tone

    Silencing the Trouble Tone The trouble tone sounds and the OK light blinks when there is system trouble, such as low batteries cause system troubles. When there is system trouble, the trouble tone sounds and the OK light blinks. Press the [CLEAR] key to silence the trouble tone. Use Checking System Troubles (press [4]) to discover the origin of the system trouble.

  • Page 26: Show Passcode Types

    Show Passcode Types I have this feature. I do not have this feature. This feature requires a passcode. Use this feature to find out which passcode type is currently assigned to each of the users of your system. Passcode types are shown on lights 1 through 8.

  • Page 27: Change Passcode Type

    Change Passcode Type I have this feature. I do not have this feature. This feature allows those with Owner type passcodes to change the passcode type for each of the users in the system. You cannot change your own passcode type. Passcodes can be one of three types: Owner, User, or One-Time.

  • Page 28: Change Other Users' Passcodes

    Change Other Users’ Passcodes I have this feature. I do not have this feature. This feature allows those with Owner type passcodes to change the passcodes of system users. Press key [6] to enter Show User Mode. Enter your passcode. (Owner type required.) Press [0].

  • Page 29: System Test

    System Test I have this feature. I do not have this feature. This feature helps to ensure that your system is operating properly. Be sure to contact your security company before you begin. Make sure the system is turned off. Press the [1] key and enter your passcode (Owner type required).

  • Page 30: Security System Limitations

    Security System Limitations Not even the most advanced security system can guarantee protection against burglary, fire, or environmental threats. All security systems are subject to possible compromise or failure-to-warn for a variety of reasons including, but not limited to, the following: •...

  • Page 31: Fire Safety And Evacuation

    Fire Safety and Evacuation Residential fire is a leading cause of accidental death. Most fire related deaths occur at night when occupants suffocate in their sleep from smoke and toxic gases, rather than from burns. To help reduce this risk, implement the following program: Minimize fire hazards.

  • Page 32: Security System Glossary

    Security System Glossary All On - Turns on all of the points in the system. Burglary Alarm Tone - Constant warble tone. Bypass - Selectively removes points from the security system temporarily. Central Station - Facility where trained personnel monitor your security system 24 hours a day.

  • Page 33: Maintenance And Service

    Maintenance and Service This security system requires very little maintenance: however, you should test the system weekly to ensure it works properly. A test schedule and maintenance program can be arranged. If you notice a change in operation during normal use or testing, call for service as soon as possible.
  • Page 34 NOTES:...
  • Page 35 NOTES:...
  • Page 36 71-07374-000-C 04/03 Security System User’s Guide ©2003 Bosch Security Systems Page 36 of 36...
