Sony CRX300A Product Information

Introduction
This product offers the following features. Features "Power-Burn conformed"
technology to prevent buffer under-run
An internal CD-RW/DVD-ROM drive errors.
with ATAPI (EIDE) interface for PCs. "Power-Burn conformed" is used to refer to a
CD-R/RW that uses CD-R/RW recording
Writes up to 48 speed on CD-R disc
technology (ICs and/or firmware) other than
media.
Power-Burn, but provides performance equivalent
Writes up to 24 speed on CD-RW disc to that of Sony original Power-Burn technology
based on the Power-Burn concept.
media.
Reads CD-ROM discs at up to 48
Notes
speed.
With the Turbo Boost function, easily • Writing speed may automatically be adjusted
depending on the disc specified speed or disc
switch from the default 40 read/write
conditions such as weight imbalance and eccentricity.
speed to 48 speed.*
• 1 and 2 writing speed and discs are not supported.
Reads DVD-ROM discs at up to 16
speed.
* For details, see "Turbo Boost Function" below.
System Requirements
This CD-RW/DVD-ROM drive can be used At least 32 MB RAM (64 MB or higher
in systems with the following capabilities. recommended)
At least 1 GB available hard disk space
CPU: Pentium 266 MHz or higher One available EIDE (ATAPI) interface
For stable writing performance at high connection with DMA capability
speeds, the CPU speed should be One empty 5-inch half-height drive bay
considerably higher than the above One available internal +12 V/+5 V power
minimum requirement. For writing at connector
48 speed, a Pentium II/400 MHz or
higher is recommended. Notes
PC/AT-compatible PC
• The above system configuration is given as a
OS:
minimum requirement for a system on which basic
® CD-RW writing performance can be obtained. In
Windows 98 Second Edition
actual use, the requirements for the writing software
Windows ® 2000 Professional
and "Windows" also have to be taken into
®
Windows Millennium Edition
consideration. (Normally, these requirements will be
Windows ® XP Home Edition higher than the above specifications.)
®
Windows XP Professional • The drive cannot be assured to operate properly if
connected to an ATAPI interface adapter card (we
cannot guarantee compatibility or offer user support).
Package Contents
Please verify that the package includes the following accessories with the drive when
unpacking.
If any of these items appears to be missing or damaged, please contact your supplier.
• CD-RW/DVD-ROM drive • 40-pin ATAPI (IDE) flat cable
• Screws ( 4)
• Product Information (this document)
• Software Quick Start Guide
• Quick Start Guide (for ATAPI (EIDE) Interface Drive)
• Software disc
• Warranty cards
Note
To guard against possible loss or damage, be sure to make a backup copy of the provided software disc on a CD-R
disc or other media. The software disc is not sold separately.
Please Record Responsibly
Before copying anything onto a CD-R or CD-RW disc, make sure that you are not violating
copyright laws. Most software companies allow you to make a backup or archive copy of
software. Check your software license agreement for details.
Turbo Boost Function
2 Press the Eject button for five
The default CD-R and CD-ROM read/write
speed of this drive is 40 speed. With a seconds.
single touch, you can activate the Turbo The Busy indicator blinks twice and the
Boost function, making the read/write speed speed switches to 48 speed. (The Turbo
48 speed. Boost function is active.)
CAUTION Notes
• On rare occasions, some discs may not be able to • When you want to write at 48 speed, insert the disc
tolerate 48 speed, causing them to break. We into the drive, activate the Turbo Boost function, and
recommend that you do not use deeply scratched, then start writing to the disc.
brittle, or other discs that may break at 48 speed.
• When writing with the Turbo Boost function, the Busy
• The Turbo Boost function does not increase read/write indicator blinks more rapidly than usual. (About twice
speed with CD-RW or DVD-ROM discs. as fast as when writing at the default write speed.)
1 • When you open the disc tray, the speed reverts to its
Insert a disc into the drive.
default of 40 speed.
The speed when you insert a disc is
• The Turbo Boost function does not guarantee a 48
normally 40 speed.
write speed. Depending on the condition of the disc
you are using, the speed may be lower.
Specifications
Compatible discs Buffer under-run error protection
CD-R CD-RW technology
CD-ROM CD-ROM XA
1)
CD-DA CD Extra (CD+)
Operating Environment
Video CD CD TEXT
5 to 40 °C
Photo CD
DVD-ROM DVD-Video
Power and Miscellaneous
Disc diameter 12 cm
8 cm (reading only)
DC +5 V 1.5 A
DC +12 V 1.5 A
1) This product is designed to playback discs that conform to the Compact
Size
Disc (CD) standard. Recently, various music discs encoded with copyright
Approx. 145.8 41.3 165 mm (W H D)
protection technologies are marketed by some record companies. Please
be aware that among those discs, there are some that do not conform to the
(excluding front bezel)
CD standard and may not be playable by this product.
Weight
When you use this unit as an audio CD player, please use compact discs
Approx. 0.9 kg (drive only)
with the following mark.
Interface
Drive interface
Writing Systems
ATAPI (EIDE)-compliant
Track-at-once Disc-at-once
Session-at-once Packet writing
Drive Inquiry
Vender Identification = "SONY"
Drive
Product Identification = "CD-RW
Data transfer rate
CD-ROM Up to 7200 KB/s (48 speed) 2) 3)
Buffer capacity
DVD-ROM Up to 21350 KB/s (16 speed) 3)
2 MB
Access time
Average random stroke CD-ROM 120 ms
Please note that specifications and
DVD-ROM 140 ms
appearance may be subject to change
without notice.
2) When using the Turbo Boost function.
3) The maximum data transfer rate depends on the
capabilities of the host PC.
Product and Support Information
Sony Global Sites Information
Product purchased in the USA:* Product purchased in Taiwan:*
http://sony.storagesupport.com/ http://www.sony.com.tw/stwn/cpd/index.htm
Product purchased in Canada: Product purchased in Korea:*
http://www.sony.ca/ http://www.sony.co.kr/cp
Product purchased in Australia or New Product purchased in Brazil:
Zealand: http://www.sony.com.br/eletronicos
http://www.sony.com.au/support.asp
Product purchased in the Middle East:
Product purchased in Europe:* http://www.sony-middleeast.com
http://www.sonydvd-link.com
* Local Web sites for computer peripheral products
Product purchased in Hong Kong:* About the Bundled Writing Software
http://www.sony.com.hk/Electronics/cp Detailed information about the supplied
writing software is available on the Web
Product purchased in China:*
sites of the software manufacturers and
http://www.sony.com.cn/Electronics/edmh/
software distributors. (Accessible from the
service.htm
links in each software application)
Product Purchase in Singapore:
http://www.sony.com.sg/asianit/
Technical Support
Please consult the above sources before Product purchased in Australia or New
calling with questions about using this Zealand (Sony Australia Limited):
product, or with technical questions about Monday to Friday 8:30 a.m. - 9:00 p.m. EST
the drive or the supplied software. If using • Toll Free: (Australia) 1300-13-7669
telephone or e-mail support, please have the (NZ) 0800-7669-7895
following information available: • E-mail: CIC-Customerissues@ap.sony.com
• Model number: CRX300A Product purchased in Europe:
• Serial number Monday to Friday
• Date and place of purchase 8:00 a.m. - 6:00 p.m. CET
th
• Computer maker and model number (Except December 25 and January 1
• Austria 0179 567 397
• Computer specifications (CPU speed,
• Belgium 027 173 220 / 027 173 221
memory size, OS version, etc.)
• Denmark 70 112 107
• Writing software used (version, etc.)
• Finland 01080 6570
• France 0803 827962
Local technical support service is
• Germany 01805 987 986
available only in the following
• Greece 00800 4412 1175
sales regions: • Ireland 01890925069
• Italy 848800977
Product purchased in the USA • Luxembourg 034 208 083 60
(Sony Electronics Inc.): • Netherlands 020 346 9404
• Norway 810 01 005
Monday to Saturday 8:00 a.m. - 8:00 p.m. CT
• Portugal 214 154 221
• Toll Free: 1-800-588-3847
• Spain 901 120 105
• Free telephone support is offered for 90
• Sweden 0858 769 241
days from your first call.
• Switzerland 084 424 6336 / 084 423 7337
• United Kingdom 0870 240 2410
Product purchased in Canada
• E-mail: support@sonyopticalstorage-link.com
(Sony of Canada Limited):
24 hours / 7 days a week
Product purchased in Singapore
• Toll Free: 1-800-961-7669 (Sony Electronics Singapore Pte. Ltd.):
• http://www.sony.ca/sonyca/
Monday to Friday 9:00 a.m. - 5:00 p.m.
customersupport_contactus.shtml • Storage Support Hotline (not toll free):
+65-3291715
• E-mail: EDMS.Support@ap.sony.com
Safety Regulations
WARNING
You are cautioned that any changes or modifications not expressly approved in this document could void your
authority to operate this equipment.
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.
CAUTION:
As the laser beam in the CRX300A is harmful to the eyes, do not attempt to disassemble the cabinet. Refer
servicing to qualified personnel only.
The use of optical instruments with this product will increase eye hazard.
The use of controls or adjustments or performance of procedures other than those specified herein may result in
hazardous radiation exposure.
This label is located on the top of the drive unit enclosure.
Dieses Etikett befindet sich an der Oberseite des Laufwerksgehäuses.
CRX300E"
The CD-RW/DVD-ROM drive is classified as a CLASS 1 LASER PRODUCT.
The CLASS 1 LASER PRODUCT label is located at the top of the enclosure.
Bei diesem CD-RW/DVD-ROM-Laufwerk handelt
CLASS 1
es sich um ein Laser-Produkt der Klasse 1.
LASER PRODUCT
Das Etikett mit der Aufschrift LASER KLASSE 1
LASER KLASSE 1
PRODUKT befindet sich auf der Oberseite des
PRODUKT
Gehäuses.
FCC Compliance:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Note:
If you have any questions about this product, you may call the telephone number listed in the "Product and
Support Information" section. The telephone number below is not for customer service, but for official
purposes only.
Declaration of Conformity
Trade Name: SONY
Model No.: CRX300A
Responsible Party: Sony Electronics Inc.
Address: 680 Kinderkamack Road, Oradell, NJ 07649 USA
Telephone No.: 201-930-6972
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
CE Sicherheitsbestimmungen
Diese Ausrüstung erfüllt die Europäischen EMC-Bestimmungen für die Verwendung in folgender / folgenden
Umgebung(en):
st • Wohngegenden • Gewerbegebiete • Leichtindustriegebiete
)
(Diese Ausrüstung erfüllt die Bestimmungen der Norm EN55022, Klasse B.)
• Power-Burn and are trademarks of Sony Corporation.
• Pentium is a registrated trademark of Intel Corporation.
• Microsoft, MS, MS-DOS and Windows are registered trademarks of Microsoft Corporation.
• Other system and product names used herein are registered trademarks or trademarks of their respective
TM
manufacturers, although the and ® marks are not used in the text.
Before using this device, be sure to read the end-user license agreements for the software provided with your
computer.
Our product warranty is valid only when the supplied accessories (including software) are used in the
specified or recommended system environment, in accordance with the documentation, and applies
only to the CD-RW/DVD-ROM drive. Our customer service and user support apply only under these
product warranty conditions.
Please note that we cannot accept responsibility for failure of the computer or other devices,
incompatibility with special hardware, operating problems caused by improper installation of software,
loss of data, discs or other accidental or incidental damage that might occur when using this product.
The guarantee and user support for this product are valid only within the countries or sales regions
specified on the warranty card.
Copyright laws prohibit the copying in part or in full of the supplied software and documentation, or
loaning the software, without obtaining permission of the copyright holder.
We cannot accept responsibility for any direct or indirect financial damage or loss of profit that might
occur when using the supplied software.
The supplied software can only be used with this product.
Specifications of the supplied software may be changed without notice in the interest in product
improvement.
CD-RW/DVD-ROM
Drive
Product Information
Included Documents
Quick Start Guide
Software Quick Start Guide
Electronic manual on the software disc
Warranty cards
Product Information (this document)
LUOKAN 1 LASERLAITE
KLASS 1 LASER APPARAT
CRX300A
2003 Sony Corporation
English
Please refer to this manual together with the "ATAPI Interface Drive User's Guide" in the attached Software
Disc, which carries more detailed information.
Français
Reportez-vous au présent manuel ainsi qu'au document intitulé "Lecteur d'interface ATAPI - Guide de
l'utilisateur" contenu sur le disque du logiciel accompagnant ce produit pour plus de détails.
Deutsch
Einzelheiten entnehmen Sie bitte diesem Handbuch sowie der "Laufwerk mit ATAPI-Schnittstelle -
Anwenderanleitung" auf der mitgelieferten Software-Disc.
Español
Consulte este manual junto con la "Unidad de interfaz ATAPI - Guía del usuario" del disco de software
suministrado, que contiene información más detallada.
Italiano
Fare riferimento al presente manuale insieme a "Guida dell'utilizzatore dell'unità disco con interfaccia ATAPI"
nel disco del software allegato, nel quale sono contenute informazioni più dettagliate.
Português
Consulte este manual juntamente com o "Guia do Utilizador do Drive de Interface ATAPI" incluído no disco
de software fornecido, para obter informações mais detalhadas.
Nederlands
Raadpleeg deze handleiding alsook de "ATAPI Station-interface -Gebruikershandleiding" op de bijgevoegde
Software Disc, die meer gedetaileerde informatie bevat.
Svenska
Förutom denna bruksanvisning finns mer information i "Brukanvisning för enhet med ATAPI gränssnitt" på
den medföljande programskivan.
A-BKW-100-12(1)
Printed in China P/N: 7819900504
