Summary of Contents for Zanussi ZV280
- Page 1 CONGELADOR FREEZER ZV280 ZV280R ZV320 ZV320R INSTRUCCIONES DE USO INSTRUCTION BOOKLET 818 14 97--01/0...
-
Page 2: Table Of Contents
......Electrical connection ......Zanussi 8181497-01/0... -
Page 3: Description Of The Appliance
Description of the Appliance Model ZV280, ZV280R freezing tray shelf with flap freezer vasket ventilation grill freezer calender Model ZV320, ZV320R freezing tray shelf with flap freezer vasket ventilation grill freezer calender Control Panel A. Red warning lamp D. Green indicator lamp Flashes when one of the alarms in the cabinet has Lights when the freezer is operating. -
Page 4: Before Use
Temperature inside the freezer To ensure that foodstuff will keep for a long time, be sure that the temperature inside the freezer is -18°C or below. Please note, however, that the energy consumption increases as the temperature decreases. Zanussi 8181497-01/0... -
Page 5: Freezing
20 mm from the front edge. This allows maximum use of the available space. Do not remove the bottom drawer. It is required to assure proper air circulation. Zanussi 8181497-01/0... -
Page 6: Hints And Tips
All parts in the packaging can be recycled. · Defrost the freezer when the frost layer reaches a · The cabinet has been designed for easy thickness of 3-5 mm. dismantling and subsequent recycling. · Make sure the door gasket is complete and always clean. Zanussi 8181497-01/0... -
Page 7: Maintenance And Cleaning
Make sure the door is open when removing the ventilation grille. Unsnap the upper edge of the grille by pulling outward/downward. Then pull the grille straight out to completely remove it. Model ZV280, ZV320 Unsnap the ventilation grille by pulling it toward you. Defrosting the freezer A certain amount of frost will always form on the freezer shelves and around the top compartment. -
Page 8: To Change The Light Bulb
Set a higher temperature. The compressor operates continuously. Set a higher temperature. Make sure that the door is completely closed and that the insulating strip is complete and clean. The temperature where the cabinet is placed is above normal room temperature. Zanussi 8181497-01/0... -
Page 9: Guarantee Conditions
Guarantee Conditions See Guarantee Conditions on the Registration Card. Technical specification ZV280 ZV280R ZV320 ZV320R Model 252 l 252 l... -
Page 10: Installation
If the cabinet is placed in a corner and the side with the hinges faces the wall, the distance between the wall and the cabinet must be at least 10 mm to allow the door to open enough so that the shelves can be removed. Zanussi 8181497-01/0... -
Page 11: Door Reversal
7. Put the cabinet in position. Check that it stands straight. See the section "Positioning the cabinet". Electrical connection Connect the cabinet to a grounded electrical outlet. Voltage: 230 V. Fuse: 10 A. Refer to the rating plate on the left inside the cabinet. Zanussi 8181497-01/0... - Page 12 MARIESTAD DD--AV...
