WARNINGS It is most important that this instruction book should be If the appliance has been transported retained with the appliance for future reference. Should the horizontally, it is possible that the oil contained in appliance be sold or transferred to another owner, or should the compressor flows in the refrigerant circuit.
INSTALLATION If this appliance featuring magnetic door seals is to Electrical connection replace an older appliance having a spring lock on the Before plugging in, ensure that the voltage and door or lid, be sure to make that spring lock unusable frequency shown on the serial number plate before you discard the old appliance.
Changing the opening direction of the door Fig. 1 Unplug the freezer before performing the following operations: Remove the ventilation grid (C-Fig. 1). Unscrew the bottom hinge (D-Fig. 1). Remove the door from the upper pivot (A-Fig. 2). Remove the pivot from the upper hinge (B), then mount it on the opposite side.
Installation under the kitchen’s work-top Fig. 4 Open the door. Remove from the upper hinges the screws (F- Fig. 4) that fix the appliance’s work-top. Push the work-top (G) toward the back of the appliance and remove it. Remove the work-top’s brackets (H) from the appliance.
The freezer is marked with the symbol, which means that the compartment is suitable for freezing fresh food and for long-term storage of frozen food. Control panel (Fig. 7) A. Temperature adjustment knob B. Quick freezing switch C. Operating pilot lamp D.
Freezing of fresh foods A special card is located in the holder on the inner door of the freezer compartment. On the upper part To quick-freeze foods when the appliance has not it shows pictures of different types of food followed been in use, switch on the freezer and let it run on by a figure.
Positioning the cold accumulator Ice cube trays Pull out the bottom drawer. The appliance includes one tray for producing ice Remove the cold accumulator (A-Fig. 9) which is cubes. This tray should be filled with drinkable placed on the floor of the compartment for safety water and repositioned inside the freezer.
MAINTENANCE Before carrying out any maintenance operation, always Periodical cleaning disconnect the plug from the wall socket. Wash the interior of the appliance with lukewarm water and sodium bicarbonate. Defrosting Clean cabinet outer surfaces with a silicone-wax spray. The frost should be removed with the special plastic The condenser and compressor should be cleaned scraper provided, whenever the thickness exceeds 4 using a brush or a vacuum cleaner.
