Important Safety Information These warnings are provided in the interest of your safety. You MUST read them carefully before installing or using the appliance. Keep this instruction book for future reference and ensure it is passed on to any new owner. Installation •...
Contents For the User For the Installer Important Safety Information Instructions for the Installer Description of the Appliance Building in Controls Electrical Connection Before the First Use Gas connection Using the Oven Conversion from Natural to LPG Gas Using the Traditional Gas Oven Grilling Grilling with the turnspit Cleaning the Oven...
Description of the Appliance 1. Control panel 2. Minute minder 3. Light and Grill control knob 4. Gas oven control knob 5. Grill control light 6. Mains on light 7. Grill 8. Oven lamp 9. Turnspit hole 10. Rating plate 11.
Mains on Light The mains on light will come on when the “Light and Grill” control knob is set. Grill Control Light The Grill (thermostat) control light will come on when the thermostat control knob is turned. The light will remain on until the correct temperature is reached.
Using the Oven • Always cook with the oven door closed. • Stand clear when opening the drop down oven door. Do not allow it to fall open - support the door using the door handle, until it is fully open. •...
Using the Traditional Gas Oven During cooking, the door should be opened as little Cooking Chart as possible to avoid heat loss, and excessive fuel consumption. TEMP. SHELF COOKING FOOD (°C) POSITIONS TIME To ignite the oven gas burner: MEAT & POULTRY 1.
Grilling Hints and Tips Grilling must be carried out with the oven door closed. Most foods should be placed on the grid in the grill pan to allow maximum circulation of air to lift the How to Use the Grill food out of the fats and juices.
Cleaning the Oven Before cleaning always allow the cooling fan to Oven Cavity cool the oven down before switching off at the The enamelled oven cavity is best cleaned whilst the electricity supply. oven is still warm. This appliance cannot be cleaned with steam or Wipe the oven over with a soft cloth soaked in warm with a steam cleaning machine.
Replacing the Oven Light Disconnect the appliance. If the oven bulb needs replacing, it must comply with the following specifications: - Electric power: 15W, - Electric rate: 230-240 V (50 Hz), - Resistant to temperatures of 300°C, - Connection type: E14. These bulbs are available from your local Service Force Centre.
Something Not Working If the appliance is not working correctly, please carry out the following checks, before contacting your local Service Force Centre. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee.
Instructions for the Installer Technical Data Oven Model Name: ZGT 1 Grill Element 1,650 W Oven burner 2,7 W (Natural gas) APPLIANCE GAS SUPPLY: Natural Gas G20 20mbar 2,5 W (LPG) APPLIANCE CATEGORY:II 2H3+ Oven light 25 W Cooling fan...
Please ensure that when the oven is installed it is easily accessible for the engineer in the event of a breakdown. BUILDING IN The surround or cabinet into which the oven will be built must comply with these specifications: the dimensions must be as shown in the relevant diagrams;...
Electrical Connection The oven is designed to be connected to 230 V (50Hz) electricity supply. The oven has an easily accessible terminal block which is marked as follows: Letter L Live terminal Letter N Neutral terminal or E Earth terminal THIS OVEN MUST BE EARTHED The cable used to connect the oven to the electrical supply must comply to the specifications given below.
Gas connection Connecting the appliance to the View flexible from metallic pipe gas supply above gasket The gas supply connection ramp is located in the upper side of the oven, right behind the control panel. To carry out the gas connection: 1.
Conversion from Natural to LPG Gas IMPORTANT The replacement/conversion of the gas hob should only be undertaken by qualified personnel. It is important to note that this model is designed for use with natural gas at a feeding pressure of 20 mbar but can be converted for use with LPG providing the correct injectors are fitted.
Page 18
Minimum level adjustment of gas oven burner This procedure must be undertaken by qualified personnel only. Disconnect the appliance from the electricity supply. 2. Remove all the knobs. 3. Open the oven door and locate the ventilation grid which is fixed right below the control panel.
