- Page 1 KDC-4757SD KDC-3657SD CD-RECEIVER INSTRUCTION MANUAL CD-RECEIVER BEDIENUNGSANLEITUNG CD-PECИBEP ИHCTPУKЦИЯ ПO ЭKCПЛУATAЦИИ CD-РЕСІВЕР ІНСТРУКЦІЯ З ЕКСПЛУАТАЦІЇ...
- Page 2 Declaration of Conformity with regard to the EMC Directive 2004/108/EC Manufacturer: Information on Disposal of Old Electrical and Electronic Equipment and Batteries (applicable for EU countries that have adopted separate waste EU Representative’s: collection systems) Konformitätserklärung in Bezug auf die EMC-Vorschrift 2004/108/EC Hersteller: EU-Vertreter: Entsorgung von gebrauchten elektrischen und elektronischen Geräten und...
- Page 3 Декларація про Відповідність Вимогам Технічного Регламенту Обмеження Використання деяких Небезпечних Речовин в електричному та електронному обладнанні (затвердженого Постановою №1057 Кабінету Міністрів України) The marking of products using lasers Kennzeichnung von Geräten mit Laser-Abtastern Маркировка изделий, использующих лазеры For Turkey Маркування виробів, обладнаних лазером Eski Elektrik ve Elektronik Ekipmanların İmha Edilmesi Hakkında Bilgi (ayrı...
-
Page 4: Table Of Contents
CONTENTS BEFORE USE BEFORE USE Warning Do not operate any function that takes your attention away from safe driving. BASICS GETTING STARTED Caution Volume setting: RADIO • Adjust the volume so that you can hear sounds outside the car to prevent accident. •... -
Page 5: Basics
BASICS Faceplate Insert an SD card Press L SRC to turn off the power. Volume knob (turn/press) Loading slot Attach KDC - 4757SD Detach the faceplate. Insert the SD card into the SD CARD slot until it clicks. (With the label side up and the notched section on the right.) Detach SD CARD slot... -
Page 6: Getting Started
4 inches, 6×9 inches or 6 inches) or OEM speakers for optimum performance. F/W UPDATE F/W UP xx.xx YES: Starts upgrading the firmware. ; NO: Cancels (upgrading is not activated). For details on how to update the firmware, see: www.kenwood.com/cs/ce/... -
Page 7: Radio
RADIO Selects the available Program Type (see below), then, press 4 / ¢ to start. PTY SEARCH Press the volume knob to enter PTY language selection. Turn the volume knob to select the PTY language (ENGLISH/ FRENCH/ GERMAN), then press the knob. ON: Allows the unit to temporarily switch to Traffic Information. -
Page 8: Cd / Usb / Sd / Ipod
Turn the volume knob to make a selection, then press the knob. • AAC/MP3/WMA file: Select the desired folder, then a file. The source changes to USB and playback • iPod or KENWOOD Music Editor Light (KME Light)/ KENWOOD Music starts. Control (KMC) file *... -
Page 9: Aux
CD / USB / SD / iPod Preparation: KDC - 4757SD Select a song by name (for Set the skip ratio Select [ON] for [BUILT-IN AUX]/ [BUILTIN AUX]. (➜ 4) KDC - 4757SD While listening to iPod... While listening to iPod (for ) or KME Press Light/ KMC file... -
Page 10: Audio Settings
AUDIO SETTINGS While listening to any source... BASS BOOST B.BOOST LV1/ B.BOOST LV2/ B.BOOST LV3: Selects your preferred bass Press the volume knob to enter [FUNCTION]. boost level. ; OFF: Cancels. Turn the volume knob to select [AUDIO CONTROL]/ [AUDIO CTRL], then press the LOUDNESS LOUDNESS LV1/ LOUD LV1/ LOUDNESS LV2/ LOUD LV2: Selects your knob. -
Page 11: Display Settings
DISP DIMMER ON: Dims the display illumination. ; OFF: Cancels. Multi Card Reader. “KENWOOD Music Control,” you can search for a file by • Connecting a cable whose total length is longer than TEXT SCROLL AUTO/ ONCE: Selects whether to scroll the display information title, album or artist name using Music Search. -
Page 12: Troubleshooting
TROUBLESHOOTING Symptom Remedy Symptom Remedy Sound cannot be heard. • Adjust the volume to the optimum level. “NA DEVICE” appears. • Connect a supported USB device, and check the connections. • Check the cords and connections. • Insert a supported SD card properly. “PROTECT”... -
Page 13: Specifications
SPECIFICATIONS FM Frequency Range 87.5 MHz to 108 MHz (50 kHz space) Compatible Physical Format Version 2.00 Usable Sensitivity (S/N = 26 dB) 1.0 μV/75 Ω Maximum Memory Capacity 32 GB Quieting Sensitivity 2.5 μV/75 Ω File System FAT16/ 32 (DIN S/N = 46 dB) AAC Decode AAC-LC “.m4a”... -
Page 14: Installation / Connection
Installating the unit (in-dash mounting) Warning • The unit can only be used with a 12 V DC power supply, negative ground. Do the required • Disconnect the battery’s negative terminal before wiring and wiring. (➜ 13) mounting. • Do not connect Battery wire (yellow) and Ignition wire (red) to the car chassis or Ground wire (black) to prevent a short circuit. -
Page 15: Wiring Connection
To the terminal that is grounded when either the telephone rings or during conversation. ( ×1 ) (Mute control wire) (To connect the Kenwood navigation system, consult your navigation manual.) MUTE E Extraction key Connecting the ISO connectors on some VW/...
