Sharp FO-IS110N Quick Setup Manual

FO-IS110N QUICK SETUP GUIDE
For detailed instructions
on setting up and using the FO-IS110N, see the
online guide on the CD-ROM.
To open the manual, insert the CD-ROM in your
CD-ROM drive and click "Browse CD
Contents" in the screen that appears. Double-
click the Manual folder, the Thailand folder, the
Thai or English folder depending on which
language you prefer, and then double-click
FO-IS110N Online Manual.pdf.
(Note: Adobe Reader is required to view the
manual. To install Adobe Reader, double-click
the Adobe Reader folder on the CD-ROM and
then double-click AdbeRdrxxx_en_US.exe.)
All company names and product names appearing
in this setup guide are the trademarks of their
respective owners.
3
Attach the trays.
Insert trays at an
angle and rotate back
6
Install the toner cartridge and drum cartridge.
1. Open the top cover of the machine.
4. Remove the drum cartridge from its
packaging. Insert the cartridge into
the print compartment, sliding it along
the guides.
➊
7. Close the side cover , the front cover
➋ ➌
, and the top cover .
1
1
Make sure you have the following items.
If any are missing, contact your dealer.
Handset
Handset
cord
Document Phone
exit tray line cord
CD-ROM
Caution!
Do not touch the
inside of the print
compartment after
the machine has
been in operation.
Parts of the print
compartment may
become very hot.
Grasp this
handle to
push the
cartridge in
Caution!
Do not expose the drum to light
for more than several minutes.
Do not touch the green cylinder.
3
Display:
TONER EXCHANGED?
1=NEW, 2=OLD
2
Received
Paper tray
document
tray
Toner
Drum
cartridge
cartridge
Quick
Reference
Quick Setup
Guide
Guide
4
Plug the power cord into a
220-240 V, earthed AC outlet.
or
➊
2. Press the release and
➋
open the front cover .
2
1
5. Remove the toner cartridge from its
packaging. Shake the cartridge side
to side four or five times as shown.
8. Press "NEW" and
to select
then press (This resets the
.
toner cartridge counter.)
2
Connect the handset.
Document
feeder
tray
Rapid Key
labels
5
Connect the phone line cord
to the TEL. LINE socket and
a wall socket.
3. Open the side cover.
6. Insert the toner cartridge into the
print compartment, sliding it along
the guides until it clicks into place.
9. Reset the drum cartridge counter:
a.
Press
[LIFE] appears in the display.
b. Press , then until [CLEAR DRUM
COUNTER] appears.
c. Press .
English
Grasp this handle to
insert the cartridge
, and then until
