KX-TCD970E-B
PLEASE READ BEFORE USE AND SAVE.
Charge the battery for about 3 hours before initial use.
This equipment is not designed for making emergency
telephony calls when the power fails. Alternative arrangements
should be made for access to emergency services.
Digital Cordless Answering System
Model No.
Operating Instructions
KX-TCD970E-B
KX-TCD960E-B
KX-TCD960E-B
