Panasonic TH-50PHW3 Operating Instructions Manual

High definition plasma display
Hide thumbs Also See for TH-50PHW3:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
+
—
VOL
INPU
T
DBY
/
R - STAN
POW
ER
ER ON
G POW
Before connecting, operating or adjusting this product, please read these instructions completely. Please keep this
manual for future reference.
English
High Definition Plasma Display

Operating Instructions

PLASMA DISPLAY
TH-50PHW3
TH-50PHD3
Model No.
®
TQBC0252

Advertisement

Table of Contents
loading

Related Manuals for Panasonic TH-50PHW3

Summary of Contents for Panasonic TH-50PHW3

  • Page 1: Operating Instructions

    ® High Definition Plasma Display Operating Instructions PLASMA DISPLAY TH-50PHW3 — TH-50PHD3 INPU R - STAN ER ON G POW Model No. Before connecting, operating or adjusting this product, please read these instructions completely. Please keep this manual for future reference.
  • Page 2 Dear Panasonic Customer Welcome to the Panasonic family of customers. We hope that you will have many years of enjoyment from your new High Definition Plasma Display. To obtain maximum benefit from your set, please read these Instructions before making any adjustments, and retain them for future reference.

  • Page 3: Table Of Contents

    How to connect the PC Input Terminals ....14 (3D Y/C Filter) ..........28 How to connect the SERIAL Terminals ....15 Colour system / Panasonic Auto ......29 Power On/Off and input signal selection ....16 [Sync] ............... 30 Power On/Off ............

  • Page 4: Warnings And Precautions

    If you lose the fuse cover the plug must not be used until a replacement cover is obtained A replacement fuse cover can be purchased from your local Panasonic Dealer.. If the fitted moulded plug is unsuitable for the socket outlet in your home, then the fuse shall be removed and the plug cut off and disposed of safety.
  • Page 5 High voltages which can cause severe electric shocks are present inside the High Definition Plasma Display. For any inspection, adjustment and repair work, please contact your local Panasonic dealer. Securely insert the power cord plug as far as it will go.

  • Page 6: Cleaning And Maintenance

    If water or foreign objects get inside the High Definition Plasma Display, if the High Definition Plasma Display is dropped, or if the cabinet becomes damages, disconnect the power cord plug immediately. • A short circuit may occur, which could cause fire. Contact your local Panasonic dealer for any repairs that need to be made. CAUTION When using the High Definition Plasma Display Do not bring your hands, face or objects close to the ventilation holes of the High Definition Plasma Display.

  • Page 7: Accessories

    SET UP PICTURE POS. /SIZE ASPECT OFF TIMER PLASMA DISPLAY Guarantee Card RCA-BNC adapter plug (for Model No. TH-50PHW3 only) (for Model No. TH-50PHW3 only) Optional Accessories • Speakers • Pedestal • Wall stand • Mobile stand TY-SP50PH3W (for TH-50PHW3)

  • Page 8: Remote Control Batteries

    Remote Control Batteries Requires two R6 batteries. 2. Install the batteries as shown in 3. Replace the cover and slide in 1. Turn the transmitter face down. Press and slide off the battery the battery compartment. reverse until the lock snaps. cover.

  • Page 9: Basic Controls

    Basic Controls – INPUT R - STANDBY G POWER ON TH-50PHW3 Main Power On/Off Switch Volume Adjustment Input button Push the Volume Up “+” or Down Power Indicator (VIDEO (S-VIDEO)/COMPONENT, “–” button to increase or decrease The Power Indicator will light.

  • Page 10: Connections

    Connections When connecting the speakers, be sure to use only the optional accessory speakers. Refer to the speaker’s Installation Manual for details on speaker installation. Speakers (Optional accessories) SPEAKERS Terminals (L) SPEAKERS Terminals (R) – Cable fixing bands Secure any excess cables with bands as required. To tighten: To loosen: Push...

  • Page 11: How To Connect The Av Input Terminals

    Connections How to connect the AV Input Terminals S-VIDEO Signal Connection (Example) When connecting a S-Video VCR (DVD Player / S-VIDEO VCR) Audio Video S-Video AUDIO VIDEO S-VIDEO AV IN S-VIDEO 4 pin socket Luminance earth Chrominance earth Video input to S-VIDEO socket VIDEO AUDIO...

  • Page 12: How To Connect The Component/Rgb Input Terminals

    Connections How to connect the COMPONENT/RGB Input Terminals COMPONENT signal Connection Example of input signal source Video input to Y, P sockets HDTV-compatible VCR cables AUDIO COMPONENT/RGB IN RGB camera AUDIO 2 RCA Audio cables Audio input to L/R sockets RGB signal (R, G, B, HD, VD) Connection The TUNER input terminal is reserved for use with future external compatible components.
  • Page 13 Connections VIDEO Signal Connection (DVD / Satellite Receiver) AUDIO VIDEO S-VIDEO AV IN Video input to BNC socket RCA-BNC adapter plug AUDIO COMPONENT/RGB IN RCA-BNC adapter plug The cable shown is for connection detail only. If you wish to use this connection method, please consult your Dealer for the cable.

  • Page 14: How To Connect The Pc Input Terminals

    Connections How to connect the PC Input Terminals COMPUTER AUDIO PC IN POWER R - STANDBY INPUT — G POWER ON Conversion adapter (if necessary) D-sub 15p PC cable Audio 1/8" (3mm) Stereo Plug Connect a cable which matches the audio output terminal on the computer. Notes: (1) Computer signals which can be input are those with a horizontal scanning frequency of 15.5 to 110 kHz and vertical scanning frequency of 48 to 120 Hz.

  • Page 15: How To Connect The Serial Terminals

    If multiple commands are transmitted, be sure to PC mode wait for the response for the first command to come Screen mode select (toggle) None from this unit before sending the next command. Normal (4:3) NORM Zoom ZOOM Full FULL Just JUST Panasonic Auto SELF...

  • Page 16: Power On/Off And Input Signal Selection

    (see page 19) Select the desired language using the keys and press the store button. R - STANDBY G POWER ON TH-50PHW3 OSD Language lish ( UK ) Deutsch Remote Control Sensor Power Indicator Fran ais...

  • Page 17: Select The Input Signal

    Power On/Off and input signal selection Select the input signal INPUT Press the INPUT button to select the input video signal to be played back from the equipment such as a VCR which has been connected to the High Definition Plasma Display.

  • Page 32: Specifications

    Specifications TH-50PHW3 TH-50PHD3 Power Source Power Consumption Plasma Display panel Screen size Operating condition Applicable signals Connection terminals Accessories Supplied...
  • Page 36 Warranty Service purposes. Model Number Serial Number Panasonic (U.K.) Ltd. Matsushita Electric Industrial Co., Ltd. Willoughby Road, Bracknell, Central P.O. Box 288, Osaka 530-8692, Japan...

This manual is also suitable for:

Th-50phd3
