TCD200G(e-g).book Page 1 Tuesday, February 8, 2005 8:57 AM

Operating Instructions

Digital Cordless Phone
KX-TCD200G
Model No.
This unit is Caller ID compatible. To display the caller's phone number,
you must subscribe to Caller ID service.
Charge the batteries for about 7 hours before initial use.
Please read these operating instructions before using the unit and save them for future
reference.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-TCD200G

Summary of Contents for Panasonic KX-TCD200G

  • Page 1: Operating Instructions

    TCD200G(e-g).book Page 1 Tuesday, February 8, 2005 8:57 AM Operating Instructions Digital Cordless Phone KX-TCD200G Model No. This unit is Caller ID compatible. To display the caller’s phone number, you must subscribe to Caller ID service. Charge the batteries for about 7 hours before initial use.
  • Page 2 L In the event of problems, you should contact your equipment supplier in the first instance. Declaration of Conformity: L Panasonic Communications Co., Ltd. declares that this equipment is in compliance with the essential requirements and other relevant provisions of Radio & Telecommunications Terminal Equipment (R&TTE) Directive 1999/5/EC.

  • Page 3: Table Of Contents

    TCD200G(e-g).book Page 3 Tuesday, February 8, 2005 8:57 AM Inhalt Preparation Useful Information Accessory information....4 Wall mounting......31 Important information .

  • Page 4: Accessory Information

    TCD200G(e-g).book Page 4 Tuesday, February 8, 2005 8:57 AM Preparation Accessory information Included accessories AC adaptor Telephone line cord Rechargeable batteries PQLV19CE AAA (R03) size HHR-4EPT Handset cover Operating instructions Additional/replacement accessories Model No. Description P03P 2 rechargeable nickel metal hydride (Ni-MH) batteries KX-TCA120EX Additional Digital Cordless Handset KX-A272...

  • Page 5: Important Information

    TCD200G(e-g).book Page 5 Tuesday, February 8, 2005 8:57 AM Preparation stopped and contact an authorised service Important information centre. Location General L For maximum distance and noise-free L Use only the AC adaptor included with this operation, place your base unit: product, noted on Seite 4.

  • Page 6: Controls And Displays

    TCD200G(e-g).book Page 6 Tuesday, February 8, 2005 8:57 AM Preparation Hinweis: Controls and displays L Up to 3 menu items can be displayed at a time. To select a menu item not shown on the current page, scroll up or down by pressing the Controls navigator key, {e} or {v}, respectively.

  • Page 7: Connections

    TCD200G(e-g).book Page 7 Tuesday, February 8, 2005 8:57 AM Preparation Display icon Meaning Connections Voice enhancer is set to high [VE] When the AC adaptor is connected, a short beep or low tone. (Seite 11) will be heard. If it is not heard, check the Night mode is on.

  • Page 8: Battery Installation

    TCD200G(e-g).book Page 8 Tuesday, February 8, 2005 8:57 AM Preparation When the batteries are fully charged, 5 Battery installation remains on the display. Insert the batteries negative (T) terminal first. Close the handset cover. Hinweis: L It is normal for the handset to feel warm during charging.

  • Page 9: Battery Replacement

    TCD200G(e-g).book Page 9 Tuesday, February 8, 2005 8:57 AM Preparation Battery life Turning the power on/off After your Panasonic batteries are fully charged, you can expect the following performance: Power on Ni-MH batteries (700 mAh) Press {ih} for about 1 second.

  • Page 10: Making/Answering Calls

    TCD200G(e-g).book Page 10 Tuesday, February 8, 2005 8:57 AM Making/Answering Calls Press {R}. Making calls L The last number dialled will be displayed. Press {e} or {v} repeatedly to select the Lift the handset and dial the phone number. desired number. L To correct a digit, press {C/T}, then enter L To exit the list, press {ih}.

  • Page 11: Answering Calls

    TCD200G(e-g).book Page 11 Tuesday, February 8, 2005 8:57 AM Making/Answering Calls Select the desired category (Seite 13), then conversation. Contact your service provider for press {>}. details. Select “Speichern”, then press {>}. Hinweis: L If your unit is connected to a PBX (private Press {ih}.

  • Page 12: Other Features

    TCD200G(e-g).book Page 12 Tuesday, February 8, 2005 8:57 AM Making/Answering Calls Hinweis: L The ringer volume cannot be adjusted if the handset is on the base unit. Other features Handset locator Using this feature, you can locate the handset if it has been misplaced.

  • Page 13: Phonebook

    TCD200G(e-g).book Page 13 Tuesday, February 8, 2005 8:57 AM Phonebook Changing category names Using the phonebook Press {k}, then press {j/OK}. The phonebook allows you to make calls without Select “Kategorie”, then press {>}. having to dial manually. You can add 20 names Select the category you want to change the and phone numbers to the phonebook, assign name of, then press {>}.

  • Page 14: Chain Dial

    TCD200G(e-g).book Page 14 Tuesday, February 8, 2005 8:57 AM Phonebook Select “Kategoriesuche”, then press One touch dial {>}. Select the category you want to search, then Assigning an entry in the phonebook to a one press {>}. touch dial key L The first entry in that category is Dial keys {1} to {9} can each be used as a one displayed.

  • Page 15: Copying Phonebook Entries To Other Handsets15

    Phonebook entries (Seite 13) can be copied from desired entry. the handset to the phonebook of a compatible L To search by first character (index search), Panasonic handset. see Seite 13. To search by category, see Seite 13. Copying one entry Press {>} to dial the number.

  • Page 16: Handset Settings

    TCD200G(e-g).book Page 16 Tuesday, February 8, 2005 8:57 AM Handset Settings Guide to handset settings For your reference, a chart of all items which can be customised for the handset is printed below. L When customising the handset, the current item or setting is indicated by >. Handset settings Sub-menu Sub-menu 2...

  • Page 17: Time Settings

    TCD200G(e-g).book Page 17 Tuesday, February 8, 2005 8:57 AM Handset Settings Select “Mobilteileinst.”, then press Time settings {>}. Select “Ruftoneinstell.”, then press Alarm {>}. Select “Ruflautstärke”, then press {>}. An alarm will sound for 3 minutes at the set time Press {e} or {v} repeatedly to select the once or daily.
  • Page 18 TCD200G(e-g).book Page 18 Tuesday, February 8, 2005 8:57 AM Handset Settings sleeping. Night mode can be set independently Setting the ring delay for night mode for the handset and the base unit (Seite 22). This setting allows the handset to ring during Using the phonebook’s category feature (Seite night mode if the caller waits long enough.

  • Page 19: Display Setup

    TCD200G(e-g).book Page 19 Tuesday, February 8, 2005 8:57 AM Handset Settings Changing the display contrast Display setup Press {j/OK}. Selecting the standby mode display Select “Mobilteileinst.”, then press {>}. “Basis Kennung”: The current base unit Select “Display-Einst.”, then press number is displayed. “Mobilt.-Nr.”: The current handset number is {>}.

  • Page 20: Other Options

    PIN. The unit will not reveal the PIN to you. If you forget your PIN, consult your L The following items will be deleted or reset to their default settings: nearest Panasonic service centre. – Settings listed on Seite 16 Press {j/OK}. – Redial list Select “Mobilteileinst.”, then press...

  • Page 21: Base Unit Settings

    TCD200G(e-g).book Page 21 Tuesday, February 8, 2005 8:57 AM Base Unit Settings Guide to base unit settings For your reference, a chart of all items which can be customised for the base unit is printed below. L When customising the base unit, the current item or setting is indicated by >. Base unit settings Sub-menu Sub-menu 2...

  • Page 22: Ringer Setup

    TCD200G(e-g).book Page 22 Tuesday, February 8, 2005 8:57 AM Base Unit Settings L If you use 12-hour time entry, select “AM” Ringer setup or “PM” by pressing {*} repeatedly before entering the time. Press {j/OK}. Ringer volume Press {ih}. Press {j/OK}. Select “Basis-Einstell.”, then press Turning night mode on/off {>}.

  • Page 23: Call Options

    TCD200G(e-g).book Page 23 Tuesday, February 8, 2005 8:57 AM Base Unit Settings L If the memory location already contains an Call options emergency number, the number is displayed. Enter/edit the number, then press {j/OK}. Changing the recall time L To erase an emergency number, press and Change the recall time, if necessary, depending hold {C/T}.
  • Page 24 TCD200G(e-g).book Page 24 Tuesday, February 8, 2005 8:57 AM Base Unit Settings L If the location already contains a carrier Setting call restriction code, the code is displayed. You can restrict selected handsets from dialling Enter the carrier code (7 digits max.), then certain numbers.

  • Page 25: Other Options

    PIN. The unit will not reveal the PIN L After resetting the base unit, you will not be to you. If you forget your PIN, consult your able to make or receive calls for a few nearest Panasonic service centre. moments. Press {j/OK}. Select “Basis-Einstell.”, then press {>}.

  • Page 26: Caller Id Service

    TCD200G(e-g).book Page 26 Tuesday, February 8, 2005 8:57 AM Caller ID Service Category features for Caller ID Using Caller ID service subscribers Wichtig: Categories can help you identify who is calling by L This unit is Caller ID compatible. To use Caller using different ringtones for different categories ID features (such as displaying caller phone of callers.

  • Page 27: Erasing Caller Information

    TCD200G(e-g).book Page 27 Tuesday, February 8, 2005 8:57 AM Caller ID Service Press {C} or {s} to call back the displayed party. Editing a caller’s phone number before calling back Press {j/OK}. Select “Anruferliste”, then press {>}. Press {e} or {v} repeatedly to display the desired entry.

  • Page 28: Multi-Unit Operation

    TCD200G(e-g).book Page 28 Tuesday, February 8, 2005 8:57 AM Multi-unit Operation Lift the additional handset and press {ih} Operating additional units to put the handset in standby mode. Press and hold {x} on the base unit for about 3 seconds, until the registration tone Additional handsets sounds.

  • Page 29: Cancelling A Base Unit

    You can increase the range of the base unit by Enter “335”. using a DECT repeater. Please use only the Select “Mobilt. Löschen”, then press Panasonic DECT repeater noted on Seite 4. {>}. Consult your Panasonic dealer for details. L The numbers of all handsets registered to Wichtig: the base unit are displayed.

  • Page 30: Intercom Between Handsets

    TCD200G(e-g).book Page 30 Tuesday, February 8, 2005 8:57 AM Multi-unit Operation L If you changed the PIN, enter it (Seite 25). Transferring a call without speaking to the Select “Andere Optionen”, then press other handset user {>}. During an outside call, press {INT}, then Select “Wiederholmodus”, then press press the desired handset number.

  • Page 31: Useful Information

    TCD200G(e-g).book Page 31 Tuesday, February 8, 2005 8:57 AM Useful Information Wall mounting 60 mm Screws Hooks Hinweis: L Make sure the screws are securely fastened to the wall. L Do not pinch the telephone line cord and AC adaptor cord between the base unit and the wall. L Use the following wall template to position the screws before drilling.

  • Page 32: Available Character Entries

    TCD200G(e-g).book Page 32 Tuesday, February 8, 2005 8:57 AM Useful Information Available character entries The dial keys are used to enter characters and numbers. Each dial key has multiple characters assigned to it. The available character entry modes are, Alphabet, Numeric, Greek, Extended 1, Extended 2, and Cyrillic.
  • Page 33 TCD200G(e-g).book Page 33 Tuesday, February 8, 2005 8:57 AM Useful Information Extended 1 character table (N) L The following are used for both uppercase and lowercase: Extended 2 character table (O) L The following are used for both uppercase and lowercase: Cyrillic character table (P)

  • Page 34: Troubleshooting

    TCD200G(e-g).book Page 34 Tuesday, February 8, 2005 8:57 AM Useful Information Troubleshooting If you still have difficulties after following the instructions in this section, disconnect the AC adaptor and turn off the handset, then reconnect the AC adaptor and turn on the handset. Initial settings Problem Cause &...
  • Page 35 TCD200G(e-g).book Page 35 Tuesday, February 8, 2005 8:57 AM Useful Information Telephone Problem Cause & solution I cannot make or receive calls. L The AC adaptor or telephone line cord is not connected. Check the connections. L If you are using a splitter to connect the unit, remove the splitter and connect the unit to the wall socket directly.
  • Page 36 Cancel unused handset registrations from the base unit (Seite 29). L You entered the wrong PIN number. If you forget your PIN, consult your nearest Panasonic service centre. L Locate the handset and the base unit away from other electrical appliances.

  • Page 37: Specifications

    TCD200G(e-g).book Page 37 Tuesday, February 8, 2005 8:57 AM Useful Information Provision of frequencies for general use Specifications I Standard: DECT (Digital Enhanced Cordless Telecommunications), GAP (Generic Access Profile) I Number of channels: 120 Duplex Channels I Frequency range: 1.88 GHz to 1.9 GHz I Duplex procedure: TDMA (Time Division Multiple Access) I Channel spacing:...

  • Page 38: Guarantee

    TCD200G(e-g).book Page 38 Tuesday, February 8, 2005 8:57 AM Useful Information Guarantee...

  • Page 39: Free Troubleshooting

    TCD200G(e-g).book Page 39 Tuesday, February 8, 2005 8:57 AM Useful Information Free Troubleshooting...

  • Page 40: End-User Hotline For Use-Related And General Queries

    TCD200G(e-g).book Page 40 Tuesday, February 8, 2005 8:57 AM Useful Information End-User Hotline for Use-related and General Queries...

  • Page 41: Index

    TCD200G(e-g).book Page 41 Tuesday, February 8, 2005 8:57 AM Index K Key lock: 11 Index Keytones: 20 M Making calls: 10 A Alarm: 17 Missed calls: 26 Answering calls: 11 Mute: 11 ARS (Automatic Route Selection): 23 N Night mode Area codes: 24 Base unit: 22 Carrier codes: 23...
