- Page 1 Website:http://us.lgservice.com CROWAVE OrE INSTALLATIONINSTRUCTIONS PLEASEREAD AND SAVETHESE INSTALLATIONINSTRUCTIONS. LMV1680BB LMV1680ST LMV1680WW LMV1630BB LMV1630ST LMV1630WW P/NO.: 3828W5U0529...
-
Page 2: Your Safety First
Your Safety First BEFORE YOU START • Proper installation is the installer's responsibility! - Read the entire manual before you begin. The model number label is located on the oven front. See Figure 1. The mounting plate is located on back side of microwave oven. See Figure 2. NOTE: Vent grille appearance varies by model. - Page 3 Your Safety First • THIS APPLIANCE MUST BE GROUNDED! - If there is an electrical short circuit, grounding reduces the risk of electrical shock by providing an escape wire for the electric current This appliance is equipped with a cord having a grounding wire with a grounding plug •...
- Page 4 Your Safety First • MAKE SURE YOU HAVE ENOUGH SPACE AND SUPPORT. - Mount the oven against a flat, vertical wall so it is supported by the wall. The wall should be constructed of minimum 2" x 4" wood studding and 3/8" thick drywall or plaster/lath. -ATTACH (See note on page 5) the two lag screws supporting the oven to a vertical, 2"x 4"...
-
Page 5: Parts, Tools, Materials
Parts, Tools, Materials THE FOLLOWING PARTS ARE SUPPLIED WITH THE OVEN: NOTE: Depending on your ventilation requirements, you may not use all of these parts. Damper/duct connector One power cord clamp and (for roof venting or wall venting installation) One dark-colored mounting screw Not Actual Size (2 pieces must be assembled as (to hold the power cord) - Page 6 Parts, Tools, Materials You will need the following tools and materials for the installation: Carton or other heavy material such as a blanket for covering the counter top. Stud Finder or Thin Nail Clear Tape (for taping the templates to the wall) Keyhole Saw (for the power cord hole) Saber Saw (for cutting vent holes for roof...
-
Page 7: Step 1 : Prepare The Electrical Connection
STEP 1 : Prepare The Electrical Connection _WARNING AVOID ELECTRICAL SHOCK! THIS APPLIANCE MUST BE GROUNDED! 1. Locate the grounded electric outlet for this oven in the cabinet above the oven. as shown in Figure 5. Upper Cabinet NOTE: The outlet should be on a circuit dedicated to the microwave oven (120V, 60 Hz. - Page 8 STEP 2: Prepare The Ventinc/ System NOTE: The ductwork you need for outside ventilation is not included with your oven. The standard ductwork fittings and length are shown in Figure 10, page 9. j IL WA R N I N G THIS OVEN MUST BE PROPERLY VENTED!
- Page 9 STEP 2: Prepare The Ventinc/ System Standard Fittings NOTE: if the existing duct is round, you must use a rectangular-to-round adapter, with a rectangular 3" extension duct installed between the damper assembly and the adapter to prevent the exhaust damper's sticking. Duct Length The total length of the duct system, including straight duct, elbows, transitions, and wall or roof caps must not...
-
Page 10: Remove The Mounting Plate
STEP 3: Prepare The Ventincl Blower Your microwave oven is shipped with the blower assembled for room-vented. You need to adjust the blower if you want wall-vented or roof-vented installation. j IL WA R N I N G ELECTRICAL SHOCK HAZARD! UNPLUG UNIT BEFORE... - Page 11 STEP 3: Prepare The Ventinc/ Blower WALL-VENTED INSTALLATION: BlowerPlate i MountingScrew 1. Remove one blower unit mounting screw and one or ..BlowerPlate several blower plate mounting screw(s). Remove the blower plate from cabinet. See Figure 13. BlowerUnit_- Back Plate 2.
- Page 12 STEP 3: Prepare The Ventinc/ Blower ROOF-VENTED INSTALLATION: blower plate mounting screws 1. Remove one blower unit mounting screw and one or several blower plate mounting screw(s). Remove the blower plate from cabinet. Figure 19. 2. Carefully lift the blower unit out of the microwave oven.
-
Page 13: Step 4: Prepare The Wall & Upper Cabinet
STEP 4: Prepare The Wall & Upper Cabinet AWARNINGA To avoid personal injury or property damage, do not attempt to install this microwave oven if you cannot find a wall stud. Consult a carpenter or contractor. Measure And Track/rape Up The Templates 1. - Page 14 STEP 4: Prepare The Wall & Upper Cabinet WARNING To avoid risk of personal injury, electrical shock or death: • Note where electrical outlets and electrical wires are before you drill into the wall. • Locate and disconnect power to any electrical circuits that could be affected installing...
- Page 15 STEP 5: Install The Mountinc/ Plate The Oven Must Be Connected To At Least One 2216 HO_ on Studs Wall Stud, 5_8 Hole on Dlywall Only 1. Draw a vertical line on the wall at the center of the 30" wide space.
- Page 16 STEP 5: Install The Mountincl Plate For Wall-Vented • Make the box cutout for the rear wall duct. - 1-piece mounting plate: Using a pencil, put dots through slots F and G, and through holes H and I. Remove the mounting plate and draw lines extending through the points.
-
Page 17: Step 6: Attach The Oven To The Wall
STEP 6: Attach The Oven To The Wall _WARNING To avoid risk of personal injury or property damage, you will need two people to install this microwave oven. 1. Carefully lift microwave oven and hang it on supped tabs (See Figure 27) at the bottom of the mounting plate.Reaching through upper cabinet, thread Power Cord power supply cord through the power supply cord... - Page 18 STEP 6: Attach The Oven To The Wall 5. Roof venting installation: See Figure 33, Install ductwork through the vent opening in the upper cabinet. Complete the venting system through the roof according to the method needed. See Prepare The Venting System STEP 2.
- Page 19 LG Era÷err÷nits into Printed in China...
