Electrolux E30WD75DSS1 Installation Instructions Manual

INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
_IVAV-'I:IOlI_[¢ 1 FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
GENERAL INFORMATION
The Warm & Serve Drawer can be used:
* As a stand alone appliance
* As a combination Warm & Serve Drawer with a 30" (76 cm) built-in oven mounted above
IMPORTANT: The warmer drawer must be installed on a leveled surface from left to right, rear to front and the surface
must be capable of supporting 100 Ibs (45 Kg).
Warm & Serve Drawer Dimensions
NOTE: A 60" (152 cm) long cable is supplied with the
Warm & Serve Drawer.
Stand Alone Installation
Drawer
_.4in. 8 3/8"(21,3clh) 28 1/2_ (72,4 clh) 24' (61cm)
_.4ax. 8 5/8"(21,9clh) 28 3/4" (73crn}
IMPORTANT: The Warm & Serve Drawer runs off a
single phase three-wire 120 volt, 60 hertz, AC only
electrical supply with ground.
Combination Warm & Serve Drawer/
30" (76 cm) Built-in Oven Installation
Caution: Two 3 (7,6 cm)
wide X 3iz' (I,9 crn) thick
planks have to be insta:l and
they should be able to
support 200 pounds (90,7
B\ jC
H* =10 1/8 _ (25,7 cm) Min, is o Critical
dimension and has to be respected.
P/N 318201801 (0311) Rev. B
English - pages 12
Espa_ol - p_lginas 34
Francois - pages 56
Notes pages 78
