- Page 1 Portable Washing Machine User's manual This manual is for HWM10-01 Please read this manual carefully before using. Retain it for future reference.
-
Page 2: Table Of Contents
Contents Names of the parts...1 Safety precautions ...2 Installation and adjustment ...4 Preparation before washing ...5 Process washing...6 Disposal after washing ...8 Trouble shooting ...8 Packing list *Specification..9... -
Page 3: Names Of The Parts
Names of the par ts Handle Top Cover Washing Tub Pulsator Base frame Meaning and description of the symbols Contents marked with that symbol are related to the safety Warning sign of the product and the personal safety of the users. Please operate in strict conformity to the contents, otherwise it may cause damage of the machine or injure the personal safety of the user. -
Page 4: Safety Precautions
Safety precautions Please insert the power cord into special receptacle with rated voltage. Be sure to use single-phase three pins receptacle. The earthing terminal of the receptacle must be earthed reliably. If possible, please adopt electric leakage protector. Do not damage the power cord, bend , extend, twist, bind or alter it by force. Do not press or nip it with weight. - Page 5 Safety precautions Do not stretch hands into the working machine. It is dangerous even if the rotation is slow. Take special care of the children. Do not let the children climb the washing machine. Do not put any hot or heavy items (such as the kettle with hot water ) on the washing machine.
-
Page 6: Installation And Adjustment
Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Usage of the drain hose The drain hose shall drain smoothly 1.The height of the drain hose shall be less than 10cm, or the drainage will not be smooth, and cost such long time that the machine may stop at mid way. -
Page 7: Preparation Before Washing
How to use the washing powder Direct dissolved in the machine 1.Fill some water. 2.Add the power. Run for 30 seconds to dissolve it completely. 3.Put in the laundries. Select suitable water level. The instant dissolving of the washing powder: 1.Prepare warm water of 30 2.Add the powder while stirring to fully dissolve it. -
Page 8: Process Washing
Process washing 1.Put into the laundry fill the water needed. The selection of detergent quantity Water level Detergent quantity(kg) /Water quantity under700g High water level about 9L Under300g Low water level about 5L Attention 1.Confirm that the drain hose is properly hanged before fill water, or the water will flow through the drain hose. - Page 9 Process washing 2.Close the top lid 3.Connect the power line Confirm that the washing machine is earthed reliably. Then insert the power plug into the receptacle. Do not connect the earth terminal to the gas pipe and tap water pipe. 4.Set the washing duration Select washing duration depending on the laundry Laundry...
-
Page 10: Disposal After Washing
Disposal after washing Please first pull off the power plug from the receptacle before cleaning. After washing, pull off the power plug hang up the power cord. Do not store water in the washing machine for a long period. Drain the water completely after each using. Wipe off the water drops on the surface of the machine and inside the tub. -
Page 11: Packing List *Specification
Packing list Name Quantity User's manual Portable Washing machine Specification Water level/Water quantity (about) Rated Voltage Rated Frequency Rated Wash power Rated Current of Fuse Water Injection pressure Rated washing Capacity Made in China Storage position Inside the document bag 9L/High Water Level 5L/Low Water Level 127V~...
