Summary of Contents for Haier HRF-288K

Page 1: Table Of Contents
HRF-288K/318K/348K Household Refrigerator Serial Number:0060506138 ·Please read this operation manual carefully before using the appliance. ·Keep this manual in a safe place. ·Appearance, color and layout of the door according to the prodct. Table of Contents Table of Contents Table of Contents...
Page 2: Primary Features
Primary features ①Four temperature zones Four temperature zones for satisfaction of varied storage needs. ②Chiller zone Unique refrigeration technology for -2 preserve fresh food nutrition. ③Freezer zone 1 Defrosting is not required before service for the food stored in the -7 zone.
Page 3: Diagram Of Parts
Thank you for your purchasing Haier product. Please read this manual carefully before using the electrical appliance that you have just purchased. Due to product moditication, your purchased Haier refrigerator may have some difference with which shown in the manual. We apologize here. ③ Crisper ④...
Page 4: Safety Precautions
Do not step on the cable. ● Avoid damage to the electric cable when moving the refrigerator. Inflammable gas leakage in the vicinity of the refrigerator ●Turn off any leaking valve. ●Open the doors and windows. ●Do not, under any circumstances, unplug electrical appliances in the vicinity of the leak.
Page 5 Do not install the refrigerator near gasoline or other inflammable articles.. Do not swing on or apply excessive pressure to the refrigerator door. This refrigerator should be used for food storage. It is not recommended to place microbiological or chemical materials, which have special requirement in temperature setting.
Page 6 Disassembly, renovation or cooling system maintenance of refrigerator must be authorized. Unplug the refrigerator in the event of a power interruption or during cleaning. Allow at least 5 minutes lapse before restarting the refrigerator. Do not spray or splash the refrigerator when cleaning the refrigerator, nor place the refrigerator in a damp area.
Page 7: Location
Location The refrigerator should be placed on a flat and solid surface. If the refrigerator is to be leveled, a flat, strong and fire- resistant material must be used. The front foot of the refrigerator can be adjusted clockwise or anti-clockwise to lift or lower the refrigerator if it is placed on an uneven surface.
Page 8: Preparation
Ensure that the refrigerator is properly located. (See section "Location") ④ Clean the refrigerator before using. (See section "Cleaning") ⑤ Time lapse before power supply Connect the refrigerator to power source at least 30 minutes after the refrigerator is sited and cleaned.
Page 9: Operation
Some time will be required for the refrigerator to reach the set point when the temperature is adjusted. The length of this period is determined by difference in the existing and set temperatures, the ambient temperature, the frequency with Caution which the door is opened and closed and the amount of food in storage.
Page 10: Functions
J will be disappear and lock-off mode is set. ------Refrigerating temperature setting / (Pressed for 3 seconds under lock-on mode) Refrigerator compartment on/off ------Freezer zone 1 temperature setting / (Pressed for 3 seconds under lock-on mode) Freezer zone 1 compartment on/off...
Page 11 Manual Setting Mode is set.) If button A is pressed, the refrigerating temperature can be reset and icon E of originally set refrigerator value blinks. Every press of button A will result in an increase of the refrigerating temperature by 1°C between 2°C and 10°C.
Page 12 If the super-freezing mode is set, the temperature of freezer zone 2 cannot be adjusted while the temperature in the refrigerator and freezer zone 1 can be reset. Caution （Under the condition ℃...
Page 13 Functions ⑻ Control display The background light of the display screen extinguishes automatically 1 hour after the latest press of any button. ⑼ Refrigeration On/Off When lock-on mode is set (icon J appears): When lock-on mode is set (icon J appears): When lock-on mode is set (icon J appears): When lock-on mode is set (icon J appears): When lock-on mode is set (icon J appears):...
Page 14 Functions ⑾ Over-temp warning If temperature in the refrigerator is above set value, icon K will be displayed. Check to see if the refrigerator door is tightly closed, or excessive hot food is loaded. Icon K will disappear automatically when the temperature inside the refrigerator cools down. If icon K remains display for an extended period, technical assistance should be required from the authorized agent.
Page 15: Refrigerating Storage Compartment
Although the temperature in most areas in the refrigeration compartment can be regulated between C and 10 C, extended periods of food storage is not recommended. Refrigerator should only be used for short-term storage. Storage areas As cold air circulates inside the refrigerator, temperature differences exist inside the storage compartments.
Page 16: Refrigerating Storage Precautions
Refrigerating storage precautions Hot food must be cooled to room temperature before storing in the refrigerator. Food to be stored should be properly sealed. This will prevent moisture in the food from evaporating and prevent vegetables and fruit from tainting in flavor.
Page 17: Suggestions
Vegetables and fruits should be stored on the upper areas in the refrigerator when ambient temperature is 0-10 the refrigerator compartment will be around 0...
Page 18: Instructions For Freezer Zone 1 Freezor Zone 1 Compartment
Freezer zone 1 temperature compartment Temperature of the freezer zone 1 (See the label shown below) ranges between -3 C. Advantages listed below can be achieved when the temperature of the zone is set between -3 C and -7 ●Defrosting free: Food in storage in this compartment can be prepared for cooking without manual or microwave defrosting ●...
Page 19: Instructions For Freezer Zone 2 Freezing Storage Compartment
●Tilt a bit the front side of ice cube tray and never use a knife or metal tool when removing it from the refrigerator. ●Ice cubes can be easily removed after the tray has been placed in warm water for a short time.
Page 20: Freezing Storage Precautions
Freezing storage precautions Hot food should not be stored in the refrigerator until it has cooled down to room temperature. The outside of any food packing should be dried before storage in the freezer, and any packing materials should be odor-free, airtight, non- poisonous and nontoxic.
Page 21: Defrosting
● To defrost the compartment, first disconnect the power by unplugging the refrigerator, and then remove any food from the refrigerator and place it in a cool place. Remove and replace the drawers. A bowl of hot water can be placed on the evaporator to accelerate the defrosting process.
Page 22: Cleaning
Cleaning The refrigerator should be cleaned regularly to prevent the formation of bad odors. ●Disconnect the power before cleaning the refrigerator. ●Clean the refrigerator with a soft cloth or sponge with mild detergent. Do not use a hard brush, steel brush, detergent, gasoline or other solvents, hot water, acid or alkali for cleaning.
Page 23: Vacation
It is recommended that the refrigerator be not turned off unless it is necessary. Caution Do not restart the refrigerator until a period of at least five minutes has elapsed.
Page 24: Vacation
●Remove the food from refrigerator if the vacation is short. Turn the temperature selection knob to the proper position, and make sure that the door of the refrigerator is properly closed. ●If the vacation is long, take out the food from the refrigerator and disconnect the power.
Page 25: Question Answering
Temperature of the refrigerator and the compressor will rise and the compressor will run for comparatively longer periods when the refrigerator is first started. The two sides, the middle connection and rear panel of the refrigerator will be warm due to heat radiation of the appliance.
Page 26 Energy efficiency specified in the technical parameters is measured under the following conditions: ambient temperature 25˚C, refrigerator compartment temperature 5˚C, freezer compartment temperature -18˚C and 24h continuous operation with doors closed. Actual power consumption may exceed this value if more food in storage, ambient temperature higher and the door more frequently opened.
Page 27: Troubleshooting
Troubleshooting In the event that the refrigerator does not work properly, please check out and solve problems according to the following methods. If problems persist, contact the authorized service agent. Information of model, accessory list and serial number of the refrigerator is required.
Page 28: Troubleshooting
Water drain is blocked. Clear the path with the cleaning pin. (See section "Defrosting") Cleaning pin Thick frost on the back of refrigerator ●Temperature is not properly set. See section "Operation" ●Door is not tightly closed. ●Door is frequently opened.
