Page 3
3 seconds* per page which results in reduced telephone line charges. * Approximately 3 seconds per page fax data transmission time based on Canon FAX Standard Chart No.1, (Standard Mode) at 33.6Kbps modem speed. The Public Switched Telephone Network (PSTN) currently supports 28.8Kbps modem speeds or lower, depending on tele-...
Safety Information Laser Safety Information Laser radiation could be hazardous to the human body. For this reason, laser radiation emitted inside this unit is hermetically sealed within the protective housing and external cover. No radiation can leak from the machine in the normal operation of the product by the user.
Plain Paper Fax Features ................Printer Features ..................Copier Features ..................Telephone Features .................. Using the FAX-L360 With the Printer Driver ..........System Requirements................Using Your Documentation ................How to Use This User’s Guide ..............Type Conventions Used in This User’s Guide.........
Page 6
Loading Paper in the Multi-Purpose Tray .......... 2-42 Testing the FAX-L360................... 2-44 Chapter 3 Registering Information in the FAX-L360 ..........Guidelines for Entering Information.............. Entering Numbers, Letters, and Symbols ..........Editing Information ................Using the One-Touch Speed Dial button/One-Touch Speed Dial Panel .
Page 7
The Multi-Purpose Tray ................4-16 Chapter 5 Speed Dialling....................Speed Dialling Methods................. One-Touch Speed Dialling ................Storing Numbers for One-Touch Speed Dialling........Changing a Number/Name Stored Under a One-Touch Speed Dialling Button ....................Using One-Touch Speed Dialling ............5-10 Coded Speed Dialling ..................5-12 Storing Numbers for Coded Speed Dialling ..........
Page 8
Sending a Document to More Than One Destination ......6-31 Sending a Document Using Group Dialling ..........6-33 Delayed Sending .................... 6-34 Sending Other Documents While the FAX-L360 is Set for Delayed Sending....................6-36 Chapter 7 Receiving Faxes .................... Different Ways to Receive a Fax ..............
Page 9
Long Distance Dialling ................10-4 How to Enter Pauses................10-4 Confirming a Dial Tone ................10-5 Using Tone Dialling On a Pulse Line ............10-6 Restricting Use of the FAX-L360..............10-8 Restricting Reception..................10-10 Chapter 11 Making Copies....................11-1 Making Copies ....................11-2 Chapter 12 Reports and Lists ..................
Page 10
Jams in the Front Area of the Unit?............ 13-15 Jams in the Rear Cover of the Unit?........... 13-18 After Clearing a Paper Jam..............13-20 Problems Feeding Paper into the FAX-L360........... 13-21 Faxing Problems..................13-24 Sending Faxes..................13-24 Receiving Faxes.................. 13-27 Telephone Problems.................
Page 11
Document Sizes ..................... A-11 PC Interface ....................A-13 Printer Driver ....................A-13 Appendix B Attaching the Optional Handset to the FAX-L360 ........Handset ......................Attaching the Handset to Your Unit ........... Adjusting the Ringer Volume Switch ............Maintaining Your Handset ............... Contents...
Page 13
Chapter 1 Introducing the FAX-L360 This chapter introduces you to the main features of the FAX-L360. It also explains how to get the most out of the documentation that comes with the unit, and gives important safety instructions. ❏ Welcome ....................
Welcome Thank you for purchasing the new Canon FAX-L360. We are sure that your FAX-L360 will meet your printing and copying needs easily and conveniently, as well as your fax and phone requirements FAX-L360 Introducing the FAX-L360 Chapter 1...
The FAX-L360 uses G3 data encoding methods that increase transmission speed to approximately 3 seconds* per page. Memory sending/receiving The FAX-L360 can store up to 400* fax pages (either received or to be sent) in its built-in memory, and can receive faxes while printing. Reduced-size printing The FAX-L360 automatically scales received faxes to fit the size of the paper loaded in the paper cassette or the multi-purpose tray.
Copier Features Up to 99 copies The FAX-L360 can make up to 99 copies of a document at a time, at a rate of up to 6 copies per minute. Resolution × The FAX-L360 scans documents at 400 300 dpi when using direct copying and ×...
Using the FAX-L360 With the Printer Driver The printer driver that is included with your FAX-L360 unit allows you to use the FAX-L360’s printing function directly from your PC. ❏ Use the FAX-L360 as the default printer for Windows applications For more information on using the printer driver with your FAX-L360, refer to the Printer Driver Guide also stored on this CD-ROM.
Page 19
CD-ROM drive, or access to one over a network connection ❏ Monitor 256-colour SVGA monitor or greater ❏ Printer Cable A USB cable 5 meters (16.4 feet) in length or shorter. For help in purchasing the correct cable, consult your dealer or retailer. Chapter 1 Introducing the FAX-L360...
❏ Carefully follow the instructions in Chapter 2 to get your unit unpacked and assembled properly. ❏ Read Chapter 3 to learn how to enter information in the FAX-L360 and to register your user information. ❏ Read Chapte 4 to learn about the types of print media you can use with your FAX-L360, and for instructions on selecting paper delivery and loading paper.
❏ Look over Chapter 14 to become familiar with procedures for cleaning your FAX-L360 and replacing the toner cartridge. ❏ Refer to Chapter 15 to learn how to change the settings of the FAX-L360. ❏ Refer to Appendix A for the FAX-L360 technical specifications.
If you encounter a problem with the unit’s operation, try to solve it by using the information in Chapter 13. If you cannot solve the problem or if you think your FAX-L360 needs servicing, contact your local authorised Canon dealer or the Canon help line.
❏ Use the FAX-L360 only on a sturdy, stable, level surface. If the unit falls, it could be seriously damaged. ❏ Do not use the FAX-L360 near water. If you spill liquid on or into the unit, unplug it immediately and call your local authorised Canon dealer or the Canon help line.
Page 24
❏ Whenever you unplug the FAX-L360, wait at least five seconds before you plug it back in. ❏ Keep the FAX-L360 away from direct sunlight, as this can damage it. If you have to place it near a window, install heavy curtains or blinds.
Page 25
Unplug the FAX-L360 and contact your local authorised Canon dealer or the Canon help line in any of these situations: ❏ If the power cord or plug is damaged or frayed. Caution ❏ If liquid spills into the unit, or if it is otherwise exposed to rain or liquids.
Page 26
1-14 Introducing the FAX-L360 Chapter 1...
Chapter 2 Setting Up Your FAX-L360 This chapter tells you how to unpack, assemble, and connect your FAX-L360, install the FX-3 toner cartridge, and load paper— everything you need to know to get your FAX-L360 ready to use. ❏ Choosing a Location for Your FAX-L360 ..........
Page 28
• Installing/Replacing the Toner Cartridge ........... 2-31 ❏ Loading Recording Paper ............... 2-37 Loading Paper in the Cassette ............2-39 Loading Paper in the Multi-Purpose Tray ........2-42 ❏ Testing the FAX-L360 ................2-44 Setting Up Your FAX-L360 Chapter 2...
FAX-L360 as a printer, fax machine, copier, and telephone. ❏ Do not plug the FAX-L360 into the same circuit as an appliance such as an air conditioner, electric typewriter, television, or copier. Such devices generate electrical noise that can interfere with your unit’s ability to send or receive...
SIDE VIEW 361 mm BOTTOM VIEW 773 mm 483 mm If you need help installing your FAX-L360 or have any questions about it, contact your local authorised Canon dealer or the Canon help line. Note Setting Up Your FAX-L360 Chapter 2...
Carefully remove all items from the box. You should have someone help by holding the box while you lift the FAX-L360 and its protective packaging out of the carton. Make sure you have the following items:...
❏ If you have purchased the optional handset, see Appendix B for the items included. ❏ In addition to the items shipped with your FAX-L360, if you wish to use the FAX-L360 as a printer, you will need a USB cable, which you can purchase from your Canon dealer.
Removing Shipping Materials In order to protect your FAX-L360 during shipping, the unit has been packed with protective material that you must remove before using. Follow these steps: 1. Remove all pieces of shipping tape from the outside of the FAX-L360.
Page 34
3. Open the front cover by lifting the right side release latch of the unit. ❏ Lift the cover forward to its open position. 4. Remove all pieces of shipping tape from the inside of the FAX-L360. Setting Up Your FAX-L360...
Replaceable Parts The only component of the FAX-L360 that needs regular service or replacement is the FX-3 toner cartridge. Although Canon manufactures many types of toner cartridges, the FX-3 toner cartridge is the only one designed to be used with your FAX-L360.
Assembling the FAX-L360 Use the following instructions to assemble your FAX-L360 main unit and components. To see how the FAX-L360 will look fully assembled, see “Getting Acquainted With Your FAX-L360” on page 2-21. Attaching Components Attaching the Paper Loading Warning Label The paper loading warning label is included with your FAX-L360 unit.
Make sure the tab is inserted into the slot finally not to come off. Note Straightening the Multi-Purpose Tray To straighten the paper rest, hold its centre tab and pull it up until it stops. Then, unfold the attached flap. Chapter 2 Setting Up Your FAX-L360 2-11...
The other support tray holds documents as they are fed into the Automatic Document Feeder (ADF). To install this support, insert the tabs into the corresponding slots above the Automatic Document Feeder (ADF), making sure that the smaller tab is on the left. 2-12 Setting Up Your FAX-L360 Chapter 2...
Connecting the FAX-L360 to Your PC Your FAX-L360 has a USB port that allows you to connect it to a PC. To do this, you need to purchase a USB cable from your dealer.
Connecting the Telephone Line Connect the FAX-L360 to a telephone line as follows: 1. Connect one end of the supplied telephone line to the jack marked on the left side of the FAX-L360. 2. Connect the other end of the line to your wall telephone jack.
Connect the end of the extension phone or answering machine cord to the jack marked ❏ If you connect an answering machine to the FAX-L360, be sure to read your answering machine’s manual. You can also connect the extension phone to the jack marked if you have not connected the optional handset.
❏ Unplug the unit only by pulling on the plug itself. Never pull on the cord. ❏ Do not plug the FAX-L360 into an outlet shared with an appliance such as an air conditioner, computer, electric typewriter, or copier. These devices generate electrical noise, which can interfere with the operation of the FAX-L360.
Page 43
2. Plug the other end of the power cord into the outlet. The FAX-L360 has no power switch, so its power is on as long as it is plugged in. Once connected, though, the unit still needs to warm up before you can use it.
Page 44
CART alternates with the standby mode display. In this case, install the toner cartridge. (See “Installing/Replacing the Toner Cartridge” on page 2-31.) Note HE K OVER/ ART 31/12 2002 TUE 10:00 FaxOnly STANDARD 2-18 Setting Up Your FAX-L360 Chapter 2...
LCD display. For some countries, you also need to select the country where you are using the FAX-L360. The FAX-L360 automatically switches the selectable settings and the default settings in the menus to suit the selected country.
Page 46
DATA LIST. (See “User’s Data List” on page 12-14.) ❏ You can change the display language or country setting using the SYSTEM SETTINGS menu. (See “Accessing the SYSTEM SETTINGS Menu” on page 15-15.) 2-20 Setting Up Your FAX-L360 Chapter 2...
Getting Acquainted With Your FAX-L360 Before using your FAX-L360, look over the diagrams on these pages to become familiar with the unit’s components. Front View PAPER REST SUPPORT TRAYS MULTI-PURPOSE TRAY PAPER GUIDE AUTOMATIC RELEASE DOCUMENT LATCH FEEDER (ADF) DOCUMENT GUIDES...
Inside View FX-3-TONER CARTRIDGE COMPARTMENT TRANSFER CHARGING ROLLER (DO NOT TOUCH) PAPER RELEASE LEVER FIXING ASSEMBLY FRONT COVER 2-22 Setting Up Your FAX-L360 Chapter 2...
(PBX). See page 10-2 for details. Document feed lever Set this lever to the left ( ) for automatic document feed, or to the right ( ) for manual document feed. 2-24 Setting Up Your FAX-L360 Chapter 2...
Page 51
Lights when the telephone line is being used or a document has been received in memory. Alarm lamp This lamp flashes when an error occurs, or when the FAX-L360 is out of paper or toner. One-Touch Speed Dial buttons Use these buttons for one-touch speed dialling.
Page 52
Press this button to cancel sending, receiving, or any other operation. Set button Press this button to select a menu item when registering information. One-Touch Speed Dial panel Open this panel to access the registration buttons. 2-26 Setting Up Your FAX-L360 Chapter 2...
Use this button to print activity reports. See Chapter 12, “Reports and Lists” for details. ❏ D.T. button* Press this button to confirm the dial tone when dialling a number. See page 10-5 for details. * This feature is available for certain countries only. Chapter 2 Setting Up Your FAX-L360 2-27...
Page 54
❏ Cursor buttons Use these buttons to move the cursor left or right during data registration. Use also these buttons to check the documents stored in memory. 2-28 Setting Up Your FAX-L360 Chapter 2...
❏ Avoid locations subject to high temperature, high humidity, or rapid changes in temperature. Store the cartridge between 0 and 35 C. ❏ Hold the cartridge as shown so that your hand is not touching the drum’s protective shutter. Chapter 2 Setting Up Your FAX-L360 2-29...
Page 56
❏ Do not store the cartridge in salty air or where there are corrosive gases such as from aerosol sprays. ❏ Do not remove the cartridge from the FAX-L360 unless necessary. DO NOT PLACE THE CARTRIDGE IN FIRE. TONER POWDER IS FLAMMABLE.
Installing/Replacing the Toner Cartridge The FAX-L360 uses a Canon FX-3 toner cartridge. The procedure below explains how to install the cartridge for the first time, and how to replace it when the toner runs out. When the message CHANGE CARTRIDGE appears, the toner in the cartridge may simply be unevenly distributed.
Page 58
4. If replacing a used cartridge, hold the cartridge by its handle and remove it as shown. HANDLE ❏ Dispose of the toner cartridge properly. To recycle your used cartridge, simply follow the instructions included with your new FX-3 toner cartridge. 2-32 Setting Up Your FAX-L360 Chapter 2...
Page 59
6. Gently rock the cartridge from side to side several times to distribute the toner evenly inside the cartridge. ❏ Poor print quality may result if the toner becomes unequally distributed inside the cartridge. Chapter 2 Setting Up Your FAX-L360 2-33...
Page 60
❏ Use a firm, even pull to remove the plastic seal. To avoid breaking the seal, do not jerk on it unevenly. SIDE VIEW PULL IN THIS DIRECTION TOP VIEW PULL IN THIS DIRECTION 2-34 Setting Up Your FAX-L360 Chapter 2...
Page 61
❏ Always hold the cartridge by its handle when inserting it in the unit. HANDLE 9. Gently press the cartridge into the unit as far as it will go. ❏ Press down and back on the cartridge’s handle. Chapter 2 Setting Up Your FAX-L360 2-35...
Page 62
10. Close the front cover. ❏ Use both hands to lift the cover back to its closed position. 2-36 Setting Up Your FAX-L360 Chapter 2...
❏ Be sure to load paper of the correct size, weight, and quantity recommended for your FAX-L360. (See Chapter 4, “Paper Handling.”) ❏ Stack the paper so that the top and bottom edges and sides are straight and even before placing it in the paper cassette/the multi-purpose tray.
Page 64
Store unused paper from opened packs in a cool, dry location in the original packaging. ❏ Your FAX-L360 is factory-set to use A4-size paper in the paper cassette/the multi-purpose tray. If you wish to use different sized paper, you must change the setting from the PRINTER SETTINGS menu.
Be sure to remove the paper cassette completely before loading paper. 2. Before loading the paper, stack it so that the leading edge and sides of the paper are even. Chapter 2 Setting Up Your FAX-L360 2-39...
Page 66
❏ Make sure the paper stack is not higher than the limit marks ( ) on the sides of the cassette. Note ❏ Check all corners and edges of the paper stack to be sure they are flat and even. 2-40 Setting Up Your FAX-L360 Chapter 2...
Page 67
❏ If the paper cassette sticks when you try inserting it in the fax, remove it from the fax and open the front cover. Then close it and try reinserting the paper cassette. Chapter 2 Setting Up Your FAX-L360 2-41...
Note 1. Before loading paper, stack it so that the leading edge and sides of the paper are even. 2. Open the paper guides to the approximate width of the stack of paper. 2-42 Setting Up Your FAX-L360 Chapter 2...
Page 69
4. Adjust the paper guides to the width of the paper. ❏ Make sure there is no space between the paper guides and the stack of paper. NO SPACE PAPER PAPER GUIDES TOP VIEW Your FAX-L360 is now ready to print. Chapter 2 Setting Up Your FAX-L360 2-43...
Chapter 11, “Making Copies.” Note the following: ❏ If the printed sheets are curled as they exit the FAX-L360, remove them from the output slot immediately to avoid paper jams. ❏ Make sure your text or graphics fall within the printable area.
Page 71
Chapter 3 Registering Information in the FAX-L360 This chapter describes how to enter information in your FAX-L360. ❏ Guidelines for Entering Information ............• Entering Numbers, Letters, and Symbols........... Editing Information ................. • Using the One-Touch Speed Dial button/ One-Touch Speed Dial Panel..............
If you pause while entering information and do not make an entry for more than 60 seconds, the FAX-L360 returns to standby mode and loses all information you had entered up to that point. You will then have to start again.
Page 73
2. Press 2 twice to display "b." NIT NAME To enter a symbol, press # repeatedly until the symbol you want appears. Press any other button or to enter the symbol and move the cursor to the right. Note Chapter 3 Registering Information in the FAX-L360...
If you make a mistake while entering a name, you can correct it by using the buttons. 1. Use to scroll to the incorrect character. NIT NAME CANE _ N 2. Type in the correct character. NIT NAME CANO _ N Registering Information in the FAX-L360 Chapter 3...
Open the One-Touch Speed Dial panel to access the Special Function buttons. These Special Function buttons consist of Delayed Transmission button, Report button, etc. Data Delayed Memory Registration Transmission Polling Reference Report D.T. Space Clear Chapter 3 Registering Information in the FAX-L360...
Using the Menu System The FAX-L360 employs a menu system you can use to register important information or to set up important features. The system includes these items: ❏ DATA REGSTRATION USER SETTINGS Lets you enter the information that prints on the faxes you send, to set scanning contrast, and to enter other basic data.
Page 77
1.DATA EGST ATION 3. Use the to change the menu display. 4. Press Set to select an item from the menu, or press Stop to cancel the menu selection and return to standby mode. Chapter 3 Registering Information in the FAX-L360...
* If you send a fax using speed dialling, the top line also includes the name registered under the speed dialling button or code you entered. The following pages explain how to enter this information. Registering Information in the FAX-L360 Chapter 3...
2.UNIT TELEPHONE # 6. Press Stop to return to standby mode. 31/12 2002 TUE 10:00 FaxOnly STANDA D * For certain countries, the date (day, month, and year) is shown in a different order. Chapter 3 Registering Information in the FAX-L360...
❏ You can enter up to 20 digits for your fax/telephone number. ❏ You can enter spaces with the Space button to make the number easier to read. ❏ To enter a plus sign (+) before the fax/telephone number, press the + button. 3-10 Registering Information in the FAX-L360 Chapter 3...
Page 81
❏ You can delete the entire entry by opening One-Touch Speed Dial panel and pressing Clear. 8. Press Set to save the name. SER SETTINGS 4.TX TERMINAL ID 9. Press Stop to return to standby mode. 31/12 2002 T E 10:00 FaxOnly STANDARD Chapter 3 Registering Information in the FAX-L360 3-11...
TEL LINE TYPE TOUCH TONE TEL LINE TYPE OTA Y PULSE 6. Press Set to save the telephone line type. USE SETTINGS 10. -KEY SETTING 3-12 Registering Information in the FAX-L360 Chapter 3...
Some countries adopt the summer time system that shifts the clock time ahead or back according to the change in seasons. You can select if the time information in your FAX-L360 changes to match your country’s summer time system and set the day and time when the summer time begins and ends.
Page 84
❏ You can select from the following: – FIRST WEEK – SECOND WEEK – THIRD WEEK – FOURTH WEEK – LAST WEEK (forth or fifth week depending on the selected month) 11. Press Set twice. UNDAY 3-14 Registering Information in the FAX-L360 Chapter 3...
Page 85
15. Press Set, and set the day and time when the summer time ends in the same manner as setting the begin date and time. SUMMER TIME 2.EN ATE/TIME 16. Press Stop to return to standby mode. 31/12 2002 TUE 10:00 FaxOnly STAN AR Chapter 3 Registering Information in the FAX-L360 3-15...
Page 86
3-16 Registering Information in the FAX-L360 Chapter 3...
Chapter 4 Paper Handling This chapter describes how to select and prepare the print media for the different functions your FAX-L360 can perform. ❏ Guidelines for Selecting Print Media ............. • Plain Paper..................• Envelopes ................... • Labels ....................• Transparencies ..................
* 75g/m² ** To use letter-size paper, it is necessary to adjust the paper cassette. For details on adjusting the paper size of the cassette, please contact your local authorised Canon dealer or the Canon help line. *** 1 sheet available for 64-105 g/m²...
Page 89
Type Size Weight Capacity CUSTOM1/ 64-90 g/m² 100* sheets LONG (Max. 10 mm stack 216 × 317 mm to height)** 216 × 340 mm*** CUSTOM2/SHORT 64-90 g/m² 100* sheets 216 × 254 mm to (Max. 10 mm stack 216 × 270 mm*** height)** Envelopes European DL...
Plain Paper Follow these guidelines when selecting paper: ❏ The laser printing process uses high temperatures to fuse toner to the paper. Use paper that will not melt, vaporize, discolour, or emit dangerous fumes at temperatures near 170ºC. For example, do not use vellum paper in a laser printer.
❏ To prevent the transparency from curling, remove the transparency as it comes out of the FAX-L360 and set it on a flat surface to cool. When feeding transparencies, be sure to use face-up delivery.
The Paper Path Understanding how paper feeds through the FAX-L360 will help you to determine how to load paper and handle paper jams. The page travels first to the FX-3 toner cartridge. Here a laser beam “draws” the print image on the drum, then the drum applies toner to the page. The page then travels to the fixing assembly where the toner is fused to the page.
Page 93
When you are printing, follow these guidelines: ❏ Always set the paper delivery selector before starting to print. ❏ Do not switch the paper delivery selector until the printout comes out of the delivery slot completely. Otherwise, a paper jam may occur. ❏...
Selecting Paper Delivery Received faxes, copies, and prints can be delivered through the face-up or face-down delivery slots. Choose paper delivery according to the job the FAX-L360 is performing and the type of print media you are using. FACE-DOWN DELIVERY...
Face-Down Delivery Face-down delivery is used for most jobs and when using plain paper only (64-90 g/m²). Printed pages are stacked in the order printed in the face-down delivery slot. This slot holds up to approximately 50 sheets of plain paper (75 g/m²).
Face-Up Delivery Face-up delivery is mainly used when printing on media other than plain paper, such as transparencies, labels, and envelopes. Be sure to use face-up delivery when feeding print media other than standard plain paper. Note Move the paper delivery selector forward to the mark.
Page 97
You can also use face-up delivery when printing or receiving a large number of pages. In this case, remove the extension tray and place the unit on the edge of a table. This will allow the pages to fall away from the unit and avoid blocking the Note face-up delivery slot.
When receiving faxes the default setting is the paper cassette, with same size paper remaining in both of the paper cassette and the multi-purpose tray. If paper runs out in paper cassette, FAX-L360 changes the setting to the multi- Note purpose tray automatically.
Loading Envelopes in the Multi-Purpose Tray Do not use the multi-purpose tray to load envelopes when temperature or humidity levels are high. The glue on the flap may become sticky and stick to the envelope, or cause a paper jam. Caution Be sure to use face-up delivery when printing on envelopes.
Page 100
2. Adjust the paper guides to the approximate width of the stack of envelopes. 3. Insert the stack of envelopes–print side facing you into the multi-purpose tray. ❏ Insert the stack until it stops, but do not force it. AUTOMATIC DOCUMENT FEEDER (ADF) MULTI-PURPOSE TRAY FACE-DOWN DELIVERY...
Page 101
4. Adjust the paper guides to the stack of envelopes. 5. Move the paper delivery selector forward to the mark. FACE-UP DELIVERY ❏ Be sure to use face-up delivery when printing on envelopes. Your FAX-L360 is now ready to print. Chapter 4 Paper Handling 4-15...
Changing the Paper Size Setting The Multi-Purpose Tray 1. Open One-Touch Speed Dial panel. 2. Press Data Registration. EGIST ATION Data Registration 1.DATA EGST ATION 3. Press Set and use to select 5.PRINTER SETTINGS. DATA EGST ATION 5.P INTE SETTINGS 4.
Page 103
7. Press Set. RINTER SETTINGS 3.ECONOMY RT 8. Press Stop to return to standby mode. 31/12 2002 TUE 10:00 FaxOnly STANDARD To set a Custom-size: 7. Be sure to select CUSTOM in step 6. Press Set. CUSTOM CUSTOM1/LONG 8. Use to select paper size.
Chapter 5 Speed Dialling This chapter describes how to register and use the speed dialling features of the FAX-L360. ❏ Speed Dialling Methods ................. ❏ One-Touch Speed Dialling..............• Storing Numbers for One-Touch Speed Dialling ....... • Changing a Number/Name Stored Under a One-Touch Speed Dialling Button ....................
Speed Dialling Methods In addition to regular dialling, the FAX-L360 provides several ways to dial fax/ telephone numbers automatically. ❏ One-Touch Speed Dialling Dial a fax/telephone number by pressing the One-Touch Speed Dialling button that the number is assigned to.
One-Touch Speed Dialling Storing Numbers for One-Touch Speed Dialling Your FAX-L360 can store up to 32 of your most frequently dialled numbers under One-Touch Speed Dialling buttons. Follow this procedure to store One-Touch Speed Dialling numbers and names. 1. Open One–Touch Speed Dial panel.
Page 108
2.NAME 9. Press Set again, then use the numeric buttons to enter the name you want to store. NAME Canon Europa _ PQRS WXYZ ❏ For details on entering letters, see page 3-2. ❏ You can store up to 16 characters for the name.
Page 109
10. Press Set. -TOUCH SPD DIAL 3.OPTIONAL SETTING This completes the minimum settings for registering a One-Touch Speed Dialling button. To continue with the optional settings: Go to step 11. To stop here and register another button: Press Data Registration. Repeat the procedure from step 5.
Page 110
14. Press Set to store TX TYPE. If you select REGULAR TX, it goes back to 1-TOUCH SPD DIAL. If you want to register another speed dial repeat the procedure from step 5. To return to standby mode, press Stop. To perform PSWD/SUBADDRESS settings: 15.
20. After you register a number for One-Touch Speed Dialling, it is recommended to write the name of the other party on a destination label and stick it on the One-Touch Speed Dial panel above the number of the One-Touch Speed Dialling button where the number is registered.
Page 112
6. Press Set twice. -TOUCH SPD DIAL .TELEPHONE NUMBER TELEPHONE NUMBER TEL=20 545 8545_ To delete a number: 7. Press Clear to delete the number, then press Set. TELEPHONE NUMBER Clear TEL= ❏ When you delete a number, the name registered for that number is also deleted.
Page 113
9. To change the name, use the numeric buttons to enter the new name over the previous name. Canon CA A _ DA PQRS WXYZ ❏ For details on entering letters, see page 3-2. ❏ You can enter up to 16 characters for the name.
2. Press the One-Touch Speed Dialling button assigned to the number to which you wish to fax. 2 50921 04 Canon U.K. ❏ The name registered under that One-Touch Speed Dialling button is displayed. If no name is registered, the number registered under that button will be displayed.
Page 115
TIME OUT setting. See pages 15-7 and 15-8 for more details. ❏ If an error occurs during sending, the FAX-L360 will print an error report. If this happens, try sending the fax again. See “Faxing Problems” on page 13-24 for details about errors.
Coded Speed Dialling Storing Numbers for Coded Speed Dialling You can store up to 100 numbers for coded speed dialling. Follow this procedure to store coded speed dialling numbers and names. 1. Open One-Touch Speed Dial panel. 2. Press Data Registration. EGIST ATION Data Registration...
Page 117
Using Coded Dial buttons 7. Press Coded Dial, then use the numeric buttons to enter the number you want to store. ODED SPEED DIAL Coded Dial ✱ PQRS WXYZ ❏ If a number is already registered under the code you select, that number is displayed.
Page 118
11. Press Set again, then use the numeric buttons to enter the name you want to store. Canon OPTICS _ PQRS WXYZ ❏ For details on entering letters, see page 3-2. ❏ You can store up to 16 characters for the name.
Page 119
The TX TYPE menu includes these items: REGULAR TX Designates the transaction as a normal transmission with no special features. You can cancel the currently set PSWD/ SUBADDRESS by selecting REGULAR TX. PSWD/SUBADDRESS Allows you to enter an ITU-T password or subaddress for the transmission.
Page 120
20. Press Set to store a password. ODED SPEED DIAL ✱ 21. To continue registering numbers, names and TX type, repeat steps 7 to 20. -or- If you have finished registering numbers, names and TX type, press Stop to return to standby mode. 31/12 2002 TUE 10:00 FaxOnly STANDARD...
Changing a Number/Name Stored under a Coded Speed Dialling Code Follow these steps if you want to change the number and/or name registered under a Coded Speed Dialling code, or if you want to delete all information stored under a code.
Page 122
Using Coded Dial button 7. Press Coded Dial, then use the numeric buttons to enter the number you want to store. ODED SPEED DIAL Coded Dial 1 432 2060 ✱ PQRS WXYZ ❏ If the code you select is registered for group dialling, GROUP DIAL is displayed.
Page 123
11. To change the name, use and the numeric buttons to enter the new name over the previous name. NAME Canon I ALIA _ PQRS WXYZ ❏ For details on entering letters, see page 3-2. ❏ You can enter up to 16 characters for the name.
Page 124
13. To change additional numbers and/or names, press Data Registration and repeat steps 7 to 12. -or- If you have finished changing numbers and/or names, press Stop to return to standby mode. 1/12 2002 TUE 10:00 FaxOnly STANDARD 5-20 Speed Dialling Chapter 5...
2. Press Coded Dial. Coded Dial ✱ 3. Use the numeric buttons to enter the two-digit code assigned to the fax number. 2 50921 04 Canon CANADA ✱ PQRS WXYZ ❏ The name registered under that coded speed dialling code is displayed. If no name is registered, the number registered under that code will be displayed.
Page 126
TIME OUT setting. See pages 15-7 and 15-8 for more details. ❏ If an error occurs during sending, the FAX-L360 will print an error report. If this happens, try sending the fax again. See “Faxing Problems” on page 13-24 for details about errors.
Group Dialling If you frequently send faxes to the same group of numbers, you can create a “group.” Groups are stored under One-Touch Speed Dialling buttons or Coded Speed Dialling codes and can contain as many as 131 numbers. Creating Groups for Group Dialling The numbers you register in a group must already be stored under One-Touch Speed Dialling buttons or Coded Speed Dialling codes.
Page 128
To store a group under a One-Touch Speed Dialling button: 7. Use , or the One-Touch Speed Dialling button to select an unused One- Touch Speed Dialling button (01 to 32). ROUP DIAL ❏ If a group or number is already registered under the button you select, GROUP DIAL or 1-TOUCH SPD DIAL is displayed.
Page 129
8. Press Set twice. ROUP DIAL 1.TELEPHONE NUMBER TEL= 9. Enter the speed dialling numbers you want to store in the group. ❏ To enter in the group a number stored under a One-Touch Speed Dialling button, press the desired One-Touch Speed Dialling button(s). ❏...
Page 130
10. Press Set twice. ROUP DIAL 2.NAME NAME ❏ See page 3-2 for details on entering letters. ❏ You can enter up to 16 characters for the name. 11. Enter the name using the numeric buttons for the group. NAME UK ROUP _ PQRS WXYZ...
Using Group Dialling To send a document to a group of numbers, follow these instructions. Be sure to adjust the document feed lever before loading your document. See page 6-6 for more details. Note 1. Prepare the document and load it, face down, into the Automatic Document Feeder (ADF).
Page 132
FAX-L360 begins sending automatically. If you have entered more than one speed dialling button or code, the FAX-L360 waits for 10 seconds before it begins sending. If you do not want the FAX-L360 to send automatically, you need to change the TIME OUT setting. See pages 15-7 and 15-8 for more details.
Chapter 6 Sending Faxes This chapter describes how to use your FAX-L360 to send faxes. ❏ Preparing to Send a Fax ................• Document Requirements ..............Scanning Area.................. • Selecting Automatic/Manual Document Feed........Loading Documents for Automatic Feed ........Loading Documents for Manual Feed ..........
Page 134
• Sending a Document to More Than One Destination ......6-31 • Sending a Document Using Group Dialling........6-33 ❏ Delayed Sending ..................6-34 • Sending Other Documents While the FAX-L360 is Set for Delayed Sending................. 6-36 Sending Faxes Chapter 6...
Preparing to Send a Fax Before you can send a fax, you need to load the document into the FAX-L360. For instructions and information about the types of documents you can fax with the FAX-L360, see below. Document Requirements The documents you load into the FAX-L360 must meet these requirements: When the document feed lever is set to Automatic Document Feed: •...
Page 136
❏ Make sure any glue, ink, or correction fluid on the paper is completely dry before loading the document into the Automatic Document Feeder (ADF). ❏ If you have a document that will not feed into the FAX-L360 properly, make a photocopy of the document, then load the copy instead.
Scanning Area The margins of 3.0 mm on both sides of the sheet, and 4.0 mm on the top and bottom are outside the FAX-L360’s scanning area. Make sure your document’s text and graphics do not extend into these margins.
Selecting Automatic/Manual Document Feed With the FAX-L360, you can select whether you want to scan documents automatically or manually. Automatic document feed is used when scanning multipage documents on normal paper. Use manual document feed when scanning single-page documents such as photos, business cards, or documents on other special types of paper.
Loading Documents for Automatic Feed 1. Make sure the document feed lever is set to automatic document feed. Be sure to pull the feed lever towards you before sliding it to the left. Note 2. If the document has multiple pages, tap it on a flat surface to even the edges. Chapter 6 Sending Faxes...
Page 140
3. Adjust the document guides to the width of the document. 4. Gently insert the document face down (top of the document first) into the Automatic Document Feeder (ADF) until it stops. Sending Faxes Chapter 6...
Page 141
The document is now ready for scanning. The FAX-L360 automatically feeds the pages one by one from the bottom of the stack. Wait until all pages of your document have been scanned completely before starting a new job. Note Trouble With Multipage Documents If you have trouble feeding a multipage document, do the following: 1.
Page 142
2. Gently insert the stack into the Automatic Document Feeder (ADF) until it stops. ❏ If you have further trouble with page jams while feeding, see “Jams in the Automatic Document Feeder (ADF)?” on page 13-5. Note ❏ You cannot feed a multipage document of thick media, such as postcards or business cards.
Loading Documents for Manual Feed 1. Make sure the document feed lever is set to manual document feed. 2. Adjust the document guides to the width of the document. Chapter 6 Sending Faxes 6-11...
Page 144
3. Gently insert the document face down (top of the document first) into the Automatic Document Feeder (ADF) until it stops. The document is now ready for scanning. ❏ Wait until your document has been scanned completely before starting a new job.
Canon’s Ultra High Quality (UHQ™) imaging technology enables you to send faxes with a print quality that is very close to that of the original document. The FAX-L360 also lets you adjust the resolution it uses in sending faxes to best suit your particular document.
Contrast is the difference in brightness between the lightest and darkest parts of a printed document. You can adjust the contrast the FAX-L360 uses when scanning documents to be sent. STANDARD is the default setting and is adequate for most documents.
Memory sending allows you to send a document easily and quickly. This method of sending scans the document into memory, and as the first page of a multipage document is being scanned, the FAX-L360 already begins calling the other party and transmitting the information even as the remaining pages are being scanned.
Page 148
Since the FAX-L360 is multitasking, you can even scan a document into the memory while sending a document, receiving a document, or printing a report. 6-16 Sending Faxes Chapter 6...
Dialling Methods There are several ways of dialling the number of the party you want to send to: ❏ Regular Dialling Use the numeric buttons to dial the recipient’s fax number. ❏ One-Touch Speed Dialling Press the One-Touch Speed Dialling button (1 to 32) under which you have registered the number you want to send to.
Sending Documents This section describes the different ways to send faxes with the FAX-L360. Manual Sending Via the Handset You can send faxes manually. This allows you to talk to the other party via the handset before sending the fax, which can be useful if the other party uses a single line for both voice and fax transmissions.
Page 151
3. If a person answers, you can converse normally. When you hear the other party answer, pick up the handset so you can talk if you have not already done so. Then go to step 4. -or- If you hear a high pitched signal, instead of the other party’s voice, they are ready to receive your document.
Memory Sending Memory sending is a quick and easy way to send a fax. The FAX-L360 scans the document into its memory as it dials the fax number. If the line is free, the FAX-L360 begins sending the fax as it scans the rest of the document.
Page 153
❏ When the FAX-L360 finishes sending the fax, the display shows the TRANSMITTING OK message. If an error occurs during sending, the FAX-L360 will print out an error report. If this happens, try sending the fax again. See “Faxing Problems” on page 13-24 for details about errors.
Adding Pages to the Document in the Automatic Document Feeder (ADF) The FAX-L360 Automatic Document Feeder (ADF) can hold up to 30 A4-, 30 letter-, or 20 legal-size pages at a time when the document feed lever is set to automatic document feed.
2. To cancel sending, press ✱. ❏ If you change your mind and want the unit to continue sending, press the # button. The FAX-L360 will continue sending normally. After you cancel a fax, you may need to open the operation panel to remove the document from the Automatic Document Feeder (ADF).
Removing the Document From the Automatic Document Feeder (ADF) 1. Open the operation panel by gently pulling it toward you. 2. Remove the document by pulling it out from the top or bottom. ❏ Do not pull the document without opening the operation panel, otherwise the document will tear.
Page 157
3. When you are finished, close the operation panel by pressing it down from the centre as shown. Be sure to close the operation panel until it locks into place. Otherwise the unit will not function properly. Note Chapter 6 Sending Faxes 6-25...
You can also control how many times the FAX-L360 will redial the number and how long it will wait between dialling attempts. See “Setting Up Automatic Redialling”...
❏ If you used One-Touch or Coded Speed Dialling to dial the number, the name registered under that button or code will also be displayed. If the receiving fax machine does not answer on the last attempt, the FAX-L360 displays BUSY/NO SIGNAL (if the unit is set not to print a report).
2. Press Stop. ❏ The FAX-L360 asks you to confirm that you want to cancel: AN EL DURING TX/RX? YES ( ) NO ( ) ✱ 3. To cancel the redialling, press ✱. ❏ The FAX-L360 beeps and alternates the following displays: 31/12 2002 TUE 10:00 TX/RX NO.
Page 161
Follow the procedure below to adjust the automatic redialling settings. 1. Open One-Touch Speed Dial panel. 2. Press Data Registration. EGIST ATION Data Registration 1.DATA EGST ATION 3. Press Set, then press to select 3.TX SETTINGS. DATA EGST ATION 3.TX SETTINGS 4.
Page 162
9. Press Set again, then use , or the numeric buttons to select the time interval between rediallings. EDIAL INTE VAL 2MIN. PQRS WXYZ 10. Press Set. TX SETTINGS 4.TIME OUT 11. Press Stop to return to standby mode. 31/12 2002 TUE 10:00 FaxOnly STANDA D 6-30 Sending Faxes...
Sequential Broadcasting Sending a Document to More Than One Destination The FAX-L360’s sequential broadcasting feature allows you to send a fax to a sequence of up to 133 fax numbers, using any combination of dialling methods as follows: ❏ One-Touch Speed Dialling:up to 32 destinations ❏...
Page 164
FAX-L360 waits for 10 seconds before it begins sending. If you do not want the FAX-L360 to send automatically, you need to change the TIME OUT setting. See pages 15-7 and 15-8 for more details.
3. When you finish entering numbers, press Start/Copy to begin sending, or wait a few seconds for the FAX-L360 to begin sending automatically. ❏ The FAX-L360 then scans the document into memory, and begins sending it to the destinations in numerical order, starting with the one-touch speed dial numbers, then the coded speed dial numbers, and finally the number dialled with the numeric buttons or Redial/Pause button.
Delayed Sending Your FAX-L360 allows you to scan a document into its memory and send it automatically at a preset time. By using this feature, you can take advantage of lower long distance rates at night, for example. Be sure to adjust the document feed lever before loading your document. See page 6-6 for more details.
Page 167
See page 6-24 to remove your document from Note the Automatic Document Feeder (ADF). ❏ You can only register one preset sending operation at a time. When the set time comes, the FAX-L360 dials and sends the document. Chapter 6 Sending Faxes 6-35...
Sending Other Documents While the FAX-L360 is Set for Delayed Sending The FAX-L360 is a multitasking unit, so you can send, receive, print, and copy other documents even when you have set the FAX-L360 for delayed sending. To print, copy, or send other documents after setting the FAX-L360 for delayed sending, simply follow the procedures described in this user’s guide.
Chapter 7 Receiving Faxes This chapter describes how to use your FAX-L360 to receive faxes. ❏ Different Ways to Receive a Fax ............FAX/TEL AUTO SW ..............FAX ONLY MODE ................. • Setting the RX MODE................ • Setting the Receive Mode..............
To adjust these settings via the operation panel, see page 7-5. ❏ MANUAL MODE Use this mode if you frequently use the FAX-L360 as a telephone and want to answer every call yourself, including fax calls. The FAX-L360 then rings for...
Page 171
❏ ANS.MACHINE MODE Use this mode if you plan to connect an answering machine to the FAX-L360 to receive faxes and phone messages. The FAX-L360 then receives incoming faxes normally, and routes incoming phone calls to the answering machine. Once you have decided which mode you want, set the mode as described in “Setting the Receive Mode”...
Setting the RX MODE Set the FAX-L360 RX MODE as follows: 1. Open One-Touch Speed Dial panel, then press Data Registration. EGIST ATION Data Registration 1.DATA EGST ATION 2. Press Set. DATA EGST ATION 1.USE SETTINGS 3. Use to select 4.RX SETTINGS.
Receive Mode Receiving Faxes and Phone Calls Automatically: Fax/Tel Mode Set this mode if you want your FAX-L360 to automatically switch between voice and fax calls. You can control precisely how your FAX-L360 handles incoming calls by adjusting the settings described below.
Page 174
❏ F/T RING TIME When your unit is set to receive both fax and telephone calls automatically, it rings to alert you to pick up the handset if the call is from a person. If you do not pick up the handset within a certain amount of time, the unit stops ringing. Use this option to change the number of times the unit rings, from 10 to 60 seconds.
Not all fax machines are capable of sending a fax tone. For those cases if you set the DEFAULT ACTION to RECEIVE, the FAX-L360 switches to receive mode automatically and starts receiving the document. If no document comes in, it disconnects after approximately 40 seconds.
Page 176
Set the Fax/Tel Mode options as follows: 1. Open One-Touch Speed Dial panel, then press Data Registration. EGIST ATION Data Registration 1.DATA EGST ATION 2. Press Set. DATA EGST ATION 1.USE SETTINGS 3. Use to select 4.RX SETTINGS. DATA EGST ATION 4.
Page 177
8. Press Set. AX/TEL AUTO SW 2. /T RING TIME 9. Press Set again, then use , or the numeric buttons to enter a time between 10 and 60 seconds. /T RING TIME 22SEC PQRS WXYZ ❏ This setting determines how many seconds the unit rings while waiting for someone to pick up the handset.
To use this mode, you must have the optional handset or a telephone connected to the FAX-L360. See “Connecting the Optional Handset” on page 2-14. In MANUAL MODE, the FAX-L360 rings every time it receives a call, whether the call is from a telephone or a fax machine.
15-12 for details on changing the code (REMOTE RX ID setting). Receiving Faxes Automatically: FAX ONLY MODE When the FAX-L360 is set up for a dedicated line, set FAX ONLY MODE to automatically receive documents whenever a call comes over the fax line.
Canon does not recommend using an “answering service” (like those offered by local telephone companies that provide voice mail) on the telephone line you are connecting to the FAX-L360. If you do subscribe to an answering service, you may Note want to dedicate a separate line for fax communication only and connect that line to the FAX-L360.
The FAX-L360 memory can store up to approximately 400 A4-size pages. Note Messages Displayed When Documents are Received in Memory If the FAX-L360 receives a document into its memory, the LCD displays one of the following messages. These messages show the action you must take to correct the problem. Cause: The toner cartridge ran out of toner or is not installed properly.
If you receive a fax while you are making copies or printing, the FAX-L360 stores the incoming fax in memory. Then, as soon as you finish making copies or printing, the FAX-L360 automatically prints the fax.
Cancelling an Incoming Fax To cancel an incoming fax, follow this procedure: 1. Press Stop. AN EL DURING TX/RX? YES=( NO-(#) ✱ 2. Press ✱ to stop receiving, or to resume receiving the fax. 3. Press Stop to return to standby mode. 31/12 2002 TUE 10:00 FaxOnly STANDARD...
Chapter 8 Using the Memory Features This chapter shows you how to use the memory features of the FAX-L360. ❏ Documents Stored in Memory..............• Printing a List of Documents Stored in Memory ....... • Printing Documents Stored in Memory..........
Printing a List of Documents Stored in Memory The FAX-L360 can print out a list of documents stored in memory, along with the transaction (TX/RX) number of each. Once you know the transaction number of a document in memory, you can delete it.
Printing Documents Stored in Memory When you print a document stored in memory using the following procedure, the print is reduced to 90% of the original. Note Method 1 1. Open One-Touch Speed Dial panel, then press Memory Reference. E ORY REFERENCE Memory Reference 1.DOC.
7. Press Stop to return to standby mode. 1/12 2002 TUE 10:00 FaxOnly STANDARD When you print a document stored in memory using the following procedure, the print is reduced to 90% of the original. Note Method 2 1. Open One-Touch Speed Dial panel, then press Delayed Transmission. DELAYED TX Delayed Transmission...
Page 189
7. Press Stop to return to standby mode. 1/12 2002 TUE 10:00 FaxOnly STANDARD Chapter 8 Using the Memory Features...
Sending Documents Stored in Memory 1. Open One-Touch Speed Dial panel, then press Memory Reference. E ORY REFERENCE Memory Reference 1.DOC. E ORY LIST 2. Use to select 3.RESEND DOCUMENT. E ORY REFERENCE 3.RESEND DOCU ENT 3. Press Set. RESEND DOCU ENT TX/RX NO.
Page 191
6. Enter the destination(s) using any of the following three methods. ❏ One-Touch Speed Dialling: Press the desired One-Touch Speed Dialling button(s). ❏ Coded Speed Dialling: Press Coded Dial, then enter the two-digit code (00-99) using the numeric buttons. Coded Dial •...
Deleting a Document Stored in Memory Follow this procedure to delete a document from memory. Method 1 1. Open One-Touch Speed Dial panel, then press Memory Reference. E ORY REFERENCE Memory Reference 1.DOC. E ORY LIST 2. Use to select 4.DELETE DOCUMENT. E ORY REFERENCE 4.DELETE DOCU ENT 3.
Chapter 9 Setting Up and Using Polling This chapter shows you how to set up and use polling sending and receiving. Polling is useful when one or both parties cannot be in the office at the same time. ❏ What’s Polling?..................•...
❏ If the other party’s fax does not support ITU-T subaddress/password transactions, you can ask them to set the polling ID to 255 or 11111111 binary when the other party’s fax machine is a Canon fax. Setting Up and Using Polling...
Polling to Receive Faxes The FAX-L360 polling feature allows you to request a document to be faxed to you from another fax machine. The sender only needs to make sure the document is on his fax machine and ready to be sent: when your FAX-L360 polls that machine, the document is sent automatically.
Page 198
5. Enter the destination(s) using any of the following three methods. ❏ One-Touch Speed Dialling: Press the desired One-Touch Speed Dialling button(s). ❏ Coded Speed Dialling: Press Coded Dial, then enter the two-digit code (00-99) using the numeric buttons. Coded Dial •...
Cancelling a Polling To cancel an incoming fax, follow this procedure: 1. Press Stop. AN EL DURING TX/RX? YES=( NO (#) ✱ 2. Press ✱ to stop receiving, or to resume receiving the fax. 3. Press Stop to return to standby mode. 31/12 2002 TUE 10:00 FaxOnly STANDARD...
Setting Up Polling Sending This section shows you how to set up your fax to store and hold a document until it is polled by another fax to send it. Before You Can Be Polled to Send Before you set up your polling box, contact the parties who are going to poll your fax to receive documents and confirm the following points: ❏...
Page 201
POLLING BOX 1.SETUP FILE SETUP FILE 1.FILE NAME FILE NAME 5. Enter FILE NAME using the numeric buttons. FILE NAME CANON TOKYO _ PQRS WXYZ 6. Press Set. SETUP FILE 2.PASSWOR 7. If you don’t want to set password, press the to display the next item and go to step 10.
Page 202
9. Press Set. ETUP FILE 3.TX PA WORD 10. If you don’t want to enter the ITU-T password, press the to display the next item and go to step 13. -or- If you want to enter an ITU-T password press Set. TX PA WORD 11.
15. Press Set. OLLING BOX 2.CHANGE DATA 16. Press Stop to return to standby mode. 31/12 2002 TUE 10:00 FaxOnly STANDARD Scanning a Document into the Memory for Polling Sending Follow this procedure to store a document in the polling box. 1.
Page 204
❏ If no password is registered for the document in the polling box and the other party’s polling request contains a password, then the document is not sent. 9-10 Setting Up and Using Polling Chapter 9...
Changing the Polling Box Setup Follow this procedure to change the setup of a polling box. 1. Open One-Touch Speed Dial panel. 2. Press Data Registration. EGIST ATION Data Registration 1.DATA EGST ATION 3. Press Set. DATA EGST ATION 1.USE SETTINGS 4.
Page 206
8. Press Set. HANGE DATA 1.FILE NAME 9. Use to display the item you want to change. 10. Press Set, then change the setting. Follow the same procedures you used to set up the polling box setup file. 11. Press Stop to return to standby mode. 31/12 2002 TUE 10:00 FaxOnly STANDARD...
Cancelling a Polling Box Follow this procedure to cancel a polling box. You cannot cancel a polling box when the polling box is holding a document for polling sending. Note 1. Open One-Touch Speed Dial panel. 2. Press Data Registration. EGIST ATION Data Registration...
Page 208
7. Press Set, then enter the four-digit password using the numeric buttons. ELETE FILE PASSWOR PQRS WXYZ 8. Press Set. ATA REGSTRATION 7.SYSTEM SETTINGS 9. Press Stop to return to standby mode. 31/12 2002 TUE 10:00 FaxOnly STAN AR 9-14 Setting Up and Using Polling Chapter 9...
Chapter 10 Special Features This chapter describes the special features of the FAX-L360. ❏ Special Dialling ..................10-2 • Dialling Through a Switchboard ............10-2 Registering the Access Type and Outside Line Access Number Under the R button................ 10-2 • Long Distance Dialling...............
A PBX (Private Branch Exchange) is an on-site telephone switchboard. If your FAX-L360 is connected through a PBX or other telephone switching system, you have to dial the outside line access number first, and then dial the number of the party you are calling.
Page 211
5. Press Set, then use to select the access line type for the switching system. HOOKING REFIX If you select PREFIX, go to the next step. If you select HOOKING, go to step 8. 6. Press Set, then use the numeric buttons to enter the outside line access number (up to 20 digits).
Long Distance Dialling When you register a long distance number, you may have to insert a pause either within or after the number. For long distance dialling, the location and length of the pause may differ depending on the telephone system. How to Enter Pauses Use this procedure to enter pauses within or at the end of numbers.
Confirming a Dial Tone* Use this feature when registering a number or using regular dialling. In some areas you may have to confirm the dial tone in the middle of the facsimile number before dialling the rest of the number. This is called dial tone detection. 1.
Using Tone Dialling On a Pulse Line Even if you have a pulse line, the FAX-L360 enables you to use tone dialling once you have connected to the number you are calling. This lets you take advantage of many services that require tones, such as selecting options from telephone “touch- line”...
Page 215
When registering One-Touch Speed Dialling and Coded Speed Dialling numbers, if you enter the Tone button after the number, you will switch to tone dialling after the phone connection is made. Note Example: Radial/Pause Radial/Pause Radial/Pause Operation ELEPHONE NUMBER Display EL=123456ppp ✱✱...
Restricting Use of the FAX-L360 If you do not want unauthorised people to be able to make calls, set the LOCK PHONE feature to ON. Set the password and LOCK PHONE option as follows: 1. Open One-Touch Speed Dial panel, and press Data Registration.
Page 217
7. Press Set twice. ❏ If a password is already registered, it will be displayed: ASSWORD _ 1 234 ❏ If a password is not registered, the following is displayed: ASSWORD 8. To register or change the current password, enter a four-digit number, then press Set.
Restricting Reception By enabling this feature, you can restrict reception of faxes to only the numbers registered for speed dialling on your FAX-L360. This feature is useful to prevent reception of unsolicited faxes (e.g. junk mail). Follow this procedure to enable or disable receiving restriction: 1.
Page 219
8. Press Set. X CONDITION EGSTE ED SENDE 9. Use to select the restriction type setting you want. X CONDITION EGSTE ED SENDE ❏ You can select from the following: – REGSTERED SENDER To allow reception from the numbers registered for speed dialling –...
Page 221
Chapter 11 Making Copies This chapter describes how to make copies with your FAX-L360. ❏ Making Copies..................11-2 Chapter 11 Making Copies 11-1...
Making Copies One of the FAX-L360’s convenient features is its ability to make up to 99 high- quality copies of a document. To make copies, do the following: Be sure to adjust the document feed lever before loading your document. See page 6-6 for details.
Page 223
WXYZ ❏ You can make up to 99 copies. The FAX-L360 scans at 400 × 300 dpi for single copies, and at 200 × 300 dpi for multiple copies. For high resolution copying, make one copy at a time. Note 5.
Page 224
6. Press Start/Copy to begin copying. OPYING ❏ To stop copying, press the Stop button. You may then need to lift the operation panel to remove the document. See “Jams in the Automatic Document Feeder (ADF)?” on page 13-5. If MEMORY FULL appears in the display while you are making multiple copies of a document, you will not be able to use the multiple copy feature for copying the document.
Reports and Lists This chapter describes how to print reports and lists. These include activity reports (transmission and reception reports), lists of registered numbers, list of user’s data registered in the FAX-L360 and the memory clear report. ❏ Activity Report ..................12-2 ❏...
Activity Report The Activity Report is printed out automatically by the FAX-L360 after every 20 sending and receiving transactions. This report lists the details of the documents you have sent or received so that you can keep track of the transaction operations your FAX-L360 has performed.
Page 227
31/12 2002 09:58 FAX 8334423 WORLD ESTATE,INC. *************************************** ACTIVITY REPORT *************************************** ST. TIME CONNECTION TEL CONNECTION ID MODE PGS. RESULT *31/12 08:28 732 2233 ADAM BOOK.CPA 0007 TRANSMIT ECM 1 OK 00’06 *31/12 08:49 1 213 978 3314 BELZER.INC. 5005 AUTO RX 1 NG 00’20 1 STOP *31/12 09:08...
Transmission (TX) Reports The FAX-L360 normally prints a report only when an error occurs during sending (TX Error Report). However, you can set the FAX-L360 to print a report every time you send a document (TX Report). If you send a document using memory, you can also select whether the first page of the document is printed with the report.
TX Report 31/12 2002 09:58 FAX 8334423 WORLD ESTATE,INC. TX REPORT TRANSMISSION OK TX/RX NO 0006 CONNECTION TEL 20 545 8545 SUBADDRESS CONNECTION ID JOHN BARRISTER ST. TIME 31/12 09:48 USAGE T 00’16 PGS. SENT RESULT WHEN YOU SET THE FAX TO PRINT THE THE SLEREXE COMPANY LIMITED FIRST PAGE OF...
PGS. SENT When OK appears under RESULT (see below), PGS.SENT represents the number of pages that were successfully transmitted when an error did not occur in the first attempt or in consequent retries. When NG appears under RESULT (see below), PGS.SENT indicates the pages after this page were not sent.
Normally the FAX-L360 does not print a reception report (RX Report) unless you set it to do so. You can set the FAX-L360 to print the RX Report every time you receive a document or only if an error occurs during receiving. See pages 15-5 and 15-6 for details on setting this option.
If there are one or more documents in the image memory when the power is cut off, the machine will print the Memory Clear Report when the power is restored unless the FAX-L360 is running out of paper or toner. Note...
Speed Dialling Lists Your FAX-L360 can print speed dialling lists. These lists allow you to review the numbers and names registered under One-Touch Speed Dialling buttons and Coded Speed Dialling codes (including Group Dialling numbers). Follow this procedure to print the lists.
Page 234
6. Use to select YES or NO. ORTED OUTPUT 1.NO ORTED OUTPUT 2.YE ❏ NO The One-Touch or Coded Speed Dial list is printed in order of the Speed Dial numeric list, from the lowest number to the highest number. ❏...
One-Touch Speed Dial List 31/12 2002 10:32 FAX 8334423 WORLD ESTATE,INC. 1-TOUCH SPD DIAL LIST 1 NOT SORTED TX TYPE CONNECTION TEL CONNECTION ID 1 914 438 3619 SEYMOUR GREEN REGULAR TX 722 2655 ROBERT STUART REGULAR TX 1 516 911 4411 NATALIE SMITH REGULAR TX 761 1298...
Coded Speed Dial List 31/12 2002 10:32 FAX 8334423 WORLD ESTATE,INC. CODED SPEED DIAL LIST 1 NOT SORTED CONNECTION ID TX TYPE CONNECTION TEL 555 1234 BILL REGULAR TX 1 914 438 3619 SEYMOUR GREEN REGULAR TX 1 516 911 4411 NATALIE SMITH REGULAR TX 1 617222322...
SEYMOUR GREEN TX TYPE REGULAR TX Group Dial List 31/12 2002 13:36 FAX 833 4423 WORLD ESTATE,INC. GROUP DIAL LIST CANON GROUP 01] 876 2398 CANON TX 02] 613 9076 CANON OH 01] 225 7823 CANON NY 10] 233 7766...
User’s Data List You can print a list of the data registered in your FAX-L360. This list is useful when you want to review the user data information you may have entered (such as your name and number, the date and time) and all other settings currently selected.
Page 239
31/12 2002 13:36 FAX 8334423 WORLD ESTATE,INC. USER’S DATA LIST 1.USER SETTINGS UNIT TELEPHONE # 8334423 UNIT NAME WORLD ESTATE,INC. TX TERMINAL ID TTI POSITION OUTSIDE IMAGE TELEPHONE # MARK NING CONTRAST STANDARD ERASE 7.SYSTEM SETTINGS UN/LOCK PHONE LOCK PHONE RX RESTRICTION DATE SETUP DD/MM/YY...
31/12 2002 13:36 FAX 8334423 WORLD ESTATE,INC. USER’S DATA LIST TX/RX NO MODE CONNECTION TEL/ID PGS. SET TIME ST. TIME 0051 DEL SQ BDCST [ 01] CANON 1 31/12 09:30 31/12 09:35 516 328 5000 31/12 09:35 12-16 Reports and Lists Chapter 12...
Chapter 13 Frequently Asked Questions If your FAX-L360 is not operating properly, use the information and suggestions in this chapter to try to solve the problem. ❏ If You Cannot Solve the Problem ............13-2 ❏ Problems Index ..................13-3 •...
If You Cannot Solve the Problem If you have a problem with your FAX-L360 and cannot solve it using the information in this chapter, contact your local authorised Canon dealer or the Canon help line. If the FAX-L360 makes strange noises, emits smoke or strange smells, unplug it immediately and contact your local authorised Canon dealer or the Canon help line.
Envelopes will not feed?................. 13-23 Faxing Problems—Sending Faxes..............13-24 Cannot send a fax?.................. 13-24 Images on faxes received from the FAX-L360 are spotted or dirty?..13-25 The FAX-L360 cannot send a fax using ECM?........13-25 Errors occur frequently while sending faxes? ........13-26 Faxing Problems—Receiving Faxes..............
Page 244
MEMORY FULL appears in the LCD display when you are making multiple copies? ................... 13-32 Printing Problems ..................13-33 The Alarm lamp comes on and the FAX-L360 beeps while printing? ... 13-33 Nothing prints? ..................13-33 Printout does not match paper size? ............13-34 The printout curls? ..................
Feeder (ADF) or the paper in the paper cassette/the multi-purpose tray may misfeed or jam. If this happens, you can usually fix the problem using one of the following procedures. You do not need to unplug the FAX-L360 while clearing paper jams. Note Jams in the Automatic Document Feeder (ADF)? Use this procedure if the document in the FAX-L360’s Automatic Document...
Page 246
3. Remove the jammed page by pulling it in either direction. If the paper does not pull out easily, do not force it. Contact your local authorised Canon dealer or the Canon help line. Note 4. When you are finished, close the operation panel by pressing it down from the centre as shown.
“Loading Recording Paper” on page 2-37. If the paper jam occurred while a fax was being received into the FAX-L360 memory, that fax will print automatically when the jam is cleared.
Jams in the Paper Cassette? If the recording paper jams or misfeeds while you are printing or copying, check the following areas in the order described below. Be sure to remove any documents or printed pages from the fax before removing the paper jam.
Page 249
b. Reinsert the stack of paper into the cassette. Make sure all corners and edges are flat and even, that the stack is not higher than the limit mark LIMIT MARK 4. Replace the paper cassette. ❏ If the paper cassette sticks when you try inserting it in the fax, remove it from the fax and open the front cover.
Jams Inside the Unit? 1. Open the front cover by lifting the release latch on the right side of the unit. ❏ Lift the cover forward to its open position. Do not open the front cover without lifting the release latch as this may cause damage to your unit.
Page 251
2. Hold the cartridge by its handle and remove it from the unit. ❏ Cover the cartridge with its original protective bag or a cloth to protect it from the light. HANDLE 3. Move the paper release lever toward the back of the unit. Chapter 13 Frequently Asked Questions 13-11...
Page 252
4. Locate the jammed piece of paper. ❏ First check the inside of the unit and then the front area. The fixing assembly (shaded) becomes extremely hot when the unit is in use. Be very careful not to touch it, as injury may result. Caution 13-12 Frequently Asked Questions Chapter 13...
Page 253
If the paper has jammed near the multi-purpose tray slot Hold the unit steady and pull the jammed paper straight out from the unit. ❏ Do not tear the jammed paper. If the paper tears, remove the paper scraps from the unit.
Page 254
If the top edge of the paper is in the fixing assembly > First move the jammed paper towards the unit ; then pull it towards you to remove it FIXING ASSEMBLY Be very careful not to touch the fixing assembly (shaded) as it becomes extremely hot during use.
Jams in the Front Area of the Unit? If the top edge of the paper has passed through the fixing assembly 1. Pass the paper under the roller as shown. 2. Use both hands to carefully pull the jammed paper. ❏...
Page 256
If the paper has jammed near the face-up delivery slot Hold the front cover and gently pull the sheet through the exit slot. Do not close the front cover while removing a jammed sheet of paper. This will return the paper release lever to its locked position. Note 13-16 Frequently Asked Questions Chapter 13...
Page 257
❏ The fixing assembly (shaded) becomes extremely hot when the unit is in use. Be very careful not to touch it, as injury may result. ❏ When removing the jammed paper, be careful not to touch the transfer charging Caution roller as its surface is very delicate and susceptible to finger oil and scratches, which may lead to print quality deterioration.
Jams in the Rear Cover of the Unit? 1. Open the rear cover. Lift the paper cassette slightly and pull it out a little to help pulling out jammed paper. Note 2. Gently pull out any jammed paper from the rear area being careful not to tear 13-18 Frequently Asked Questions Chapter 13...
Page 259
3. Close the rear cover (make sure it clicks in place). Gently insert the paper cassette into the fax until it clicks into position. Note Chapter 13 Frequently Asked Questions 13-19...
• Check that the paper you are using and your printing environment are within the specifications of the unit. See Appendix A, “Specifications.” ❏ Make sure you have removed any scraps of paper from inside the FAX-L360. Not doing so will cause paper to jam again.
Problems Feeding Paper into the FAX-L360 If you are having problems feeding paper into the FAX-L360, check the following table. If you are using the multi-purpose tray, whenever you correct one of these problems, be sure to remove the paper from the multi-purpose tray and reload it. See page 2-42.
Page 262
Problem Possible cause Solution Several sheets feed The multi-purpose tray may Make sure the multi-purpose tray through the multi- contain too many sheets. is not filled past the limit. See purpose tray at once? page 2-37. (continued) Do not force the stack into the multi-purpose tray.
Page 263
PC. See the printer driver manual. The envelopes may not meet the Envelopes must be European DL (220 × 110 mm) or U.S. FAX-L360 specifications. Commercial No. 10 (9.5 × 4.1 in.). Chapter 13 Frequently Asked Questions 13-23...
FAX-L360 and let it cool for several minutes. Then plug it back in and try sending again. The FAX-L360 may not be set for Make sure the FAX-L360 is set the type of telephone line you for the type of telephone line you have (pulse/tone).
Page 265
FAX-L360 (which is a G3 fax machine). If none of the above solve the problem, try unplugging the FAX-L360 for at least five seconds, then plugging it back in. If the problem persists, contact your local authorised Canon dealer or the Canon help line. Please note that any documents Note stored in memory will be erased unless you plug it back in within 1 hour.
Page 266
LCD ECM reception is turned on. display when sending.) (continued) ECM sending on the FAX-L360 Turn ECM sending on. See pages may be turned off. 15-7 and 15-8 (ECM TX setting). Errors occur frequently...
Receiving Faxes Problem Possible cause Solution The FAX-L360 cannot The FAX-L360 may not be set to For the FAX-L360 to receive receive faxes receive automatically. faxes automatically, it must be in automatically? FAX ONLY MODE, ANS.MACHINE MODE, or Fax/ Tel Mode. See page 7-2.
Page 268
An error may have occurred Check the LCD display for an switch between during reception. error message. See page 13-38 for telephone and fax calls a listing of the FAX-L360’s error automatically? messages. (continued) Print an activity report and look for an error code.
Page 269
ECM, then the FAX-L360 ECM? receives the fax in normal mode without error checking. ECM reception may not be turned Make sure the FAX-L360 ECM RX setting is enabled. See pages 15-9 and 15-10. Nothing prints? The toner cartridge may not have Make sure the toner cartridge is been installed properly.
Page 270
Problem Possible cause Solution Errors occur frequently The telephone lines may be in Lower the speed at which the unit while receiving? poor condition, or you may have a receives faxes in the RX START bad connection. SPEED setting. See pages 15-15 and 15-16.
Make sure the telephone line is dial? connected properly. securely connected to the FAX-L360. See page 2-14. The FAX-L360 may not be set for Make sure the FAX-L360 is set the type of telephone line you for the type of telephone you have (pulse/tone).
DOCUMENT READY. The handset may be off its hook. Make sure the handset is on its cradle. The FAX-L360 may not be Print a document from your PC to operating properly. make sure the FAX-L360 is operating properly. See the printer driver manual.
Printing Problems If you are having problems printing with the FAX-L360, check the problems and solutions listed in the following table. When printing problems occur while printing from your PC, refer to the Printer Driver Guide. Problem Possible cause Solution...
Page 274
The printout curls? Your pages may include a large Remove the printout as soon as it amount of toner. exits the FAX-L360 and then roll it in the direction opposite of the curl. The paper jams? You may be using face-down...
The medium you are using may Use only print media specified in not be supported by the “Guidelines for Selecting Print FAX-L360. Media” on page 4-2. You may be printing on the wrong Many types of paper have a side of the paper.
Nothing appears in the The FAX-L360 may not be Check the plug and be sure it is LCD display? receiving power. firmly plugged into the power connector and the wall outlet.
If the Power Goes Out If power to the FAX-L360 is cut off, any documents stored in its fax memory will be retained for approximately one hour by a built-in battery. While power is out, you can only use the FAX-L360 to receive telephone calls (if you have the optional handset or a telephone connected to the unit) and to make calls (if you have a telephone connected to the unit).
Error Codes, Messages, and Solutions This table lists the messages that appear in the FAX-L360 LCD display and the corresponding error codes that appear in activity reports, and tells what to do for each. Message Error Code Cause Action AUTO REDIAL —...
Page 279
Message Error Code Cause Action BUSY/NO SIGNAL #018 The receiving fax Contact the other party (continued) machine did not answer and have them check within 55 seconds. their fax machine. You can also try to send the document manually. For an overseas call, add pauses to the registered number.
Page 280
Make sure the subaddress password has been and/or password match entered on your the settings on the other FAX-L360, or the party’s fax machine. See subaddress and/or pages 5-6 and 5-15. password do not match the settings on the other party’s fax machine.
Page 281
Wait five seconds, then plug it back in. If the message remains in the LCD, contact your local authorised Canon dealer or the Canon help line. CHK SUBADDR/ #083/102 You attempted to send a Contact the other party to PSWD document or poll another check their settings.
Page 282
See pages 15-7 and 15-8 (ECM TX setting). LOAD PAPER — The FAX-L360 is out of Load paper in the paper recording paper. cassette/the multi- purpose tray. Any documents received in memory will then be printed automatically.
Page 283
MEMORY USED nn% — Shows how much of the If you need more space, FAX-L360’s memory is wait for the unit to send in use. any faxes. Also, print, send, or delete any documents in memory you no longer need.
Page 284
Add paper to both the out, or a paper jam paper cassette and the occurred, so the multi-purpose tray with FAX-L360 received the set up paper size, change document in memory. the toner cartridge, or clear the paper jam. SELECT POL REJCT...
Page 285
You pressed the Stop — button to cancel the transmission. TX/RX NO. nnnn — When the FAX-L360 Write the number down sends or receives a fax, it if you will need it later. assigns a unique You can also print an...
Chapter 14 Maintaining Your FAX-L360 Your FAX-L360 requires no maintenance other than periodic cleaning, and replacing of the toner cartridge as needed. ❏ Cleaning the FAX-L360................14-2 • Cleaning the FAX-L360 Exterior ............14-2 • Cleaning the Inside of the FAX-L360 ..........
LCD display, follow the steps on pages 7-13 through 7-14 to print out the document. ❏ If you disconnect the FAX-L360 while it is waiting to send a document, you will have to set the FAX-L360 to send your document again once you finish cleaning the unit.
Cleaning the Inside of the FAX-L360 To prevent toner powder and paper dust from accumulating and affecting the quality of the unit’s printing, clean the inside of the FAX-L360 periodically as follows. When you unplug the unit, any documents stored in memory will be erased if you leave the unit unplugged for one hour or more.
Page 290
4. Use a clean, soft, dry, lint-free cloth to remove any toner or paper debris from the shaded area. DO NOT TOUCH THE TRANSFER CHARGING ROLLER (BLACK) Do not touch the transfer charging roller (black) at the back, as this may affect the print quality of your faxes. Caution 14-4 Maintaining Your FAX-L360 Chapter 14...
Page 291
5. When you have finished cleaning the FAX-L360, replace the toner cartridge. ❏ Gently press the cartridge into the unit as far as it will go. Press down and back on the cartridge’s handle. 6. Close the front cover. ❏ Use both hands to press the cover back into its closed position.
Be sure to plug in the unit after cleaning to avoid this happening. Note 1. Unplug the FAX-L360. 2. Open the operation panel by gently pulling it toward you. 14-6 Maintaining Your FAX-L360...
Page 293
4. Clean the shaded areas of the operation panel and the unit. ❏ Dirt and dust particles that collect on the underside of the operation panel also affect the quality of documents you copy and send. Chapter 14 Maintaining Your FAX-L360 14-7...
Page 294
6. When you are finished, close the operation panel by pressing it down from the centre as shown. Be sure to close the operation panel until it locks into place. Otherwise the unit will not function properly. Note 7. Plug the FAX-L360 back in. 14-8 Maintaining Your FAX-L360 Chapter 14...
Transporting the FAX-L360 Whenever you plan to transport the FAX-L360, you need to prepare it so it will not be damaged during the move. 1. Unplug the unit from the wall outlet. 2. Remove any paper and/or documents from the unit.
Page 296
14-10 Maintaining Your FAX-L360 Chapter 14...
Chapter 15 The Menu System This chapter summarizes the FAX-L360 menu system. Use the information here as a guide to help you customise operations your unit performs. ❏ Understanding the Menu System............15-2 ❏ Accessing the USER SETTINGS Menu..........15-3 ❏...
Understanding the Menu System The FAX-L360 menu system allows you to customise the way your unit operates. The menu system consists of seven menus, each containing settings that control different functions of your FAX-L360. This chapter outlines the various menus and shows you how to use them.
Accessing the USER SETTINGS Menu 1. Open One-Touch Speed Dial panel. 2. Press Data Registration. EGIST ATION Data Registration 1.DATA EGST ATION 3. Press Set. DATA EGST ATION 1.USE SETTINGS 4. Press Set, then use the to display the item you want to set or change. Chapter 15 The Menu System 15-3...
USER SETTINGS For details on accessing the settings below, see page 15-3. The selectable settings and the default settings vary depending on the country where you have purchased the FAX. The values shown here are average values. Setting Description Sub-Settings 1.DATE &...
Accessing the REPORT SETTINGS Menu 1. Open One-Touch Speed Dial panel. 2. Press Data Registration. EGIST ATION Data Registration 1.DATA EGST ATION 3. Press Set. DATA EGST ATION 1.USE SETTINGS 4. Use to select 2.REPORT SETTINGS. DATA EGST ATION 2. EPO T SETTINGS 5.
REPORT SETTINGS For details on accessing the settings below, see page 15-5. The selectable settings and the default settings vary depending on the country where you have purchased the FAX. The values shown here are average values. Setting Description Sub-Settings 1.TX REPORT Enables/disables automatic printing of a TX (transmission) PRINT ERROR ONLY...
Accessing the TX SETTINGS Menu 1. Open One-Touch Speed Dial panel. 2. Press Data Registration. EGIST ATION Data Registration 1.DATA EGST ATION 3. Press Set. DATA EGST ATION 1.USE SETTINGS 4. Use to select 3.TX SETTINGS. DATA EGST ATION 3.TX SETTINGS 5.
Page 304
TX SETTINGS For details on accessing the settings below, see page 15-7. The selectable settings and the default settings vary depending on the country where you have purchased the FAX. The values shown here are average values. Setting Description Sub-Settings 1.ECM TX Enables/disables Error Correction Mode (ECM) during transmission.
Accessing the RX SETTINGS Menu 1. Open One-Touch Speed Dial panel. 2. Press Data Registration. EGIST ATION Data Registration 1.DATA EGST ATION 3. Press Set. DATA EGST ATION 1.USE SETTINGS 4. Use to select 4.RX SETTINGS. DATA EGST ATION 4. X SETTINGS 5.
Page 306
(TX/RX NO.) at the bottom of each received fax page. * This setting is available for certain countries only. **Even if you have set INCOMING RING to ON, the FAX-L360 will only ring if you have connected the optional handset or an extension telephone.
Accessing the PRINTER SETTINGS Menu 1. Open One-Touch Speed Dial panel. 2. Press Data Registration. EGIST ATION Data Registration 1.DATA EGST ATION 3. Press Set. DATA EGST ATION 1.USE SETTINGS 4. Use to select 5. PRINTER SETTINGS. DATA EGST ATION 5.P INTE SETTINGS 5.
Page 308
* To adjust the paper cassette to accept letter-size paper, it is necessary to attach the dedicated paper guide to the paper cassette. For details on adjusting the paper size of the cassette, contact your local authorised Canon dealer or the Canon help line.
Accessing the POLLING BOX Menu 1. Open One-Touch Speed Dial panel. 2. Press Data Registration. EGIST ATION Data Registration 1.DATA EGST ATION 3. Press Set. DATA EGST ATION 1.USE SETTINGS 4. Use to select 6.POLLING BOX. DATA EGST ATION 6.POLLING BOX 5.
Page 310
TX PASSWORD Enter a 20-digit (max.) standard ITU-T password. – ERASE AFTER TX Tell the FAX-L360 how to handle the document after it is polled and sent. ON: Document is erased from the memory after it is polled and sent.
Accessing the SYSTEM SETTINGS Menu 1. Open One-Touch Speed Dial panel. 2. Press Data Registration. EGIST ATION Data Registration 1.DATA EGST ATION 3. Press Set. DATA EGST ATION 1.USE SETTINGS 4. Use to select 7.SYSTEM SETTINGS. DATA EGST ATION 7.SYSTEM SETTINGS 5.
SYSTEM SETTINGS For details on accessing the settings below, see page 15-15. The selectable settings and the default settings vary depending on the country where you have purchased the FAX. The values shown here are average values. Setting Description Sub-Settings 1.UN/LOCK PHONE Enables/disables restriction of the FAX (See page 10-8.).
Page 313
FAX. The values shown here are average values. Setting Description Sub-Settings 7.COUNTRY SELECT* Select the country where you are using FAX-L360 to automatically switch the selectable settings and the default GERMANY settings to suit the selected country. FRANCE...
(main unit only, no trays, no optional handset) Weight: Approximately 13kg Environmental • Temperature: 10°-32.5°C requirements: • Humidity: 20%-80% RH * Based on Canon FAX Standard Chart No.1, ECM-MMR, standard mode ** Based on Canon FAX Standard Chart No.1, standard mode Specifications Appendix A...
Page 317
Applicable standards: • Electrical safety: • Radiation: CISPR Pub 22, Class B • PTT • Energy Star compliant • CE Marking Interface: Appendix A Specifications...
• Automatic document feed: 50-90 g/m² • Manual document feed: 40-340 g/m² Transmission time: Approx. 3 seconds** (G3 ECM MMR)² * Based on 75 g/m² paper ** Based on Canon FAX Standard Chart No.1, A4, standard mode Specifications Appendix A...
Page 319
• Automatic redialling (including error redialling) • Manual redialling • Pause button * May occur to reduce stack of sheets or to enlarge the margins on a page. ** Based on Canon FAX Standard Chart No.1, A4, standard mode Appendix A Specifications...
Economy mode for printing received faxes approximately 1.5 times the cartridge life. Copier • 600 × 600 dpi (The FAX-L360 scans documents at Resolution: 400 × 300 dpi when using direct copying, and at 200 × 300 dpi when using memory copying.
Telephone • Automatic FAX/TEL switchover • Answering machine connection (CNG detecting signal) • Telephone connection • Optional handset connection* • Remote reception by telephone (Default reception ID: 25) • Tone button • Redial/Pause button • Net Switch* * This feature is available for certain countries only. Appendix A Specifications...
Maximum 206 mm (A4) * To use letter-size paper, it is necessary to adjust the paper cassette. For details on adjusting the paper size of the cassette, please contact your local authorised Canon dealer or the Canon help line. ** May occur to reduce stack of sheets or to enlarge the margins on a page.
Printable Area: Papers The shaded area in the following figure shows the printable area for papers. Printable area: A4 size Letter size Legal size a 210 mm a 8.5" a 8.5" b Max. 4.0 mm b Max. 0.24" b Max. 0.24" c Max.
Printable Area: Envelopes The shaded portion in the following figure shows the printable area for envelopes. Printable area: European DL U.S. Commercial No. 10 a 110 mm a 4.1" b Max. 4.0 mm b Max. 0.16" c Max. 4.0 mm c Max.
Document Sizes The following illustrations show the largest and smallest documents you can feed into the FAX-L360. When te document feed lever is set to Automatic document feed Maximum Document Size Minimum Document Size 148 mm 216 mm 105 mm...
Page 326
MAX. 4.0 mm A4/LETTER/LEGAL MAX. 4.0 mm MAX. 3.0 mm MAX. 3.0 mm The margins of 3.0 mm on both sides of the sheet, and 4.0 mm on the top and bottom are outside the FAX-L360’s scanning area. A-12 Specifications Appendix A...
PC Interface Type: Printer Driver System requirements: • IBM or compatible computer with the following Pentium processor: • Microsoft Windows 98, Windows Me, Windows 2000, or Windows XP Windows 98: A 90-megahertz (MHz) Pentium – processor or higher Windows Me: A 150-MHz Pentium processor –...
Page 329
Appendix B Attaching the Optional Handset to the FAX-L360 This section describes how to attach the optional handset to your FAX-L360 unit. ❏ Handset ....................Attaching the Handset to Your Unit ..........• Adjusting the Ringer Volume Switch ..........• Maintaining Your Handset..............
Handset The optional handset is available in certain countries. Contact your local authorised Canon dealer for more information on purchasing this option. Please note that the shape of your handset may differ from the one shown in this section. However, both handsets have exactly the same functions and performance.
To attach the handset to your unit, follow these steps: 1. Use a screwdriver to remove the two covers on the left side of the FAX-L360. 2. Remove the screws from the plugs and insert the plugs into the holes on the handset cradle.
Page 332
This will allow you to insert the plugs without the unit moving. Note 4. Insert the screws into the plugs and push them in with your finger. Attaching the Optional Handset to the FAX-L360 Appendix B...
Page 333
5. Connect the handset cord to the input jack marked at the left side of the unit. When carrying the unit, do not lift it by the handset cradle as it may break. Caution Appendix B Attaching the Optional Handset to the FAX-L360...
❏ Do not install your handset in hot or humid conditions. ❏ Do not spray aerosol polishes on your handset as they may enter the holes on your handset and cause damage. ❏ Use a damp cloth to clean your handset. Attaching the Optional Handset to the FAX-L360 Appendix B...
Page 335
FAX-L360. Automatic image reduction The FAX-L360 can print the date, time, company name, and a fax number at the top of the faxes it receives. To prevent this information from crowding the faxed image on the page and possibly lengthening the fax, the FAX-L360 automatically reduces the size of the image on the page.
Page 336
FAX-L360 waits a specified time and then automatically redials the number. If the receiving fax is still busy or does not answer, the FAX-L360 waits the specified time and dials again. If the fax still does not go through, the FAX-L360 prints an error TX report.
Page 337
FAX-L360 produces a resolution of 600 dpi. Dual access (Multitasking) Enables the FAX-L360 to receive a fax, even if it is copying or printing a document. Also enables you to load other faxes into memory, make copies, print out reports, print documents or register information while the FAX-L360 sends a fax from memory.
Page 338
FAX/TEL switching This option allows you to set the FAX-L360 to automatically detect whether a call is from a fax or telephone. If the call is from another fax, the transmission is automatically received. If the call is from a telephone, the FAX-L360 rings to let you know, so you can pick up the handset.
Page 339
The cable used to create the interface between a printer and a computer. Interface port The FAX-L360 comes with one USB port, located on the back of the unit. You attach the cable that connects your computer and FAX-L360 to this port.
Page 340
One-Touch Speed Dialling An automatic dialling method that allows you to dial a fax or telephone number by pressing a single One-Touch Speed Dialling button. The FAX-L360 can store up to 32 numbers for One-Touch Speed Dialling. One-Touch Speed Dialling buttons The buttons numbered 1 to 32 on the operation panel, each of which may be registered as a fax or telephone number.
Page 341
Printer driver The printer driver allows you to use the FAX-L360 as a printer for your PC with Windows 98, Windows Me, Windows 2000, or Windows XP installed. To use the FAX-L360 as a printer, install the supplied printer driver in your PC.
Page 342
The button that controls how the FAX-L360 receives fax and telephone calls. Receiving Receiving transmission is also defined as RX or Reception. The FAX-L360 can be customised to receive fax documents in many ways: ❏ Receive fax documents only (FAX ONLY MODE) ❏...
Page 343
FAX-L360. Remote reception Activating fax reception by answering a telephone that is connected to the FAX-L360, but that is not located near the FAX-L360. You need to dial a remote receiving ID number to start remote reception. Report A document printed by the FAX-L360 and containing information about the faxes it has sent or received.
Page 344
A document setting for sending normal typewritten or printed documents containing only text and no drawings, photographs, or illustrations. Standby The mode in which the FAX-L360 is on and ready to use. All operations start from standby mode when the LCD displays the date and receiving mode. Timed sending See Delayed sending.
Page 345
A button that allows you to temporarily switch to touch-tone from pulse dialling. In some countries, on-line data services may require that you use tone dialling. Tone/pulse setting The ability to set the FAX-L360 to match the telephone dialling system your telephone line uses: touch-tone or rotary pulse. Toner A black, resin coated powder contained in the FX-3 toner cartridge.
Page 347
Index jams 13-5 removing document 6-24 Automatic redialling Activity Report cancelling 6-27 printing 12-2 setting up 6-28 sample 12-3 Alarm lamp explanation 2-25 ALARM VOLUME setting 15-4 ANS.MACHINE MODE Broadcasting description 7-3 sequential 6-31 using 7-12 BUSY/NO SIGNAL message 13-38 Answering machine connecting 2-15 jack 2-23...
Page 348
exterior 14-2 Cursor button inside of unit 14-3 explanation 2-28 scanner components 14-6 Customer support 13-2 CLEAR PAPER JAM message 7-13, 13-41 Coded Dial button explanation 2-24 Coded speed dial list printing 12-9 D.T. button sample 12-12, 12-13 explanation 2-27 using 10-5 Coded speed dialling changing numbers/names 5-17...
Page 349
Document Editing adding pages in ADF 6-22 information 3-4 guides 2-21 Entering identifying your 3-8 date 3-9 in memory 7-13, 8-2 guidelines 3-2 loading 6-7 letters 3-2 loading for automatic feed 6-7 numbers 3-2 loading for manual feed 6-11 pauses 10-4 problem 6-4 symbols 3-2 quantity 6-3...
Page 350
main 1-3 plain paper fax 1-3 printer 1-4 telephone 1-5 Jack answering machine 2-15, 2-23 Feeding paper handset 2-14, 2-23 Fixing assembly 2-22 telephone 2-15, 2-23 Front cover 2-21, 2-22 telephone line 2-14, 2-23 problems 13-21 Jams after clearing 13-20 in Automatic Document Feeder (ADF) 13-5 in front area 13-15...
Page 351
paper release 2-22, 13-11, 13-20 printing list of documents in 8-2 sending 6-15, 6-20 Lifting unit 2-6 MEMORY FULL message 11-4, 13-43, 13-45 LINE MONITOR VOL. setting 15-4 Memory Reference button explanation 2-27 List coded speed dial 12-9, 12-12, 12-13 MEMORY USED nn% message 11-2, 13-43 documents in memory 8-2 Menu system...
Page 355
problems 13-24 SUMMER TIME setting 15-17 with group dialling 5-27, 6-33 Support trays 2-5, 2-21 Sequential broadcasting 6-31 attaching 2-12 Serial number Switchboard unit 13-2 dialling through 10-2 Setting SYSTEM SETTINGS menu contrast 6-13, 6-14 accessing 15-15 copying resolution 11-2 description 3-6 scanning resolution 6-13 setting 15-16...
Page 356
handling 2-29 unable to solve 13-2 installing 2-31 Unit replacing 2-31 assembling 2-10 storing 2-29 cleaning 14-2 TONER SUPPLY LOW setting 15-12 components 2-5, 2-21 dimensions 2-4 Touch tone front view 2-21 setting 3-12 inside view 2-22 using on a pulse line 10-6 lifting 2-6 Transmission reports 12-4 main features 1-3...
Page 357
LINE MONITOR VOL. setting 15-4 VOLUME CONTROL setting 15-4 Weight document 6-3 paper 4-2 Index I-11...
