Please read this instruction booklet before using the appliance
Gas hob
Mod. EGG 689
GB

Advertisement

Table of Contents
loading

Summary of Contents for Electrolux EGG 689

  • Page 1 Gas hob INSTR INSTR UCTION BOOKLET UCTION BOOKLET INSTR UCTION BOOKLET UCTION BOOKLET INSTR INSTR UCTION BOOKLET Please read this instruction booklet before using the appliance Mod. EGG 689 35678-9002...
  • Page 2: Important Safety Information

    Important Safety Information You MUST read these warnings carefully before installing or using the hob. If you need assistance, contact our Customer Care Department on 08705 950950 During Operation About Installation, Cleaning and Manteinance • This appliance has been designed for non professional purpose in private houses only.
  • Page 3: Table Of Contents

    Contents • The ceramic hob is shockproof, but not unbreakable! Hard or pointed objects falling from a height can damage the hob. If scratches or cracks are noticed, disconnect the appliance from the electrical supply For the User to avoid the risk of electric shock and call you nearest Service Force Centre.
  • Page 4: Description Of The Hob

    Description of the Hob 1. Hob top 2. Rapid Burner 3. Semi-rapid Burner 4. Auxiliary Burner 5. Control knobs Operation Hob burners Prolonged cooking with potstones, earthenware pans or cast-iron plates is inadvisable. Also, do " To light a burner: not use aluminium foil to protect the top during push in the relevant control and turn it to maximum use.
  • Page 5: Maintenance And Cleaning

    Maintenance and Cleaning Before any maintenance or cleaning can be carried The Burners out, you must DISCONNECT the hob from the The burner caps and crowns can be removed for cleaning. electricity supply. Wash the burner caps and crowns using hot soapy water, The hob is best cleaned whilst it is still warm, as and remove marks with a mild paste cleaner.
  • Page 6: Engineers Technical Data

    Instructions for the Installer Engineers technical data Overall dimensions Ignition HT Spark Spark Generator Ispra Control's BF 50046 Width: 580 mm. 230-240V 0.6 YA T 120 Depth: 510 mm. Spark Gap Fixed Cut out dimensions Semi-rapid Burner Width: 550 mm. Heat Input 1.9 kW (6483 BTU/HR) Depth:...
  • Page 7: Important Safety Requirements

    Important safety requirements This hob must be installed in accordance with the Gas Safety (Installation and FITTING THE GAS HOB Use) Regulations (Current Edition) and the IEE Wiring Regulations (Current WITHOUT A COOKER HOOD ABOVE Edition). Detailed recommendations are contained in the following British Standards Codes Of Practice: B.S.
  • Page 8: Building In

    Cut Out Size The dimensions of the cut-out are given in the diagram. FO 2098 Building In FO 0763 Building over a cupboard or drawer If the hob is to be installed above a cupboard or drawer it will be necessary to fit a heat resistant board below the base of the hob on the underside of the work surface.
  • Page 9: Electrical Connections

    Electrical connections Permanent Connection Any electrical work required to install this hob should be carried out by a qualified electrician or In the case of a permanent connection, it is necessary competent person, in accordance with the current that you install a double pole switch between the hob regulations.
  • Page 10: Wiring Diagram

    Wiring Diagram A. IGNITOR SWITCH Brown B. IGNITOR UNIT Fault Finding Preliminary Electrical Systems SOCKET PLUG (with cover (face view) removed) Check Earth Wire Green/Yellow Blue Green START Yellow Isolate appliance and carry out: A: Earth Continuity Neutral Wire Blue check.
  • Page 11 Ignition System / Gas Ignition Check gas supply at Ignitor does not spark burner Check plug top fuse and replace if necessary Light burner manually Check polarity and earth Check by pass simmer continuity of supply point adjusted Check position of the Check earth continuity electrode of appliance...
  • Page 12: Commissioning

    Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. Turn the gas tap to the MAX position and ignite. Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times.
  • Page 13: Conversion From Natural Gas To Lpg

    Conversion from Natural Gas to To adjust the gas rate It is important to note that this model is designed for use with natural gas but can be converted for use with With the aid of a thin bladed screwdriver completely butane or propane gas providing the correct injectors tighten down the by pass adjustment screw.
  • Page 14: Guarantee/Customer Service

    Guarantee/Customer Service Service and Spare Parts Standard guarantee conditions In the event of your appliance requiring service, or if you We, Electrolux, undertake that if within 12 months of the wish to purchase spare parts, please contact your local date of the purchase this Electrolux appliance or any Service Force Centre by telephoning part thereof is proved to be defective by reason only of 0870 5 929 929...
  • Page 15: European Guarantee

    European Guarantee This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appliance guarantee or otherwise by law. If you move from one of these countries to another of the countries listed below the appliance guarantee will move with you subject to the following qualifications: •...
  • Page 16 11/06...
