- Page 1 Operating and Installation Instructions EFP 60202 EFP 90202...
-
Page 2: Table Of Contents
Contents Safety warnings ..............................3 For the installer ................................3 For the user ................................4 Description of the appliance ..........................5 Extraction mode ............................... 5 Recirculation mode ..............................5 Description of the hood ............................5 Control Panel .................................6 Correct ventilation ..............................6 Maintenance and care ............................7 Cleaning the hood ..............................7 Metal grease filter ..............................7 Charcoal filter ................................8... -
Page 3: Safety Warnings
Safety warnings For the installer • If the hood is used in its recirculation mode, it • When used as an extractor unit, the hood must will operate simply and safely in the above be fitted with a hose having preferably the same conditions without the need for any of the diameter as the outlet hole. -
Page 4: For The User
For the user This appliance is marked according to the European directive 2002/96/EC on Waste • The cooker hood is designed to extract Electrical and Electronic Equipment (WEEE). unpleasant odours from the kitchen, it will not By ensuring this product is disposed of correctly, extract steam. -
Page 5: Description Of The Appliance
Description of the appliance • The cooker hood is designed to extract unpleasant odours from the kitchen, it will not extract steam. • The charcoal filter is supplied. The hood, therefore, can be used immediately in the recirculation mode. We advise removing the charcoal filter to use the hood in the extraction mode. -
Page 6: Control Panel
Control Panel • The best results are obtained using low speed with normal cooking and a higher speed in the case of a particular concentration of fumes. The switches are mounted on the upper right side of the visor (Fig. 1 - E - Fig. 2). Motor switch Light switch Fig. -
Page 7: Maintenance And Care
Maintenance and care • The hood must always be disconnected from the electricity supply before beginning any maintenance work. Cleaning the hood Warning • Failure to observe the instructions on cleaning • Clean the outside of the hood using a damp the unit and changing the filters will cause a cloth and a solution of water and mild washing up liquid. -
Page 8: Charcoal Filter
Charcoal filter • The charcoal filter should only be used if you want to use the hood in the recirculation function. • To do this you will need an original charcoal filter (available from your local Service Force Centre). • Replacing the charcoal filter Type 150 This filter cannot be cleaned or reused. -
Page 9: Changing The Light Bulb
Changing the light bulb • Disconnect the cooker hood from the main supply. • Open the lamp cover by pushing simultaneously two unlocking button R. Disengage the lamp cover from its hanging rails (Fig. 5). • Replace the old light bulb(s) with a new light bulb of the same kind. -
Page 10: Technical Assistance Service
Technical assistance service You are welcome to telephone our technical assistance service (see list of technical assistance centres) whenever you need information or in the unlikely event of a fault. For service in Australia call 1300 650 020. When calling, please be ready to specify: The model code number The serial number (E-Nr.) The manufacturing number (F-Nr.) -
Page 11: Guarantee Conditions
Guarantee Conditions Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. -
Page 12: Technical Specifications
Technical Specifications Model EFP 60202 EFP 90202 Dimensions (in cm): Height: 39,5 39,5 Width: 59,8 89,8 Depth: 27,5 (+ front panel) 27,5 (+ front panel) Grease filter: Power absorption: 235 W 235 W Lighting: 11 W (PL) 11 W (PL) -
Page 13: Mounting Accessories Included
Mounting accessories included 1 allen spanner for torx screws 1 deflector 4 spacers for 16mm side walls 2 screws 2,9 x 13 to fix flange or deflector 4 screws 4,5 x 16 mm for fixing to side walls 1 Flange Ø 120 mm 1 charcoal filter frame + 2 screws 3,5x9,5 Preparing the wall unit ceiling Extraction mode... -
Page 14: Spice Rack
Spice rack • If a spice rack is to be incorporated in front of the hood, a minimum distance of 5 mm must be provided between the front edge of the fume extractor hood and the spice rack wall (this air gap being necessary for air circulation). -
Page 15: Fitting The Charcoal Filter For Recirculation Mode
