Dear customer, Please read these operating instructions carefully and pay particular attention to the safety notes indicated in the first pages. We recommend that you keep this instruction booklet for future reference and pass it on to any future owners. Transport damages When unpacking the appliance, check that it is not damaged.
Warnings The following warnings are provided in the interests of overall safety. You must read them carefully before installing or using the appliance. Installation • Use only the recommended quantities of fabric softener. An excessive amount could damage the • All internal packing must be removed before using laundry.
Child safety • Keep all detergents in a safe place out of children’s reach. • Children are often not aware of how dangerous • Make sure that children or pets do not climb into electrical appliances can be. When the machine is the drum.
Technical specifications DIMENSIONS Height 85 cm Width 60 cm Depth 58 cm WASHING DRYING MAXIMUM LOAD Cotton 5.5 kg 2.75 kg Synthetics 2.5 kg Delicates 2.5 kg Woollens SPIN SPEED 1000 rpm max. POWER SUPPLY VOLTAGE/FREQUENCY 220-230 V/50 Hz TOTAL POWER ABSORBED 2200 W MINIMUM FUSE PROTECTION 10 A...
Installation Unpacking Positioning Install the machine on a flat hard floor. All transit bolts and packing must be removed Make sure that air circulation around the machine is before using the appliance. not impeded by carpets, rugs etc. Check that the machine does not touch the wall or other kitchen units.
Water drainage Electrical connection This machine is designed to operate on a 220-230 V, The end of the drain hose can be positioned in three single-phase, 50 Hz supply. ways: Hooked over the edge of a sink using the plastic Check that your domestic electrical installation can hose guide supplied with the machine.
Control panel 1 Programme guide If this button is not activated, the washing programmes will end with a spin. The Rinse Hold button must not be depressed when using NON-STOP operation (automatic 2 Drying indicator light washing and drying). This light illuminates when the machine is drying. 6 On/Off button 3 Drying time selector dial By depressing this button the machine starts...
Laundry weights Washing hints The following weights are indicative: bathrobe 1200 g Sorting the laundry napkin 100 g Follow the wash code symbols on each garment quilt cover 700 g label and the manufacturer’s washing instructions. Sort the laundry as follows: sheet 500 g whites, coloureds, synthetics, delicates, woollens.
Ink: depending on the type of ink, moisten the fabric Quantity of detergent to be used first with acetone (*), then with acetic acid; treat any The type and quantity of detergent will depend on residual marks on white fabrics with bleach and then the type of fabric, load size, degree of soiling and rinse thoroughly.
Drying symbols on garment labels Drying hints Always look at the garment label to check whether As a dryer, the machine works on the condensation garments can be machine dried. principle. The following symbols refer to drying: Therefore, the water tap must be open and the drain hose must drain water into a sink or into Machine drying is usually possible the drain pipe, even during the drying cycle.
International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature temperature temperature temperature 95°C 60°C 40°C 30°C Hand wash Do not...
4. Depress the required option(s) Operating sequence Washing only Before washing your first load of laundry, we recommend that you run a cotton cycle at 60°C, with the machine empty, in order to remove any manufacturing residue from the drum and tub. Pour half a measure of detergent into the main wash compartment and start up the machine.
8. At the end of the programme The machine stops automatically. When selecting the Rinse Hold Option , the water of the last rinse is not emptied out to avoid creasing in the laundry. Drain the water by selecting programme Q or K. The door is controlled by a safety device which releases 2 minutes after the end of the programme.
Drying only Automatic washing and drying (NON-STOP programme) Warning! Do not exceed the maximum laundry loads: Warning! For NON-STOP programmes, it is also - 2.75 kg for linen and cottons essential not to exceed the maximum load sizes of 2.75 kg for cotton and 2 kg for synthetics. kg for synthetics.
Washing Programmes Programmes for cotton and linen Programme/ Degree of soil Possible Max. Wash programme Description Temperature and type of laundry option load Prewash at 40 °C WHITES For heavy soiled Wash at 60°-95°C 5.5 kg WITH cotton items. 3 rinses 60°-95°...
Washing Programmes Programmes for synthetics, mixed fabrics, delicates and wool Degree of soil Programme/ Possible Max. Wash programme Description and type of laundry Temperature option load Synthetic or mixed Prewash at 40° fabrics, underwear, SYNTHETICS Wash at 40°-60° C coloured garments, 2.5 kg WITH 3 rinses...
Drying Programmes Timed drying Degree of Drying time Type of fabric Max. load Spin speed drying mins Light blue section Cotton and linen 1000 2.75 kg (towels, T-shirts, bathrobes) Store dry 1 kg 1000 Programme G Suitable for items to put away without Yellow section Synthetic and mixed...
Maintenance 1. Bodywork 3. Drain filter Clean the outside of the machine with warm water The drain filter collects threads and small objects and a detergent used to handwash dishes. Rinse inadvertently left in the laundry. Check regularly that with clean water and dry with a soft cloth. the filter is clean.
5. Emergency emptying out If the water is not discharged (outlet pump is blocked, filter or drain hose are clogged), proceed as follows to empty out the machine: • pull out the plug from the power socket; • close the water tap; •...
Something not working? Problems which you can resolve yourself. Problem Possible cause • The machine does not start up: • The door is not firmly closed. • The machine is not plugged in or there is no power at the socket. •...
Page 24
Problem Possible cause • Spinning starts late or the • The electronic unbalance detection device has cut in because the laundry is not evenly distributed in laundry is not spun enough: the drum. The laundry is redistributed by reverse rotation of the drum. This may happen several times before the unbalance disappears and normal spinning can resume.
