Important Safety Information You MUST read these warnings carefully before installing or using the hob. If you need assistance, contact our Customer Care Department on 08705 950950 Service Installation This hob should only be repaired or serviced by an This hob must be installed by qualified personnel, authorised Service Engineer and only genuine according to the manufacturer’s instructions and to approved spare parts should be used.
Contents For the User For the Installer Important Safety Information Instructions for the Installer Description of the Hob Important safety requirements Operation Installation Maintenance and Cleaning Building In Something Not Working? Electrical connections Service and Sparte Parts Wiring Diagram Customer Care Department Fault Finding Guarantee Conditions Commissioning...
Operation Hob burners To light a burner: push the electric ignition push-button which is marked Burner minimum maximum by a little spark symbol ( diameter diameter at the same time turn the relevant control knob anticlockwise to maximum position; Ultra-rapid then adjust the flame as required.
Pan Supports and Wok Stand To keep the pan supports in the correct position, they are hooked into hinges at the back of the hob. The pan supports can be lifted for easier cleaning, as shown in Fig. 1. To remove the pan supports completely, proceed as shown in Fig.
Service and Spare Parts In the event of your appliance requiring service, or if you wish to purchase spare parts, please contact your local Electrolux Service Force Centre by telephoning: 0870 5 929929 Your telephone call will be automatically routed to the Service Force Centre covering your post code area.
Guarantee Conditions Electrolux Guarantee conditions We, Electrolux, undertake that if, within 12 months of * Appliances found to be in use within a commercial the date of the purchase, this Electrolux appliance or or similar environment, plus those which are the any part thereof is proved to be defective by any reason subject to rental agreements.
Instructions for the Installer Engineers technical data Ignition HT Spark Spark Generator Ispra Control's BF 80066 OVERALL DIMENSIONS 220- 240V 0.6 VA T 120 Spark Gap Fixed Width: 680 mm. Depth: 510 mm. Rear Left Burner (semi rapid) Heat Input 2.0 kW (6824 BTU/HR) CUT OUT DIMENSIONS Front Left Burner (auxiliary)
Important safety requirements This hob must be installed in accordance with the Gas Safety (Installation FITTING THE GAS HOB WITHOUT A COOKER HOOD ABOVE and Use) Regulations (Current Edition) and the IEE Wiring Regulations (Current Edition). Detailed recommendations are contained in the following British Standards Codes Of Practice: B.S.
Cut Out Size Rectangular cut-out size for hob The dimensions of the cut-out are given in the diagram. Dimensions are given in mm. Building In FO 2038 Building over a cupboard or Building over a kitchen unit with drawer door If the hob is to be installed above a cupboard or drawer it Proper arrangements must be taken in designing the will be necessary to fit a heat resistant board below the...
Seal FO 0199 Electrical connections Any electrical work required to install this hob Permanent Connection should be carried out by a qualified electrician or In the case of a permanent connection, it is necessary competent person, in accordance with the current that you install a double pole switch between the hob regulations.
Wiring Diagram A. IGNITOR SWITCH B. IGNITOR UNIT 220/240 Fault Finding Preliminary Electrical Systems SOCKET PLUG (with cover Check (face view) removed) Earth Wire Blue Brown Green/Yellow Green Yellow START Isolate appliance Neutral Wire and carry out: Blue A: Earth Continuity check.
Page 13
Ignition System / Gas Ignition Check gas supply at Ignitor does not spark burner Check plug top fuse Light burner manually replace if necessary Check polarity and Check by pass simmer earth continuity of adjusted supply point Check position of the Check earth continuity electrode of appliance...
Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. Turn the gas tap to the MAX position and ignite. Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times.
Conversion from Natural Gas to LPG To adjust the gas rate It is important to note that this model is designed for use with natural gas but can be converted for use with With the aid of a thin bladed screwdriver completely butane or propane gas providing the correct injectors tighten down the by pass adjustment screw.
