Hitachi CP-D32WN Quick Manual

CP-D32WN LCD Projector
Accessories and Lenses
Supplied Remote control, power cord,
Accessories computer cable, user's manual,
network manual
Optional USBWL11N USB wireless adapter,
Accessories MS-1 switcher, MS-1WL wireless switcher
(switchers have limited function with this
projector model)
Replacement Parts
Lamp DT01381
Remote Control HL02881
Filter UX37191
Projection Throw Chart (In inches)
Screen Size 4:3 Throw Distance
Diagonal Width
60 48
70 56
80 64
90 72
100 80
Throw Ratio: (distance : width) 0.4 : 1
HI0217-06/13
All specifications subject to change without notice.
3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.
iPad and iPhone are registered trademarks of Apple Inc., registered in the U.S. and other countries.
©2013 Hitachi America, Ltd. All Rights Reserved.
Hitachi America, Ltd.
900 Hitachi Way, Chula Vista, CA 91914
Toll Free: 1.800.HITACHI Email: dmd.info@hal.hitachi.com
•
Web: hitachi-america.us/projectors
Specifications
Projection Technology
Resolution
White Light Output
Color Light Output
Colors
Aspect Ratio
Contrast Ratio
Throw Ratio
(distance : width)
Focus Distance
Display Size
Lens
Lamp Wattage
Expected Lamp Life*
Expected Filter Life**
Speaker Output
Acoustic Noise Level
Keystone
Computer
H-Sync
V-Sync
20.1
Composite Video
24.0
Component Video
28.0
HDMI
32.0
Digital Input
35.9
Computer Input 1
Computer Input 2
Computer Monitor Output
Video Input
Audio Input
Audio Output
Network LAN Wired
Network LAN Wireless
USB
Control Terminals
Power Supply
Power Consumption
Operating Temperature
Dimensions (W x D x H)
Weight
Approvals
Warranty
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
filter life specified are not guaranteed and do not constitute part of the product warranty.
3LCD, 3 chip technology
XGA - 1024 x 768
3,200 ANSI lumens
3,200 ANSI lumens
16.7 million colors
Native 4:3 / 16:9 and 16:10 compatible
3000 : 1 (using active IRIS)
0.4 : 1
20" - 36"
60" - 100"
F = 2.0, f = 6.1 mm
215W
Approximately 3,000 hours (standard mode)
5,000 hours (Eco mode)
Approximately 4,000 hours
10W
34 dB (28 dB in Eco mode)
+/- 5º (vertical only)
VGA, SVGA, XGA
WXGA/WXGA+/SXGA/SXGA+/UXGA (compressed), MAC 16"
31.5 kHz - 106 kHz
56 Hz - 120 Hz
NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
480i, 480p, 576i, 720p, 1080i, 1080p
480i, 480p, 576i, 720p, 1080i, 1080p,
computer signal TMDS clock 27 MHz - 150 MHz
HDMI x 1 (HDCP compliant)
15-pin mini D-sub x 1
15-pin mini D-sub x 1
15-pin mini D-sub x 1
S-Video Mini DIN 4-pin x 1
Composite Video RCA jack x 1
Component Video 15-pin mini D-sub x 2, (shared with computer in 1/2)
3.5 mm stereo mini jack x 2, RCA jack (L/R) x 1,
MIC-in 3.5 mm mini jack x 1
RCA jack (L/R) x 1
RJ-45 port (10 base-T / 100 base-TX)
USB-A, IEEE802.11 b/g/n - optional wireless adapter required
Type A x 2 (PC-less presentation, wireless adapter)
Type B x 1 (USB display or mouse control)
9-pin mini D-sub x 1 (RS-232 control)
AC100-120V / AC220-240V, 50/60Hz
320W
32ºF - 104ºF (0ºC - 40ºC)
13.6" x 11.9" x 3.4" (excl. protruding parts)
Approximately 8.2 lbs
UL 60950-1 / cUL FCC Part 15 subpart B Class B
3 year limited parts and labor.
Extended Service Contract available (additional cost)
CP-D32WN
Short Throw
Series
